NEXCAM NA70126 User manual

AXIS SHOOTING REST
INSTRUCTION MANUAL
MODEL: NA70126 Shooting Rest
THIS INSTRUCTION MANUAL MUST ALWAYS ACCOMPANY THIS PRODUCT AND BE TRANSFERRED WITH IT UPON
CHANGE OF OWNERSHIP, WHEN LOANED, OR PRESENTED TO ANOTHER PERSON.
Thank you for purchasing our NEXCAM product. This product is designed by hunters, for hunters. It is engineered for
safety, comfort, steady shot, and stealth, putting the odds in your favor when the moment of truth arrives.
Constructed with only the highest quality materials it’s built for years of satisfying hunts.
Read this instruction manual and all warnings in its entirety before using this product.
If you have any questions on assembly, use, safety warnings, or anything else, please contact us by email at
[email protected]om.
YOU MUST READ, UNDERSTAND, FOLLOW ALL WARNINGS AND INSTRUCTIONS
BEFORE USING THIS PRODUCT!
Always read, understand and follow all Nexcam AXIS Chair instructions and
warnings before installing and using this product.
This product is only intended for use with Nexcam AXIS Chairs. Never use without
Nexcam AXIS Chair.
Always follow safe weapon/firearm handling rules while using this product.
Always keep firearm/crossbow pointed in a safe direction.
This product is intended for use by adults or under strict supervision of an adult.
When a firearm/crossbow is placed on the rest, always take care not to bump
firearm/crossbow, rest or chair.
Never use, place or store firearm/crossbow on rest if you are not sitting in chair.
DO NOT use for any purpose other than intended use.
Always hold firearm/crossbow securely with both hands and keep contact between
rear of stock and shoulder at all times while aiming and firing. Shooting Rest is not
intended to hold or absorb recoil from firearm/crossbow.
Questions contact NEXCAM by email at [email protected].
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN SERIOUS INJURY OR
DEATH!
1
QUESTIONS? Email [email protected] for assistance.
Compatible with :
AXIS SG 360 Ultimate / AXIS SG 360 / AXIS RG 360 / AXIS RC 360
Not compatible with other models.

Shooting Rest Diagram
2
QUESTIONS? Email [email protected] for assistance.
Pinch Point Hazard.
Keep hands clear of
these areas.

Parts List
1
Cradle
(Rubber V)
Qty
2
2
Cradle Arm
Qty
1
3
Horizontal
Pivot Arm
Qty
1
4
Chair
Attachment
Arm
Qty
1
5
Vertical Post
Qty
1
6
Velcro Strap
Qty
2
3
QUESTIONS? Email [email protected]m for assistance.

Hardware
Step
1
1/4"
-20*2"
(with plastic
washer w/
Mark 1)
Qty
1
Step
2
1/4"
-20*2"
(with plastic
washer w/
Mark 2)
Qty
1
Step
3
M8X65
(with steel
washer and
plastic
washer)
Qty
1
Step
4
M8X40
Knob
Qty
2
Step
5
M6x16
Knob (With
Clamp &
Coil Spring )
Qty
2
QUESTIONS? Email [email protected] for assistance. 4
NOTICE MARK 1 ON WASHER
NOTICE MARK 2 ON WASHER

Tools Required
1
M8 Wrench
(2 pcs)
(Included)
2
1/4” Wrench
(Not Included)
QUESTIONS? Email [email protected] for assistance. 5

Setup Instructions
Step 1:
6
QUESTIONS? Email [email protected] for assistance.
Figure 1
Step 2:
Step 3:
Figure 2
Figure 3
Install front side Cradle (#1)
on CradleArm (#2) using
one (1) 1/4"-20*2" bolt and
plastic washer (Marked 1) as
shown in Figure 1.
Tighten so cradle is secure
to cradle arm.
Install back side Cradle (#1)
on CradleArm (#2) using one
(1) 1/4"-20*2" bolt and plastic
washer (Marked 2) and
locknut as shown in Figure 2.
Tighten so cradle is secure to
cradle arm.
Note –Make sure both
cradles are parallel so they
hold firearm/crossbow. If not
loosen, adjust and retighten.
Install Cradle Arm (#2) on
Horizontal Pivot Arm (#3) using
one (1) M8X65 with steel /
plastic washer and locknut as
shown in Figure 2.
Note –Do not over tighten as
cradle arm is designed to pivot.
Plastic washer
(Marked 1)
Plastic washer
(Marked 2)

