nextys OR50 User manual

OR50
Instruction Manual
SI000036A01_I.S.OR50.doc
www.nextys.com
Page 1/5
OR50 – 50A Universal Active ORing Controller
Main Features:
•Ultra Compact Redundancy Module
•CPU controlled
•Wide input voltage range 12…85Vdc (on a single model)
•50A Max
•Extremely low loss up to 99% efficiency
•Pluggable connectors
•Hot pluggable
•Easy acknowledgment of the power supplies availability status
•Easy correct current share status
•Up to 75°C operating temperature with no derating
INDEX
Page
Installation Requirements
2
Declaration of Conformity
2
User Instructions
3
Connections
3
Dimensions
3
Distances
3
Mounting
4
Dismounting
4
Set-up
5
Environment
5
Accessory Device
5

OR50
Instruction Manual
SI000036A01_I.S.OR50.doc
www.nextys.com
Page 2/5
READ THIS CAREFULLY BEFORE INSTALLATION!
LEGGERE ATTENTAMENTE PRIMA
DELL’INSTALLAZIONE!
A LIRE ATTENTIVEMENT AVANT L’INSTALLATION!
Before operating, read this document thoroughly and retain
it for future reference.
Non-respect of these instructions may reduce
performances and safety of the devices and cause danger
for people and property.
The products must be installed, operated, serviced and
maintained by qualified personnel in compliance with
applicable standards and regulations.
Don’t open the device, it does not contain replaceable
components, the tripping of the internal fuse (if included) is
caused by an internal failure.
Don’t repair or modify the device, if malfunction or failure
should occur during operation, send unit to the factory for
inspection. No responsibility is assumed by Nextys SA for
any consequences deriving from the use of this material.
Prima dell’installazione, leggere attentamente questo
documento istruzioni e conservarle per future consultazioni.
L’inosservanza delle presenti istruzioni può compromettere le
caratteristiche e la sicurezza dell’apparecchio e causare
pericolo per le persone e le cose.
Il prodotto deve essere installato, utilizzato e riparato da
personale qualificato e nel rispetto delle normative vigenti.
Non aprire il prodotto, esso non contiene componenti sostituibili,
il guasto del fusibile interno (se previsto) è causato da un
guasto interno. Non tentare di riparare o modificare il prodotto,
se durante il funzionamento si verificano guasti o anomalie,
inviarlo al produttore per il controllo.
Nextys SA non si assume nessuna responsabilità per
qualunque conseguenza derivante dall’uso di questo materiale.
Lisez ces instructions avant l'installation, conservez ce
manuel pour référence future.
Défaut de se conformer à ces instructions peut affecter les
caractéristiques et la sécurité du dispositif de danger et de
causer aux personnes ou aux biens.
Les produits doivent être installés, exploité et entretenus par
personnel qualifié et en conformité avec les règlements.
N'ouvrez pas le produit, il ne contient aucune pièce réparable,
le déclenchement du fusible interne (le cas échéant) est
causé par un défaut interne. Ne pas essayer de réparer ou
modifier le produit ; si des défaillances se produisent pendant
le fonctionnement ou les dysfonctionnements, le retourner au
fabricant pour inspection. Nextys SA n'assume aucune
responsabilité des conséquences éventuelles découlant de
l'utilisation des produits.
CAUTION
ATTENZIONE
AVVERTISSEMENT
RISK OF BURNS, EXPLOSION, FIRE, ELECTRICAL
SHOCK, PERSONAL INJURY.
Never carry out work on live parts! Danger of fatal injury!
The product’s enclosure may be hot, allow time for cooling
product before touching it. Do not allow liquids or foreign
objects to enter into the products.
To avoid sparks, do not connect or disconnect the device
before having previously turned-
off input power and wait for
internal capacitors discharge (minimum 1 minute).
Radio interference!
This is an electrical appliance according to EN55032, class
A. It may cause radio interference in residential areas.
RISCHIO USTIONI, ESPLOSIONE, INCENDIO, SCOSSA,
LESIONI GRAVI.
Non effettuare mai operazion
i sulle parti sotto tensione! Pericolo
di lesioni letali! Il contenitore può scottare, lasciar quindi
raffreddare il dispositivo prima di toccarlo. Non far entrare liquidi
o oggetti estranei nel dispositivo.
Per evitare scintille, non collegare o scollegare
l'apparecchiatura prima di avere tolto tensione di ingresso e
prima che sia avvenuta la scarica dei condensatori interni (min.
1 minuto).
Interferenza radio!
Questo apparecchio è un dispositivo di classe A secondo lo
standard EN55032. Può causare interferenze radio nelle aree
residenziali.
RISQUE DE BRULURES, EXPLOSION, INCENDIE,
ELECTROCUTION, DOMMAGE AUX PERSONNES.
Ne jamais effectuer des opérations sur les parties sous
tension! Danger de mort! Le récipient peut produire des
brulures, le laisser refroidir avant de toucher l'appareil. Ne
faites pas pénétrer des liquides ou des corps étrangers dans
l'appareil. Pour éviter des étincelles, ne pas connecter ou
déconnecter l'équipement jusqu'à ce que vous avez supprimé
la tension d'entrée et avant qu'elle n'ait lieu de décharge des
condensateurs internes (minimum 1 minute).
Perturbations radioélectriques!
Cet appareil est un dispositif de catégorie A selon le standard
EN55032. Il peut causer des perturbations radioélectriques
dans les zones résidentielles.
DECLARATION OF CONFORMITY
NEXTYS SA.
Via Luserte Sud 6, 6572 Quartino - Switzerland
Phone: [phone]; Fax: [phone]
E-mail: [e-mail]
This Declaration of Conformity is suitable to the European Standard EN45014 "General criteria for supplier’s declaration of conformity".
We declare under our sole responsibility that the device included in this box, has passed all processing inspections and the final test and it is in conformity with the product
requirements, including all reference codes and supply specifications.
ROHS compliance: the product respects the EC requirements related to ROHS substances, according to “Restriction of Hazardous Substances” as per document 2011/65/UE
REACH compliance: the product respects the EC requirements related to REACH SVHC directive (2015)
Note: all the reported information comes from our suppliers, NEXTYS SA. has not run any test to evaluate if the specific elements are present.
All indicated devices are designed according to the latest Reference standards, if not expressly indicated through the official documents or files, they have been tested through
our internal pre-compliance testing. Consult directly on www.nextys.com the reference standards applied to each model.
Code Description
OR50 50A Universal Active ORing Controller 12…85Vdc
Certifications and approvals
IND.CONT.EQ. 4WX9
Reference standards
2014/35/EU (2014) (Low Voltage Directive)
2014/30/EU (2014) (EMC directive)
EN61010-1 (Safety Standard)
EN61010-2-201 (Safety Standard)
UL508 (Certified - IND. CONT. EQ. 4WX9 file no. E356563)
EN61000-6-2:2005 (Generic immunity standard for industrial environments)
- EN61000-4-2:2008 (Electrostatic discharge immunity test)
- EN61000-4-3:2006 /A2:2010 (Radiated, radio-frequency, electromagnetic field immunity test)
- EN61000-4-4:2012 (Electrical fast transient/burst immunity test)
- EN61000-4-5:2014 (Surge immunity test)
- EN61000-4-11:2004 /A1:2010 (Voltage dips, short interruptions and voltage immunity test)
EN61000-6-4:2007 /A1:2011 (Generic emission standard for industrial environments)
- EN55022:2010 (CISPR22 - EMC)
- EN55011:2009 /A1:2010 (CISPR11 - EMC)

