USER GUIDE AND SPECIFICATIONS
NI CF-6004
This user guide describes how to use the National Instruments CF-6004
data acquisition (DAQ) device and lists specifications.
Introduction
The NI CF-6004 provides connection to four analog input (AI) channels
and four digital input/output (DIO) channels, with a type II CompactFlash
interface.
Figure 1. NI CF-6004
NI CF-6004
4-Ch. Input, 14-Bit,
Multifunction DAQ
INSERT CARD

NI CF-6004 User Guide and Specifications 2 ni.com
Figure 2. NI CF-6004 Installation
Safety Guidelines
Caution Operate the hardware only as described in these operating instructions.
The following section contains important safety information that you must
follow when installing and using the NI CF-6004.
Do not operate the NI CF-6004 in a manner not specified in this document.
Misuse of the device can result in a hazard. You can compromise the safety
protection built into the device if the device is damaged in any way. If the
device is damaged, contact National Instruments for repair.
Do not substitute parts or modify the device except as described in this
document. Use the device only with the chassis, modules, accessories, and
cables specified in the user guide. You must have all covers and filler panels
installed during operation of the device.
1 PDA with Type II CompactFlash Slot
2 NI CF-6004
3 I/O Cable
4 Accessory
5 Input/Output Cable
1
2
3
4
5

©National Instruments Corporation 3 NI CF-6004 User Guide and Specifications
Do not operate the device in an explosive atmosphere or where there may
be flammable gases or fumes. If you must operate the device in such an
environment, it must be in a suitably rated enclosure.
If you need to clean the device, use a dry cloth. Make sure that the device
is completely dry and free from contaminants before returning it to service.
Operate the device only at or below Pollution Degree 2. Pollution is foreign
matter in a solid, liquid, or gaseous state that can reduce dielectric strength
or surface resistivity. The following is a description of pollution degrees:
• Pollution Degree 1 means no pollution or only dry, nonconductive
pollution occurs. The pollution has no influence.
• Pollution Degree 2 means that only nonconductive pollution occurs in
most cases. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
• Pollution Degree 3 means that conductive pollution occurs, or dry,
nonconductive pollution occurs that becomes conductive due to
condensation.
You must insulate signal connections for the maximum voltage for which
the device is rated. Do not exceed the maximum ratings for the device.
Do not install wiring while the device is live with electrical signals. Do not
remove or add connector blocks when power is connected to the system.
Avoid contact between your body and the connector block signal when hot
swapping modules. Remove power from signal lines before connecting
them to or disconnecting them from the device.
Operate the device at or below the Measurement Category I1. Measurement
circuits are subjected to working voltages2and transient stresses
(overvoltage) from the circuit to which they are connected during
measurement or test. Measurement categories establish standard impulse
withstand voltage levels that commonly occur in electrical distribution
systems. The following is a description of measurement categories:
• Measurement Category I is for measurements performed on circuits
not directly connected to the electrical distribution system referred
to as MAINS3 voltage. This category is for measurements of
voltages from specially protected secondary circuits. Such voltage
measurements include signal levels, special equipment, limited-energy
parts of equipment, circuits powered by regulated low-voltage sources,
and electronics.
1 Measurement Category as defined in electrical safety standard IEC 61010-1. Measurement Category is also referred to as
Installation Category.
2 Working Voltage is the highest rms value of an AC or DC voltage that can occur across any particular insulation.
3 MAINS is defined as a hazardous live electrical supply system that powers equipment. Suitably rated measuring circuits may
be connected to the MAINS for measuring purposes.

