2/04 revised 11/04 Form Number 56041577
Captor™ 4300B, 4800B
Instructions For Use
English
CR 1100B, 1200B
Advance MODELS 56303001 (4300B), 56303000 (4800B)
Nilfisk MODELS 56303005 (1100B), 56303004 (1200B)

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 3
ENGLISH / 3
TABLE OF CONTENTS
Page
Introduction...................................................................................................4
Parts and Service...........................................................................................4
Nameplate......................................................................................................4
Uncrating the Machine....................................................................................4
Cautions and Warnings..................................................................................5
Consignes de prudence et de sécurité...........................................................6
General Information........................................................................................7
Battery Installation.......................................................................................8-9
Know Your Machine / Operator’s Compartment..............................10 – 17
Preparing the Machine for Use
Pre-Operational Checklist.............................................................................18
Main Broom..................................................................................................18
Scrub Brush Installation...........................................................................18-19
Filling the Solution Tank................................................................................20
Operating the Machine
Sweeping......................................................................................................21
Emptying the Hopper....................................................................................21
Scrubbing.....................................................................................................22
Emptying the Recovery Tank........................................................................22
After Using the Machine
After Use.......................................................................................................23
Maintenance Schedule
Maintenance Schedule.................................................................................23
Charging the Battery.....................................................................................24
Main Broom Maintenance.............................................................................25
Side Broom Maintenance.............................................................................26
Squeegee Maintenance................................................................................27
Hopper Dust Control Filter............................................................................ 28
Hydraulic Oil.................................................................................................28
Drive Wheel Gear Case Oil..........................................................................29
Lubrication....................................................................................................29
Circuit Breaker Location...............................................................................29
Troubleshooting....................................................................................30 – 31
Technical Specifications...............................................................................32

4 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
4 / ENGLISH
INTRODUCTION
ThismanualwillhelpyougetthemostfromyourNilfisk-Advance™Sweeper/Scrubber. Readitthoroughlybeforeoperatingthemachine. Referencesto“right”
and “left” in this manual mean right or left as seen from the driver’s seat.
Note: Bold numbers or letters in parentheses indicate an item illustrated on pages 10 – 13 unless referred to a specific figure number.
PARTSAND SERVICE
Repairs,whenrequired,shouldbeperformedbyyourAuthorizedNilfisk-AdvanceServiceCenter,whoemploysfactorytrainedservicepersonnel,andmaintains
an inventory of Nilfisk-Advance original replacement parts and accessories.
Call the NILFISK-ADVANCE INDUSTRIAL DEALER named below for repairs or service. Please specify the Model and Serial Number when discussing your
machine.
(Dealer, affix service sticker here.)
NAMEPLATE
The Model Number and Serial Number of your machine are shown on the Nameplate, located on the wall of the operator’s compartment. This information is
needed when ordering repair parts for the machine. Use the space below to note the Model Number and Serial Number of your machine for future reference.
MODEL
SERIALNUMBER
Note: Reference the separately supplied engine manufacture’s maintenance and operator manual for more detailed engine specification and service data.
UN-CRATING
Upon delivery, carefully inspect the shipping crate and the machine for damage. If damage is evident, save all parts of the shipping crate so that they can be
inspected by the trucking company that delivered the machine. Contact the trucking company immediately to file a freight damage claim.
1 After removing the crate, remove the wooden blocks next to the wheels and any hold down straps.
2 Check the hydraulic oil level.
3 Read the instructions in the Preparing the Machine For Use section of this manual, then install the battery.
4 Place a ramp next to the front end of the pallet.
5 Read the instructions in the Operating Controls and Operating the Machine sections of this manual. Slowly drive the machine forward down the ramp to
the floor. Keep your foot lightly on the brake pedal until the machine is off the pallet.
CAUTION!
Use extreme CAUTION when operating this machine. Be certain that you are thoroughly familiar with all operating instructions
before using this machine. If you have any questions, contact your supervisor or your local Nilfisk-Advance Industrial Dealer.
Ifthemachinemalfunctions,donottrytocorrecttheproblemunlessyoursupervisordirectsyoutodoso. Haveaqualifiedcompany
mechanic or an authorized Nilfisk-Advance Dealer service person make any necessary corrections to the equipment.
Use extreme care when working on this machine. Loose clothing, long hair, and jewelry can get caught in moving parts. Turn the
KeySwitch OFF andremove the keybefore servicingthemachine. Usegood common sense,practice good safetyhabits andpay
attention to the yellow decals on this machine.
Drive the machine slowly on inclines. The drive pedal will control machine speed while descending inclines. DO NOT turn the
machine on an incline; drive straight up or down.
The maximum rated incline for sweeping and scrubbing is 6°. The maximum rated incline during transport is 8°.

