Niles ZR-4 SERIES User manual

INCLUDES:
• ZR-4 SERIES 2 OVERVIEW
• ZR-4 SERIES 2 SYSTEM APPLICATIONS
ZR-4 SERIES 2 MULTIZONE RECEIVER KIT
SYSTEM DESIGN GUIDE
NILES AUDIO CORPORATION

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 2
ZR-4 SERIES 2 MULTIZONE RECEIVER KITS APPLICATION NOTES
The ZR-4 Series 2 Four-Source, Four-Zone MultiZone Receiver
Kit delivers unparalleled features and quality at an affordable
price. It is the perfect home entertainment solution for the light-
commercial, multiple dwelling unit (MDU), and starter home
markets. The ZR-4 Series 2 comes packaged as a complete kit
and includes everything needed to install the system; you just
supply the loudspeakers and the wire. The ZR-4 Series 2 takes
care of everything else: the MultiZone receiver, four weather-
resistant keypads, a hand-held IR learning remote control, and
three IR MicroFlashers®to control connected components. The
ZR-4 is easy to install and requires virtually no programming, so
you’ll have the system up and running in record time.
ZR-4 SERIES 2 MULTIZONE RECEIVER
The ZR-4 Series 2 has features usually reserved for higher-end
MultiZone receivers. These features include a built-in digital
AM/FM tuner allowing the ZR-4 Series 2 to play music right out
of the box without any additional components or wiring. An
advanced digital power amplier delivers eight channels of
robust power (40 watts per zone/20 watts per channel). This
amplier is capable of driving a 4-ohm load, and now features
an enhanced power supply and fan-cooled circuitry. The ZR-4
Series 2 was designed as a four-zone receiver, but if you need
even more zones, the Expansion Port enables you to add
another ZR-4 Series 2 to quickly create an eight-zone system.
SOLO®-4IR KEYPADS
The Solo-4IR is a single-gang keypad with a built-in IR sensor
that offers convenient, basic control for the ZR-4’s built-in tuner
and up to three additional sources. The keypad includes source
selection, local zone volume control, muting, and zone turn off.
In addition, simply pressing and holding the Off key can turn off
the entire system. The sources can be custom labeled to match
the system using the laser-etched Master Keys provided with
each keypad. The keypads are elegantly designed with recently
improved nish and come in white. Color change kits are
available in light almond, bone, and black. But what makes the
Solo-4IR truly unique is its weather-resistant design, making it
possible to install keypads in bathrooms, saunas, or even in
covered outdoor areas like patios. Built into each Solo-4IR is a
plasma and LCD-proof IR sensor for the ZR-4’s included R-6L
hand-held IR learning remote and almost any other IR remote
control. This allows activation and control of sources from
across the room. All Solo-4IR keypads are compatible with both
the original ZR-4 and the ZR-4 Series 2.
R-6L HAND-HELD IR LEARNING REMOTE
This versatile remote provides advanced, automated control of
all four of the ZR-4 Series 2’s sources, as well as a local TV and
an additional local source such as a DVD player or satellite
receiver. The R-6L can create IR macros and comes preloaded
with a library of IR commands for both the ZR-4 Series 2 as well
as many popular brands of equipment. It also learns IR
commands directly from factory remote controls.
OVERVIEW: ZR-4 SERIES 2 MULTIZONE RECEIVER KIT
ZR-4 Series 2
FG01610
4 Source, 4 Zone MultiZone
Receiver Kit with AM/FM Tuner
and Weather-Resistant Keypads
ZR-
4 S
eri
i
es
2
FG01610
4
S
ource
,
4 Zone MultiZo
ne
R
ece
iv
e
r Kit with AM
/
FM T
u
n
e
r
and
Weat
her-
Resi
stan
t Ke
ypad
s
Z
F

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 3
BUILT-IN AM/FM TUNER
The ZR-4 Series 2 features a built-in digital AM/FM tuner with 20
preset stations that can now be easily modied. There is no
need for any additional components or wiring to receive quality
radio programming.