Setup Instructions
Step 4:
7
QUESTIONS? Email [email protected] for assistance.
Figure 4
Step 5:
Figure 5
Install Chair AttachmentArm
(#4) on NEXCAM hunting
chair seat support base
using two (2) M8x40 knob as
show in Figure 4.
Securely hand tighten both
knobs.
Install Vertical Post (#5)
through Chair AttachmentArm
(#4) & through Horizontal
Pivot Arm (#3). Using two
M6x16 Knob (With Clamp &
Coil Spring ) secured on
Vertical Post (#5) by tightening
the knobs. Show in Figure 5.
To adjust shooting rest height,
loosen knob(s) and slide arm
up/down on vertical post and
retighten knob.
WARNING!Always be sure all
knobs are securely tightened
before use to prevent rest
from sliding down.
M6x16 Knob With
Clamp & Coil Spring
Front
Side Back Side
Using two Velcro Straps,
wrap around Nexcam
hunting chair for carrying
as shown in Figure 6.
Packing on Chair
Figure 6

Before each use, review and follow all Nexcam Chair instructions and warnings
found in chair instruction manual.
Before each use check to assure all locking / adjustment knobs are tight.
Never lean on or apply your weight on shooting rest. Shooting rest is designed
to only hold weight of firearm or crossbow. Applying excessive weight could
result in slippage or collapse of shooting rest.
Always hold firearm / crossbow on shooting rest. Shooting rest is designed to
aid in steadying firearm / crossbow for better shot placement.
To avoid injuries to fingers and pinch hazards, use care when folding and
adjusting shooting rest.
Always follow safe weapon/firearm handling practices. Always keep
firearm/crossbow muzzle pointed in a safe direction.
Always know your target and what lies beyond in case you miss or projectile
passes through target.
Always keep your finger off trigger until ready to fire.
Ensure firearm/crossbow is unloaded when removing from shooting rest.
Always be sure firearm/crossbow reciprocating parts, trigger area, ejection
port, etc. are not restricted by shooting rest. If any part is restricted, do not
use and reposition firearm/crossbow.
When used with crossbows, always ensure fingers are clear / below path of
bow string.
Failure to properly clamp weapon to the cradles may result in weapon falling.
Prior to every use, inspect chair for damage. DO NOT USE IF ANY DAMAGE IS
VISIBLE OR SUSPECTED, including but not limited to cuts, frayed portions,
corrosion, or other damage to chair. If damage is visible or suspected, DO NOT
USE THE PRODUCT. If there are any questions, DO NOT use the product and
contact NEXCAM by email at [email protected]m. for assistance.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN SERIOUS INJURY
OR DEATH!
Place Chair on a level surface with base flat on surface and make all necessary adjustments to the chair per the
chair's instruction manual.
Adjusting Shooting Rest:
WARNING! Always remove firearm/crossbow from shooting rest before making any adjustments to
shooting rest.
While sitting in chair, place unloaded firearm/crossbow in cradles making sure firearm/crossbow is balanced.
Using rubber keeper straps, place these overtop of firearm/crossbow to clamp firearm/crossbow to shooting
rest.
WARNING! When using crossbow, never place keeper straps overtop of barrel or in path of bow strings.
Shooting Rest is ready to be used.
USE:
8
QUESTIONS? Email [email protected] for assistance.
Adjusting Height:
Loosen Vertical Post Knob(s) and slide arm(s)
up/down on vertical post and retighten knob(s).
Adjusting Angle:
Loosen Horizontal Pivot Arm Friction Knob and
adjust shooting rest angle and retighten knob.
WARNING! Always be sure all knobs are securely tightened
before use and while not actively aiming. Angle friction knob
must always be tightened to prevent unintentional tilting
when not actively aiming.

MAINTENANCE AND STORAGE:
Do not modify this product in any way by making repairs, replacing parts, altering,
adding or attaching anything to it except if explicitly authorized in writing by
NEXCAM.
Use only NEXCAM authorized replacement parts. The use of unauthorized
replacement parts may result in serious injury or death.
Proper maintenance and inspection is required for this product.
Never use a shooting rest that is damaged in any way. If you have questions,
contact NEXCAM by email at [email protected] for assistance.
Failure to follow these instructions can lead to serious injury or death.
Should any damage occur or to purchase NEXCAM replacement parts, contact customer service by email at
[email protected]om for assistance.
Care and maintenance is required to assure trouble free performance of your shooting rest.
Store this product indoors in a clean, dry environment free from direct sunlight, harmful chemicals, excessive
heat and dust. Exposure to sunlight, excessive heat and the elements can weaken material over time.
