Newland N5S User manual

N5S
4G Mobile Terminal
User Guide

Disclaimer
© 2018 Fujian Newland Auto-ID Tech. Co., Ltd. All rights reserved.
Please read through the manual carefully before using the terminal and operate it according to the manual. It is advised that you
should keep this manual for future reference.
Do not disassemble the device or remove the seal label from the device, doing so will void the terminal warranty provided by
Fujian Newland Auto-ID Tech. Co., Ltd.
All pictures in this manual are for reference only and actual product may differ. Regarding to the terminal modification and update,
Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make changes to any software or hardware to improve reliability,
function, or design at any time without notice. The information contained herein is subject to change without prior notice.
The terminals depicted in this manual may include software copyrighted by Fujian Newland Auto-ID Tech. Co., Ltd or third party.
The user, corporation or individual, shall not duplicate, in whole or in part, distribute, modify, decompile, disassemble, decode,
reverse engineer, rent, transfer or sublicense such software without prior written consent from the copyright holders.
This manual is copyrighted. No part of this publication may be reproduced, distributed or used in any form without written
permission from Newland.
Risk Warning Regarding Unauthorized System Updates:
You should use the Newland-provided tool to update this product’s system. Modifying system files through installing a third-party
ROM system or using any cracking method may result in product malfunction or data loss and this will void your warranty.
Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make final interpretation of the statement above.
Fujian Newland Auto-ID Tech. Co., Ltd.
3F, Building A, No.1, Rujiang West Rd., Mawei, Fuzhou, Fujian, China 350015
http://www.newlandaidc.com

Revision History
Version
Description
Date
V1.0.0
Initial release.
December 10, 2018

Table of Contents
Revision History .......................................................................................................................................................................- 3 -
Chapter 1 About This Guide ........................................................................................................................................................1
Introduction.......................................................................................................................................................................1
More Information ..............................................................................................................................................................1
Chapter 2 Getting Started ............................................................................................................................................................2
Unpacking ........................................................................................................................................................................2
Accessories (Optional) .....................................................................................................................................................2
Safety Instructions............................................................................................................................................................3
Getting Started .................................................................................................................................................................4
The N5S...................................................................................................................................................................4
Installing the Battery ................................................................................................................................................5
Charging the Battery ................................................................................................................................................5
Installing SIM and MicroSD Cards ...........................................................................................................................6
Chapter 3 Basics ..........................................................................................................................................................................7
Powering On/ Rebooting/ Powering Off the N5S..............................................................................................................7
Locking/ Unlocking the N5S .............................................................................................................................................7
Home Screen ...................................................................................................................................................................8
Status Icons......................................................................................................................................................................8
Service Shortcuts .............................................................................................................................................................9
Transferring Files Between the Terminal and PC ...........................................................................................................10
Installing an App .............................................................................................................................................................10
Uninstalling an App......................................................................................................................................................... 11
Chapter 4 System Settings ........................................................................................................................................................12
Starting the Settings App................................................................................................................................................12
Configuring the System Parameters...............................................................................................................................13
Display ...................................................................................................................................................................13
Apps.......................................................................................................................................................................13
Screen Lock ...........................................................................................................................................................14