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 5
ENGLISH / 5
CAUTIONSAND WARNINGS
SYMBOLS
Nilfisk-Advanceusesthesymbolsbelowtosignalpotentiallydangerous conditions. Alwaysreadthisinformationcarefullyandtake
the necessary steps to protect personnel and property.
DANGER!
Is used to warn of immediate hazards that will cause severe personal injury or death.
WARNING!
Is used to call attention to a situation that could cause severe personal injury.
CAUTION!
Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.
GENERAL SAFETY INSTRUCTIONS
Specific Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.
WARNING!
*This machine shall be used only by properly trained and authorized persons.
*While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills.
*Keep sparks, flame and smoking materials away from battery. Explosive gases are vented during normal operation.
*Charging the battery produces highly explosive hydrogen gas. Charge battery only in well-ventilated areas away from open
flame. Do not smoke while charging the battery.
*Remove all jewelry when working near electrical components.
*Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
*Never work under a machine without safety blocks or stands to support the machine.
*Do not dispense flammable cleaning agents, operate the machine on or near these agents, or operate in areas where flam-
mable liquids exist.
*Do not clean this machine with a pressure washer.
*Only use the brushes provided with the appliance or those specified in the instruction manual. The use of other brushes may
impair safety.
CAUTION!
*This machine is not approved for use on public paths or roads.
*This machine is not suitable for picking up hazardous dust.
*Use care when using scarifier discs and grinding stones. Nilfisk-Advance will not be held responsible for any damage to floor
surfaces caused by scarifiers or grinding stones.
*When operating this machine, ensure that third parties, particularly children, are not endangered.
*Before performing any service function, carefully read all instructions pertaining to that function.
*Do not leave the machine unattended without first turning the key switch off (O), removing the key and applying the parking
brake.
*Turn the key switch off (O) before changing the brushes, and before opening any access panels.
*Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
*Use caution when moving this machine in below freezing temperature conditions. Any water in the solution or recovery tanks
or in the hose lines could freeze.
* The battery must be removed from the machine before the machine is scrapped. The disposal of the battery should be safely
done in accordance with your local environmental regulations.
*Do not use on surfaces having a gradient exceeding that marked on the machine.
*All doors and covers are to be positioned as indicated in the instruction manual before using the machine.
SAVE THESE INSTRUCTIONS

6 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
6 / ENGLISH
CONSIGNES DE PRUDENCE ET DE SÉCURITÉ
SYMBOLES
Lessymboles reproduits ci-dessoussontutilisés pourattirerl’attentionde l’opérateursurdessituations dangereuses. Ilestdonc conseillédelireattentivement
ces indications et de prendre les mesures adéquates en vue de protéger le personnel et le matériel.
DANGER!
Ce symbole est utilisé pour mettre l’opérateur en garde contre les risques immédiats pouvant provoquer des dommages corporels graves, voire entraîner la
mort. ATTENTION!
Ce symbole est utilisé pour attirer l’attention sur une situation susceptible d’entraîner des dommages corporels graves.
PRUDENCE!
Ce symbole est utilisé pour attirer l’attention de l’opérateur sur une situation qui pourrait entraîner des dommages corporels minimes, ou des dommages à la
machine ou à d’autres équipements.
CONSIGNES GENERALES DE SECURITE
Les consignes spécifiques de prudence et de sécurité mentionnées ici ont pour but de vous informer de la survenance de tout risque de dommages matériels
ou corporels.
ATTENTION!
*Cette machine ne pourra être utilisée que par du personnel parfaitement entraîné et dûment autorisé.
* Evitezlesarrêtssubitslorsque lamachine estchargée etse trouvesurdes rampesou desplans inclinés. Evitezlesviragesserrés. Adoptez une
vitesse réduite lorsque la machine est en descente. Ne nettoyez que lorsque la machine monte la pente.
*Eloignez les batteries de toutes flammes, étincelles ou substance fumigène. Les gaz explosifs sont ventilés pendant le fonctionnement normal.
*Deplus, dugaz hydrogèneexplosif s’échappedes batterieslorsqu’elles sonten charge. Neprocédez auchargement desbatteriesque dansune
zone bien ventilée, loin de toute flamme. Ne fumez pas à proximité des batteries lorsqu’elles sont en charge.
*Otez tous vos bijoux lorsque vous travaillez à proximité de composants électriques.
*Positionnez la clé de contact sur off (O) et déconnectez les batteries avant de procéder à l’entretien des composants électriques.
*Ne travaillez jamais sous une machine sans y avoir placé, au préalable, des blocs de sécurité ou des étais destinés à soutenir la machine
*Ne déversez pas d’agents nettoyants inflammables, ne faites pas fonctionner la machine à proximité de ces agents ou d’autres liquides inflam-
mables.
*Ne nettoyez pas cette machine avec un nettoyeur à pression.
*Utilisezuniquementlesbrossesfourniesavecl’appareiloucellesspécifiéesdanslemanueld’instructions.L’utilisationd’autresbrossespeutmettre
la sécurité en péril.
PRUDENCE!
* Cette machine n’est pas conçue pour une utilisation sur les chemins ou voies publics.
* Cette machine n’est pas conçue pour le ramassage des poussières dangereuses.
* N’utilisez pas de disques de scarificateur ni de meules. Nilfisk-Advance ne pourra en aucun cas être tenue pour responsable des dommages
occasionnés à vos sols par ce type d’équipement (vous risquez également d’endommager le système d’entraînement des brosses).
* Lors de l’utilisation de cette machine, assurez-vous que des tiers, et notamment des enfants, ne courent pas le moindre risque.
* Avant de procéder à toute opération d’entretien, veuillez lire attentivement toutes les instructions qui s’y rapportent.
* Ne laissez pas la machine sans surveillance sans avoir, au préalable, coupé le contact, enlevé la clé de contact (O) et tiré le frein à main.
* Positionnez la clé de contact sur off (O) avant de remplacer les brosses ou d’ouvrir tout panneau d’accès.
* Prenez toutes les mesures nécessaires pour éviter que les cheveux, les bijoux ou les vêtements amples ne soient entraînés dans les parties
mobiles de la machine.
* Faites attention lorsque vous déplacez cette machine dans un endroit où la température peut descendre sous 0°. Car l’eau contenue dans les
réservoirs de solution ou de récupération ou dans les conduites risquerait de geler et par là même d’endommager les valves et raccords de la
machine. Rincez avec un liquide de lave-glace.
* Prenez soin d’enlever les batteries de la machine avant de mettre cette dernière au rebut. Pour ce qui est de l’élimination des batteries, confor-
mez-vous aux réglementations locales en matière d’environnement.
*N’utilisez pas sur des surfaces dont la pente dépasse celle mentionnée sur la machine.
*Toutes les portes et couvercles doivent être dans la position mentionnée dans le manuel d’instruction avant de mettre la machine en service.
CONSERVEZ SOIGNEUSEMENT CES INSTRUCTIONS