NI CF-6004 User Guide and Specifications 4 ni.com
• Measurement Category II is for measurements performed on circuits
directly connected to the electrical distribution system. This category
refers to local-level electrical distribution, such as that provided by a
standard wall outlet (for example, 115 V for U.S. or 230 V for Europe).
Examples of Measurement Category II are measurements performed
on household appliances, portable tools, and similar devices.
• Measurement Category III is for measurements performed in the
building installation at the distribution level. This category refers to
measurements on hard-wired equipment such as equipment in fixed
installations, distribution boards, and circuit breakers. Other examples
are wiring, including cables, bus-bars, junction boxes, switches,
socket-outlets in the fixed installation, and stationary motors with
permanent connections to fixed installations.
• Measurement Category IV is for measurements performed at the
primary electrical supply installation (<1,000 V). Examples include
electricity meters and measurements on primary overcurrent
protection devices and on ripple control units.
Related Documentation
The following section lists documentation that is available for use with the
NI CF-6004.
NI-DAQmx Base (Linux/Mac OS X/LabVIEW PDA 8.x)
The NI-DAQmx Base Getting Started Guide describes how to install your
NI-DAQmx Base software, your NI-DAQmx Base-supported DAQ device,
and how to confirm that your device is operating properly. In Windows,
select Start»All Programs»National Instruments»NI-DAQmx Base»
Documentation»Getting Started Guide.
Getting Started with NI-DAQmx Base for Linux and Mac Users describes
how to install your NI-DAQmx Base software, your NI-DAQmx
Base-supported DAQ device, and how to confirm that your device is
operating properly on your Mac/Linux machine.
The NI-DAQmx Base Readme lists which devices are supported by this
version of NI-DAQmx Base. In Windows, select Start»All Programs»
National Instruments»NI-DAQmx Base»DAQmx Base Readme.
The NI-DAQmx Base VI Reference Help contains VI reference and
general information about measurement concepts. In LabVIEW, select
Help»NI-DAQmx Base VI Reference Help.

©National Instruments Corporation 5 NI CF-6004 User Guide and Specifications
The NI-DAQmx Base C Reference Help contains C reference and general
information about measurement concepts. In Windows, select Start»All
Programs»National Instruments»NI-DAQmx Base»Documentation»
C Function Reference Help.
Note All NI-DAQmx Base documentation for Linux is installed at /usr/local/
natinst/nidaqmxbase/documentation.
Note All NI-DAQmx Base documentation for Mac OS X is installed at
/Applications/National Instruments/NI-DAQmx Base/documentation.
Example Programs
The NI-DAQmx Base software ships with example programs you can use
to get started programming with the NI CF-6004. Refer to the NI-DAQmx
Base Getting Started Guide that shipped with your device, and is also
accessible from Start»All Programs»National Instruments»
NI-DAQmx Base»Documentation, for more information.
Note For information about non-Windows operating system support, refer to
ni.com/info and enter BaseGSGML.
Training Courses
If you need more help getting started developing an application with NI
products, NI offers training courses. To enroll in a course or obtain a
detailed course outline, refer to ni.com/training.
Technical Support on the Web
For additional support, refer to ni.com/support or zone.ni.com.
Installing the Software
Software support for the NI CF-6004 for Windows Vista/XP/2000 is
provided by NI-DAQmx Base.
Note For non-Windows operating support, refer to ni.com/info and enter BaseGSGML.

NI CF-6004 User Guide and Specifications 6 ni.com
Block Diagram
The following block diagram shows key functional components of the
NI CF-6004.
Figure 3. NI CF-6004 Device Block Diagram
Logic
CompactFlash Bus
+3.3V
FIFO
ADC AMP MUX
AI <0..3>
PFI <0..3>
15–Pin Connector

©National Instruments Corporation 7 NI CF-6004 User Guide and Specifications
I/O Connector
The NI CF-6004 is available with either a SH-15-15 DB-15 or a
SH-15-15-B bare-wire adapter cable. Additional accessories are available
for custom cable and DIN-rail applications. For more information, visit
ni.com.
Table 1 lists the terminal assignments for the SH-15-15 DB-15 adapter
cable.
Table 1. Terminal Assignments
Module Terminal Signal Wire Color
1AI GND White or Red
2AI 0 White/Black
3AI 1 Red/Black
4AI 2 Yellow/Black
5AI 3 Green/Black
6RSRVD Green or Blue
7RSRVD Blue/Black
8+3.3 V Brown/White
9NC —
10 D GND Orange or Gray
11 PFI 0 Orange/Black
12 PFI 1 Gray/Black
13 PFI 2 Purple/White
14 PFI 3 Pink/Black
15 D GND Purple or Pink
9
1
8
15

NI CF-6004 User Guide and Specifications 8 ni.com
Signal Descriptions
Table 2 describes the signals available on the I/O connectors.
Table 2. Signal Descriptions
Signal Name Reference Direction Description
AI GND — — Analog Ground—These terminals are
the reference point for single-ended AI
measurements. The AI GND and D GND
ground references are connected on the device.
AI <0..3> AI GND Input Analog Input Channels 0 to 3—For
single-ended measurements, each signal is an
analog input voltage channel.
+3.3 V D GND Output +3.3 V Power Source—Provides +3.3 V power
up to 10 mA.
D GND — — Digital Ground—D GND supplies the
reference for PFI <0..3> and +3.3 V. The
AI GND and D GND ground references are
connected on the device.
PFI <0..3> D GND Input or
Output
Programmable Function I/O or Digital
I/O—Each of these terminals are configurable
as a PFI terminal or a digital I/O terminal. You
can individually configure each digital I/O
signal as an input or output. You can configure
any of the terminals as a PFI input for a digital
AI trigger.

