Newtons4th PPA55 Series User guide

PPA5500
This manual is copyright © 2006-2021 Newtons4th Ltd.
and all rights are reserved. No part may be copied or
reproduced in any form without prior written consent.
Document Title: PPA55xx Start Up Guide v4.0
Document Release Date: 04th March 2021
PPA55xx Firmware version on release date: v2.185
Document Ref: D000228 issue 04
Start Up Guide

PPA55xx Quick User Guide
Page 1
CONTENTS
Contents
......................................................................
Page.1
1.
Getting Started................................................
Page.3
1.1
Unpacking and Contents....................................
Page.3
1.2
Handle Fitment.................................................
Pages.4-5
2.
Safety.............................................................
Page.6
2.1
Safety Instructions...........................................
Page.6
2.2
Cautions.........................................................
Page.7
2.3
Warranty.........................................................
Page.8
3.
Front Panel Layout Diagram...............................
Page.9
3.1
Front Panel Display Key Functions......................
Pages.10-29
4.
Rear Panel Layout Diagram................................
Page.30
5.
Basic Key Operation..........................................
Page.31
5.1
Set up to start.................................................
Page.31
5.2
Setting the Time..............................................
Page.31
5.3
Setting the Date..............................................
Page.32
5.4
Adjusting the Screen Brightness........................
Page.32
5.5
Adjusting Keyboard Beep..................................
Page.32
5.6
Setting User Data............................................
Page.33
6.
Quick User Guide.............................................
Page.34
6.1
Wiring............................................................
Pages.34-37
6.2
Start Up.........................................................
Page.38
6.3
6.3.1
6.4
6.4.1
Zoom Functions...............................................
Analogue Output..............................................
Speed & Smoothing..........................................
Efficiency........................................................
Pages.39-40
Pages.41-44
Pages.45-47
Page.48
6.5
Application Modes............................................
Page.49
6.5.1
PWM Motor Drive Mode.....................................
Pages.50-56
6.5.2
6.5.3
6.5.4
6.5.5
6.5.6
6.5.7
6.5.8
6.5.9
6.5.10
6.5.11
6.5.12
Lighting Ballast Mode........................................
Inrush Current Mode........................................
Transformer Mode............................................
Standby Power Mode........................................
Calibration Mode..............................................
Oscilloscope Mode / Capture (RAW Data) Mode....
Harmonics / Flicker Mode..................................
Aircraft TVF105 Mode.......................................
Extended Frequency Range 417 Harmonics……….
Interharmonic Sweeps…………………………………………
HF Current Shunts...........................................
Page.57
Pages.58-64
Pages.65-70
Pages.71-73
Page.74
Pages.75-84
Page.85
Pages.86-92
Pages.93
Pages 94-99
Pages.100-105
6.5.13
LEM6 3-6 Channel Interface………………………………….
Pages.106-109

PPA55xx Quick User Guide
Page 2
7.
7.1
7.1.1
7.2
Remote Settings..............................................
Transferring Internal Datalogs to USB Memory Stick
Data Logging to USB Memory Stick....................
Program Store / Recall / Delete.........................
Pages.110-112
Pages.113-114
Pages.115-116
Pages.117-120
8.
8.1
9.
10.
Repair / Recalibration.......................................
Basic Functionality Check..................................
Specifications..................................................
PPA Comparison Table......................................
Page.121
Pages.122-138
Pages.139-142
Page.143

PPA55xx Quick User Guide
Page 3
1 Getting Started
1.1 Unpacking
Remove the instrument and accessories from the packaging and check them
against the supplied packing list. Please contact your N4L office or local sales
distributor should any items found to be missing or damaged during
transportation.
Please retain the original packaging to ensure easy and safe return of the
equipment for calibration etc.
If rack mounting brackets have been fitted to the equipment, please remove
them before packaging the equipment for return. This reduces the risk of
damage to the equipment during transportation.