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 7
ENGLISH / 7
HOPPER SAFETY SUPPORT
WARNING!
Make sure the Hopper Safety Support (HH) is in place whenever attempting to do any maintenance work under or near the raised
hopper. The Hopper Safety Support (HH) holds the hopper in the raised position to allow work to be performed under the hopper.
NEVER rely on the machine’s hydraulic components to safely support the hopper.
JACKING THE MACHINE
CAUTION!
Never work under a machine without safety stands or blocks to support the machine.
• When jacking the machine, do so at designated locations (Do Not jack on the hopper) - see jacking locations (11)
TRANSPORTING THE MACHINE
CAUTION!
Before transporting the machine on an open truck or trailer, make sure that . . .
•All access doors are latched securely.
• The machine is tied down securely - see tie-down locations (4).
•The machine parking brake is set.
TOWING OR PUSHINGA DISABLED MACHINE
CAUTION!
Ifthemachinemustbetowedorpushed,makesuretheMainPowerSwitch(CC)isintheOFFpositionanddonotmovethemachine
faster than a normal walking pace (2-3 miles per hour) and for short distances only. If the machine is to be moved long distances
the rear drive wheel needs to be raised off the floor and placed on a suitable transport dolly.
HH

8 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
8 / ENGLISH
BATTERY INSTALLATION
See Figure 1 & 2. The battery required for this machine is sold separately. The maximum battery weight for this machine is 1,875 lbs (850 kg); the minimum
battery weight is 1,400 lbs (635kg). For proper battery installation, please consult your Nilfisk-Advance Industrial Dealer. DO NOT attempt to install the bat-
tery with an overhead hoist or forklift; it can only be installed with a battery cart. Connect the connector plug (A) on the battery to the machine plug behind the
steering wheel. Make sure the battery is firmly seated against the End Brace (B) on the driver’s side of the battery compartment. Reinstall the battery Stop
Plate (C) on the left side of the compartment and snug up the Bumpers (D) so the battery cannot slide from side-to-side. NOTE: The Battery Disconnect Tab
(E) has to be assembled to the Battery Connector Plug (A) on the battery.
WARNING!
Battery weight in excess of 1,875 lbs (850 kg) or below 1,400 lbs (635kg) may cause the premature failure of parts including
the tires, and may result in decreased stability and control, which could cause personal injury or death and/or property damage.
Use of a battery in excess of the weight limit will void the warranty.
IMPORTANT!
Followinstructionspackedwiththebatteryandchargerbeforechargingthebattery. ReadtheinstructionsforChargingtheBattery
in the Maintenance section of this manual.
FIGURE 1