4-OHM STABLE DIGITAL AMPLIFIER
The advanced digital power amplier delivers 20 watts per
channel and now features an enhanced power supply and fan-
cooled circuitry. The ZR-4 Series 2 can comfortably drive two
pairs of 8-ohm speakers per zone.
WEATHER-RESISTANT KEYPADS
Install the Solo-4IR keypads wherever your customer desires,
even in wet areas such as bathrooms, saunas, outdoor patios
and near pools. The keypad meets the requirements of the IEC
60529, IP 54 standard, guaranteeing continued performance.
RS-232 AND DISCRETE IR CONTROL
FOR EACH ZONE
Control the ZR-4 with third-party control systems using RS-232
control protocols and/or infrared commands.
ZONE 4 PREAMP OUTPUT
Connect an external amplier to provide more power for a large
area such as a patio, or for a zone where higher than normal
volume levels are desired. The Zone 4 preamp output can be
switched for xed or variable levels.
12V CONTROL OUTPUT
Automate power turn-on and turn-off of connected components
such as a Niles AC-3 Voltage Triggered AC Power Strip, or
trigger a Systems Integration Amplier®to turn on when any
zone is activated.
PAGING INPUT
Connect a telephone system and/or doorbell to provide paging
throughout the home. Overrides all other inputs and can be
congured to work in any number of zones.
PARTY MODE
The Party Mode turns on all zones (or a pre-congured number
of zones) to play the same source of music, instantly lling the
house with music.
HOME THEATER SYNC
The ZR-4 can share source components with an independent
home theater system. When the home theater receiver is on, the
ZR-4 will stay active (even if all zones are turned off) and will
continue to execute the appropriate 12V and IR functions.
KEYPAD COLOR OPTIONS
The Solo-4IR Keypads included in the ZR-4 kit come in white.
Optional color change kits are available in light almond, bone,
and black. For more info, visit: www.nilesaudio.com
OVERVIEW: ZR-4 SERIES 2 KEY FEATURES
Simple, scalable
system expansion
Home theater integration
with source sharing
capability
Audio
paging
input
Discrete IR control
for each individual zone
RS-232
control
Built-in
AM/FM
tuner
Independent bass, treble
and variable loudness
controls for each zone Robust power
supply ensures ideal
performance under
the most demanding
circumstances
Advanced digital power
amplier design that’s
stable to 4 ohm and delivers
superior sound quality

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 4
WHAT DOES THIS APPLICATION DO?
This application distributes four audio sources (including the ZR-4 Series 2’s built-in AM/FM tuner) to four zones.
DO THIS FIRST Review the ZR-4 Series 2 Overview
CRITICAL KNOWLEDGE
When installing the Solo4-IR into a
“wet” environment, the unit must have
a complete “positive” seal with the
mounting surface. This is achieved
by using silicone caulking on the
gap around the Decora®style insert
and then installing the wall plate to
complete the seal.
Since the ZR-4 Series 2 does not
include the ability to manage the
power of connected sources, it is
recommended that you use one of
these power management options:
• If the source has latching power
(mechanical power button), use the
Niles AC-3 (FG00242) to manage
power to this device. This type of
source normally has an “automatic
play” feature, which is also required.
• If source has non-latching power,
then use an R-6L (FG01446) at each
keypad location. The R-6L can be
programmed to accomplish the
following sequence:
1. Issue source ON command
2. Issue zone ON command
3. Issue PLAY command or favorite
channel sequence
APPLICATION: STAND-ALONE ZR-4 SERIES 2 MULTIZONE RECEIVER KIT
The ZR-4 Series 2 has a built-in tuner and
can accommodate 3 additional sources.
Each zone can have up to 2 keypads by
using a ZR-KE keypad expander.
GLOBAL FEATURES INCLUDE:
• Party Mode – Press-and-hold a
source button and all pre-configured
zones will turn on to play that source.