©National Instruments Corporation 9 NI CF-6004 User Guide and Specifications
Analog Input
You can connect analog input signals to the NI CF-6004 through the I/O
connector. Refer to Table 2 for more information about connecting analog
input signals.
Analog Input Circuitry
Figure 4 illustrates the analog input circuitry of the NI CF-6004.
Figure 4. Analog Input Circuitry
MUX
The NI CF-6004 has one analog-to-digital converter (ADC). The
multiplexer (MUX) routes one AI channel at a time to the ADC.
AMP
The amplifier provides an effective input gain of 1.
A/D Converter
The analog-to-digital converter (ADC) digitizes the AI signal by
converting the analog voltage into a digital code.
AI FIFO
The NI CF-6004 can perform both single and multiple A/D conversions of
a fixed or infinite number of samples. A first-in-first-out (FIFO) buffer
holds data during AI acquisitions to ensure that no data is lost.
AI
AMP AI FIFO
ADC
MUX

NI CF-6004 User Guide and Specifications 10 ni.com
Connecting Single-Ended Voltage Signals
To connect single-ended voltage signals to the NI CF-6004, connect the
positive voltage signal to the desired AI terminal, and the ground signal
to an AI GND terminal.
Figure 5. Connecting a Single-Ended Voltage Signal
Digital Trigger
When an AI task is defined, you can configure any one of the PFI inputs as
a digital trigger input. When the digital trigger is enabled, the AI task waits
for either a rising or falling edge on any PFI before starting the acquisition.
To use AI Start Trigger with a digital source, specify the desired PFI input
as the source and select the desired edge.
AI
+
–
Voltage
Source NI CF-6004
AI GND

©National Instruments Corporation 11 NI CF-6004 User Guide and Specifications
Digital I/O
The NI CF-6004 has four digital lines, PFI <0..3>, which comprise the DIO
port. GND is the ground-reference signal for the DIO port. You can
individually program all lines as inputs or outputs.
Digital I/O Circuitry
Figure 6 shows PFI <0..3> configured for digital input and digital output.
Digital input applications include receiving TTL signals and sensing
external device states, such as the state of the switch shown in Figure 6.
Digital output applications also include sending TTL signals and driving
external devices.
Figure 6. Example of Connecting a Load
Caution Exceeding the maximum input voltage ratings, which are listed in the
Specifications section, can damage the DAQ device and the computer. National
Instruments is not liable for any damage resulting from such signal connections.
TTL Signal
Switch
I/O Connector D GND
PFI <0..3>
+3.3V

NI CF-6004 User Guide and Specifications 12 ni.com
Source/Sink Info
The NI CF-6004 DIO ports are push-pull, allowing 3.3 V operation.
I/O Protection
To protect the NI CF-6004 against overvoltage, undervoltage, and
overcurrent conditions as well as ESD events, use the following guidelines:
• If you configure a DIO line as an output, do not connect it to any
external signal source, ground signal, or power supply.
• If you configure a DIO line as an output, understand the current
requirements of the load connected to these signals. Do not exceed
the specified current output limits of the DAQ device.
• If you configure a DIO line as an input, do not drive the line with
voltages outside of its normal operating range. The DIO lines have
a smaller operating range than the AI signals.
• Treat the DAQ device as you would treat any static-sensitive device.
Always properly ground yourself and the equipment when handling or
connecting to the DAQ device.
Power-On States
At system startup and reset, the hardware sets all DIO lines to
high-impedance inputs. The DAQ device does not drive the signal
high or low.
Static DIO
Each of the NI CF-6004 DIO lines can be used as a static DI or DO line.
You can use static DIO lines to monitor or control digital signals. All
samples of static DI lines and updates of DO lines are software-timed.
+3.3 V Power Source
The NI CF-6004 supplies a 3.3 V, 10 mA output. This source can be used
to power external components.

