nextys OR20 User manual

OR20
Instruction Manual
OR20 V4.0
www.nextys.com
Page 1/5
OR20 – 20A Universal Active ORing Controller
Main Features:
Ultra Compact Redundancy Module
Wide input voltage range 12…85Vdc(on a single model)
20A Max
Extremely low loss up to 99% efficiency
Pluggable connectors
Hot pluggable
Up to 70°C operating temperature with no derating
INDEX
Page
Installation Requirements
2
Declaration of Conformity
2
User Instructions
3
Connections
3
Dimensions
3
Distances
3
Mounting
4
Dismounting
4
Set-up
5
Environment
5
Accessory Device
5
1 OR20_1680-21539-0007-E-1117

OR20
Instruction Manual
OR20 V4.0
www.nextys.com
Page 2/5
READ THIS CAREFULLY BEFORE INSTALLATION!
LEGGERE ATTENTAMENTE PRIMA
DELL’INSTALLAZIONE!
A LIRE ATTENTIVEMENT AVANT L’INSTALLATION!
Before operating,read this document thoroughly and retain
it for future reference.
Non-respect of these instructions may reduce
performances and safety of the devices and cause danger
for people and property.
The products must be installed, operated, serviced and
maintained by qualified personnelin compliance with
applicable standards and regulations.
Don’t open the device, it does not contain replaceable
components, the tripping of the internal fuse (ifincluded) is
caused by an internal failure.
Don’t repair or modify the device, if malfunction or failure
should occur during operation, send unit to the factory for
inspection. No responsibility is assumed by Nextys SA for
any consequences deriving from theuse of this material.
Prima dell’installazione, leggere attentamente questo
documento istruzioni e conservarle per future consultazioni.
L’inosservanza delle presentiistruzioni può compromettere le
caratteristiche e la sicurezza dell’apparecchio e causare
pericolo per le persone e le cose.
Il prodotto deve essere installato, utilizzato e riparato da
personale qualificato e nel rispetto delle normative vigenti.
Non aprire ilprodotto, esso non contiene componenti sostituibili,
il guasto del fusibile interno (se previsto) è causato da un
guasto interno. Non tentare di riparare o modificare il prodotto,
se durante ilfunzionamento siverificano guasti o anomalie,
inviarlo al produttore per il controllo.
Nextys SA non siassume nessuna responsabilità per
qualunque conseguenza derivante dall’uso diquesto materiale.
Lisez ces instructions avant l'installation, conservez ce
manuel pour référence future.
Défaut de se conformer à ces instructions peut affecter les
caractéristiques et la sécurité du dispositif de danger et de
causer aux personnes ou aux biens.
Les produits doivent être installés, exploité et entretenus par
personnel qualifié et en conformité avec les règlements.
N'ouvrez pas le produit, ilne contient aucunepièce réparable,
le déclenchement du fusible interne (le cas échéant) est
causé par un défaut interne. Ne pas essayer de réparer ou
modifier le produit ; si des défaillances se produisent pendant
le fonctionnement ou les dysfonctionnements,le retourner au
fabricant pour inspection. Nextys SA n'assume aucune
responsabilité des conséquences éventuelles découlant de
l'utilisation des produits.
CAUTION
ATTENZIONE
AVVERTISSEMENT
RISK OF BURNS, EXPLOSION, FIRE, ELECTRICAL
SHOCK, PERSONAL INJURY.
Never carry out work on live parts! Danger of fatal injury!
The product’s enclosure may be hot,allow time for cooling
product before touching it. Do not allow liquids or foreign
objects to enterinto the products.
To avoid sparks, do not connect or disconnect the device
before having previously turned-off input power and wait for
internal capacitorsdischarge (minimum1 minute).
RISCHIO USTIONI, ESPLOSIONE, INCENDIO, SCOSSA,
LESIONI GRAVI.
Non effettuare mai operazioni sulle parti sotto tensione! Pericolo
di lesioni letali! Il contenitore può scottare, lasciar quindi
raffreddare il dispositivo prima ditoccarlo. Non far entrare liquidi
o oggetti estranei nel dispositivo.
Per evitare scintille, non collegare o scollegare
l'apparecchiatura prima di avere tolto tensione di ingresso e
prima che sia avvenuta la scarica dei condensatoriinterni (min.
1 minuto).
RISQUE DE BRULURES, EXPLOSION, INCENDIE,
ELECTROCUTION, DOMMAGE AUX PERSONNES.
Ne jamais effectuerdes opérations sur les parties sous
tension! Danger de mort! Le récipient peut produire des
brulures, le laisser refroidir avant de toucher l'appareil. Ne
faites pas pénétrerdes liquides ou des corpsétrangers dans
l'appareil. Pour éviter des étincelles, ne pas connecter ou
déconnecter l'équipement jusqu'àce que vous avez supprimé
la tension d'entrée et avant qu'elle n'ait lieu de décharge des
condensateurs internes (minimum 1 minute).
DECLARATION OF CONFORMITY
NEXTYS SA.
Via Luserte Sud 6, 6572 Quartino - Switzerland
Phone: [phone]; Fax: [phone]
E-mail: [email protected]om
This Declaration ofConformity issuitable to the European Standard EN45014 "General criteria forsupplier’s declaration of conformity".
We declare underour sole responsibilitythat the device included in this box, has passed all processing inspections and the final test and it isin conformitywith the product
requirements, including all reference codes and supply specifications.
ROHS compliance: the product respects the EC requirements related to ROHS substances, according to “Restriction of Hazardous Substances” as per document 2011/65/UE
REACH compliance: theproduct respectsthe EC requirements related to REACHSVHC directive (2015)
Note: all the reported information comes from our suppliers, NEXTYS SA. has notrun any test to evaluate if the specific elements arepresent.
All indicated devices are designedaccording to the latest Reference standards, ifnot expresslyindicated through the official documents or files, they have been tested through
our internal pre-compliance testing. Consult directly on www.nextys.com the reference standards applied to each model.
Code Description
OR20 20A Universal Active ORing Controller 12…85Vdc
Certifications and approvals
Reference standards
2014/35/EU (2014) (Low Voltage Directive)
2014/30/EU (2014) (EMC directive)
EN60950-1:2006 /A2:2013 (Safety Standards)
UL508 (Safety Standards)
EN61000-6-2:2005 (Generic immunity standard for industrial environments)
- EN61000-4-2:2008 (Electrostatic discharge immunity test)
- EN61000-4-3:2006 /A2:2010 (Radiated, radio-frequency, electromagnetic field immunity test)
- EN61000-4-4:2012 (Electrical fast transient/burst immunity test)
- EN61000-4-5:2014 (Surge immunity test)
- EN61000-4-11:2004 /A1:2010 (Voltage dips, short interruptions and voltage immunitytest)
EN61000-6-4:2007 /A1:2011 (Generic emission standard for industrial environments)
- EN55022:2010 (CISPR22 - EMC)
- EN55011:2009 /A1:2010 (CISPR11 - EMC)
Date: 25.02.2016
Place: Quartino, Switzerland
The product manager
Marius Ciorica
2 OR20_1680-21539-0007-E-1117