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 9
ENGLISH / 9
FIGURE 2

10 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
10 / ENGLISH
KNOW YOUR MACHINE
1 Operator’s Seat
2 Strobe Light (optional / standard on Nilfisk Models)
3 Solution Tank Fill
4 Tie Down Locations
5 Recovery Tank Drain Hose
6 Recovery Tank Latch
7 Left Battery CompartmentAccess Panel
8 Main Broom LeftAccess Door
9 Hopper Cover Prop Rod
10 Front Wheel
11 Jacking Location
12 Left Side Broom
13 Hopper Cover Latch
14 Headlights
15 Right Side Broom
16 Hopper Cover
17 Dust Control Filter
18 Dust Control ShakerAssembly
19 ShakerAssembly Latch
20 Battery
21 Battery Compartment Door
22 Steering Wheel
1
2
3
4
5
7
8
4
10
12
13
14
15
16
17
18
19
9
21
22
11
6
20

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 11
ENGLISH / 11
KNOW YOUR MACHINE (CONTINUED)
23 Electrical Compartment Door
24 Water Level Gauge
25 Recovery Tank Lid
26 Recovery Tank “Tip-Out” Grip
27 Hydraulic Power Unit (Reservoir & Filter)
28 Right Battery CompartmentAccess Panel
29 Main Broom RightAccess Door
30 Access Door Latch
31 SkirtAssembly
32 Inline Solution Filter
33 Solution Tank Drain Hose
34 Rear Roller Bumper
35 Squeegee Tool Handle
36 Squeegee Tool Assembly
37 Tail Light
36 35
37
25
26
27
4
28
29
30
31
32
33
4
34
11
24
23

12 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
12 / ENGLISH
CONTROL PANEL
A Low Battery Indicator
B Horn
* Horn ON Indicator
C Parking Brake Indicator (not used)
D Headlights
* Headlight ON Indicator
E Machine Needs Service Indicator
F Hydraulic Filter Plugged Indicator
G Speed Switch
* Speed Switch Indicator
H Scrub Pressure Decrease Switch
* Scrub Pressure Decrease Indicator
I Scrub Pressure Increase Switch
* Scrub Pressure Increase Indicator
J Scrub Pressure Display
K Solution Switch
* Solution ON Indicator
L Solution Tank Empty Indicator
M Recovery Tank Full Indicator
N Vacuum System Switch
* Vacuum System ON Indicator
O Scrub System OFF Switch
* Scrub System Indicator
P Side Broom ON
* Side Broom ON Indicator
Q Main Broom ON Indicator
R Light Sensor
S Shaker Switch
* Shaker ON Indicator (left)
* Dust Filter Plugged Indicator (right / optional)
T Dust Control Switch
* Dust Control ON Indicator
U Side Broom UP/OFF Switch
* Side Broom OFF Indicator
V Open Dump Door Switch
* Open Dump Door Indicator
W Hopper Open Indicator
X Hopper Overtemp Indicator
Y Close Dump Door Switch
* Close Dump Door Indicator
Z Lower Hopper Switch
* Lower Hopper Indicator
AA Raise Hopper Switch
* Raise Hopper Indicator
BB Hour Meter Display
CC Main Power Switch
DD Battery Condition Indicator
AB
C
D
E
FG
BB
CC
DD
I
J
H
K
L
M
P
Q
R
S
V
W
X
Y
Z
AA
T
U
N
O

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 13
ENGLISH / 13
OPERATOR’S COMPARTMENT
EE Solution Flow Control Lever
FF Main Broom Raise/Lower (ON/OFF) Lever
GG Main BroomAdjust Knob
HH Hopper Safety Support Lever
II Control Panel
JJ Main Broom Overload Indicator Light
KK Emergency Battery Disconnect
LL Tilt Wheel Lever
MM Drive Pedal
NN Brake Pedal
OO Parking Brake Latch
PP Operator SeatAdjustment Lever
MM
NN
FF GG HH II
EE KK
LL
JJ
OO
PP

