NexxTech 3-Station FM Wireless Intercom System User manual

4308995 OWNER’S MANUAL — Please read before using this equipment.
©2003 ORBYX Electronics. All Rights Reserved.
3-Station FM Wireless Intercom System
Your Nexxtech 3-Station FM Wireless
Intercom System is convenient and easy to
use. Installation is quick and simple. Simply
plug each of the three supplied stations into
a standard three-wire AC outlet, and you are
ready to send and receive calls or monitor an
area where a station is installed. Each of
your intercom’s stations has the following
features:
Precision PLL (Phase-Locked Loop)
Circuit — provides clear and reliable
communications.
Built-In Frequency Modulation Circuit —
reduces line noise and interference from
appliances.
Adjustable Volume Control — allows you
to alter the volume to suit the noise level in
the room.
Lockable Talk Bar — allows you to talk to or
monitor a room hands-free.
Call Tone — alerts other stations before you
start talking.
Talk Indicator — illuminates when you
transmit to another station by pressing
CALL, TALK, or LOCK.
Desk or Wall Mounting Capabilities —
provide easy, convenient placement of
stations.
Your intercom system is cUL listed to CSA
standards and meets all applicable Industry
Canada standards.
Caution: This product is equipped with a
three-wire grounding-type plug (a plug
having a third grounding pin). This plug will
only fit into a grounding-type power outlet.
This is a safety feature. If you are unable to
insert the plug into your AC outlet, contact
your electrician to replace your outlet. Do not
defeat the safety purpose of the grounding-
type plug.
WARNING: To reduce the risk of fire or
shock hazard, do not expose this product to rain
or moisture.
CAUTION
!
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
This symbol is intended to alert
you to the presence of
uninsulated dangerous voltage
within the product’s enclosure that
might be of sufficient magnitude
to constitute a risk of electric
shock. Do not open the product’s
case.
!
This symbol is intended to inform
you that important operating and
maintenance instructions are
included in the literature
accompanying this product.

2
INSTALLATION
You can install the stations almost anywhere
there is a standard AC outlet. Simply plug
each station into an outlet and place it directly
on a desk, shelf, table or on a wall.
Important: Stations can transmit up to 90
metres (300 feet) and between buildings as
long as they are connected to the same power
line transformer.
Note: Make sure you install the stations at
least 3 metres (10 feet) away from each other.
Placing the stations too close together
produces feedback and creates a squealing
sound.
Mounting
To mount a station on the wall, you need two
screws (not supplied) with heads that fit into
the keyhole slots on the bottom of the
stations.
1. Select a location for the station. Mark the
mounting screw locations on the wall
70mm (23/4inches) apart, one above the
other.
2. Drill holes at the marked locations.
3. Thread a screw into each hole allowing
the screw heads to extend about 3.5mm
(1/8inch) from the wall.
4. Align the keyhole slots on the bottom of
the station with the screw heads in the
wall. Slide the station down onto the
screws to secure it.
OPERATION
Setting the Channel
Each station has three channels, so you can
select which station or stations you want to
communicate with. You can also use a station
to monitor sounds near another station.
For example, you could set a station installed
in the kitchen to Channel A, a station installed
in the family room to Channel B, and a station
installed in a bedroom to Channel C. Write the
names on the Station Directory.
A B C
Kitchen Family room Bedroom
Using the station installed in the kitchen, you
can communicate with the station in the family
room by setting the channel selector to B, or
with the station in the bedroom by setting the
channel selector to C. Or, if you set all
stations to Channel A, you can communicate
with the other two stations from any station.
Set the channel selector on each station as
follows:
• If you want all the stations to
communicate with each other at the same
time, set all stations to the same channel.
• If you want to use a station to
communicate with only one of the other
stations, set only those stations to the
same channel.
Turning a Station On and Off/
Adjusting the Volume
Rotate VOLUME clockwise until it clicks.
POWER indicator lights. Then adjust VOLUME
to a comfortable listening level. To turn off the
station, rotate VOLUME counterclockwise until
it clicks. POWER indicator turns off.
Calling Another Station
1. Be sure the stations you plan to use are
turned on and adjusted to the desired
volume.
2. Set the channel selector to the channel
(A, B or C) for the station(s) you are
calling.
3. Press CALL. Each station that is on and
set to the selected channel sounds a
tone.
4. Hold down TALK and speak in a normal
voice. When you finish speaking,
release TALK and listen for the
response.