•
Paging – Allows front and rear door
doorbell chimes from the Niles DBI-1 or
paging from a phone system, or both,
to be heard through the speakers in
pre-configured zones. The zones of
the ZR-4 that are on will mute so the
doorbell/page can be heard. The zones
that were off will turn on so the doorbell/
page can be heard. When the page
is completed, zones that were on will
automatically begin playing music again
and the zones that were off will again
turn off.
• Zone Linking – Zones can be
“linked” together so that they always
play the same source while retaining
independent volume adjustment. Only
one linked group per chassis.
• All Zones Off – Press-and-hold the
Off button to turn off all zones.
ZONE FEATURES INCLUDE:
• Weather-Resistant Keypads – The
Solo-4IR keypad is weather-resistant
and can be mounted in wet areas such
as outdoors, by showers, and saunas.
When installing in these areas, special
installation techniques are required. See
the critical knowledge section.
•
Bass, Treble, and Variable
Loudness Adjustment – Each
zone can have its own custom tailored
sound.
•
IR Sensor On/Off – The built-in IR
sensor in each keypad can be turned
off. It may be necessary to disable the
IR sensor if the keypad is exposed to
direct sunlight.
ADDING A SEPARATE IR SENSOR
When adding a separate IR sensor in a
zone you must:
• Add a separate IR repeater system and
route the data and ground to the Global
IR input.
• Teach discrete zone commands into the
R-6L from an IR-CS capture station, an
IntelliFile®3 capture station, or a third
party remote.
ZONE CONTROL
The included Solo-4IR keypads offer basic
system operation (e.g. source selection,
volume +/-, etc.). Preset stations on the
tuner can be advanced by pressing the
Radio key when the radio is playing. For
more advanced control, the customer
will need an R-6L remote control in
each zone to activate sources and for
transport control (e.g. power, play, stop,
track +/-, etc.). Source activation can be
programmed into a sequence on the R-6L.
Key Considerations
Customer Benets
The ZR-4 Series 2 is an inexpensive
solution that allows your customer to
choose up to 4 independent sources,
including the built-in AM/FM tuner, for up
to 8 areas of the house that are controlled
via simple keypads or a remote control.
They also can access features such as
“Party Mode” which allows a source to be
activated in pre-selected zones, and “All
Off” which allows the customer to shut off
the system from any keypad location.
Installation Benets
The ZR-4 Series 2 gives you a cost
effective solution to replace speaker
selectors, volume controls, and IR
systems with a 4-source, up to 8 zone
MultiZone receiver (built-in tuner) in an
extremely small footprint (1U rackspace
high). Each zone can have its sound
custom tailored through the use of zone
independent bass, treble, and variable
loudness.
INSTALLATION REQUIREMENTS
All CAT-5 wiring must be terminated
using the T568A wiring convention.
Steps required to configure a ZR-4
Series 2 Kit:
1. Set tuner presets
2. Configure unit via front panel display
3. Set bass, treble, variable loudness,
and IR sensor on/off for each zone
from keypad
4. Program all R-6L remotes

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 5
AC-3
CABLE SCHEDULE
Source connections to ZR-4 Series 2 chassis Room connections (needed for each area that accesses the audio sources)
QTY CABLE SIGNAL FROM TO QTY CABLE SIGNAL FROM TO
1 Stereo RCA Audio CD Player ZR-4 Source 2 Input 1 CAT-5 Data ZR-4 Keypad Output Keypad (Solo-4IR)
1 Stereo RCA Audio Cable Box ZR-4 Source 3 Input 1 Speaker Audio ZR-4 Zone Amp Output Speakers
1 Stereo RCA Audio Satellite Receiver ZR-4 Source 4 Input Other connections
1 Flasher IR ZR-4 #2 IR Output CD Player 1 3.5mm 12V DC ZR-4 Trigger Output AC-3 Trigger Input
1 Flasher IR ZR-4 #3 IR Output Cable Box
1 Flasher IR ZR-4 #4 IR Output Satellite Receiver
WIRING LEGEND
Audio
CAT-5 Data
Flasher
3.5 mm
Speaker Cable
AC
FM Antenna
ZR-4 Series 2
Solo-4 IR
Loudspeakers
Solo-4 IR
Loudspeakers
Solo-4 IR
Loudspeakers
Solo-4 IR
Loudspeakers
ZONE 3
BEDROOM 2
ZONE 2
BEDROOM 1
ZONE 1
DINING ROOM
ZONE 4
POOL
CD
Player
Cable
Box
Satellite
Receiver
AM Antenna
APPLICATION: STAND-ALONE ZR-4 SERIES 2 MULTIZONE RECEIVER KIT
Switched
Outlet
Control In

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 6
WHAT DOES THIS APPLICATION DO?
