Nilfisk-Advance EXTREME User manual

823 0064 000 c
User Manual
Betriebsanleitung
Instructions d’utilisation
Instrucciones de manejo
Instruções de operação
Istruzioni sull’uso
Gebruiksaanwijzing
Driftsinstruks
Driftsvejledning
Brugsvejledning
Käyttöohje
Nilsk Extreme

A
21
22
20
19
14
1817
16
15
27
26
25
24
28
29
30
31
23
Eco, X100, X110 X150, X200, X210
X250, X300
Eco, X100, X110,
X150, X200, X210
X300
X300
X250, X300
X210, X300

English 4
Deutsch 12
Français 20
Español 28
Português 36
Italiano 44
Nederlands 52
Svenska 60
Norsk 68
Dansk 76
Suomi 84
Illustrations 92-93
WEEE 94-95
B
www.nilfisk.com

4
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN
Table of contents
Overview 4
Display symbols 4
Safety instructions 5
Instructions for use 6
Cleaning tips 9
Trouble shooting 10
Service and maintenance etc. 10
Guarantee and service 11
Display symbols
The dust bag is full and
needs to be changed.
Flashing indicator
- early warning, the dust
bag soon needs to be
changed.
The HEPA filter needs to
be changed.
Flashing indicator - the
machine is connected
to a wall socket and in
standby mode - X150,
X200, X210, X250 and
X300.
Machine ON - Eco,
X100, and X110.
Indicates current power
level.
Specifications and details are subject
to change without prior notice.
Overview - (illustrations inside front cover)
1 On/off button
2 Dust bag indicator, mechanical
3 On/off button, touch control
4 Dust bag indicator, electronic
5 Power level indicator
6 HEPA filter indicator
7 Power level 1-2-3, touch control
8 On/off button
9 Dust bag indicator, electronic
10 Power level indicator
11 HEPA filter indicator
12 On/off button and
power level 1-2-3-4-5,
remote control
13 Sliding valve
14 Parking bracket
15 Cable rewinder
16 Open/close button, accessory lid
17 Active carbon filter
18 Prefilter
19 Dust bag
20 Open/close button, dust container
21 Outlet for electro nozzle
22 Parking bracket
23 Rating plate
24 HEPA filter
25 Crevice nozzle
26 Upholstery nozzle
27 Brush nozzle
28 Hard floor nozzle (not standard on
all models)
29 Combination nozzle
30 Turbo nozzle (not standard
on all models)
31 Electro nozzle (optional accessory)
Welcome!
Thank you for choosing a
Nilfisk Extreme vacuum cleaner.

5
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN
Safety instructions
• Do not use the machine without
dust bag and filters properly fitted.
• This machine is not intended for
the suction of hazardous materials
or gas, doing so may expose
people to serious health risks.
• The machine must not be used for
the suction of water or other
liquids.
• Do not pick up sharp objects such
as needles or pieces of glass.
• Do not pick up anything that is
burning or smoking such as
cigarettes, matches or hot ashes.
• Use and store this machine indoors
and in a dry environment, 0 °C to
60 °C.
• Do not use the machine outdoors.
• Do not handle the machine with
wet hands.
• Turn off the machine before
unplugging.
• To unplug, grasp the plug, not by
pulling on the cord. Do not carry or
pull the machine by the cord.
• The machine must not be used if
the cord shows any sign of
damage. Regularly inspect the
cord for damage, in particular if it
has been crushed, shut in a door
or run over.
• Do not use the machine if it
appears faulty. Have the machine
inspected by an authorized service
center if the machine has been
dropped, damaged, left outdoors or
has been exposed to water.
• No changes or modifications to the
mechanical or electrical safety
devices should be made.
• All repair must be carried out by an
authorized service center.
• Use only original dust bags,
original filters and original
accessories from your local dealer.
Use of unauthorized dust bags and
filters will void the warranty.
• Turn off the machine and unplug
before starting dust bag or filter
change, grasp the plug, not by
pulling on the cord.
• Do not use the machine as a toy.
Do not leave children with the
machine without supervision.
• This appliance is not to be used by
children or persons with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or
instruction. Children must be
supervised not to play with the
appliance.
• If the supply cord cord is dama-
ged, it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order
to avoid hazard.
The equipment meets the
requirements in EN 61000-3-11, and
connection to the public mains is
possible following consultation with
the power supplier.
The equipment may only be
connected to the mains with a
network impedance that is below
0,43 ohm. Network impedance at
the point of delivery can be obtained
from the power supplier. If the mains
has a higher network impedance,
momentary drops in mains voltage
may occur during start/operation
of the equipment. This may also
affect or disrupt the operation of
other equipment, e.g. flashing
lights, particularly equipment that is
connected to the same service line.