14 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
14 / ENGLISH
KNOW YOUR MACHINE DESCRIPTIONS
1Operator’s Seat – Operator sits here. Seat is adjustable forward and back.
2Strobe Light (optional / standard on Nilfisk models) – This light starts flashing when the ignition switch is turned ON.
3Solution Tank Fill – Open to fill the solution tank, use non-foaming chemicals only. 75 gallon (284 liter) maximum capacity.
4Tie down Locations – Safe point to tie down machine while transporting.
5Recovery Tank Drain Hose – Used to empty the recovery tank (hold the end of the hose above the water level in the tank to avoid sudden, uncontrolled
flow of waste water).
6 Recovery Tank Latch – Push down on latch lever to release recovery tank for “Tip-Out” feature.
7LeftBatteryCompartmentAccessPanel–PanelliftsstraightupafteropeningBatteryCompartmentDoor(21)toprovideaccesstothebatterycompart-
ment from the left side of the machine. SERVICE NOTE: Battery can only be removed from this side.
8Main Broom LeftAccess Door – Open to access main broom for servicing.
9Hopper Cover Prop Rod – Used to support the hopper cover while raised.
10 Front Wheel – Machine front wheel.
11 Jacking Location – Safe points for jacking machine up. DO NOT jack the machine on the hopper.
12 Left Side Broom – Used for sweeping along walls or curbs.
13 Hopper Cover Latch – Holds Hopper Cover (16) in place.
14 Headlights – Use when sweeping in hard to see areas.
15 Right Side Broom – Used for sweeping along walls or curbs.
16 Hopper Cover – Open to access the hopper dust control filter.
17 Dust Control Filter – Filters dust from the air.
18 Dust Control ShakerAssembly – Vibrates the Dust Control Filter (17) to shake dust out of it.
19 ShakerAssembly Latch – Used to hold the ShakerAssembly (18) UP while servicing the filter.
20 Battery – Provides electrical power for operating the machine.
21 Battery Compartment Door – Unlatch and open to access battery compartment.
22 Steering Wheel – Used to steer machine left or right.
23 Electrical Compartment Door – Open this door to access the main controller and solenoids. DO NOT open this door unless the Emergency Battery
Disconnect (KK) has been pushed IN.
24 Water Level Gauge – When filling the solution tank do not exceed the maximum level.
25 Recovery Tank Lid – Open to rinse and clean inside of recovery tank.
26 Recovery Tank “Tip-Out” Grip – Grab and pull here after unlatching to tip the recovery tank out to the side for cleaning.
27 Hydraulic Power Unit (Reservoir / Filter) – Holds the hydraulic system oil, 1.7 quart (1.6 liter) capacity. SERVICE NOTE: Open and prop the hopper
to add oil. Hydraulic return oil filter on side of the unit filters oil after flowing through system and prior to returning to reservoir.
28 Right Battery CompartmentAccess Panel – Panel lifts straight up after opening Battery Compartment Door (21) to provide access to the battery com-
partment from the Right side of the machine.
29 Main Broom RightAccess Door – Open to access main broom for servicing.
30 Access Door Latch – Push UP on lever to unlatch (RecoveryTank utilizes same latch for “Tip-Out” feature).
31 SkirtAssembly – Scrub system has left and right skirt assemblies to channel solution on floor into the path of the squeegee assembly.
32 Inline Solution Filter – Filters solution prior to dispensing on floor.
33 Solution Tank Drain Hose – Used to empty the solution tank.
34 Rear Roller Bumper – Protects both machine and other objects in the event the machine brushes up against anything.
35 Squeegee Handle – Loosen these two handles to remove the squeegee assembly from the machine.
36 SqueegeeAssembly – Picks up solution after scrubbing.
37 Tail Light – Turns ON with headlights.

