Nilfisk-Advance Advenger 2400D User manual

3/03 revised 5/06 Form Number 56043088
SERVICE MANUAL
Advance MODELS 56314000, 56314001, 56314002, 56314003, 56314004,
56314005, 56314006, 56314007
Nilfisk MODELS 56314010, 56314011, 56314012, 56314013, 56314014,
56314015, 56314016, 56314017
Advenger™2400D, 2600D, 2810D,
3210D, 2400C, 2600C, 2810C, 3210C
BR 600S, 650S, 700S, 800S,
600CS, 650CS, 700CS, 800CS

68 - FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
GENERALINFORMATION...................................................................................................................................................2
SAFETY INSTRUCTIONS....................................................................................................................................................3
SPECIFICATIONS & MAINTENANCE...............................................................................................................................4-6
PM CHECKLIST ................................................................................................................................................................7-8
KNOW YOUR MACHINE.................................................................................................................................................9-13
STEERING SYSTEM.....................................................................................................................................................14-15
STEERING COLUMNASSEMBLY SHROUD REMOVAL................................................................................................14
STEERING CHAIN REMOVALAND TENSIONING .........................................................................................................15
WHEELDRIVE SYSTEM...............................................................................................................................................16-25
GENERALFUNCTIONALOVERVIEW.............................................................................................................................16
DRIVE MOTOR SYSTEM CONTROLLER FUNCTION OVERVIEW ...............................................................................16
WHEEL DRIVE TROUBLESHOOTING GUIDE................................................................................................................19
STEERING SPINDLE & WHEELDRIVE MOTORASSEMBLY REMOVAL......................................................................20
DRIVE TIRE REMOVAL....................................................................................................................................................20
BRAKEADJUSTMENT.....................................................................................................................................................22
DRIVE WHEELBRAKE STRAP REPLACEMENT...........................................................................................................23
WHEELDRIVE MOTOR CARBON BRUSH INSPECTION..............................................................................................23
POTENTIOMETER REMOVAL & TESTING.....................................................................................................................24
POTENTIOMETER INSTALLATION &ADJUSTMENT.....................................................................................................25
DRIVE PEDALNEUTRALADJUSTMENT & PEDALREPLACEMENT............................................................................25
SCRUB BRUSH SYSTEM.............................................................................................................................................26-33
FUNCTIONALOVERVIEW...............................................................................................................................................26
SCRUB BRUSH SYSTEM TROUBLESHOOTING...........................................................................................................27
SCRUB BRUSH DECK REMOVAL (DISC & CYLINDRICAL)..........................................................................................28
SCRUB BRUSH MOTORASSEMBLY REMOVAL (DISC)...............................................................................................29
SCRUB BRUSH GEARBOX REMOVALAND OUTPUT SHAFT REPLACEMENT(DISC)..............................................29
SCRUB BRUSH SIDE SKIRTREPLACEMENT (DISC)...................................................................................................30
SIDE SKIRT HEIGHTADJUSTMENT (DISC)...................................................................................................................30
SCRUB BRUSH DECK FRONT/REAR SKIRTREPLACEMENT (DISC).........................................................................30
BRUSH DECKACTUATOR REMOVAL(DISC & CYLINDRICAL)....................................................................................31
SCRUB BRUSH MOTOR REMOVAL(CYLINDRICAL)....................................................................................................32
SCRUB BRUSH BELT REPLACEMENT (CYLINDRICAL)...............................................................................................32
SCRUB BRUSH SYSTEM MAINTENANCE.....................................................................................................................32
SCRUB BRUSH REMOVALAND INSTALLATION (CYLINDRICAL)................................................................................33
SIDE SKIRT MAINTENANCE & ADJUSTMENT (CYLINDRICAL) ...................................................................................33
SOLUTION SYSTEM.....................................................................................................................................................34-37
FUNCTIONALOVERVIEW...............................................................................................................................................34
SOLUTION SOLENOID CIRCUIT OVERVIEW................................................................................................................35
TROUBLESHOOTING GUIDE .........................................................................................................................................36
SOLUTION SYSTEM MAINTENANCE.............................................................................................................................36
SOLUTION SOLENOID REMOVAL..................................................................................................................................36
SOLENOID VALVE DISASSEMBLYAND CLEANING .....................................................................................................37
RECOVERY SYSTEM...................................................................................................................................................38-41
FUNCTIONALOVERVIEW...............................................................................................................................................38
VACUUM MOTOR CIRCUIT OVERVIEW ........................................................................................................................39
TROUBLESHOOTING GUIDE .........................................................................................................................................40
VACUUM / RECOVERY SYSTEM SERVICE MAINTENANCE CHECKLIST...................................................................40
MAINTENANCE OF VACUUM FILTERAND FLOAT CAGE.............................................................................................40
RECOVERYTANK REMOVAL.........................................................................................................................................41
VACUUM MOTOR REMOVAL..........................................................................................................................................41
SQUEEGEE SYSTEM...................................................................................................................................................42-44
SQUEEGEE SYSTEM LIFT MOTOR OVERVIEW...........................................................................................................42
TROUBLESHOOTING......................................................................................................................................................42
SQUEEGEE LIFTACTUATOR MOTOR REMOVAL.........................................................................................................43
SQUEEGEE LIFT CABLE REPLACEMENT.....................................................................................................................43
SQUEEGEE MAINTENANCE...........................................................................................................................................44
SQUEEGEEADJUSTMENT.............................................................................................................................................44
TABLE OF CONTENTS