3
Notes:
• Only one party can talk on a channel at
a time.
• The TALK indicator on the station you
are using remains lit as long as you
hold down TALK or CALL, or when you
press LOCK.
• If your voice sounds distorted, you
might be speaking too loudly or too
close to the microphone.
• Set the channel selector back to your
designated channel after you finish
talking, so others can easily reach you.
Monitoring
You can set any station so it continuously
transmits sounds from the area where it is
located to another station. For example, you
could set the station in a baby’s bedroom,
then use the station in the kitchen to monitor
the sounds.
Note: You can monitor only one station at a
time.
1. Press LOCK on the station in the area you
want to monitor. The TALK indicator
lights.
Note: The TALK indicator stays lit until
you press CALL or TALK. This lets you
know that the station is transmitting.
2. Set the channel selectors on both
stations to the same channel.
3. When you finish monitoring, release the
lock by pressing TALK or CALL on the
station in the area you are monitoring.
The TALK indicator turns off.
Note: After pressing LOCK on a station,
you cannot call or talk to that station until
you press TALK or CALL to release the
lock.
Using Additional Stations
You can add additional stations to your
intercom system as long as they transmit on
the same frequency. Any intercom that
transmits on the same frequencies is
compatible. The intercom’s channels and
transmitting frequencies are shown below:
A ....................................... 200 kHz ±2.5 kHz
B ....................................... 270 kHz ±2.5 kHz
C ....................................... 230 kHz ±2.5 kHz
Stations in the same box have the same
frequency.
Be sure the frequency of the stations you plan
to add matches the frequency of your current
stations. If you want to set up a separate
intercom system, however, be sure it operates
on a different frequency.
INDUSTRY CANADA NOTICE
This equipment complies with the limits of a
Class B digital device as specified in Industry
Canada regulations. These limits provide
reasonable protection against radio and TV
interference in residential areas. However,
this device might cause radio or TV
interference even when it is operating
properly.
Operation is subject to the following two
conditions: (1) This device may not cause
interference, and (2) this device must accept
any interference including interference that
may cause undesired operation of the device.
To eliminate the interference, you can try one
or more of the following:
• Reorient or relocate the receiving
antenna.
• Move your device away from the receiver.
• Connect your device to an outlet that is
on a different electrical circuit from the
receiver.
Contact your local electronic store for help
if the problem persists.
This digital apparatus does not exceed the
Class B limits for radio noise emissions from
digital apparatus.

10A03
4308995 Printed in China
CARE
Keep the station dry; if it gets wet, wipe it dry
immediately. Use and store the station only in
normal temperature environments. Handle the
station carefully; do not drop it. Keep the
station away from dust and dirt, and wipe it
with a damp cloth occasionally to keep it
looking new.
Modifying or tampering with the unit’s internal
components can cause a malfunction and
invalidate its warranty. If your unit is not
performing as it should, take it to your local
electronic store for assistance.
LIMITED WARRANTY
Who is Providing This Warranty?
• Orbyx Electronics, LLC (“Orbyx), as the distributor of this
Nexxtech product (your “Product”).
What Does This Warranty Cover?
• This warranty covers defects in materials or
workmanship in your Product under normal use and
conditions.
What is the Period of Coverage?
• This warranty covers your Product for 12 months from
the original purchase date.
Who Is Covered?
• This warranty covers the original consumer purchaser.
Coverage terminates if you sell or otherwise transfer
your Product.
What Will We Do To Correct Problems?
• We will repair your Product or replace your Product with
a new or reconditioned equivalent product, at our option.
How Do You Get Service?
• Call Orbyx TOLL FREE at 1-866-363-3059 for
instructions for obtaining warranty service from Orbyx’s
authorized service providers.
• Or, return your Product directly to the retail store from
which you purchased the Product.
• When you obtain service for your Product, you must
provide a purchase receipt (or other proof of the original
purchase date) and a description of the defect(s).
What Does This Warranty Not Cover?
• This warranty DOES NOT COVER:
• damage due to misuse, abuse, alteration, unauthorized
repair, or accident (such as improper electrical current);
• damage due to “acts of God” (such as lightning) or other
contingencies beyond our control;
• cosmetic damage;
• externally generated static, signal reception or antenna
problems not caused by your Product; or batteries.
• This warranty also DOES NOT COVER, and in no case
will we be liable for, any incidental damages (such as
transportation costs to and from an authorized service
provider, or loss of time) or consequential damages
(such as costs of repairing or replacing other property
which is damaged, including tapes, discs, speakers not
included with your Product or other accessories, or
external electrical systems) resulting from the use of
your Product. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
• Defacing the serial number, or using your Product for
commercial or institutional purposes, voids this warranty.
Are There Other Warranties?
• There are no express warranties other than those
expressed herein. Neither the sales personnel nor any
other person is authorized to make any other warranties
or to extend the duration of any warranties.
• ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY (AN
UNWRITTEN WARRANTY THAT A PRODUCT IS FIT
FOR ORDINARY USE), ARE LIMITED TO 90 DAYS.
Some states do not allow limitations on how long an
implied warranty lasts, so the above limitation may not
apply to you.
How Does State Law Apply?
• This warranty gives you specific legal rights, and you
may also have other rights which vary from state to
state.
ORBYX ELECTRONICS WARRANTY
ORBYX Electronics warrants that this product will be free
from defects in materials and workmanship for a period of
one (1) year from the date of purchase. Within this period,
simply take the product and your proof of purchase to any
ORBYX Electronics store or dealer and the product will be
repaired without charge for parts and labour. ORBYX
Electronics reserves the right to charge for transportation.
Any product which has been subject to misuse or
accidental damage is excluded from this warranty.
This warranty is only applicable to a product purchased
through ORBYX Electronics' company owned stores and
dealers and to a product that is presented for repair in a
country where ORBYX Electronics offers the product for
sale. While this warranty does not confer any legal rights
other than those set out above, you may have additional
statutory rights which will vary under the laws of the
various countries, states, province and other governmental
entities in which ORBYX Electronics operates. This
warranty is subject to all statutory rights you may have in
the country of purchase.
LIMITED WARRANTY
Distributed exclusively in the U.S. by
Orbyx Electronics, LLC
501 South Cheryl Lane,
Walnut, CA 91789
Imported in Canada for/Importé au Canada pour
Orbyx Electronics,
Concord, Canada, L4K 4M3
Manufactured in China
For parts, service, and general inquiries please call 1-866-363-3059
Limited Warranty/Garantie Limiteé
U.S.A & Canada
© 2004 ORBYX Electronics. All Rights Reserved.