This application covers the use of a second ZR-4 Series 2 to distribute the four audio sources (including a built-in AM/FM tuner) to eight
zones.
DO THIS FIRST Review the ZR-4 Series 2 Overview
APPLICATION: ZR-4 SERIES 2 WITH A SECOND CHASSIS (8 ZONES)
The ZR-4 Series 2 has a built-in tuner and
can accommodate 3 additional sources.
Each zone can have up to 2 keypads by
using the ZR-KE keypad expander.
GLOBAL FEATURES INCLUDE:
• Party Mode – Press-and-hold a source
button and all pre-configured zones will
turn on to play that source.
•
Paging – Allows front and rear door
doorbell chimes from the Niles DBI-1 or
paging from a phone system, or both,
to be heard through the speakers in
pre-configured zones. The zones of the
ZR-4 Series 2 that are on will mute so
the doorbell/page can be heard. The
zones that were off will turn on so the
doorbell/page can be heard. When the
page is completed, zones that were on
will automatically begin playing music
again and the zones that were off will
turn off again.
•
Zone Linking – Zones can be
“linked” together so that they always
play the same source, while retaining
independent volume adjustment. Only
one link group per chassis.
•All Zones Off – Press-and-hold the Off
button to turn off all zones.
ZONE FEATURES INCLUDE:
• Weather-Resistant Keypads – The
Solo-4IR keypad is weather-resistant
and can be mounted in wet areas such
as outdoors, showers, and saunas.
When installing in these areas, special
installation techniques are required. See
the critical knowledge section.
•
Bass, Treble, and Variable
Loudness – Each zone can have its
own custom tailored sound.
• IR Sensor On/Off – The built-in IR
sensor in each keypad can be turned off.
It may be necessary to disable the
IR sensor if the keypad is exposed to
direct sunlight.
POWERING OUTDOOR AREAS
The amplifier power of the ZR-4 Series
2 is sufficient for indoor applications,
but outdoor applications may require a
more powerful amplifier. A Niles Systems
Integration Amplifier is recommended
when more power is needed. The ZR-4
Series 2 has a Zone 4 preamp output that
provides an audio signal to the amplifier
and can be switched between variable
level (volume level controlled by keypad)
or fixed level (volume level controlled by a
separate volume control).
ADDING A SEPARATE IR SENSOR
When adding a separate IR sensor in a
zone you must:
• Add a separate IR repeater system and
route the data and ground to the Global
IR input.
• Teach discrete zone commands into
the R-6L from an IR-CS capture station,
an IntelliFile 3 capture station, or a third
party remote.
ZONE CONTROL
The included Solo-4IR keypads offer basic
system operation (e.g. source selection,
volume +/-, etc.). Preset stations on the
tuner can be advanced by pressing the
Radio key when the radio is playing. For
more advanced control, the customer will
need the R-6L remote control in each
zone to achieve activation of sources and
transport control (e.g. power, play, stop,
track +/-, etc.). Source activation can be
programmed into a sequence on the R-6L.
TWO-CHASSIS CONFIGURATION
When using two ZR-4 Series 2’s you have
access to these features and capabilities:
• Global features such as Party Mode, All
Zones Off, and Zone Linking
• Individual tuners for each 4 zones (per
chassis). When activating Party Mode,
both tuners are automatically set to the
frequency selected in the initiating zone.