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 15
ENGLISH / 15
CONTROL PANEL DESCRIPTIONS
ALow Battery Indicator – This indicator will flash when the battery requires charging.
BHorn Switch – This switch will sound the horn as long as the switch is held.
*Horn Indicator: Lights up when the horn switch is pressed.
CParking Brake Indicator – This indicator is currently not used.
DHeadlight Switch – Turns the headlights and taillights ON or OFF.
*Headlight ON Indicator: Lights up when the lights are ON. It is OFF when the lights are OFF.
EService Indicator – This indicator will illuminate when preventative maintenance is required.
FHydraulic Filter Plugged Indicator – Indicates when the hydraulic oil filter should be serviced. Have your Nilfisk-Advance Service Center check the
machine. SERVICE NOTE: This light may give a FALSE indication when the hydraulic oil is cold.
GSpeed Select Switch –Thisswitch willallowthe operatortoselect thetransportspeed limitwhilethe scrubsystemis enabledtherebyallowing scrubbing
at a higher rate of speed. This option can be disabled if desired. See the programming section for details.
The transport and scrub speed limits can be programmed using a Curtis handheld programmer. Refer to the service manual for details
*Speed Select Switch Indicator: This indicator will be green if a scrub mode has been selected and the faster scrub speed has been selected. This
indicator will be off if the Speed Select Switch has been turned OFF.
SCRUB SYSTEM
HScrub Pressure Decrease Switch – If the scrub system is off, pressing this switch will cause the following to occur:
• The scrub system will be enabled with the scrub pressure set to the lightest setting and the scrub deck will be lowered
• The vacuum system will be enabled and the squeegee will be lowered
• The solution system will be enabled
• As soon as the drive pedal is moved from the neutral position the scrub brushes will start turning and the vacuum will turn on. If the direction is forward
the solution flow will start. If the direction is reverse, the squeegee will raise and the solution flow will be stopped. The scrub brushes will turn off after an
adjustable delay once the drive pedal returns to neutral. See the service manual for details.
If the scrub system is already enabled when this switch is pressed and the scrub pressure is at 2 or 3, the scrub pressure will decrease. If the switch is
held, the pressure will decrement until the minimum setting of 1 is reached.
*Scrub Pressure Decrease Indicator: The scrub pressure decrease indicator will be lit if the scrub system is enabled and the pressure is set at 1 or 2.
The indicator will be off if the scrub system is off or if the scrub pressure is set to 3.
IScrub Pressure Increase Switch – If the scrub system is off, pressing this switch will cause the following to occur:
• The scrub system will be enabled with the scrub pressure set to the lightest setting and the scrub deck will be lowered
• The vacuum system will be enabled and the squeegee will be lowered
• The solution system will be enabled
• As soon as the throttle is moved from the neutral position the scrub brushes will start turning and the vacuum will turn on. If the direction is forward the
solution flow will start. If the direction is reverse, the squeegee will raise and the solution flow will be stopped. The scrub brushes will turn off after an
adjustable delay once the drive pedal returns to neutral. See the service manual for details.
If the scrub system is already enabled when this switch is pressed and the scrub pressure is at 1 or 2, the scrub pressure will increase. If the switch is
held, the pressure will increment until the maximum setting of 3 is reached.
*Scrub Pressure Increase Indicator: The scrub pressure increase indicator will be lit if the scrub system is on and the pressure is set at 2 or 3. The
indicator will be off if the scrub system is off or if the scrub pressure is set to 1.
J Scrub Pressure Display:
Thesinglecharacterdisplay onthecontrolpanelisused as adisplayforthescrubpressure. If thescrubsystemisON,the displaywillindicatetherelative
pressure setting of 1, 2 or 3 otherwise it is blank.
K Solution Switch - This switch is used to turn the solution system on or off. Pressing this switch when the scrub system has been activated will alternate
between on and off. The solution flow will only turn on when the drive pedal is moved from the neutral position in the forward direction. The solution flow
will turn off if the drive pedal returns to neutral or is moved to reverse. Pressing this switch when the scrub system is off will momentarily turn the solution
flow on to allow pre-wetting of the scrub brushes.
*Solution System Indicator: The solution indicator will be lit if the solution is enabled. If the solution is off, this indicator will be OFF.
LSolution Tank Empty Indicator – This indicator will illuminate when the solution tank is low.
MRecovery Tank FULL Indicator – This indicator will flash when the recovery tank is FULL. The vacuum system is shut OFF at this point. Draining the
recovery tank will reset this indicator.
NVacuum System Switch –This switchis usedto turnthe vacuumsystem onor off. Whenthe vacuumis onthe squeegeewill lower(unless themachine
isinreverse) and whenthevacuumisoffthesqueegee willrise. Pressingthisswitch willalternatebetweenonand off. The vacuum willonlyturnonwhen
the drive pedal is moved from the neutral position. It will remain on for 10 seconds after the drive pedal returns to neutral.
The vacuum also has an automatic shutoff feature that will turn the vacuum and scrub systems off if the recovery tank becomes full. If this occurs, the
recovery tank full indicator (M) will flash. The vacuum shutoff delay is adjustable. See the service manual for details.
*Vacuum System Indicator: The vacuum indicator will be lit if the vacuum is enabled. It will flash if the vacuum is in the delayed-off condition. If the
vacuum is off, this indicator will be off.
O Scrub System OFF Switch - Pressing this switch when the unit is in a scrub mode will cause the following to occur:
• The scrub brushes will turn off
• The scrub deck will raise to the UP position
• The solution flow will be stopped
• The first time that this button is pressed, the vacuum/squeegee system will NOT be turned off. This is so that any remaining water may be picked up
without having to turn the vacuum back on. If this button is pressed a second time (pressed after the scrub mode has been turned off) the squeegee will
raise and the vacuum will shut off after a 10 second delay.
*Scrub System OFF Indicator: This indicator will be lit if the scrub system is OFF. This indicator will be OFF if the scrub system is enabled or running.