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 1
TABLE OF CONTENTS
ELECTRICALSYSTEM.................................................................................................................................................45-75
BATTERIES / CHARGERS SPECIFICATIONS................................................................................................................45
INSTALLTHE BATTERIES...............................................................................................................................................45
DESCRIPTION OF THE BATTERYLOW VOLTAGE CUTOUT FEATURE......................................................................46
DESCRIPTION OF THE BATTERYCONDITION INDICATOR ........................................................................................46
CHARGING THE BATTERIES..........................................................................................................................................46
BATTERY MAINTENANCE...............................................................................................................................................47
BATTERYTESTING.........................................................................................................................................................47
ACTUATOR DRIVE NUTADJUSTMENT ....................................................................................................................48-49
CURTIS SPEED CONTROL........................................................................................................................................50-53
MAIN CONTROLBOARD FUNCTIONALOVERVIEW.....................................................................................................54
MAIN CONTROLBOARD TROUBLESHOOTING GUIDE...............................................................................................54
MAIN CONTROLLER ERROR CODES.......................................................................................................................54-55
MAIN CONTROLLER SERVICETEST MODE............................................................................................................56-59
MAIN CONTROLBOARD SPECIALPROGRAM OPTIONS.......................................................................................60-65
ELECTRICALCOMPONENT LOCATION (before SN chart)............................................................................................67
WIRING DIAGRAM (before SN chart)..............................................................................................................................68
WIRING SCHEMATIC (before SN chart)..........................................................................................................................69
WIRING DIAGRAM (after SN chart).................................................................................................................................70
WIRING SCHEMATIC (after SN chart).............................................................................................................................71
ELECTRICALCOMPONENT LOCATION (after SN chart)...............................................................................................72
Note: All references to right, left, front, or rear in this manual are as seen from the operator’s stand-point.

2- FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
INTRODUCTION
This manual will help you get the most from your Nilfisk-Advance Rider Scrubber. Read it thoroughly before servicing the machine.
Note: Bold numbers in parentheses indicate an item illustrated on pages 9-10.
This product is intended for commercial use only.
PARTS AND SERVICE
Repairs, when required, should be performed by yourAuthorized Nilfisk-Advance Service Center, who employs factory trained service personnel,
and maintains an inventory of Nilfisk-Advance original replacement parts and accessories.
Call the NILFISK-ADVANCE DEALER named below for repair parts or service. Please specify the Model and Serial Number when discussing
your machine.
(Dealer, affix service sticker here.)
NAME PLATE
The Model Number and Serial Number of your machine are shown on the Nameplate on the machine. This information is needed when ordering
repair parts for the machine. Use the space below to note the Model Number and Serial Number of your machine for future reference.
MODELNUMBER
SERIALNUMBER
TRANSPORTING THE MACHINE
CAUTION!
Before transporting the machine on an open truck or trailer, make sure that . . .
• The machine is tied down securely - see tie-down locations (25).
•All access doors and covers are secured (tape and strap as necessary).
•The machine parking brake is set.
TOWING
CAUTION!
If the machine must be towed or pushed, make sure the Key Switch (Main Power) (J) is in the OFF position and do not move the
machine faster than a normal walking pace (2-3 mph, 3-5kph) and for short distances only.
OTHER MANUALSAVAILABLE
The following manuals are available from the Nilfisk-Advance Literature Service Department, for your Rider Scrubber:
3
•Parts List - Form Number 56042438
•Operation Manual - Form Number 56041537 (Danish, Norwegian, Swedish, Finnish)
56041538 (German, French, Dutch, Russian)
56041539 (Spanish, Portuguese, Italian, Greek)
56041552 (Estonian, Latvian, Lithuanian, Slovenian)
56041553 (Slovakian, Czech, Polish, Hungarian)
56041554 (English, Spanish)
• Curtis Programmer Manual - Number 56043101
GENERAL INFORMATION

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 3
CAUTIONSAND WARNINGS
SYMBOLS
Nilfisk-Advanceusesthesymbolsbelowtosignalpotentiallydangerousconditions. Alwaysreadthis information carefully and take the
necessary steps to protect personnel and property.
DANGER!
Is used to warn of immediate hazards that will cause severe personal injury or death.
WARNING!
Is used to call attention to a situation that could cause severe personal injury.
CAUTION!
Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.
GENERAL SAFETY INSTRUCTIONS
Specific Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.
WARNING!
•This machine shall be used only by properly trained and authorized persons.
•While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. Clean only
while ascending (driving up) the ramp.
•Keep sparks, flame and smoking materials away from batteries. Explosive gases are vented during normal operation.
•Charging the batteries produces highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away from open
flame. Do not smoke while charging the batteries.
•Remove all jewelry when working near electrical components.
•Turn the key switch off (O) and disconnect the batteries before servicing electrical components.
•Never work under a machine without safety blocks or stands to support the machine.
•Do not dispense flammable cleaning agents, operate the machine on or near these agents, or operate in areas where flammable
liquids exist.
•Do not clean this machine with a pressure washer.
CAUTION!
•This machine is not approved for use on public paths or roads.
•This machine is not suitable for picking up hazardous dust.
•Donotusescarifierdiscsandgrindingstones. Nilfisk-Advancewillnotbeheldresponsibleforanydamagetofloorsurfacescaused
by scarifiers or grinding stones (can also cause damage to the brush drive system).
•When operating this machine, ensure that third parties, particularly children, are not endangered.
•Before performing any service function carefully read all instructions pertaining to that function.
•Do not leave the machine unattended without first turning the key switch off (O), removing the key and applying the parking
brake.
•Turn the key switch off (O) before changing the brushes, and before opening any access panels.
•Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
•Use caution when moving this machine in below freezing temperature conditions. Any water in the solution or recovery tanks or
in the hose lines could freeze, causing damage to valves and fittings. Flush with windshield washer fluid.
•The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries should be safely
done in accordance with your local environmental regulations.
SAVE THESE INSTRUCTIONS

4- FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
SPECIFICATIONS
General Specifications common toAll Models
Machine Length 60 5/8 in. (154cm)
Machine Height 54 1/8 in. (137.5cm)
Machine Chassis Width 29 in. (73.6cm)
Machine Current (Average) 90Amps
Solution Tank Capacity 30 gal. (113l.)
Recovery Tank Capacity 30 gal. (113l.)
Solution Flow Rate .15 – 1.0 GPM (.56 – 3.78 liter/minute)
Sound pressure level
as per IEC 60704-1 (at operator) 65 dB(A)
Vibrations at the Hand Controls (ISO 5349-1) 1.03 m/s2
Vibrations at the Seat (EN 1032) 0.24 m/s2
Transport Speed (Fwd. Maximum) 396 FPM (121m/min)
Transport Speed (Rev. Maximum) 334 FPM (102m/min)
Wheel Drive Motor 1.1 hp, 840 watt
Vacuum Motor (3 stage) .75 hp, 560 watt
Vacuum Water Lift for one motor (Sealed) 68 in.
(Open HoleAdapter 1”) 18 in.
Vacuum Water Lift for two motors (Sealed) 78 in.
(Open HoleAdapter 1”) 25 in.
Power Source (Batteries) STD (6) 6V/238 @ 20 hour rate
Battery Weight (each) 66 lbs. (30kg)
Battery Compartment Size
Height (Max.) 14.5 in. (36.8cm)
Width (Max.) 22.25 in. (56.5cm)
Length (Max.) 25.25 in. (64.1cm)
Calculated Battery Run Time 2.7 hrs.
Battery Chargers – see Electrical System Battery Section
TOP VIEW
Chassis
Width
Squeegee
Width
RIGHT SIDEVIEW
Height
Length
revised 9/05

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 5
Specifications common to deck size
Model designation: (24”)=Advenger 2400 / BR 600 (26”)=Advenger 2600 / BR 650
(28”)=Advenger 2810 / BR 700 (32”)=Advenger 3210 / BR 800
24” 26” 28” 32”
Machine Width with Squeegee (English) 28.6 in. “A” 32.6 in. “B” 32.6 in. “B” 36.6 in. “C”
Metric 72.6cm “A” 82.8cm “B” 82.8cm “B” 93cm “C”
Scrub Brush Size (qty of 2)
(Disc)Diameter 12in. (30.5cm) 13 in. (33cm) 14.25 in. (36cm) 16 in. (40.6cm)
(Cylindrical)
Diameter 5.75 in. (14.6cm) 5.75 in. (14.6cm) 5.75 in. (14.6cm) 5.75 in. (14.6cm)
Length 23 in. (58cm) 25 in. (63cm) 27 in. (68cm) 31 in. (79cm)
Scrub Brush Motor (Disc) (1) 1 HP 800 watts (1) 1.25 HP 950 watts (1) 1.5 HP 1100 watts (1) 1.5 HP 1100 watts
(Cylindrical) (2) .75 HP 560 watts (2) .75 HP 560 watts (2) .75 HP 560 watts (2) .75 HP 560 watts
Scrub Brush Speed (Disc) 250 RPM 250 RPM 250 RPM 250 RPM
(Cylindrical) 900 RPM 900 RPM 900 RPM 900 RPM
MinimumAisle Turn Width 63 in. (160cm) 63 in. (160cm) 63 in. (160cm) 63 in. (160cm)
Machine Net Weight* (English) 605 lbs. 610 lbs. 615 lbs. 620 lbs.
Metric 274 kg 277 kg 279 kg 281 kg
Machine Gross Weight** (English) 1380 lbs. 1385 lbs. 1390 lbs. 1395 lbs.
Metric 626 kg 628 kg 630 kg 633 kg
Cleaning Width (scrubbing path) (English) 24 in. 26 in. 28 in. 32 in.
Metric 61cm 66cm 71cm 81cm
Coverage Rate Per Hour (theory) (English) 44,352 ft248,048 ft251,736 ft2 59,143 ft2
Metric 4080m2 4420m2 4759m2 5441m2
Coverage Rate Per Hour (actual) (English) 22,990 ft225,080 ft227,170 ft231,350 ft2
Metric 2115m2 2307m2 2500m2 2884m2
*Net Weight: Standard machine without options, empty solution and recovery tanks, without removable scrub brushes and no batteries installed.
**Gross Weight: Standard machine without options, full solution tank and empty recovery tank, with removable scrub brushes and 305 AH
batteries.
***Listings for watts are maximum values.

6- FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
MAINTENANCE SCHEDULE
Maintenance intervals given are for average operating conditions. Machines used in severe operational environments may require service more
often.
MAINTENANCE ITEM Daily Weekly Monthly Yearly
Charge Batteries •
Check/Clean Tanks & Hoses •
Check/Clean/Rotate the Brushes/Pads •
Check/Clean/Adjust the Squeegee • •
Check/Clean Vacuum Shut-Off Float •
Check/Clean the vacuum motor foam filter(s) •
Clean Hopper on Cylindrical System •
Check Each Battery Cell(s) Water Level •
Inspect Scrub Housing Skirts •
Inspect and clean Solution Filter •
Check Foot/ Parking Brake For Wear &Adjustment •
Clean Solution Trough on Cylindrical System •
Lubrication - Grease Fittings •
* Check Carbon Brushes •
Note: See the individual machine system sections for maintenance information.
* Have Nilfisk-Advance:
Check vacuum motor carbon brushes (Qty 2) once a year or after 300 operating hours.
Check brush motor carbon brushes (Qty 4) once a year or after 500 operating hours.
Note if the vacuum or brush motor brushes are 9.5mm (3/8 inches) or shorter, replace them.
Check wheel drive motor carbon brushes every 500 operating hours. The original length of each brush is 20mm (25/32 inches). Replace when
shorter than 9.5 mm (3/8 inches) to obtain the same motor efficiency as a new brush.
WARNING!
Turn the key switch off, set the parking brake and disconnect the battery before servicing the machine.
LUBRICATING THE MACHINE
Once a month, pump a small amount of grease into each grease fitting on the machine until grease seeps out around the bearings.
Grease fitting locations are:
• Squeegee WheelAxle
• Steering Wheel Shaft Universal joint
Once a month, apply light machine oil to lubricate the:
• Steering Chain
• General Pivot Points For the Squeegee, Brush Linkage and Side Skirts
• Squeegee mount angle adjustment knob threads
BATTERIES AND CHARGERS
Attention: See the electrical system manual section for battery installation and charger system requirements.
WHEEL DRIVE MOTOR GREASE SPECIFICATION
Ifdrivemotor gear housing greasereplacementis needed whenrepairservices are performed(Exampleinspection shows grease contamination).
Cleangearsetsandhousingandre-pack. Useamulti-purpose,highmeltingpointLithiumbasedgrease,containingadditivestoprovideanti-oxidant,
anti-corrosion and good lubricity properties. Use a total quantity of 4.9-5.6 oz. (140-160g) of grease to service gear case.
Thegreasetobeusedmusthaveexcellentmechanicalstability,waterresistanceandhighloadcarryingcapacity. TheMR158greaseisparticularly
recommended for automotive applications including wheel-bearing lubrication. Available NLGI consistency 3.
Average Drop PenetrationASTM Worked
Grade Point °C (mm / 10) at 25 °C Base
MR 158 Grease 180 220 / 250 Lithium*

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 7
Copyright 2003 Nilfisk-Advance. Page 1 of 2 2/21/2001
Advance Advenger 2400, 2600, 2810, 3210
Nilfisk BR 600, 650, 700, 800
Disc and Cylindrical
PM Checklist Defect Codes
Customer A needs adjustment
Bbinding
Address C dirty or contaminated
Ddamaged, bent or torn
City St Zip Lleaks
Mmissing
Model Serial Hours Wworn out
Ref OPERATIONAL INSPECTION ITEMS OK Defect Codes
(circle)
Does
Not
Work
1 Steering AB
2 Drive Pedal Operation (check for Fwd/Rev Drive & any neutral creep) A B D
3 Seat Safety Switch A D
4 Brakes (Service & Parking) A B W
5 Drive System Performance (reference SVR Manual for Curtis drive programmer speed
changes) noisy sluggish
6 Scrub System (Raise/Lower and auto scrubbing functions) A B
7 Scrub Brush (pressure settings programming PA1-PA9) A B
8 Squeegee System (Raise/Lower and auto lift in reverse function) A B
9 Vacuum Performance (sealed water lift 65" and 1- inch open hole adapter 15 inches) C L W
10 Solution Control (On/Off and flow volume Min/Max) A B L
11 Emergency Battery Disconnect Control Knob B D
12 Pre-Sweep System Accessory (cylindrical) A B D
13 Tilt Steering Mechanism and Seat A B D
14 Optional Accessories (headlight, safety beacon, etc.) D
15 Main Control Board Special Program Options (check all applicable program settings,
reference SVR Manual 56043088); Example, Fault Recall Mode, Etc. Program as needed
16 Battery Charger Operation D
Ref VISUAL INSPECTION ITEMS Comments OK Defect Codes
(circle)
Does
Not
Work
17 Scrub Brushes, check for wear and rotate A B D W
18 Scrub Brush Motor(s) and disc machine gearboxes Carbon Brushes B L W
19 Scrub Brush Drive Belt, wear and tension (cylindrical only) A D W
20 Scrub Brush Deck Actuator Motor A B D W
21 Brush Drive Plate Retainer Clips (disc) D M
22 Scrub Deck Skirts A B W
23 Solution Solenoid Valve C L
24 Solution Flow Control Valve and Linkage A B D W
25 Solution Tank, Delivery Hoses & Filter Clean Filter Screen C L
26 Vacuum Motor Carbon Brushes Wear Limit 3/8Ó W
27 Vacuum Motor Gaskets and Filters L W
28 Vacuum Float Ball & Cage Assembly Clean Float C M
29 Recovery Tank Cover Gasket C D L
30 Recovery Tank Drain Hose & Cap Flush C L
31 Squeegee Pick-Up Tool & Hose Back flush C L

8- FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
Copyright 2003 Nilfisk-Advance. Page 2 of 2 2/21/2001
Ref VISUAL INSPECTION ITEMS (continued) Comments OK Defect Codes
(circle)
Does
Not
Work
32 Squeegee Blades (clean & rotate) A C D W
33 Squeegee Mount Wheel (lubricate) 1 Grease Zert A C W
34 Squeegee Lift Actuator Motor & Cable A B D
35 Battery Condition (clean & water) Load Test C W
36 Front Drive Wheel Motor Carbon Brushes C W
37 Front Drive Tire (rim fastener torque) Thread Wear W
38 Brake Band Lining Wear Adjust Free Play A B W
39 Drive Pedal Linkage (neutral return) A B
40 Steering Chain (lubricate & tension) 1/4Ó Deflection A B C
41 Steering Column (knob & plunger spring) also Universal Joint Grease A D
42 Rear Wheels W
43 Sweep Debris Tray (cylindrical only) C
NOTE: For additional service information see service manual form number 56043088 and
operators manual form number 56041537-56041539.
Defect Codes A needs adjustment Cdirty or contaminated Mmissing
Bbinding Ddamaged, bent or torn Wworn out
Lleaks
WORK COMPLETED BY: ACKNOWLEDGED BY:
Service Technician Signature Date Customer Signature Date

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 9
1 Recovery Tank Cover
2 Solution Tank Fill Cover
3 Operator’s Seat
4 Solution Tank Drain Hose
5 Steering Wheel TiltAdjust Knob
6 Brake Pedal / Parking Brake
7 Solution Flow Control Lever
8 Drive Pedal, Directional/Speed
9 Hopper (cylindrical models only)
10 Drive and Steer Wheel
11 Wheel Drive Circuit Breaker
12 Control Circuit Circuit Breaker
13 Emergency Stop Switch / Battery Disconnect Lever
14 Scrub Deck
15 Rear Wheel
16 Battery Compartment (under seat)
17 Recovery Tank Shutoff Float
18 Vacuum Motor Filter Housing
19 SqueegeeAssembly
20 Solution Filter
21 Recovery Tank Drain Hose
22 Machine Battery Connector
23 Control Panel
24 Squeegee Tilt Adjust Knob
25 Tie Down Locations (3)
KNOW YOUR MACHINE
1
2
3
4
5
6
7
810
11
12
13
14
15
16
17
18
19
20
21
25
23
24
9
22
25

10 - FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
A Scrub OFF Indicator
B Scrub OFF Switch
C Scrub Pressure Decrease Indicator
D Scrub Pressure Decrease Switch
E Scrub Pressure Increase Indicator
F Scrub Pressure Increase Switch
G Scrub Pressure / Hourmeter Display
H Wand Switch Indicator
I Wand Switch
J Key Switch
K Battery Condition Indicator
L Speed Select Switch
M Speed Select Indicator
N Horn Switch
O Vacuum Switch
P Vacuum System Indicator
Q Solution System Indicator
R Solution Switch
CONTROL PANEL

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 11
FUNCTIONAL DESCRIPTION OF CONTROL BUTTONS:
The controls on theAdvenger were designed with one touch operation in mind. For single pass scrubbing the user can simply depress one switch
and all systems on the machine will be ready to go.
For most single-pass scrubbing operations, the operator should only need to use the top three switches on the control panel. These are the Scrub
System Off, Scrub Pressure Decrease, and Scrub Pressure Increase switches.
Scrub Off Switch (B) - Pressing this switch when the unit is in a scrub mode will cause the following to occur:
• The scrub brushes will turn off and the scrub deck will raise to the up position
• The solution flow will be stopped
• The first time that this switch is pressed, the vacuum/squeegee system will NOT be turned off. This is so that any remaining water may be picked up without
having to turn the vacuum back on. If this switch is pressed a second time (pressed after the scrub system has been turned off) the squeegee will raise and
the vacuum will shut of after a 10 second delay.
• The travel speed limit will return to the transport speed setting.
Scrub Pressure Decrease Switch (D) – If the scrub system is off, pressing this switch will cause the following to occur:
• The scrub system will be enabled with the scrub pressure set to the last used setting and the scrub deck will be lowered
• The vacuum system will be enabled and the squeegee will be lowered
• The solution system will be enabled
• The travel speed will be limited to the scrub speed setting
• As soon as the throttle is moved from the neutralposition the scrub brusheswill start turning andthe vacuum willturn on. If the directionis forward thesolution
flow will start. If the direction is reverse, the squeegee will raise and the solution flow will be stopped.
If the scrub system is already enabled when this switch is pressed, the scrub pressure will decrease. If the switch is held, the pressure will decrement until the
minimum setting of 1 is reached.
Scrub Pressure Increase Switch (F) – If the scrub system is off, pressing this switch will cause the following to occur:
• The scrub system will be enabled with the scrub pressure set to the last used setting and the scrub deck will be lowered
• The vacuum system will be enabled and the squeegee will be lowered
• The solution system will be enabled
• The travel speed will be limited to the scrub speed setting
• As soon as the throttle is moved from the neutralposition the scrub brusheswill start turning andthe vacuum willturn on. If the directionis forward thesolution
flow will start. If the direction is reverse, the squeegee will raise and the solution flow will be stopped.
If the scrub system is already enabled when this switch is pressed, the scrub pressure will increase. If the switch is held, the pressure will increment until the
maximum programmed limit is reached (default = 9).
Wand Switch (I) – This switch is used when an external scrub wand is used. Pressing this switch will turn the vacuum on continuously without
regardtothe throttle position. Itwillalso enable the optionalsolutionpump. If the scrubsystemwas on itwillbe turned off.This includes turningoff
the scrub brushes and raising the scrub deck, turning the solution flow off (to the scrub deck) and raising the squeegee. NOTE: automatic shutoff
of the vacuum motor when the recovery tank is full is disabled when the wand is enabled. The float in the recovery tank will still prevent water from
entering the vacuum motor, but the motor will not shut off.
Key Switch (J) – Main power switch
Speed Select Switch (L) – Thisswitch willallow theoperator toselectthetransportspeedlimitwhilethescrubsystemis enabledthereby allowing
scrubbing at a higher rate of speed. This option can be disabled if desired. See the programming section for details.
The transport and scrub speed limits can be programmed using a Curtis handheld programmer. Refer to the Curtis Speed Control manual section
for details.
Horn Switch (N) – This switch will sound the horn as long as the switch is held.
The horn also functions as an automatic back-up alarm when the throttle is moved to the reverse position. The volume of the back-up alarm
is programmable. It can also be programmed to provide an annunciation feature that will sound whenever the machine is in motion. See the
programming section for details.
Vacuum Switch(O)–Thisswitchisusedtoturnthevacuumsystemonoroff.Whenthevacuumis onthesqueegeewill lower(unlessthemachine
is in reverse) and when the vacuum is off the squeegee will raise. Pressing this switch will alternate between on and off. The vacuum will only turn
on when the throttle is moved from the neutral position. It will remain on for 10 seconds after the throttle returns to neutral.
The vacuum also has an automatic shutoff feature that will turn the vacuum and scrub systems off if the recovery tank becomes full. This feature
can be disabled if desired. See the programming section for details.
Solution Switch (R) –Thisswitchis used toturnthe solutionsystemon or off.Pressing this switchwhen the scrubsystemhas been activatedwill
alternate between on and off. The solution flow will only turn on when the throttle is moved from the neutral position in the forward direction. The
solution flow will turn off if the throttle returns to neutral or is moved to reverse.
Pressing this switch when the scrub system is off will momentarily turn the solution flow on to allow pre-wetting of the scrub brushes.
KNOW YOUR MACHINE

