Nikon N Series User manual

Version: 2.00
May 2020
Part Number: 121910-01
N SERIES/K SERIES TOTAL STATION
QUICK START GUIDE

2
Item Description Item Description
1Carrying handle 14 Horizontal tangent screw
2Optical sight (Finder) 15 CFR label
3Telescope focusing ring 16 Laser Safety label
4Telescope eyepiece 17 Objective lens
CCAUTION: Laser light is emitted from this part
5Diopter ring 18 Face-2 display/keyboard (for N 2"/K 2")
6Reticle plate cover 19 EAC label
7Face-1 display/keyboard 20 Data output/Input connector
CCAUTION: Input voltage shall be 4.5 to 5.2 V DC
8FCC label 21 Trunnion axis indication mark
Tapping point for NFC
9Tribrach clamp knob 22 Optical plummet
10 Battery case mounting button 23 Circular level
11 Vertical tangent screw 24 Leveling screw
12 Vertical clamp 25 Tribrach
13 Horizontal clamp
Face 1 Face 2
1
2
3
4
5
6
7
15
10
13
14
11
12
17
16
21
8
18
20
22
23
24
25
9
19

3
Standard components
• Instrument main body
• Battery pack
• Battery charger U-120
• Adjustment pin, Allen wrench
• Objective lens cap
• Vinyl rain/dust cover
• Carrying case
• Shoulder strap
Charging the battery pack
CWARNING: Before charging or connecting the battery pack, please refer to the battery safety
information in the Nikon N Series/K Series Total Station Instruction Manual.
The battery pack is supplied partly charged. Before using it for the first time, charge the battery pack
completely.
Connect the charger to the USB bus with the supplied USB cable. The power input must be 5 V with at
least 1 A of current capability.
Note – A USB AC adapter is not included. Please prepare an appropriate one. USB PD (Power Delivery) AC
adapters cannot be used.
Inserting the battery pack
Before inserting the battery pack, clear any dust or other foreign particles from the battery contacts.
1. Hold the instrument steady with one hand.
2. Fit the two projections at the bottom of the battery
case into the concave sections at the bottom of the
instrument.
3. Press the battery case mounting button.
4. Push the battery pack against the instrument and
release the battery case mounting button. Ensure that
the battery case mounting button is fully released and
the battery pack is securely attached to the instrument.
CCAUTION: If the battery box cover is not closed,
this could adversely affect the watertightness of the
instrument.
Orange indicator
Green indicator
USB Type C connnector

© 2020, Trimble Inc. All rights reserved. Trimble is a trademark of
Trimble Inc. registered in the United States Patent and Trademark Office
and other countries. Nikon is a registered trademark of Nikon. All other
trademarks are the property of their respective owners. Version 2.00.
May 2020. P/N 121910-01.
Spectra Geospatial
10368 Westmoor Dr.
Westminster, CO, 80021
USA
www.spectrageospatial.com
N SERIES/K SERIES TOTAL STATION
QUICK START GUIDE
Safety information
Models N 2" and N 5" are a CLASS 2 LASER PRODUCT and Models K 2" and K 5" are a CLASS 1 LASER
PRODUCT in accordance with IEC 60825-1:2014: “Safety of Laser Product”.
Precautions: To counteract hazards, it is essential for all users to pay careful attention to the safety
precautions and control measures specified in the standard IEC60825-1:2014. For further information,
please refer to the Nikon N Series/K Series Total Station Instruction Manual.
Note – This product complies with IEC 60825-1:2014 and IEC 60825-1:2007 and 21 CFR 1040.10 and
1040.11 except for deviations pursuant to Laser Notice no. 50, dated June 24, 2007.
CWARNING: Only qualified and trained persons should be assigned to install, adjust and operate the
laser equipment.
CWARNING: Precautions should be taken to ensure that persons do not look directly, with or without an
optical instrument, into the beam.
CWARNING: Laser beam path should be located well above or below eye level wherever practicable.
Table 1.1 Specifications for laser emission
Laser pointer Class 2 (only applies to Nikon N models)
Wave length
Output power
630-680 nm
CW Po ≤ 1 mW
Distance meter Class 1
Wave length
Output power
Pulse width
850-890 nm
Pulse Po ≤ 22 W
< 5 ns
Table 1.2 Conforming standards
E.U. IEC60825-1:2014
Laser pointer: Class 2 (only applies to Nikon N models)
Distance meter: Class 1
USA FDA21CFR Part 1040 Sec.1040.10 and 1040.11
(except for deviations pursuant to Laser Notice No.50, dated June 24, 2007)
For details regarding the features and operations of this instrument, and to access the latest information
including instruction manuals and application software, please go to www.spectrageospatial.com.