6
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN Instructions for use
Before using the machine make sure
that the voltage shown on the rating
plate underneath the machine
corresponds with the mains voltage.
The machine is supplied with dust bag
and prefilter.
Start and stop
Start
Pull out the cord and plug the machine
to a wall socket.
Eco, X100,
X110 On/off button.
X150, X200,
X210 Touch control, one half on/off,
other half power level
1-2-3.
X250, X300 On/off button on the
machine and also
remote control on the
bent tube with
on/off button and
power level 1-2-3-4-5.
Stop
Turn off the machine and unplug.
Unplug by grasping the plug, not by
pulling on the cord.
Models with touch control - X150,
X200 and X210
Power can alter between three
settings. Current setting is shown on
the display.
Models with remote control - X250,
X300
Power can alter between five
settings. Current setting is shown on
the display.
Connecting hose, tube and nozzles
1. Insert the hose connector into the
suction inlet and turn it clockwise
until it engages.
2. Connect the bent tube to the tube
and twist until they engage with a
click.
3. Connect the tube and nozzle and
twist until they engage with a click.
4. The tube is telescopic and can be
adjusted to your height.
Pull out the adjusting handle to
extend the tube, and pull back to
shorten, to desired length.
Disengage
• Disengage the nozzle from the
tube by pressing the button.
• Disengage the bent tube from the
tube by pressing the button.
• To remove the hose connection
from the suction inlet, turn
counter-clockwise.
1

7
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN
Change of dust bag and filters
The size and quality of the dust bag
and filters affect the
machine efficiency. Use of non original
dust bags or non original filters can
cause restricted air flow which may
lead to machine overload. Using non-
original dust bag or filters will void the
warranty.
Changing the dust bag
The dust bag indicator shows when to
change the dust bag.
Always use original dust bags.
1. Release the hose connection from
the suction inlet by turning the
hose connection counter-clockwise
and then remove it.
2. Open the lid by pushing the button.
3. Seal the dust bag by pulling the
cardboard flap.
4. Remove the dust bag.
5. Insert the new dust bag by guiding
the cardboard into the tracks and
push it down.
6. Unfold the new dust bag carefully.
Check that the dust bag is correctly
fitted.
7. Close the lid.
8. Insert the hose connection into the
suction inlet and twist it clockwise
to lock it.
2
Changing the prefilter
The prefilter protects the motor by
absorbing micro-particles that the dust
bag can not keep. Change the prefilter
with every fourth dust bag. The pre-
filter is located behind the dust bag.
Always use original filters.
1. Release the hose connection from
the suction inlet by turning the
hose connection counter-clockwise
and then remove it.
2. Open the lid by pushing the button.
3. Seal the dust bag by pulling the
cardboard flap.
4. Remove the dust bag.
5. Take out the filter holder with
prefilter.
6. Open the filter holder.
7. Take out the prefilter.
8. Fit the new prefilter and close the
filter holder. Check that the prefilter
is correctly fitted in the holder.
9. Put the filter holder on the pin and
push in place.
10.Insert the new dust bag by guiding
the cardboard into the tracks and
push it down.
11.Unfold the new dust bag carefully.
Check that the dust bag is correctly
fitted.
12.Close the lid.
13.Insert the hose connection into the
suction inlet and twist it clockwise
to lock it.
3

8
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN Changing the active carbon filter
The active carbon filter removes bad
smell from the exhaust air. Change the
active carbon filter 1-2 times a year.
The active carbon filter is located
behind the dust bag and prefilter.
Always use original dust bags and
filters.
1. Release the hose connection from
the suction inlet by turning the
hose connection counter-clockwise
and then remove it.
2. Open the lid by pushing the button.
3. Seal the dust bag by pulling the
cardboard flap.
4. Remove the dust bag.
5. Take out the filter holder.
6. Remove the old active carbon filter.
7. Fit the new active carbon filter.
8. Insert the filter holder on the pin
and push in place.
9. Insert the dust bag. If the dust bag
is closed push the cardboard flap
down to open it. Check that the
dust bag is correctly fitted.
10.Close the lid.
11.Insert the hose connection into the
suction inlet and twist it clockwise
to lock it.
Changing the HEPA filter
The HEPA filter cleans the exhaust
air from micro particles the dust bag
can not keep. The HEPA filter can
not be brushed or washed clean. The
X150, X200, X210, X250 and X300
models have an HEPA filter indicator
that shows when to change the HEPA
filter. Always use original dust bags
and filters.
1. Open the lid on the machine under-
side with a coin or a screw driver.
2. Take out the HEPA filter.
3. Insert the new HEPA filter. Check
that the HEPA filter is correctly
fitted.
4. Put the lid back and close it with a
coin or a screw driver.
4Adjust the suction power
Models with a sliding valve on the
hose handle - Eco, X100, X110,
X150, X200 and X210
The suction power is maximal with
the sliding
valve closed
and minimal
when all open.
Adjust the
suction power
by putting the
sliding valve
in the desired
position.
Models with three step adjustment
- X150, X200 and X210
The suction power
is adjusted with
the sliding valve
and also with the
touch control on
the machine.
Models with five step adjustment
remote control - X250, X300
The suction power
is adjusted on the
remote control on
the hose handle.
Hose handle with
remote control
battery replacement,
battery type CR2032
1. Carefully remove the remote control
unit with a small, flat tool.
2. Remove the old
battery - replace
with new type
CR2032.
3. Carefully reas-
semble the con-
trol unit back to
the hose handle
by pushing it in
place at handle.
5
5b
Eco, X100, X110,
X150, X200, X210
X250, X300
X150, X200, X210