• Shared and/or dedicated sources for
each chassis
Shared sources must be connected to
each ZR-4 chassis. If the source does not
have multiple audio outputs, a Niles AVDA-
3 distribution amplifier must be
used (see the following cable diagram).
Key Considerations

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 7
CRITICAL KNOWLEDGE
When installing the Solo4-IR into a
“wet” environment, the unit must have
a complete “positive” seal with the
mounting surface. This is achieved
by using silicone caulking on the gap
around the plate or the Decora®style
insert and then installing the wall plate
to complete the seal. It is recommended
that additional installation time be
applied to these keypad locations.
Since the ZR-4 Series 2 does not
include the ability to manage the
power of connected sources, it is
recommended that you use one of these
power management options.
• If source has latching power
(mechanical power buttons), use the
Niles AC-3 (FG00242) to manage
power to this device. This type of
source normally has an “automatic
play” feature, which is also required.
• If source has non-latching power,
then use an R-6L (FG01446) at each
keypad location. The R-6L can be
programmed with a sequence to
accomplish the following steps:
1. Issue source ON command
2. Issue zone ON command
3. Issue PLAY command or favorite
channel sequence
Customer Benets
The ZR-4 Series 2 is an inexpensive
solution that allows your customer to
choose up to 4 independent sources,
including the built-in AM/FM tuner, for up
to 8 areas of the house that are controlled
via simple keypads or a remote control.
They also can access features such as
“Party Mode” which allows a source to be
activated in preselected zones, and “All
Off” which allows the customer to shut off
the system from any keypad location.
Installation Benets
The ZR-4 Series 2 gives you a cost-
effective solution to replace speaker
selectors, volume controls, and IR
systems with a 4-source, up to 8-zone
MultiZone receiver (built-in tuner) in an
extremely small footprint (1U rackspace
high). Each zone can have its sound
custom tailored through the use of zone
independent bass, treble, and variable
loudness controls.
INSTALLATION REQUIREMENTS
All CAT-5 wiring must be terminated
using the T568A wiring convention.
The following steps are required
to configure a ZR-4 Series 2 kit for
operation:
1. Set tuner presets
2. Configure unit via front panel display
3. Set bass, treble, variable loudness,
and IR sensor on/off for each zone
from keypad
4. Program all R-6L remotes
CABLE SCHEDULE
Source connections to ZR-4 Series 2 chassis Room connections (needed for each area that accesses the audio sources)
QTY CABLE SIGNAL FROM TO QTY CABLE SIGNAL FROM TO
1 Stereo RCA Audio CD Player AVDA-3 #1 Input 1 CAT-5 Data ZR-4 Keypad Output Keypad (Solo-4IR)
1 Stereo RCA Audio Cable Box AVDA-3 #2 Input 1 Speaker Audio ZR-4 Zone Amp Output Speakers
1 Stereo RCA Audio Satellite Receiver AVDA-3 #3 Input Other connections
1 Stereo RCA Audio AVDA-3 #1 Output ZR-4 Master Source 2 Input 1 CAT-5 Data ZR-4 Master Expansion Port ZR-4 Slave
Expansion Port
1 Stereo RCA Audio AVDA-3 #2 Output ZR-4 Master Source 3 Input Systems Integration Amplifier Connections
1 Stereo RCA Audio AVDA-3 #3 Output ZR-4 Master Source 4 Input 1 Stereo RCA Audio ZR-4 Zone 4 Preamp Output SI-275 Amplifier
1 Stereo RCA Audio AVDA-3 #1 Output ZR-4 Slave Source 2 Input 1 Speaker Audio SI-275 Amplifier Speakers (Pool)
1 Stereo RCA Audio AVDA-3 #2 Output ZR-4 Slave Source 3 Input 1 3.5 mm 12V DC ZR-4 Trigger Output SI-275 Amplifier