12 - FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
DESCRIPTION OF INDICATORS ON THE CONTROL PANEL:
In general, the following guidelines apply to the control panel indicators:
A steady red indicator means that the function is inhibited for some reason. For example, if the scrub system is off and the operator is not on the
seat, the scrub system indicator will be red indicating that the system cannot be turned on until the operator is on the seat.
A flashing red or yellow indicator means that a fault has occurred in the particular system.An example of this would be an over-current fault.
A yellow indicator means that the particular function has been enabled but is not currently on. For example, if a scrub mode is selected and the
throttle is in neutral, the scrub system, vacuum, and solution indicators will all be yellow indicating that the systems are enabled and ready to turn
on when the throttle is moved to forward or reverse.
A green indicator means that the particular system is on.
A flashing green indicator means that the particular system is in a delayed-off condition.An example of this is when a scrub mode is selected and
the throttle goes from forward or reverse to neutral. When this happens the vacuum indicator will flash green indicating that the vacuum is still on
but that it will be turning off after the delay period.
Scrub Off Indicator (A):
• This indicator will be green if the scrub system is off and ready to be activated.
• This indicator will be red if the scrub system has been turned off and the scrub deck is not up yet, or if the scrub deck is up and there is no weight on the
seat.
• This indicator will flash red if there is a fault in the scrub system.
• This indicator will be off if the scrub system has been activated.
Scrub Pressure Decrease Indicator (C):
• This indicator will be yellow if the scrub system is enabled but the drive pedal is at neutral and the current scrub pressure is at 2 or more.
• This indicator will be green if the scrub system has been turned on, the current scrub pressure is at 2 or more and the machine is moving in either direction.
• This indicator will be off if the scrub system has been turned OFF or the scrub pressure is set at 1.
Scrub Pressure Increase Indicator (E):
• This indicator will be yellow if the scrub system is enabled but the drive pedal is at neutral and the current scrub pressure is at 8 or less.
• This indicator will be green if the scrub system has been turned on, the current scrub pressure is at 8 or less and the machine is moving in either direction.
• This indicator will be off if the scrub system has been turned OFF or the scrub pressure is set at 9.
Scrub Pressure/Hourmeter Display (G):
The single character display on the control panel is primarily used as a display for the scrub pressure. This display is also used to display the
machine hours and any control system fault codes.
If any of the systems on the machine are on or if the throttle is not in neutral, the display will indicate the scrub pressure setting (1-9). If the scrub
system is off the display will indicate 0.
Upon power-up or if the machine has been idle for at least ten seconds with all systems turned off, the display will indicate the machine hours. The
format for the display of the hours is as follows:
Example 123.4 hours
• The display will indicate 1 followed by a short blank period
• The display will indicate 2 followed by a short blank period
• The display will indicate 3 followed by a short blank period
• The display will indicate _ followed by a short blank period, this is used as a decimal point to indicate tenths of hours
• The display will indicate 4 (tenths) followed by a long blank period
• The display sequence will repeat
Wand Switch Indicator (H):
• This indicator will be green if the Wand Switch has been turned ON.
• This indicator will be off if the Wand Switch has been turned OFF.
Speed Selector Indicator (M):
• This indicator will be green if a scrub mode has been selected and the faster scrub speed has been selected.
• This indicator will be off if the Speed Select Switch has been turned OFF.
Vacuum System Indicator (P):
• This indicator will be green if the vacuum is on.
• This indicator will flash green if the vacuum is in the 10 second delayed-off condition.
• This indicator will be yellow if the vacuum is enabled but the drive pedal is in neutral.
• This indicator will flash yellow if there is a vacuum system fault.
• This indicator will be off if the vacuum is disabled and turned off.
Solution System Indicator (Q):
• This indicator will be green if the solution is on.
• This indicator will be yellow if the solution is enabled but the drive pedal is in neutral.
• This indicator will flash yellow if there is a solution system fault.
• This indicator will be off if the solution is disabled and turned off.
KNOW YOUR MACHINE

FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 13
DESCRIPTION OF THE BATTERY CONDITION INDICATORS
The battery condition indicator (J) consists of three lights, a green (G), a yellow (Y), and a red (R). The voltage indication will change based on the
cutoff level (standard or alternate) selected in the control unit. The battery voltage ranges for the various indications are listed below:
Standard Alternate
Green 34.00+ 34.50+
Green & Yellow 33.00-33.99 34.00-34.49
Yellow 32.00-32.99 33.50-33.99
Yellow & Red 31.50-31.99 33.00-33.49
Red 31.00-31.49 32.50-32.99
Flashing Red/Cutoff <31.00 <32.50
NOTE: Refertoservicemanualforselectionofalternatecut-offlevel. Oncethelowvoltagecutoutlevelhasbeenreached(flashingredindicator)the
batteries must be FULLY recharged to reset the battery condition indicator. The scrub system will not function until the indicator has been reset.
DESCRIPTION OF HOURMETER / STATUS DISPLAY
The single character display in the upper right corner of the control panel is primarily used as a display for the hourmeter function. This display is
also used to display the following information depending upon which mode the control is in:
•Error codes*
•Brush pressure adjustment setting for the scrub mode*
•Display of control system default parameters*
•Recovery tank FULLindicator*
* NOTE:Reference(intheElectricalSystemmanualsection)theMainControlBoardTroubleshootingGuideandtheControlBoardSpecialProgramOptionssections.
These sections will explain the machine error code descriptions and scrub system controller default parameter changes.
KNOW YOUR MACHINE

14 - FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
STEERING SYSTEM
STEERING COLUMNASSEMBLY SHROUD REMOVAL
Upper Column
1See Figure 1. Remove the center WheelAdapter (A) from the steering wheel. Pry it off using a flat bladed screwdriver.
2RemovethesteeringshaftretainerHexNut(B) (usea3/4”socketwrench)andthetwoWashers(C&D). Nextpullstraightbackonthesteering
wheel to remove it from the metal WheelAdapter (E).
3Pull off the keyed metal wheel adapter from the steering shaft by using a two-jaw gear puller. With the wheel adapter off the loose Plastic Trim
Cup (F) can now be removed.
4Remove the (4) Screws (G) securing the Column Shroud (H) and pull it off from the Column Base (I).
Lower Column
1Tilt the steering wheel column as far back (close to the seat) as possible.
2Remove the tilt column release Knob (J) (threaded) from its shaft.
3Remove the (4) Screws (K) securing the Lower Shroud (L) and next pull the shroud far enough away from the column base to clear the tilt
release shaft through the shroud opening. Note: This will take some effort in prying the flexible plastic shroud around the movable tilt shaft.
4Grip the shroud and pull up to completely release it from the steering column base and the foot brake assembly.
FIGURE 1
FRONT
J
B
D
K
G
CE
F
A
I
L
H
View from back
side of panel (I)
Remove plug
to access/grease
universal joint

STEERING SYSTEM
FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 15
STEERING CHAIN REMOVAL AND TENSIONING
1Turn the master key switch off and separate the battery pack emergency disconnect (13).
2SeeFigure2. Fromunderneaththefrontofthemachineloosenthe(4)(M)Screwsandpushthelowersteeringcolumntotherearofthemachine.
This is done to separate the Chain (N) from the Steer Sprocket (O). Service Note: Use a 5/8” socket with 3” extension to loosen screws and
also correctly position the large hole in the Steer Plate (P) in order to access the far back left screw.
3Remove both Master Links (Q) that secure the chain to the Steer Plate (P) then remove the chain from the chassis.
4Reassemblepartsinreverseorderandadjustchaintensionsothatthereisabout3/16”-1/4”(4.7–6.4mm)totaldeflectionwithmoderatepressure
applied at the Mid-point (R) (as shown). Service Tip Note: Use a pry bar or shims between the chassis and steer column to help secure the
tension adjustment when tightening the (4) steering column mounting screws.
Maintenance
1Inspect the chain for looseness and binding, re-tension the chain to 3/16”-1/4” (4.7 – 6.4mm) deflection by following the above adjustment
instructions.
2Keep all of the steer chain links oiled to prevent excessive wear and binding.
FIGURE 2