©National Instruments Corporation 13 NI CF-6004 User Guide and Specifications
Specifications
The following specifications are typical at 25 °C, unless otherwise noted.
Analog Input
Number of channels ............................... 4 single-ended
ADC type ............................................... Successive approximation
ADC resolution ...................................... 14 bits
DNL ....................................................... No missing codes
INL ......................................................... ±1 LSB
Sample rate (might be system-dependent)
Single-channel, finite acquisition
Up to 8 kS total, raw or
calibrated ................................. 200 kS/s
Up to 1 MS, raw data............... 200 kS/s
Multi-channel, finite acquisition
Up to 8 kS total, raw or
calibrated ................................. 132 kS/s, aggregate
Up to 1 MS total, raw data....... 132 kS/s, aggregate
Continuous acquisition, single- and multi-channel
Calibrated data, monitoring ..... 18 kS/s, typical
Calibrated data, graphing......... 1 kS/s, typical
Minimum hardware-timed .............. 195 S/s
Timing accuracy..................................... 50 ppm
Timing resolution................................... 78.125 ns
Settling time ........................................... 20 ppm at 7.6 μs, 0.1 Ωsource
impedance
Input coupling ........................................ DC
Input range ............................................. ±5 V
Maximum working voltage.................... ±5 V
Input impedance..................................... 100 MΩ, in parallel with 20 pF
Input bias current ................................... 75 pA

NI CF-6004 User Guide and Specifications 14 ni.com
Crosstalk (at 1 kHz)
Adjacent channels............................–104 dB typical
Non-adjacent channels.....................–104 dB typical
Small signal bandwith –3 dB..................497 kHz
System noise ...........................................0.75 LSBrms
Input FIFO size .......................................8,192 samples
Data transfers ..........................................Programmed I/O
Overvoltage protection ...........................±15 V
Input current during overvoltage
condition .................................................15.3 mA maximum
Accuracy over the operating range.........±3.1 mV typical,
±21 mV maximum
Calibration
Recommended warm-up time.................15 minutes
Calibration interval .................................1 year
Digital I/O
Number of channels................................4 lines, PFI <0..3>
Direction control.....................................Each channel individually
programmable as input or output
Output driver type...................................Push-pull
Compatibility ..........................................3.3 V LVCMOS and LVTTL
Power-on state ........................................Input (high-impedance)
Data transfers ..........................................Programmed I/O
Absolute maximum voltage range..........–0.5 V to 4 V

©National Instruments Corporation 15 NI CF-6004 User Guide and Specifications
Digital logic levels
External Voltage References
+3.3 V output (10 mA maximum) ......... 3.3 V typical, 2.97 V minimum
Power Requirements
+3.3 V from PDA host
Idle maximum ................................. 2 mA
Typical (continuous acquisition) .... 50 mA
Maximum (all outputs loaded)........ 68 mA
Physical Characteristics
Dimensions ............................................ Type II CompactFlash Card
I/O connectors ........................................ 15-pin
Weight.................................................... 9 g (0.3 oz)
Environmental
The NI CF-6004 device is intended for indoor use only.
Operating temperature
(IEC 60068-2-1 and IEC 60068-2-2) ..... 0 to 40 °C
Operating humidity
(IEC 60068-2-56)................................... 10 to 90% RH, noncondensing
Storage temperature
(IEC 60068-2-1 and IEC 60068-2-2) ..... –20 to 70 °C
Storage humidity
(IEC 60068-2-56)................................... 5 to 90% RH, noncondensing
Level Min Max Units
Input low voltage
Input high voltage
Input leakage current
–0.3
2
–1
0.8
3.9
1
V
V
μA
Output low voltage (I = 2 mA)
Output high voltage
(I = 2 mA)
—
2.5
0.8
—
V
V
Input current (0 < Vin < 3.3 V) –1 1 μA

NI CF-6004 User Guide and Specifications 16 ni.com
Maximum altitude...................................2,000 m (at 25 °C ambient
temperature)
Pollution Degree (IEC 60664) ................2
Safety
If you need to clean the module, wipe it with a dry towel.
Safety Voltages
Connect only voltages that are within the absolute maximum limits of the
connection point. Refer to the External Voltage References and Power
Requirements sections for the appropriate limits.
Safety Standards
The NI CF-6004 is designed to meet the requirements of the following
standards of safety for electrical equipment for measurement, control,
and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
Note For UL and other safety certifications, refer to the product label, or visit ni.com/
certification, search by model number or product line, and click the appropriate link
in the Certification column.
Hazardous Locations
The NI CF-6004 is not certified for use in hazardous locations.
Electromagnetic Compatibility
This product meets the essential requirements of the following standards
of EMC for electrical equipment for measurement, control, and laboratory
use:
• EN 61326 EMC requirements; Minimum Immunity
• EN 55011 Emissions; Group 1, Class A
• CE, C-Tick, ICES, and FCC Part 15 Emissions; Class A
Note For EMC compliance, operate this device with shielded cables.

