Nice FIBARO YH-001 User manual

v1.0
USER MANUAL
YH-001
HC3-001
HC3L-001

3
TABLE OF CONTENTS
1: Important safety information 5
2: Installation 6
2.1: Connecting the gateway using Wi-Fi 6
2.2: Accessing configuration interface 6
3: Adding Z-Wave™ devices 7
3.1: Adding using Inclusion Mode 7
3.2: Adding using SmartStart 8
4: Removing Z-Wave devices 9
4.1: Removing devices using Exclusion Mode 9
4.2: Removing failed nodes 9
5: Managing Provisioning List 10
5.1: Adding devices to Provisioning List 10
5.2: Editing devices in Provisioning List 10
5.3: Removing devices from Provisioning List 10
6: Managing devices 11
6.1: Controlling and checking state of devices 11
6.2: Configuring devices 11
6.3: Identifying devices 11
6.4: Viewing events history 12
6.5: Performing actions on devices with specific command classes 12
7: Z-Wave Associations 15
7.1: Creating associations 15
7.2: Deleting associations 15
8: Rediscovering Z-Wave devices 16
9: Connecting with existing Z-Wave network 17
9.1: Adding/removing to/from existing Z-Wave network 17
9.2: Copying network information between controllers 17
9.3: DSK and PIN 18
10: Resetting to factory defaults 19
10.1: Resetting system to factory defaults 19
10.2: Resetting Z-Wave to factory defaults 19

4
11: Updating firmware 20
11.1: Updating firmware of gateway 20
11.2: Updating firmware of Z-Wave devices 20
12: Z-Wave specification 21
12.1: Supported command classes 21
12.2: Controlled command classes 22
12.3: Basic Command Class 23
12.4: Security Command Class 23
12.5: Association Command Class 23
12.6: Indicator Command Class 24

5
Important safety InformatIon
1: IMPORTANT SAFETY INFORMATION
Read this manual carefully before
installing and operating the product.
!Warning!
• The manufacturer will not be held responsible for any loss or damage
resulting from not following the instructions. Store this manual in a
secure place for future reference.
• This product is not a toy. Keep away from children and animals.
• When wall-mounted, do not place the product higher than 2 meters
from the floor.
!Caution!
• Do not attempt to disassemble, repair or modify this product yourself.
Any repair should be performed only by an authorized FIBARO service.
• This product is designed for indoor use only. Do not use outside!
• Do not expose this product to moisture, water, or other liquids. Never
place any water carrying vessels near the product.
• Do not use the product outside of the recommended temperature and
humidity ranges.
• Keep the product away from heat sources and do not place under
direct sunlight.
• Do not cover or place anything on the product.
• Do not connect cable longer than 3 meters to the USB port.
• Do not place the product in metal boxes or on metal surfaces for best
radio performance.

6
InstallatIon
2: INSTALLATION
2.1: CONNECTING THE GATEWAY USING WI-FI
1. Plug the provided power adapter into an outlet and connect it to the
gateway.
2. The gateway will turn on, wait for the indicator to turn solid red.
3. Connect your computer to Wi-Fi network created by the gateway. You
will find Wi-Fi SSID (name) and password on the bottom of the device.
2.2: ACCESSING CONFIGURATION INTERFACE
1. Go to find.fibaro.com.
2. Choose your language.
3. Log in with default credentials:
• Login: admin
• Password: admin
4. Configure the gateway by following steps in the Configuration
Interface.
Remember: connect the gateway to your home Wi-Fi network after
finishing the configuration.

7
addIng Z-Wave™ devIces
3: ADDING Z-WAVE™ DEVICES
3.1: ADDING USING INCLUSION MODE
To add the device to the Z-Wave network manually:
1. Open the Configuration Interface.
2. Go to > Devices.
3. Click .
4. Select Z-Wave Device.
5. There are few available settings:
• NWI - Network-Wide Inclusion – enabling allows for adding devic-
es outside the direct range of the gateway,
• Add in S2 Security mode if device supports it,
• Allow inclusion only in near proximity (less than 2 meters).
6. Click Start adding.
7. Follow adding procedure for the device you want to add (according to
its manual).
8. If you are adding in Security S2 Authenticated and the device is not on
the Provisioning List (see chapter 5 on page 10):
Input the PIN code (the underlined part of the DSK) and click Send.
9. The device will be added within few minutes.

8
addIng Z-Wave™ devIces
3.2: ADDING USING SMARTSTART
SmartStart enabled devices can be added into a Z-Wave network by
entering the Z-Wave DSK Code present on the product. The devices will
be automatically added to the Z-Wave network using secure connection
encrypted with Z-Wave S2 security framework.
To add the device to the Z-Wave network using SmartStart:
1. Open the Configuration Interface.
2. Go to > Z-Wave > Smart Start.
3. Click Add DSK.
4. Enter the full DSK string code you have received with your device.
5. For advanced users: In Choose Security levels select which Security
keys will be granted to the joining node (available: S2 Unauthenticated,
S2 Authenticated, S2 Access Control, S0).
6. Leave the Only S2 classic inclusion unchecked.
7. Power the device and it will be added automatically within 10 minutes.

9
removIng Z-Wave devIces
4: REMOVING Z-WAVE DEVICES
4.1: REMOVING DEVICES USING EXCLUSION MODE
To remove the device from the this or other Z-Wave network:
1. Open the Configuration Interface.
2. Go to > Devices.
3. Click .
4. Select Z-Wave Device.
5. Follow removing procedure on the device (according to its manual).
4.2: REMOVING FAILED NODES
To remove the device from the Z-Wave network if it is not responding:
1. Open the Configuration Interface.
2. Go to > Devices.
3. Go to Z-Wave tab.
4. Click next to the device you want to force remove.
5. Click Force remove.

10
managIng provIsIonIng lIst
5: MANAGING PROVISIONING LIST
The Provision List is used to add Z-Wave devices using SmartStart or
bootstrap classic S2 inclusion.
5.1: ADDING DEVICES TO PROVISIONING LIST
1. Open the Configuration Interface.
2. Go to > Z-Wave > Smart Start.
3. Click Add DSK.
4. Enter the full DSK string code you have received with your device.
5. For advanced users: In Choose Security levels select which Security
keys will be granted to the joining node (available: S2 Unauthenticated,
S2 Authenticated, S2 Access Control, S0).
6. If the device should not be automatically included when powered, but
only after the classic inclusion, check the Only S2 classic inclusion
setting.
7. Click Add.
5.2: EDITING DEVICES IN PROVISIONING LIST
1. Open the Configuration Interface.
2. Go to > Z-Wave > Smart Start.
3. Click next to the device you want to edit.
4. You can change the Security levels.
5. Save.
5.3: REMOVING DEVICES FROM PROVISIONING LIST
1. Open the Configuration Interface.
2. Go to > Z-Wave > Smart Start.
3. Click next to the device you want to remove.
4. Click Delete.
5. The device will be removed from the list, but if it was already added to
the Z-Wave network, you must perform standard removing procedure
or reset the device.