OR50
Instruction Manual
SI000036A01_I.S.OR50.doc
www.nextys.com
Page 3/5
USER INSTRUCTIONS
1) Description: DIN rail Universal Active Oring Controller for redundant connection to a common Load of 2 DC Power supplies of same rating, with any voltage in the range
12…85Vdc and Load Current ≤ 50A.
Warning: voltages ≥ 60Vdc are dangerous! Use appropriate safety rules!
2) Installation: use DIN-rails according to EN 60715. Installation should be made vertically (see Fig.4). For better device stability fix the rail to the wall close to the point where
the device is to be mounted. In order to guarantee sufficient convection, we recommend observing a minimum distance to other modules (see Fig.3).
3) Connections: the device is equipped with pluggable screw terminals. To avoid sparks, do not connect or disconnect the connectors before having previously turned-off input
power and waited for internal capacitors discharge (minimum 1 minute)
In order to comply with UL certification, use appropriate copper cables of indicated cross section, designed for an operating temperatures of:
60°C for ambient up to 45°C
75°C for ambient up to 60°C
90°C for ambient up to 70°C
Strip the connecting ends of the wires according to the indication and ensure that all strands of a stranded wire enter the terminal connection (see Fig.5)
4) Input/Output connection: The device is suitable for SELV and PELV circuitry (if you use a source that having Uout higher 60Vdc is not a SELV device)
Check Uout before connecting the power supply to the load.
5) Operating: Connect the OR50 as indicated in Fig.7.
Turn on power supply “A” and adjust the load voltage to the needed level by measuring directly at the load.
Turn on power supply “B”. Trim its voltage until the green LED in the OR50 bar-graph is lit. At this moment power supplies “A” and ”B” share the load with balanced currents.
In case one of the two power supplies does not operate anymore the load is supplied by the second one without any interruption.
6) Status Signal: OR50 provides specific status signals related to:
•acknowledgment of the power supplies availability (correct output voltage for each) (OR OK)
•correct current share between the two power supplies (SHARE OK)
•load current > 50A (OVERLOAD)
These signals are displayed on the OR50 front panel trough LEDs and are also present on 2 relays dry contacts for remote monitoring of the unit.
0BIN1 (IN2) OK LED: Indicates that the voltage present on IN1 (IN2) is > 0.9*Vout. It is an indication of the presence of the correct voltage from the power supply connected to
IN1 (IN2).
1BFAIL LED: Indicates that the system has a problem and the redundancy is no more guaranteed. It can have 3 status
•OFF continuously: means that the redundancy is guaranteed. In this status the OR-OK dry contact is closed
•ON continuously: means that the voltage on one of the two inputs is not present or out of range. In this status the OR-OK dry contact is open
Blinking at 0.5Hz: means that the output current has exceeded the maximum of 50A. In this status the SHARE-OK dry contact is closed and open at 0.5Hz rate (1s ON / 1s
OFF).
2BCurrent share bar-graph: Indicates the current distribution between the two power supplies. The current balancing is calculated in the following way: unbal=(I1-I2)/(I1+I2);
bal=0% means perfect current sharing while unbal=100% (-100%) indicates that the load current is provided only by power supply 1( 2).
The central green LED has a threshold of around ±15% current unbalancing, while the two external red LEDs are actives when the current unbalancing is greater than 60%.
When one of the two red LEDs is on the SHARE-OK dry contact is open.
Note: when the load current is <2A the bar-graph green LED is always on and the SHARE-OK dry contact is always closed.
The current unbalancing is not calculated when the load current is <2A.
3BOR-OK relay dry contact: It acts in exactly the same way as the FAIL LED. It is closed when the redundancy is guaranteed and open in case of failure. The relay contact
rating is 24V/1A
SHARE-OK relay dry contact: It is closed when the load current unbalance is <60% and open when the current unbalance is >60% indicating that the current sharing between
the two sources is lost. It toggles at 0.5Hz rate (1s closed / 1s open) when the load current exceeds 50A.
Fig.1
Connections
Fig.2
Dimensions
Fig.3
Distances
(1) Input PS1 50A Max.
(2) Input PS2 50A Max.
(3) Output Load 50A Max.
(4) Diagnostic Output: OR OK
(dry contact, NC output OK)
(5) Diagnostic Output: SHARE OK
(dry contact, NC output OK)
(6) Green LED: IN1 OK
(7) Green LED: IN2 OK
(8) Red LED: FAIL
(9) Current share Bar-graph
Input DC Line:

IN1 + = Positive DC

IN1 - = Negative DC

IN2 + = Positive DC

IN2 - = Negative DC
Output DC Line:

OUT + = Positive DC

OUT - = Negative DC
Dimension
W
D
H
mm (inc)
40.0 (1.57)
110.0 (4.33)
115.0 (4.52)
Distance
A
B
mm (inc)
20 (0.8)
20 (0.8)

OR50
Instruction Manual
SI000036A01_I.S.OR50.doc
www.nextys.com
Page 4/5
Fig.4
Mounting / Dismounting Instructions
For DIN rail fastening according to IEC 60715 TH35-7.5(-15)
Mounting as shown in figure, with input terminals on lower side, with suitable cooling and maintaining a proper distance between adjacent devices as specified in the I.S.
manual of each family.
Mounting:
1. Tilt the unit slightly backwards.
2. Fit the unit over the top edge of the rail.
3. Slide it downward until it hits the stop.
4. Press against the bottom for locking.
1
2
3
4
Dismounting:
1. Pull down the slide clamp lever
2. Tilt the unit upward
3. Unhook the unit from the rail
1 & 2
3
Fig.5
Recommended connecting cable
Recommended Tightening torque
Input / output
1.2NM
10.4 lbf in
Signals
0.2-0.25Nm
1.17-2.21 lbf in
Input / output
Solid: 0.75-16.0mm² / 18-6AWG
Stranded: 0.75-16.0mm² / 18-6AWG
L: 13-14mm / 0.51-0.55in
Signals
Solid: 0.05-1.5mm² / 30-14AWG
Stranded: 0.05-1.5mm² / 30-14AWG
L: 5-6mm / 0.20-0.24in

OR50
Instruction Manual
SI000036A01_I.S.OR50.doc
www.nextys.com
Page 5/5
Fig.6
Input protection
The Device is provided in input against the Reverse polarity connection.
Fig.7
Set-up
Input / output connection
Fig.8
Environment
Operating temperature
Derating
- 40°C…75°C
5…95% r.H. non condensing
UL certified up to 75°C
No Derating
Note:
Data may change without prior notice in order to improve the product.
Please refer to the latest version of the "Instruction Manual" for each product by visiting www.nextys.com
See also the products below that can be used in conjunction with OR50 units:
This device can be used in conjunction with every each our power supply that is able to provide an regulated Uout included between 12…85Vdc and 50A
Max.