Trigger Input
1 Stereo RCA Audio AVDA-3 #3 Output ZR-4 Slave Source 4 Input
1 Flasher IR ZR-4 #2 IR Output CD Player
1 Flasher IR ZR-4 #3 IR Output Cable Box
1 Flasher IR ZR-4 #4 IR Output Satellite Receiver

Niles Audio CorporAtioN 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 8
Niles Audio CorporAtioN 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com B
APPLICATION: ZR-4 WITH A SECOND CHASSIS (8 ZONES)
AVDA-3
MASTER ZR-4
AVDA-3
CD
Player
AVDA-3
Cable
Box
Satellite
Receiver
Loudspeakers
Solo-4IR
Loudspeakers
Solo-4IR
Loudspeakers
Solo-4IR
Loudspeakers
Solo-4IR
MASTER ZR-4 SERIES 2
ZONE 1
KITCHEN
ZONE 2
MASTER BEDROOM
ZONE 3
OFFICE
ZONE 4
GAME ROOM
Wiring LEgEnD
Audio
CAT-5 Data
Flasher
3.5 mm
Speaker Cable
30 Pin Cable
SI-275
SLAVE ZR-4 SERIES 2
Loudspeakers
Solo-4IR
ZONE 5
DINING ROOM
Loudspeakers
Solo-4IR
ZONE 6
BEDROOM 1
Loudspeakers
Solo-4IR
ZONE 7
BEDROOM 2
Loudspeakers
Solo-4IR
ZONE 8
POOL
9

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com 10
CRITICAL KNOWLEDGE
A learning IR remote must be able
to output a sequence of commands
when a single button is selected.
Only two sources can be selected
in any particular zone, the ZR-4’s
built-in AM/FM tuner or a source from
the zone 2 output on the surround
receiver.
Outdoor areas must have an outdoor
remote control. Duplicate sources can
not be used in this configuration (e.g.
two satellite receivers).
WHAT DOES THIS APPLICATION DO?
This application covers the use of a ZR-4 Series 2 to split the zone 2 output of a home theater receiver.
DO THIS FIRST Review the ZR-4 Series 2 Overview
APPLICATION: ZR-4 SERIES 2 SPLITTING THE SECOND
ZONE OF A HOME THEATER RECEIVER
This application is a two zone system,
with zone one being the home theater
and zone two being all other areas fed
by the ZR-4 Series 2 Receiver. Keep in
mind that the customer will have access
to the built-in ZR-4 Series 2 tuner and a
single source from the surround receiver.
ZONE CONTROL
A learning IR remote control must be
used in each area. This control must be
capable of programmed sequences. In
these sequences you will be building a
string of commands that will control the
“specific” zone on the ZR-4 Series 2, the
surround receiver’s 2nd zone, and the
source gear. Below is an example of a
sequence to control a CD player:
1. Surround receiver zone 2 on
2. Surround receiver zone 2 CD input
3. ZR-4 source #2
4. CD on
5. CD play
IR REPEATER SYSTEM
An outboard repeater system must be
used. IR sensors would be located in the
remote areas of the home and connected
to an IR block. The data and ground from
the system would be connected to the
Global IR Input on the ZR-4 Series 2. All
flashers to the sources and the surround
receiver would be connected to the ZR-4
Series 2 flasher outputs.
GLOBAL FEATURES AVAILABLE:
• Party Mode – Not available
• Paging – Available
• All Zones Off – Not available
ZONE FEATURES AVAILABLE:
• Keypad operation in wet
environments – Not applicable
(all control must be through learning
IR remotes)
• Zone Linking – available
•
Bass, Treble, and Variable
Loudness – available
Key Considerations Customer Benets
This application is easy for customers to
understand and to use since they have
exactly the same control in all areas of the
house. All sources that they have access
to in the home theater are available
to all secondary rooms of the home.
The customer also gets better fidelity
since each area has a dedicated amp
channel plus bass, treble, and variable
loudness control.