16 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
16 / ENGLISH
SWEEP SYSTEM
PSide Broom DOWN/ON Switch – This switch is used to lower and/or turn the side broom(s) on. The side broom(s) will lower whenever this switch is
pressed until the bottom limit is reached. The side broom(s) will turn on when the drive pedal is moved from the neutral position. They will remain on for
approximately 5 seconds after the drive pedal returns to neutral. This shutoff period is adjustable. See the service manual for details.
*Side Broom ON Indicator:
• This indicator will be lit if the side broom(s) are turned ON.
QMain Broom ON Indicator: This indicator will be lit if the main broom is down, otherwise it is OFF.
RLight Sensor – Not currently used.
SShaker Switch – This switch controls the hopper dust control filter shaker. Pressing this button will cause the dust control to turn off and the shaker to
turn on. The shaker will run for approximately 20 seconds. This period is adjustable. See the service manual for details. Pressing the switch while the
shaker is operating will cancel the timer and turn the shaker off. If the dust control was previously on, it will turn back on.
*Shaker Indicator (left): This indicator will be lit if the shaker is turned ON, otherwise it is OFF.
*DustFilter Plugged Indicator(right/ optional): This indicatorwillbelit if thedustfilterrequires cleaning,otherwiseitis OFF. NOTE: Requires optional
Hopper Filter Switch Kit.
TDust Control Switch – This switch controls the hopper dust control. Pressing this switch alternates between on and off. The dust control will run when
the drive pedal is moved from the neutral position. The dust control will remain on for approximately 5 seconds after the drive pedal returns to neutral.
This shutoff period is adjustable. See the service manual for details.
*Dust Control Indicator: This indicator will be green if the dust control system is ON, otherwise it is OFF.
USide Broom UP/OFF Switch – This switch is used to raise and/or turn the side broom(s) off. The side broom(s) will rise whenever this switch is pressed
until the upper limit is reached. When the upper limit is reached, the side broom(s) will turn off.
*Side Broom OFF Indicator: This indicator will be lit if the side broom(s) are turned OFF.
HOPPER SYSTEM
VOpen Dump Door Switch – This switch is used to open the hopper dump door. This switch will only function when the main broom is down or when the
hopper is raised. NOTE: The dump door will automatically open when the hopper is fully down and the main broom is lowered.
*Open Dump Door Indicator: This indicator will be lit while the dump door is in the process of opening, otherwise it is OFF.
WHopper Open Indicator: This indicator flashes if the hopper is open, otherwise it is OFF.
XHopper Overtemp Indicator – This indicator will flash when the hopper temperature exceeds 140 degrees Fahrenheit. NOTE: the hopper temperature
switch is optional.
YClose Dump Door Switch – This switch is used to close the hopper dump door. This switch will only function when the main broom is up or when the
hopper is raised. NOTE: The dump door will automatically close when the main broom is raised or when the hopper is raised.
*Close Dump Door Indicator: This indicator will be lit while the dump door is in the process of closing, otherwise it is OFF.
ZLower Hopper Switch – This switch is used to lower the hopper. The hopper will drop as long as this switch is held. Once the hopper is in the full-down
position,the HopperOpen Indicator(W) will turnoff. If any ofthe sweepor scrubfunctions wereon whenthe hopperwas raised,they willbe reactivated.
The dump door will automaticallyopen or close dependingon whether the main broomis down or up. The switch indicator willbe lit as long as theswitch
is held.
*Lower Hopper Indicator: This indicator will be lit while the hopper is in the process of lowering, otherwise it is OFF.
AA Raise Hopper Switch – This switch is used to raise the hopper. Pressing this switch will cause the following to occur:
• The switch indicator will illuminate
• If the dump door is open (main broom down) the door will close
• The main broom, side brooms, scrub system, solution, and vacuum will all turn off
• If the dust control was on, it will remain on unless programmed otherwise
• Once the dump door is closed, the hopper will begin to raise
• The hopper will continue to raise as long as this switch is held
Once the hopper is no longer in the full-down position, the Hopper Open Indicator (W) will flash. The dump door open and close switches will now be
functional
*Raise Hopper Indicator: This indicator will be lit while the hopper is in the process of raising, otherwise it is OFF.

