NexxTech 2516507 User manual

2516507
Flat Panel VGA Webcam
with Microphone
USER MANUAL

Contents
 Introduction …………………………………………………………………………………………………3
 System Requirements ………………………………………………………………………………….....3
 Package Contents …………………………………………………………………………………………3
 Webcam Introduction …………………………………………………………………………………….. 3
 Driver Installation ………………………………………………………………………………………… 4
 Software Installation ……………………………………………………………………………………… 4
Arcsoft Video Impression
Live Video Playing …………………………………………………………………………………………5
 Camera Specifications …………………………………………………………………………………… 5
 Warranty Information …………………………………………………………………………………….. 6
2

Introduction
Welcome to the world of digital imaging.The following information will help you use your camera to its full
capabilities.
For viewing pictures or video, camera must be connected to your personal computer.
System Requirements
• Personal computer, laptop, desktop, or IBM compatible with Pentium 166 MHz minimum, and with an
active USB(universal serial bus) port.
• Windows 98SE/ME/2000/XP, CD ROM drive, color monitor, mouse and keyboard.
• For transferring still images, or for video conference, your computer must have modem and
communication software for internet connection.
Package Contents
 PC Camera USB Cable CD-disc
Webcam Introduction
3
Snapshot Button
USB Cable
Viewfinder
LED
Clip
Lens

4
Driver Installation
• Insert CD-Disc and select your Camera
Driver.
• Click "Next".
• Select a setup type and click "Next".
• Click "Install".
• Click "Finish".
Software Installation
Arcsoft Video Impression 1.6
• Turn on computer and insert CD
Installation Disc into your CD-ROM drive.
• Select and click "Arcsoft Video Impression
1.6".
• Click "Next".
• Click "Yes".
• Click "Next".
• Click "Next".
• Click "Finish".

Live Video Playing
Arcsoft Video Impression 1.6
1. Click on the "Video Impression 1.6" icon on the desktop.
2. Click the "New" button.
3. Click "Capture".
4. Now you are playing the video.
Camera Specifications
Image Sensor  1/4" color progressive CMOS, 640 x 480 pixels,
10 bit RGB raw data
Sensitivity  2.5Lux@15fps
Lens Specification  F2.4, f=4.9mm, view angle 55˚
O/S Microsoft Windows 98SE/2000/ME/XP
White Balance  Auto
Exposure Control  Auto
Frame Rate VGA 640 x 480 pixels 15 fps
QVGA 320 x 240 pixels 30 fps
QQVGA160 x 120 pixels 30 fps
Focus Range  Manual focus, 1cm to infinity
Depth of Field  50mm to infinity
PC Interface  USB
Video Format  AVI
Audio Mic. built-in
Video Capture Res.  640 x 480 pixels,320 x 240pixels,160 x 120pixels
Snap Shot Hardware
Still Capture Res.  Up to 640 x 480 pixels
Flicker Control  50Hz, 60Hz
Power From USB port
Bundled Software  Arcsoft Video Impression 1.6
5
