Instruction Manual
XC5912
11 in 1 Multifunction Hub
with HDMI, DVI, Network, Audio &
Microphone, 4x USB2.0 & 2x USB3.0 Ports

2
SAFETY INSTRUCTIONS:
Always read the safety instructions carefully.
Keep this Instruction Manual for future reference.
Keep this equipment away from moisture/humidity.
Consult a service technician to inspect the device if any of the following
circumstances occur:
• The equipment has been exposed to moisture.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
• The equipment has not been working well or you cannot get it to work according
to the user manual.
• CPU: Dual Core Intel or AMD, 2GHz or better
• RAM: 2GB or more (Intel i5/i7 or AMD 2GHz+, 4GB RAM or more
recommended for full-screen video playback)
• Microsoft Windows 7, 8, 10, 11
• Chrome OS
• Mac OSX
• HDMI supports resolution of up to 4K@30Hz, DVI supports up to 1080p
• Multiple display modes for multi-tasking and intensive work
• Built-in USB 3.0 A port for BC1.2 fast charging
• Two USB 3.0 A ports and four USB 2.0 A ports to extend more USB
connectivity
• Gigabit Ethernet port provides high-speed network and is backwards
compatible with 10.100 Mbps networks
• Supports Microsoft Windows 7, 8, 10; Chrome OS and Mac OSX, is driver-free
only on Windows 10.
SYSTEM REQUIREMENTS:
SPECIFICATIONS:

3
1. Headphone Output
2. Microphone Input
3. Gigabit LAN Port: Connect an Ethernet cable for high-speed interface.
4. DVI Port: Connect DVI monitor with the resolution up to 1920x1080.
5. HDMI Port: Connect HDMI monitor with resolution up to 3840x2160@30Hz.
6. USB 2.0 A Ports: Fulfill all USB 2.0 devices such as scanner, digital camera,
keyboard, mouse, printer.
7. USB 3.0 A Ports: Connect any USB 3.0 devices, backward compatible with USB
2.0 devices.
8. USB 3.0 IN: Connect the Universal Docking Station to an available USB 3.0 port
on the laptop, PC or others.
9. DC Power Jack: For DC Power Adapter plug in to the Universal Docking Station
• 1 x USB 3.0 Universal Docking Station
• 1 x USB A to USB B Cable
• 1 x USB C to USB A Adapter
• 1 x DVI Converter to VGA Adapter
• 1 x DVI to HDMI Adapter
• 1 x DC12V/3A Power Adapter
• 1 x User Manual
PRODUCT OVERVIEW:
IN THE BOX:

4
1. To download the latest drivers, please visit http://dl.iqs.link/drivers.html and
find the corresponding model.
2. Click on the “exe” file to start the installation process.
DRIVER INSTALLATION:
3. Click the “Reboot” button to reboot the computer and finish the installation.

5
1. Plug the Universal Dock into a power outlet.
2. You can connect any USB 3.0 / USB 2.0 compatible devices to the Universal
Dock, the USB 3.0 interface is also backward compatible with USB 2.0 devices.
3. The docking should support dual displays in different resolution, HDMI
supports 3840x2160@30Hz and DVI supports 1920x1080 display output.
4. Connect your microphone, headset to headphone output and microphone
input port.
HARDWARE CONNECTION:

6
DISPLAY SETTINGS:
For Windows Users
1. Right-click any spot on your
desktop and select “Display
Settings”.
2. In “Display”, please select either
monitor 1 or monitor.
3. Scroll down to the “Multiple
displays”, and select the mode in
the drop-down list that is fit for
your need.

7
For Macintosh Users
1. Select “System Preferences” and choose “Displays”.
Notice
1. Due to privacy policy applied in
Mac, you may experience the
following issue:
2. Click on “Arrangement to change
the position of displays currently
connected.
3. To use the mirror mode, you have
to mark the “Mirror Displays” box
below the central icon.
2. Select “System Preferences” and
choose “Security & Privacy”. Click
on “Open Anyway” to approve of
the driver installation.