9
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN
Cleaning tips
Adjust the suction power by means
of the touch control or remote control
or the sliding valve on the bent tube
depending on model.
Crevice nozzle
Use the crevice nozzle for narrow
spaces.
Upholstery nozzle
Use the upholstery nozzle for
upholstered furniture.
Brush nozzle
Use the brush nozzle for curtains and
window sills.
Hard floor nozzle
Use the nozzle for hard floors.
Combination nozzle
Adjust the combination nozzle
depending on type of floor.
Turbo nozzle
Use the turbo nozzle for efficient
carpet cleaning.
Electro nozzle
Use the electro nozzle for deep
cleaning of carpets.
The crevice, upholstery and brush
nozzle are located under the acces-
sory lid. The accessoriy lid is opened
by pressing the release button down-
wards. The lid is closed by pushing at
the centre of the button.
The different models of these vacuum
cleaners can include different nozzles.
Thermal fuse
The machine is fitted with a thermal
fuse, which prevents the machine from
overheating. If the thermal fuse blow,
the machine automatically switches off
the motor and must cool before it can
be started again.
Restart
1. Turn off the machine and unplug
from the wall socket.
2. See to that nothing blocks the air
flow through bent tube, hose, tube,
nozzle, dust bag or filters.
3. Let the machine cool.
4. Plug in the machine again and
push start button. The machine will
not start until cool enough. If the
machine does not start turn it off
and unplug. Try again in a while.
WARNING
When activating the automatic
cord rewind, care must be taken
as the plug at the end of the cord
can swing during the last part of the
rewinding. It is recommended that you
hold on to the plug while rewinding.
6
9
7
8
13
10
11
12
Parking the tube and nozzle
There are two grooves for parking.
One located on the underside of the
machine to use when machine stands
on the back. The other on the back
of the machine, to be use when the
machine is standing on its wheels.
Standby mode
Model X150, X200, X210, X250 and
X300 automatically puts the machine
in standby mode when the nozzle is
parked in the groove on the machine
back side.

10
Extreme
DE
FR
ES
PT
I
T
NL
SV
NO
DA
FI
EN Service and maintenance
• Store the machine indoors and in a
dry environment.
• Change the prefilter with every
fourth dust bag. The dust bag
package includes four dust bags
and one prefilter.
• Clean the machine surface with a
dry cloth or a damp cloth with a
little cleaning agent.
• Order original accessories from a
local dealer.
• Service – contact your local dealer.
Recycling and scrapping
Recycle the wrapping and scrap the
machine according to recommen-
dations from the local authorities.
Cut the cord as short as possible to
avoid that someone gets injured on
the scrapped machine.
Environmental commitment
This machine is designed with the
environment in mind. All plastic parts
is marked for recycling.
Responsibility
Nilfisk disclaim all responsibility for all
damage caused by incorrect use or
modification of the machine.
Information
For more information see
www.nilfiskextreme.com
Guarantee
The warranty can vary between
different countries. Contact your local
dealer for information.
Trouble shooting
Repair or service of electrical
components as cord or motor, must
only be carried out by an authorized
service center.
If the machine
does not start See to that the plug is correctly fitted to
the wall socket.
A fuse in the
building may have
blown and needs to
be changed.
The cord or plug
can be damaged
and must be
repaired by an
authorized service
center.
Reduced suc-
tion power The dust bag can be full and needs
to be changed, see
instructions.
The prefilter, HEPA
filter or active
carbon filter can be
blocked and have
to be changed, see
instructions.
The bent tube,
hose, tube or
nozzle can be
blocked and needs
to be cleaned.
If the machine
stops The thermal fuse may have blown,
see instructions.
Accessory – The
electro nozzle
can be blocked.
Turn off the
machine and
unplug. Clean the
nozzle.