PPA55xx Quick User Guide
Page 4
1.2 Fitment of the PPA series Carry/Tilt handle
PPA5/15/45/55 series power analyzers are supplied with a Carry/Tilt Handle that
is located within the accessory pack..............................................................
The handle allows a user to position the instrument upwards at one of two angles
for easier viewing when the instrument is positioned below the line of sight. The
design also allows storage under the unit without obstruction of the rubber feet
so that instruments can be stacked and is easily removed to allow the connection
of rack mounting brackets without the need to remove instrument covers.
Correct installation of the handle is important to ensure the correct operation
and long life the handle.
The following pictures illustrate correct and incorrect handle fitment:
Correct 1 Correct 2
Correct 1/2 –Correct fitting is from the top of the unit as shown here

PPA55xx Quick User Guide
Page 5
Correct 3 Correct 4
A correctly fitted handle will have the ‘N4L Newtons4th’ wording in the correct
reading plane when the handle is to the front of the instrument (Pic. 3)
Also, a correctly fitted handle will allow storage under the unit (Pic. 4)
Incorrect 1 Incorrect 2
Fitting the handle from the bottom of the unit as shown here is wrong...
(Incorrect 1)
Incorrect fitting can be seen because the handle does not fit correctly under the
unit and handle sides do not fit flush with the registration washer (Incorrect 2)

PPA55xx Quick User Guide
Page 6
2 Safety
2.1 IMPORTANT SAFETY INSTRUCTIONS
This equipment is designed to comply with BSEN 61010-1 (2001) (Safety
requirements for electrical equipment for measurement, control, and laboratory
use) –observe the following precautions:
Ensure that the supply voltage agrees with the rating of the instrument
printed on the back panel before connecting the mains cord to the supply
This appliance must be earthed. Ensure that the instrument is powered from
a properly grounded supply
The inputs are rated at 1kV rms or dc cat II; 600V rms or dc cat III. Do not
exceed the rated input
Keep the ventilation holes on the underneath and rear free from obstruction
There are no user serviceable parts inside the instrument –do not attempt to
open the instrument, refer service to the manufacturer or his appointed agent
Input Connections:
It is critical that the 4mm inputs and BNC inputs on each PPA input
channel are not connected to any external circuit at the same time.
You MUST only use EITHER the 4mm OR the BNC connection –NOT both,
this applies to both Voltage and Current inputs.
Note: Newtons4th Ltd shall not be liable for any consequential damages,
losses, costs or expenses arising from the use or misuse of this product
however caused

PPA55xx Quick User Guide
Page 7
2.2 CAUTIONS
Do not use a damaged power cord or cables
Doing so may cause an electric shock or a fire
Do not place any object on this instrument
Do not use this instrument if faulty
If you suspect the instrument to be faulty, contact your local N4L office or
representative for repair (see section 8)

PPA55xx Quick User Guide
Page 8
2.3 Warranty
This product is guaranteed to be free from defects in materials and workmanship
for a period of 36 months from the date of purchase
In the unlikely event of a problem within this guarantee period, first contact
Newtons4th Ltd or your local representative to give a description of the problem.
Please have as much relative information to hand as possible –particularly the
serial number and release number these can be found by pressing the SYSTEM
button then the “Left Arrow”
If the problem cannot be resolved directly then you will be given an RMA number
and asked to return the unit. The instrument will be repaired or replaced at the
sole discretion of Newtons4th Ltd
This guarantee is limited to the cost of the PPA55xx itself and does not extend to
any consequential damage or losses whatsoever including, but not limited to,
any loss of earnings arising from a failure of the product or software
In the event of any problem with the instrument outside of the guarantee period,
Newtons4th Ltd offers a full repair and re-calibration service. Contact your local
representative. It is recommended that the PPA55xx be re-calibrated annually

PPA55xx Quick User Guide
Page 9
3 Front Panel Layout
1. Display Screen
2. Screen Display Function Buttons
3. Power Analyzer Mode Buttons
4. Handle
5. Measurement Control Function Keys
6. Rubber Feet
7. Menu Selection and Cursor Controls
8. Measurement Settings Buttons
9. Front USB Port
10. Power On / Off Button
1 2 3
4
5
10 9 8 7 6
