GETTING STARTED GUIDE
PXIe-8267
4-Drive, In-Chassis High-Speed Data Storage Module
This document explains how to install and configure the PXIe-8267. For more information
about configuring, using, and maintaining the PXIe-8267, refer to ni.com.
Note The standard NI warranty does not apply to the PXIe-8267. To view warranty
and services information for the PXIe-8267, go to ni.com/info and enter the Info
Code raidsupport.
Note The PXIe-8267 requires a chassis with slot cooling capacity ≥ 58 W.
Contents
Installation and Configuration.................................................................................................. 1
What You Need to Get Started..........................................................................................1
Unpacking......................................................................................................................... 2
Preparing the Environment............................................................................................... 2
Hardware Installation........................................................................................................3
Software/Driver Installation..............................................................................................4
RAID Creation.................................................................................................................. 4
Moving the PXIe-8267 to a Different System.................................................................. 8
Optimizing Streaming Performance..................................................................................9
NI Services..............................................................................................................................10
Installation and Configuration
This section explains how to unpack, install, and configure the PXIe-8267 hardware and
software.
What You Need to Get Started
The PXIe-8267 kit contains the following items:
• PXIe-8267 module
• PXIe-8267 documentation
Note The device kit does not include driver media. Refer to the Software/Driver
Installation section for information about installing the drivers.

Unpacking
Note To prevent electrostatic discharge (ESD) from damaging the device, ground
yourself using a grounding strap or by holding a grounded object, such as your
computer chassis.
1. Carefully inspect the shipping container and the PXIe-8267 for damage.
2. Check for visible damage to the metal work.
Note Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Check to make sure all hardware is undamaged.
If damage appears to have been caused during shipment, file a claim with the carrier.
Retain the packing material for possible inspection and/or reshipment.
4. Unpack any other items and documentation from the kit.
Preparing the Environment
Ensure the environment in which you are using the PXIe-8267 meets the following
specifications.
Temperature
Operating 0 °C to 55 °C1 (Tested in accordance with
IEC-60068-2-1 and IEC-60068-2-2. Meets
MIL-PRF-28800F Class 3 low temperature
limit and MIL-PRF-28800F Class 2 high
temperature limit.)
Storage2-40 °C to 71 °C (Tested in accordance with
IEC-60068-2-1 and IEC-60068-2-2; meets
MIL-PRF-28800F Class 3 limits.)
1The PXIe-8267 requires a chassis with slot cooling capacity ≥58 W. Not all chassis with slot
cooling capacity ≥58 W can achieve this ambient temperature range. Refer to the PXI Chassis
Manual for specifications to determine the ambient temperature ranges your chassis can achieve.
2Drive utilization and storage temperatures will have an impact on unpowered data retention. Visit
ni.com/info and enter the Info Code ssdtemp for more information about the impact of
temperature on drive endurance.
2| ni.com | PXIe-8267 Getting Started Guide

Humidity
Operating 10% to 90% noncondensing (Tested in
accordance with IEC-60068-2-78.)
Storage 5% to 95% noncondensing (Tested in
accordance with IEC-60068-2-78.)
Pollution Degree 2
Maximum altitude 2,000 m (800 mbar)
Indoor use only.
Note For complete specifications, refer to the PXIe-8267 Specifications at ni.com/
manuals.
Note For more information about thermal considerations, go to ni.com/info and
enter the Info Code raidsupport.
Hardware Installation
Note Before you begin, install and configure your chassis and controller.
Caution To protect both yourself and the chassis from electrical hazards, leave the
chassis off until you finish installing the PXIe-8267.
Attention Pour vous protéger, et protéger le châssis, contre les risques électriques,
laissez le châssis éteint tant que vous n'avez pas terminé l'installation du PXIe-8267.
1. Power off your PXI Express chassis, but leave it plugged in while installing the
PXIe-8267. The power cord grounds the chassis and protects it from electrical damage
while you install the module.
2. Locate an available PXI Express slot in the chassis. Do not install the PXIe-8267 in the
controller slot (slot 1 in a PXI Express chassis).
3. Remove or open any doors or covers blocking access to the slot in which you intend to
install the PXIe-8267.
4. Touch the metal part of the case to discharge any static electricity that might be on your
clothes or body.
5. Make sure the injector/ejector handle is in its downward position. Be sure to remove all
connector packaging and protective caps from retaining screws on the module. Align the
PXIe-8267 with the card guides on the top and bottom of the selected slot.
Note Do not raise the injector/ejector handle as you insert the PXIe-8267. It
will not insert properly unless the handle is in its downward position so that it
does not interfere with the injector/ejector rail on the chassis.
6. Hold the handle as you slowly slide the module into the chassis until the handle catches
on the injector/ejector rail.
PXIe-8267 Getting Started Guide | © National Instruments Corporation | 3