Installation Benets
This application allows the use of the
ZR-4 Series 2 to split the zone 2 output
of a home theater receiver into 4 separate
zones with separate amplifier outputs and
independent volume control via IR remote.
This is a simple way to provide the same
sources from the home theater to more
than one room without using volume
controls. Since all control in each zone is
via learning IR remote controls, you can
specify the same remote in all areas of
the house.
INSTALLATION REQUIREMENTS
All CAT-5 wiring must be terminated
using the T568A wiring convention.
The following steps are required
to configure a ZR-4 Series 2 kit for
operation:
1. Set tuner presets
2. Configure unit through front panel
display
3. Set bass, treble, variable loudness,
and IR sensor on/off each zone
from keypad
4. Program all learning IR remotes
When using the preamp output on the
ZR-4 Series 2 exclusively, always set
the unit to disable the internal amplifier
in the configuration. This will direct
more power to the remaining amplifier
zones.

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI- 305-238-4373 – www.nilesaudio.com
©2010 Niles Audio Corporation. All Rights Reserved. Niles, the Niles logo, and Systems Integration Amplifier are registered trademarks of Niles Audio Corporation.
All other trademarks are the property of their respective owners. TM0030A
11
CABLE SCHEDULE
Surround receiver connections Room connections (needed for each area that accesses the audio sources)
QTY CABLE SIGNAL FROM TO QTY CABLE SIGNAL FROM TO
1 Stereo RCA Audio CD Player
Audio Output
Surround Receiver
CD Audio Input 1 CAT-5 IR IR Sensor IRH610 Sensor Input
1 Stereo RCA Audio Satellite Receiver
Audio Output
Surround Receiver
DBS Audio Input 1 Speaker Audio ZR-4 Amplifier Outputs Speakers
1Component or
HDMI Video Satellite Receiver Video Output
Surround Receiver DBS
Video Input Other
1 Stereo RCA Audio Surround Receiver
Zone 2 Output ZR-4 Source 2 Input 1 3.5mm IR IRH-610 Output to MSU (data & ground only)
ZR-4 Global
IR Input
1 Flasher IR ZR-4 Flasher Output CD Player
1 Flasher IR ZR-4 Flasher Output Satellite
APPLICATION: ZR-4 SPLITTING THE SECOND ZONE OF A HOME THEATER RECEIVER
WIRING LEGEND
Audio
CAT-5 Data
Flasher
HD Video
3.5 mm
Speaker Cable
TO HOME THEATER RECEIVER
Zone 2 – AUDIO OUT
Zone 2 – IR INPUT
CD – IN
DBS – AUDIO IN
TV – VIDEO IN
ZR-4 SERIES 2
LoudspeakersLoudspeakersLoudspeakersLoudspeakers
ZONE 3
OFFICE
ZONE 2
MASTER BEDROOM
ZONE 1
KITCHEN
ZONE 4
GAME ROOM
IR
MS220
123
56
78
0
9
4
INPUT ENTER
OK
INFOMENU
VOLVOL
LAST
MUTE
CH
GUIDE
LIST
SRC6
SRC5
SRC2
AM/FM
SRC3
SRC4
TV
AUX
Remote
Data and
Ground
IRH610
IR
MS220
123
56
78
0
9
4
INPUT ENTER
OK
INFOMENU
VOLVOL
LAST
MUTE
CH
GUIDE
LIST
SRC6
SRC5
SRC2
AM/FM
SRC3
SRC4
TV
AUX
Remote
IR
MS220
123
56
78
0
9
4
INPUT ENTER
OK
INFOMENU
VOLVOL
LAST
MUTE
CH
GUIDE
LIST
SRC6
SRC5
SRC2
AM/FM
SRC3
SRC4
TV
AUX
Remote
IR
MS220
123
56
78
0
9
4
INPUT ENTER
OK
INFOMENU
VOLVOL
LAST
MUTE
CH
GUIDE
LIST
SRC6
SRC5
SRC2
AM/FM
SRC3
SRC4
TV
AUX
Remote
MF2
CD
Player
Satellite
Receiver