Language & Input...................................................................................................................................................14
Date & Time ...........................................................................................................................................................15
Restoring Factory Settings.....................................................................................................................................15
Viewing Status Information ....................................................................................................................................16
GPS.......................................................................................................................................................................16
NFC .......................................................................................................................................................................17
Wi-Fi Communications...........................................................................................................................................18
Bluetooth Communications ....................................................................................................................................19
SIM Cards and Mobile Network .............................................................................................................................20
Chapter 5 Using the Scanner ....................................................................................................................................................23
Configuring the Scanner.................................................................................................................................................23
Scanner Settings....................................................................................................................................................23
Scan Test ...............................................................................................................................................................28
Scanning Tips.................................................................................................................................................................29
Scanning 1D Barcode ............................................................................................................................................29
Scanning 2D Barcode ............................................................................................................................................30
Chapter 6 System Security ........................................................................................................................................................31
Chapter 7 System Update ..........................................................................................................................................................34
Chapter 8 Maintenance & Troubleshooting..............................................................................................................................35
Important Safety & Handling Information........................................................................................................................35
Disassembly and Retrofit .......................................................................................................................................35
External Power Supply...........................................................................................................................................35
Abnormal Situation.................................................................................................................................................35
Drop Damage.........................................................................................................................................................35
LCD Screen ...........................................................................................................................................................35
Stacking Heavy Objects.........................................................................................................................................35
Electronic Device ...................................................................................................................................................35
Hospital..................................................................................................................................................................36
Area with inflammables and Explosives .................................................................................................................36
Traffic Safety ..........................................................................................................................................................36
Storage Environment .............................................................................................................................................36

Operating Environment ..........................................................................................................................................37
Cleaning and Maintenance ....................................................................................................................................37
Battery Safety Guidelines.......................................................................................................................................38
Repair ....................................................................................................................................................................38
Troubleshooting..............................................................................................................................................................39
Chapter 9 System Customization and Software Development...............................................................................................41
System Customization....................................................................................................................................................41
Software Development ...................................................................................................................................................41

1
Chapter 1 About This Guide
Introduction
This guide provides instructions for programming and operating the N5S 4G mobile terminal (hereinafter referred to as “the
N5S” or “the terminal”) running Android 7.0.
More Information
For more product and support information, please visit our web site: http://www.newlandaidc.com.

2
Chapter 2 Getting Started
This chapter lists the parts and accessories for the N5S and explains how to install, remove and charge the battery, and
power on the N5S for the first time.
Unpacking
Carefully remove all protective material from the pack and verify that the following items are present:
1 x N5S Unit
1 x USB Cable
1 x Power Adapter
1 x Li-Polymer Battery
1 x Hand Strap
1 x Quick Start Manual
Accessories (Optional)
Cradle for the N5S
4-slot battery charger
Power Adapter for the Cradle
USB Cable

3
Safety Instructions
Before using the terminal, please read the safety instructions carefully to ensure safe and proper use of the terminal. For
more detailed information, please refer to Chapter 8.
Do not switch the terminal on when use is
prohibited or when it may cause interference
or danger.
Do not place the terminal or its accessories
in containers with a strong electromagnetic
field.
Do not use the terminal while driving.
Keep the terminal away from magnetic
devices as the radiation from this product
may erase the information stored on them.
Follow any rules or regulations in hospitals
and health care facilities. Switch off the
terminal near medical apparatus.
Do not put the terminal in a high-
temperature place or use it in a place with
flammable gas such as a gas station.
Switch off the terminal before boarding an
aircraft as it may cause interference to control
equipment of the aircraft.
Keep the terminal and its accessories out of
the reach of young children. Do not allow
children to use the terminal without
supervision.
+
Switch off the terminal near high-precision
electronic devices as it may affect their
performance.
Use only approved batteries and chargers
to avoid the risk of explosions.
Do not attempt to disassemble the terminal or
its accessories. Only authorized repair
stations are allowed to repair the terminal.
Observe any laws or regulations on the use
of wireless devices. Respect others' privacy
and legal rights when using the wireless
device.

4
Getting Started
The N5S
1
Arrow keys
9
Keypad
17
Power key
2
OK key
10
Period (.) key
18
Scan key (right)
3
Return key
11
Double-color LED*
19
Camera
4
Backspace key
12
Earpiece
20
Battery cover latch
5
Call key
13
Volume+/- key
21
Speaker
6
End key
14
Scan key (left)
22
Scanner
7
Fn key
15
Headphone jack
23
Cradle connector
8
Enter key
16
USB port
* Double-color LED indications:
Red LED on: Charging in progress.
Red LED flashes constantly: Low battery alert.
Blue LED on: Fully charged.
Blue LED flashes constantly: System notifications, eg. missed calls