16 - FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
WHEEL DRIVE SYSTEM
GENERAL FUNCTIONAL OVERVIEW
See Figures 1 & 2. An 840-watt 1.1 HP (permanent magnet) 36V motor/gear transmission combination wheel (M3) unit is used to propel all
machines. ACurtismodel1228PMCsolidstate speedcontroller (A1)regulates (outputs)thevariablespeedFwd/Revwheeldrive motorfunctions.
The controller unit is located to the left of the operator seat, behind the electrical access panel. The potentiometer R1 mounted to the operator’s
foot pedal, inputs to the (A1) controller the machine operator’s desired speed and directional demands.
DRIVE MOTOR SYSTEM CONTROLLER FUNCTION OVERVIEW
See Figure 2. To make theA1 speed controllers internal control circuits operational (power it up) the two switches S1 (key) and S2 (seat) must be
closed. This circuit inputs a positive (+) 36V to the A1 speed controls pin terminal #5 (*KSI). The F2 circuit breaker 45Amp supplies the positive
highcurrent (load)circuitinputtothe B+controller terminal(Brn/Blk wire). Theblackwirefromthe negative(-) batterystandoffsuppliesthe battery
ground input to the B- terminal for both the control and load circuits.
See Figure 3. Depressing the foot pedal in either Fwd or Rev will move the 5K Ohm (R1) potentiometer shaft off its centered balanced (neutral)
setting of approximately 2500 Ohms. With this pot shaft movement the pot’s resistance value changes which generates a variable voltage signal
(0-5 volts). These control board voltage input signals are what energizes the Fwd & Rev directional relays, which selects the motor polarity and
what also manages switches the battery voltage On and Off (**PWM) that varies the motor speed.
*KSI: Key Switch Input
**PWM:Pulse WidthModulation,alsocalled“chopping” isa techniquethat switchesbattery voltagetothemotorON andOFF veryquickly,thereby
controlling the speed of the motor.
DRIVE MODE SELECTION OPERATION OVERVIEW
TheA1 speed Controller allows operation in two distinct modes: mode 1 (M1) & mode 2 (M2).
Mode 1 (M1) is the transport speed range and is automatically selected when the scrub system is OFF (deck up). This allows maximum variable
vehicle speed operation.
Mode 2 (M2) is the reduced slower scrub speed range and is automatically selected when the scrub mode is ON (deck down).
The operator can over-ride the reduced M2 scrub speed by pressing the dash panel Speed Select Switch (L). This allows the operator to scrub at
the higher M1 transport speed. Note the Indicator Light (M) will be green when the faster transport speed is selected.
THE SPEED SELECTOR CIRCUIT INPUT
The main controller E1 will output a 30-31 volt (approximately) battery positive (B+) signal from the speed limit terminal J4-2 (Brn/Wht wire). This
positive signal connection delivers the required A1 speed control input to pin #8. The controller is now in scrub speed (mode 2) and the speed
controlmodeselectisswitchedON. PressingthedashpanelSpeedSelectSwitch(L)itsIndicatorLight(M)turnsON. Thisactionleavesthespeed
control input (pin #8) floating and actively switches it Off, 0 volts (pulling it to B-) changing the output to the transport speed (mode 1).
Note: The maximum machine drive wheel speed setting for the two drive modes 1 & 2 can be changed by using the Curtis handheld programmer.
Reference the Curtis programmer instructions found in the electrical system manual section to change speed settings from their original factory
specifications.

WHEEL DRIVE SYSTEM
FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S - 17
S1 E1
A1
F2
M3
R1
S2
FIGURE 1
FIGURE 2
S2
SW,SEAT
21
F2
CIRCUIT BREAKER, 45 AMP
M3
MOTOR
WHEEL DRIVE
Amps=23
M
S1
SW
SPSTKEY
F3
CIRCUIT BREAKER, 8 AM P
F4
FUSE, 1 A.
R1
POT. 5K OHM
1
2
3
BLK
RED
RED BRN/YEL
BRN/YEL
BRN
GRA
VIO
YEL/BLK
RED/GRN
BLU/BLK
RED/BLK
BRN/BLK
BLK
BRN/WHT
BLK
BLK
BRN
ORN
ORN
ORN/BLU
ORN
VIO
YEL
YEL
B+1
B+2
KEY SW.
SEAT SW.
POT. OUT
POT. IN
REV.
FOR./REV.
PIN 13 -- POT. LO
PIN 3 -- POT.HI
PIN 4 -- POT. WIPER
PIN 16- REV.ALARM
PIN 6 -- BRAKE
B+
B-
M2
M1
PIN 8 -- SLOW/FAST
ACC
SOLUTION
VACUUM
BRUSH
B- 1 B- 2 B- 3 B- 4
A1
SPEED CONTROLLER
INTERFACE
THERMISTOR
I -- VAC I -- BRUSH
E1
CONTROL BOARD
HORN -
HORN +
SPEED LIMIT
J4-8 J2-5
J3-5
J3-6
J4-12
J4-6
J4-2
J2-1
J2-2 J2-3
J2-8
J4-7
J4-1
J2-7 J2-6 J2-10
J3-1 J3-4 J3-3 J3-2 J4-11 J4-10 J4-4
J4-9
J4-3
PIN5 -- KSI
STATUS J4-5
PIN9 -- STATUS
J2-9 PIN 18 -- SPEED LIM IT
GND

+
21
212121

18 - FORM NO. 56043088 /Advenger™/ BR 600S, 650S, 700S, 800S
WHEEL DRIVE SYSTEM
FIGURE 4
R1 Voltage Values
0 – 2.5V Reverse
2.5 – 5V Forward
FIGURE 3
This drawing shows additional controller input circuit detail. The R1 pot is shown in the neutral position. Resistance is measured between pot low
and pot wiper.
R1
5K Ohms
E1
Main Control
Board (Partial)
BLK
YEL
BLK
VIO
2
View:Non-stem end
Speed Limit
Pot. LO
Pot. HI
J2-9
J4-9
J4-3 VIO
YEL
GRA
YEL
YEL
GRA
BLK
HI LO
WIPER
A1Speed Control
Pin Connection
FRONT
VIO
VIO
13 49
1 0 1 3 18
B+ B- M2 M1 LOGIC PROG
12 3 45 6 789
1 01 1 12 13 1 4 1 5 16 17 1 8
Used (9pins)
Not Used (9pins)
POT HIGH
POT WIPER KSI
AUXILIARYDRIVER
(scrub) MODE(M1,M2)
STATUS
POT LOW SPEED LIMIT
POT
A1
AUXILIARYDRIVER
(rev / alarm)