©National Instruments Corporation 17 NI CF-6004 User Guide and Specifications
CE Compliance
This product meets the essential requirements of applicable European
Directives, as amended for CE marking, as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2004/108/EC; Electromagnetic Compatibility Directive (EMC)
Note Refer to the Declaration of Conformity (DoC) for this product for any additional
regulatory compliance information. To obtain the DoC for this product, visit ni.com/
certification, search by model number or product line, and click the appropriate link
in the Certification column.
Environmental Management
National Instruments is committed to designing and manufacturing
products in an environmentally responsible manner. NI recognizes that
eliminating certain hazardous substances from our products is beneficial
not only to the environment but also to NI customers.
For additional environmental information, refer to the NI and the
Environment Web page at ni.com/environment. This page contains
the environmental regulations and directives with which NI complies, as
well as other environmental information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of their life cycle, all products must be sent to a WEEE recycling
center. For more information about WEEE recycling centers and National Instruments
WEEE initiatives, visit ni.com/environment/weee.htm.
⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ ˄Ё೑
RoHS
˅
Ё೑ᅶ᠋
National Instruments ヺড়Ё೑⬉ᄤֵᙃѻકЁ䰤ࠊՓ⫼ᶤѯ᳝ᆇ⠽䋼ᣛҸ (RoHS)DŽ
݇Ѣ National Instruments Ё೑ RoHS ড়㾘ᗻֵᙃˈ䇋ⱏᔩ ni.com/environment/rohs_chinaDŽ
(For information about China RoHS compliance, go to ni.com/environment/rohs_china.)

National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation.
Refer to the Terms of Use section on ni.com/legal for more information about National
Instruments trademarks. Other product and company names mentioned herein are trademarks or trade
names of their respective companies. For patents covering National Instruments products, refer to the
appropriate location: Help»Patents in your software, the patents.txt file on your CD, or
ni.com/patents.
© 2005–2007 National Instruments Corporation. All rights reserved. 371399C-01 Dec07
Where to Go for Support
The National Instruments Web site is your complete resource for technical
support. At ni.com/support you have access to everything from
troubleshooting and application development self-help resources to email
and phone assistance from NI Application Engineers.
National Instruments corporate headquarters is located at
11500 North Mopac Expressway, Austin, Texas, 78759-3504.
National Instruments also has offices located around the world to help
address your support needs. For telephone support in the United States,
create your service request at ni.com/support and follow the calling
instructions or dial 512 795 8248. For telephone support outside the United
States, contact your local branch office:
Australia 1800 300 800, Austria 43 662 457990-0,
Belgium 32 (0) 2 757 0020, Brazil 55 11 3262 3599,
Canada 800 433 3488, China 86 21 5050 9800,
Czech Republic 420 224 235 774, Denmark 45 45 76 26 00,
Finland 358 (0) 9 725 72511, France 01 57 66 24 24,
Germany 49 89 7413130, India 91 80 41190000, Israel 972 3 6393737,
Italy 39 02 41309277, Japan 0120-527196, Korea 82 02 3451 3400,
Lebanon 961 (0) 1 33 28 28, Malaysia 1800 887710,
Mexico 01 800 010 0793, Netherlands 31 (0) 348 433 466,
New Zealand 0800 553 322, Norway 47 (0) 66 90 76 60,
Poland 48 22 3390150, Portugal 351 210 311 210, Russia 7 495 783 6851,
Singapore 1800 226 5886, Slovenia 386 3 425 42 00,
South Africa 27 0 11 805 8197, Spain 34 91 640 0085,
Sweden 46 (0) 8 587 895 00, Switzerland 41 56 2005151,
Taiwan 886 02 2377 2222, Thailand 662 278 6777,
Turkey 90 212 279 3031, United Kingdom 44 (0) 1635 523545