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 17
ENGLISH / 17
BB Hour meter / Error Code Display –Upon powerupor ifthemachine hasbeenidle foratleast tensecondswith allsystemsturned off,thehour meter will
display the hours for each major electric motor system for 3seconds and continue to cycle through each system as long as the drive pedal is in neutral
and all systems are OFF. Once the drive pedal is pressed or any system activated it will indicate the drive system hours (default). If an overload fault
occurs, the display will indicate the associated error code immediately.
CC Main Power / Key Switch – Main Power Switch.
DD Battery Condition Indicator - The battery condition indicator consists of three lights, a green (G), a yellow (Y), and a red (R). The voltage indication
will change based on the cutoff level (standard or alternate) selected in the control unit. The battery voltage ranges for the various indications are listed
below:
Standard
Green 34.00
Green & Yellow 33.00-33.99
Yellow 32.00-32.99
Yellow & Red 31.50-31.99
Red 31.00-31.49
Flashing Red/Cutoff <31.00
NOTE: Refer to service manual for selection of alternate cut-off level. Once the low voltage cutout level has been reached (flashing red indicator) the battery
must be FULLY recharged to reset the battery condition indicator. The scrub system will not function until the indicator has been reset.
COCKPIT
EE Solution Flow Control Lever – Move this lever FORWARD to increase solution flow to the floor. Move BACKWARD to decrease the amount of solution
flow to the floor. When the Drive Pedal (OO) is released from either forward or reverse travel, the solution flow will stop automatically, and resume when
the drive is engaged.
FF MainBroom Raise/Lower (ON/OFF)Lever–Thisleverprimarily controlsthemainbroom. Itcan alsocontrolthesidebrooms anddustcontrolifdesired.
Lowering this lever will cause the following to occur:
• The main broom indicator will illuminate
• The main broom will be lowered to the operating position
• The side brooms will be lowered to the operating position
• The dust control will be enabled
• The hopper dump door will open
As soon as the drive pedal is moved from the neutral position the main broom and side brooms will start turning and the dust control will turn on. The
brooms and dust control will remain on for approximately 5 seconds after the drive pedal returns to neutral. This shutoff period is adjustable. See the
service manual for details.
Raising the main broom lever will cause the following to occur:
• The main broom indicator will turn off
• The main broom will be raised to the off position
• The side brooms will be raised and will turn off
• The dust control will turn off
• The hopper dump door will close
The side brooms and dust control can be programmed not to automatically come on with the main broom. See the service manual for details
GG Main BroomAdjust Knob – Used to compensate for main broom wear in order to maintain a 3 inch (7.62cm) wide broom pattern.
HH Hopper Safety Support Lever – NEVER work under a raised hopper without the safety support engaged. To engage; raise the hopper all the way UP,
pull back on lever and then lower hopper until it seats.
II Control Panel – See itemsAthrough DD.
JJ Main Broom Overload Indicator Light –This indicatorwill belit if themain broompressure istoo high. Themain broomwill shutoffif overloadedfor an
extended period of time.
KK Emergency Battery Disconnect – Push in on knob to disconnect battery.
LL Tilt Wheel Lever – Pull lever out to release steering column for adjusting up or down.
MM Drive Pedal – Controls the machine’s travel speed and direction:
Push down on the Back of the pedal to move the machine Backward.
Push down on the Front of the pedal to move the machine Forward.
The SPEED of the machine will increase as the pedal is pushed closer to the floor. Maximum forward speed is faster than maximum reverse speed.
NN Brake Pedal – Operates the mechanical brakes on the front wheels.
OO Parking Brake Latch – Used to “lock” the brake pedal in place after engaging the brakes. NEVER leave machine unattended without setting Parking
Brake. Press on this latch with your foot instead of the brake pedal to activate.
PP Operator SeatAdjustment Lever - Use this lever to slide the operator’s seat forward or backward.

18 - FORM NO. 56041577 - Captor™4300B, 4800B / CR 1100B, 1200B
18 / ENGLISH
PRE-OPERATIONAL CHECKLIST
Before Each Use:
*Inspect the machine for damage or oil and water leaks.
*Check the hydraulic oil level (27).
*Make sure the recovery tank is empty.
*Make sure the battery charger is not connected to the machine.
*Check battery charge condition.
In the Driver’s Seat:
*Be sure that you understand the operating controls and their functions.
*Adjust the seat to allow easy reach of all controls.
*InserttheMasterKeyandturntheIgnitionKeySwitch(CC)totheONposition. CheckforproperoperationoftheHorn(B),HourMeter(BB)andHeadlights
(14). Turn the Ignition Key Switch (CC) OFF.
*Check the Parking Brake Latch (OO). The latch must hold its (locked parked) setting firmly with out easily being released.
(Report all defects immediately to service personnel).
Plan Your Cleaning in Advance:
*Presweep heavily littered areas for more efficient operation.
*Arrange long runs with a minimum of stopping or starting.
*Allow 6 inches of broom path overlap to ensure complete coverage.
*Avoid making sharp turns, bumping into posts, or scraping the side of the machine.
MAIN BROOM
Severaldifferentmain broomsare available forthis machine.Contactyour Nilfisk-Advancedealer ifyouneed helpselectingthe bestbroomfor thesurface and
litter that you will be sweeping. NOTE: Reference broom maintenance for installation steps.
SCRUB BRUSH INSTALLATION
1Make sure the Key Switch (CC) is off (O). See Figure 3. Remove side skirt assemblies for easier access. NOTE: Loosen large Black Knob (A) at the
front of each skirt mounting bracket, slide the skirt assembly forward and lift straight UP and off scrub deck.
2To mount the brushes (or pad holders) align the lugs on the brush with the holes on the mounting plate and turn to lock in place according to rotation
directions shown in Figure 4.

FORM NO. 56041577 - Captor™ 4300B, 4800B / CR 1100B, 1200B - 19
ENGLISH / 19
FRONT
TOP VIEW OF SCRUB DECK SHOWING DIRECTION TO ROTATE
BRUSHES WHILE INSTALLING FOR EACH BRUSH MOTOR
Outside arrows represent brush installation rotation direction. Inside arrows represent brush
motor rotation while scrubbing.
FIGURE 3
FIGURE 4
A
A
FRONT