OR20
Instruction Manual
OR20 V4.0
www.nextys.com
Page 3/5
USER INSTRUCTIONS
1) Description: DIN rail Universal Active Oring Controller for redundant connection to a common Load of 2 DC Power supplies ofsame rating, with any voltage in the range
12…85Vdc and Load Current ≤ 20A.
Warning: voltages ≥ 60Vdc are dangerous! Use appropriate safety rules!
2) Installation: use DIN-rails according to EN 60715. Installation should bemade vertically(see Fig.4). For better device stability fix the rail to the wallclose to the point where
the device is to be mounted. In order to guarantee sufficient convection, we recommend observing a minimumdistance to other modules (see Fig.3).
3) Connections: the device is equipped with pluggable screw terminals. To avoid sparks, do not connect or disconnect the connectors before having previously turned-off input
power and waited for internal capacitorsdischarge (minimum 1 minute)
In order to complywith UL certification, use appropriate copper cablesof indicated crosssection, designed for an operating temperatures of:
60°C for ambient up to 45°C
75°C for ambient up to 60°C
90°C for ambient up to 70°C
Strip the connecting ends of the wiresaccording to the indication andensure that allstrands of a stranded wire enter the terminal connection (see Fig.5)
4) Input/Output connection: The device is suitable for SELV and PELV circuitry (if you usea source that having Uout higher60Vdc is not a SELV device)
Check Uout before connecting thepower supply to the load.
5) Operating: at the OR20 ispossible connect 2 DC Power suppliesin order to obtain a redundancyconnection system (see Fig.7), the 2 Power supplies must have setted the
same Output voltage rating in order to ensure the corrected redundancy. The correctly current sharing is possible verifythrough the status LEDs “IN1 OK” and “IN2 OK”(see
Fig.1), when you connect 2 DC Power supplies, what is has the higher output voltage determines the voltage threshold and turnson the respective LED, in order to ensure the
correct current sharing now you must increase Output voltage of the other Power supply until the two LEDs will not be turned on simultaneously. The precision of redundancy
which allows the simultaneous lighting of the two LEDs is about 10% of the highest voltage threshold. When the two LEDs are simultaneously turned on is ensured the
redundancy and also the Diagnostic Output "OR OK" relay it is closed.
Fig.1
Connections
Fig.2
Dimensions
Fig.3
Distances
(1) Input PS1 20A Max.
(2) Input PS2 20A Max.
(3) Output Load 20A Max.
(4) Diagnostic Output
(dry contact, NC output OK)
(5) Green LED: IN1 OK
(6) Green LED: IN2 OK
Input DC Line:
IN1 + = Positive DC
IN1 - = Negative DC
IN2 + = Positive DC
IN2 - = Negative DC
Output DC Line:
OUT + = Positive DC
OUT - = Negative DC
Dimension
W
D
H
mm (inc)
35.0 (1.38)
104.0 (4.09)
103.0 (4.05)
Distance
A
B
mm (inc)
20 (0.8)
20 (0.8)
3 OR20_1680-21539-0007-E-1117