7. Raise the injector/ejector handle until the module firmly seats into the backplane
receptacle connectors. The front panel of the PXIe-8267 should be even with the front
panel of the chassis.
8. Tighten the bracket-retaining screws on the top and bottom of the front panel to secure
the PXIe-8267 to the chassis.
9. Replace or close any doors or covers to the chassis.
LED Indicators
The following table describes the PXIe-8267 front panel LEDs.
LED Color Meaning
Pwr/Fault Off Power is off
Blinking red Power is out of spec
Green Power is on
Drive 1 through Drive 4 Off 3No drive activity
Blinking green Drive activity
Green No drive activity
Software/Driver Installation
The PXIe-8267 does not include interface software to configure the RAID. You must use the
Disk Management Utility in Windows to manage the software RAID.
Note The PXIe-8267 supports only Windows 10 (64-bit).
Note Refer to the drive manufacturer's website for information regarding
monitoring drive temperatures.
No driver is necessary to configure the drives. The Standard Microsoft NVME driver is pre-
installed in Windows 10.
RAID Creation
To configure the software RAID on the PXIe-8267, complete the following steps.
Note Back up your data before you configure the software RAID.
Note In the following steps, the disk drive capacities in the images are examples.
You may see different capacities depending on your disk drives.
3Drive manufacturers define the optional drive activity signal in different ways. Some
manufacturers unassert the activity signal when there is no drive activity, with LEDs off, while
others assert the signal, with LEDs on.
4| ni.com | PXIe-8267 Getting Started Guide

1. Right-click My Computer and click Manage.
2. Click Disk Management in the left window. You should see four disk drives of the same
size in basic mode. If the disks do not have a status of Unallocated, right-click any disk
and select Delete Partition.
3. Right-click any disk and select New Striped Volume, then click Next.
4. Click Add until all available disks are moved to the Selected window and click Next.
PXIe-8267 Getting Started Guide | © National Instruments Corporation | 5

5. Assign a drive letter and click Next.
6. Configure the Format Volume page as shown in the following figure and click Next.
6| ni.com | PXIe-8267 Getting Started Guide

7. Click Finish to close the New Striped Volume Wizard.
8. If the disks were configured in basic mode, click Yes in the Disk Management dialog box
to convert them to dynamic mode.
Note You must convert all disks that you want to include in the RAID array to
dynamic mode.
PXIe-8267 Getting Started Guide | © National Instruments Corporation | 7

Moving the PXIe-8267 to a Different System
Complete the following steps to move your PXIe-8267 to a different system or chassis with a
different controller.
Note The following steps apply only if the PXIe-8267 you are moving to a
different system is in software RAID mode.
Note To avoid data loss, do not move, swap, or replace the drives.
1. When the system boots, go into Disk Management. You will see four dynamic disks
with yellow caution icons. Right-click any disk with a caution icon and select Import
Foreign Disks.
2. Be sure the Foreign disk group (4 of 4 disks) checkbox is enabled and click OK.
8| ni.com | PXIe-8267 Getting Started Guide

3. You may see the following dialog box if a RAID volume was present on the PXIe-8267
before you moved it to the new system. Click OK to allow the new system to import the
RAID volume. The initial data is preserved and will be readable in the new system.
4. Your RAID drive is now ready for use in the new system.
Optimizing Streaming Performance
Note NI recommends periodically checking drive life and using software to
monitor the drive for errors, thermal events, TBW, and so on. For more information,
go to ni.com/info and enter the Info Code raidsupport.
Note If the PXIe-8267 throughput is underperforming, complete the following
steps to optimize the drives manually.
1. Back up your data before performing this operation.
2. Delete the striped array and individually partition, format, and assign a letter to
the drives.
PXIe-8267 Getting Started Guide | © National Instruments Corporation | 9

3. In the Windows taskbar, search for the Defragment and Optimize Drives tool
and optimize the drives.
4. When the operation completes, recreate the striped array.
