IW2670LCR
Professional Quality, In-Wall,
Left/Center/Right Channel Loudspeaker
D a t a S h e e t

Features
■ Dual 6.5" interlaced carbon-fiber woofers with butyl rubber surrounds provide increased sound
pressure levels and sustained high power output
■ 1" fluid-cooled Teteron® dome tweeter delivers ultra-wide dispersion and silky-smooth
high-frequency response
■ 1 1/2" fluid-cooled Teteron® dome midrange for smooth detailed dialog
■ Adjustable, cast aluminum, fully-enclosed dispersion-controlling midrange/tweeter pod enables
precise imaging regardless of placement and accommodates vertical or horizontal installations
■ Variable (+/-3dB) midrange and treble controls enable fine-tuning after installation
■ Cross-braced ported cabinet with integrated frame design fits standard 2X4 construction and is
easily retrofitted
■ Gold plated input terminals accept 12 gauge wire and ensure positive connections
■ Epoxy-coated MicroPerf™ grille provides an elegant yet unobtrusive appearance
Specifications
■ Frequency Response: 70Hz to 20kHz +/-3dB
■ Sensitivity: 90dB (2.83V@1 meter)
■ Hole Cutout Dimensions: 24 1/4 inches X 10 1/2 inches
■ Depth from Front of wall: 3 7/8 inches
■ Recommended Amplifier Power: 15 to 125 Watts
■ Impedance: 6 ohm nominal; 3.2 ohm minimum
Warranty: Five-year limited
In-wall Left/Center/Right
Channel Loudspeaker
IW2670LCR
Stock Number
FG01327
Loudspeaker Dimensions
IW2670LCR




















FRONT SIDE
BOTTOM