OR20
Instruction Manual
OR20 V4.0
www.nextys.com
Page 4/5
Fig.4
Mounting / Dismounting Instructions
For DIN rail fastening according to IEC 60715 TH35-7.5(-15)
Mounting as shown in figure, with inputterminals on lower side, with suitable cooling and maintaining a proper distance between adjacentdevices as specified in the I.S.
manual of each family.
Mounting:
1
2
1.Tilt the unit slightly backwards.
2.Fit the unit over the top edge of the rail.
3.Slide it downward until it hitsthe stop.
4.Press against the bottom for locking.
3
4
Dismounting:
1.Pull down the slide clamp lever
2.Tilt the unit upward
3.Unhook the unit from the rail
1 & 2
3
Fig.5
Recommended connecting cable
Recommended Tightening torque
0.5-0.6Nm
4.42-5.30 lbf in
Solid: 2.5mm² / 12AWG
Stranded:1.5mm² / 12AWG
L: 6.0-7.5mm / 0.24-0.30in
4 OR20_1680-21539-0007-E-1117

OR20
Instruction Manual
OR20 V4.0
www.nextys.com
Page 5/5
Fig.6
Input protection
The Device isprovided in input againstthe Reverse polarity connection.
Fig.7
Set-up
Input / output connection
Fig.8
Environment
Operating temperature
Derating
- 40°C…70°C
5…95% r.H. non condensing
No Derating
Note:
Data may changewithout prior notice in order to improve the product.
Please refer to the latest version of the "Instruction Manual" for each product by visiting www.nextys.com
See also the products below that can be used in conjunction withOR20 units:
This device can be used in conjunction with everyeach our power supply that is able to provide an regulated Uout included between 12…85Vdc and 20A
Max.
5 OR20_1680-21539-0007-E-1117

Sensors • Power Solutions - Experts on Design-In
Headquarter Switzerland:
Pewatron AG
Thurgauerstrasse 66
CH-8050 Zurich
Phone [phone]
[email protected]om
Oce Germany:
Pewatron Deutschland GmbH
Edisonstraße 16
D-85716 Unterschleißheim
Phone [phone]
[email protected]om
Flow / Level / Medical products
Dr. Adriano Pittarelli
Phone [phone]
[email protected]om
Drive technology
CH Postcode 5000 – 9999 / DE
Roman Homa
Phone + 41 76 444 00 86
[email protected]om
Drive technology
CH Postcode 1000 – 4999 / AT / IT / FR
Christian Mohrenstecher
Phone [phone]
[email protected]om
Gas sensors
Gas sensor modules
Dr. Thomas Clausen
Phone + 41 44 877 35 13
[email protected]
Linear position sensors
Angle sensors
Eric Letsch
Phone + 41 44 877 35 14
[email protected]
Current sensors / Power solutions &
Turkey
Osman Coban
Phone [phone]
[email protected]om
Pressure Sensors
Load Cells
Philipp Kistler
Phone + 41 44 877 35 03
[email protected]
Power supplies
Sebastiano Leggio
Phone + 41 44 877 35 06
[email protected]
Accelerometers
Sensor elements
Christoph Kleye
Phone [phone]
[email protected]om
Harald Thomas
Phone [phone]
[email protected]om
Sales Other Countries / Product Management
Sales International Key Accounts
Peter Felder
Phone + 41 44 877 35 05
peter[email protected]
Postcode 1000 – 2999
Christian Mohrenstecher
Phone [phone]
[email protected]om
Sales Switzerland & Liechtenstein
Postcode 3000 – 9999
Basil Frei
Phone + 41 44 877 35 18
[e-mail]
Gas sensors and modules
Peter Felder
Phone [phone]
peter[email protected]
Pressure sensors
Other products
Gerhard Vetter
Phone + 49 89 374 288 87 26
gerhard.[email protected]om
Sales Germany & Austria
Geometrical sensors
Other products
Kurt Stritzelberger
Phone + 49 89 374 288 87 22
[email protected]om
We are here for you. Addresses and Contacts.
