revised 10/00 Form Number 56041227
OPERATOR MANUAL
Advance MODELS 56393500(UHSB 20)
56393600(UHSBD 20 / OBS)
W irlamatic™ UHSB 20
W irlamatic™ UHSBD 20

2 - FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20
_____________________________________________________________________________________________________________________________
Page
Introdu tion ......................................................................................................................3
Parts and Servi e ............................................................................................................3
Nameplate .......................................................................................................................3
Un rating the Ma hine .....................................................................................................3
Cautions and Warnings ...................................................................................................4
Importantes Mesures de Sé urité ....................................................................................5
Battery Installation ...........................................................................................................6
Know Your Ma hine .........................................................................................................7
Preparing the Ma hine for Use ........................................................................................8
Operating the Ma hine ....................................................................................................9
After Use ..........................................................................................................................9
Maintenan e ..................................................................................................................10
Troubleshooting .............................................................................................................10
TABLE OF CONTENTS

FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20 - 3
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
This manual will help you get the most from your Whirlamatic. Read it thoroughly before operating the ma hine.
Note: Bold num ers in parentheses indicate an item illustrated on page 7.
This produ t is intended for ommer ial use only.
_____________________________________________________________________________________________________________________________
PARTS AND SERVICE
Repairs, when required, should be performed by your Authorized Nilfisk-Advan e Servi e Center, who employs fa tory trained servi e personnel, and maintains
an inventory of Nilfisk-Advan e original repla ement parts and a essories.
Call the NILFISK-ADVANCE DEALER named below for repair parts or servi e. Please spe ify the Model and Serial Number when dis ussing your ma hine.
(Dealer, affix servi e sti ker here.)
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
NAME PLATE
The Model Number and Serial Number of your ma hine are shown on the Nameplate on the bottom of the ma hine. This information is needed when ordering repair
parts for the ma hine. Use the spa e below to note the Model Number and Serial Number of your ma hine for future referen e.
MODEL NUMBER
SERIAL NUMBER
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
UNCRATE THE MACHINE
When the ma hine is delivered, arefully inspe t the shipping arton and the ma hine for damage. If damage is evident, save the shipping arton so that it an
be inspe ted. Conta t the Nilfisk-Advan e Customer Servi e Department immediately to file a freight damage laim.
INTRODUCTION

4 - FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20
IMPORTANT SAFETY INSTRUCTIONS
This ma hine is only suitable for ommer ial use, for example in hotels, s hools, hospitals, fa tories, shops and offi es other than
normal residential housekeeping purposes.
Read all instru tions before using.
WARNING!
To redu e risk of fire, ele tri sho k, or injury:
*Use only as des ribed in this manual. Use only manufa turer’s re ommended atta hments.
*This ma hine shall be used only by properly trained and authorized persons.
*This ma hine is for dry use only and shall not be used or stored outdoors in wet onditions.
*Do not allow to be used as a toy. Close attention is ne essary when used by or near hildren.
*Keep sparks, flame and smoking materials away from batteries. Explosive gases are vented during normal operation.
*Charging the batteries produ es highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away from open
flame. Do not smoke while harging the batteries.
*Remove all jewelry when working near ele tri al omponents.
*Turn the key swit h off (O) and dis onne t the batteries before servi ing ele tri al omponents.
*Never work under a ma hine without safety blo ks or stands to support the ma hine.
*Do not dispense flammable leaning agents, operate the ma hine on or near these agents, or operate in areas where flammable
liquids exist.
*Do not lean this ma hine with a pressure washer.
*This ma hine is not approved for use on publi paths or roads.
*Do not put any obje t into openings. Do not use with any opening blo ked; keep free of dust, lint, hair, and anything that may
redu e air flow.
*Do not operate this ma hine on ramps or in lines of more than 5 degrees.
*When operating this ma hine, ensure that third parties, parti ularly hildren, are not endangered.
*Before performing any servi e fun tion, arefully read all instru tions pertaining to that fun tion.
*Do not leave the ma hine unattended without first turning the key swit h off (O), removing the key and applying the parking brake.
*Turn the key swit h off (O) before hanging the pad, and before opening any a ess panels.
*Take pre autions to prevent hair, jewelry, or loose lothing from be oming aught in moving parts.
*Do not use without dust bag and / or filters in pla e.
*Do not stand on the pad housing.
*This ma hine is not suitable for pi king up health endangering dust.
SAVE THESE INSTRUCTIONS

FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20 - 5
IMPORTANTES CONSIGNES DE SECURITE
Cette ma hine ne onvient qu´à un usage industriel, par exemple dans les hôtels, les é oles, les hôpitaux, les usines, les boutiques
et les bureaux et autres utilisations que le ménage domestique résidentiel.
Lisez toutes les instru tions avant l´utilisation.
ATTENTION!
Pour réduire le risque d´in endie, d´éle tro ution, ou de blessure:
*Ne l´utilisez que omme dé rit dans e manuel. N´utilisez que des atta hements re ommandés par le fabri ant.
*Cette ma hine ne doit être utilisée que par des personnes proprement formées et autorisées.
*Cette ma hine n´est destinée qu´à un usage à se et ne doit pas être utilisée ou emmagasinée à l´extérieur par des temps
pluvieux.
*Ne permettez pas que l´on l´utilise omme un jouet. Une attention parti ulière est né essaire lorsqu´elle est utilisée par ou près
d´enfants.
*Gardez toute étin elle, flamme ou matériaux fumants éloignés des batteries. Des gaz explosifs sont ventilés pendant un
fon tionnement normal.
*Charger les batteries produit du gaz hydrogène hautement explosif. Ne hargez les batteries que dans des zones bien aérées,
loin de toute flamme. Ne fumez pas lors de la harge des batteries.
*Retirez tout bijou lorsque vous travaillez près des omposants éle triques.
*Tournez l´interrupteur à lé sur (O) pour l´éteindre et dé onne tez les batteries avant l´entretien des omposants éle triques.
*Ne travaillez jamais sous une ma hine sans ale de sé urité ou de so les pour supporter la ma hine.
*Ne répandez pas d´agents nettoyants inflammables, n´utilisez pas la ma hine sur ou près de es agents, ou ne l´utilisez pas
dans des zones où es produits existent.
*Ne nettoyez pas ette ma hine ave un jet à haute pression.
*Cette ma hine n´est pas destinée à un usage sur les voies publiques.
*Ne mettez au un objet dans les ouvertures. Ne l´utilisez pas ave une ouverture de bou hée; gardez la à l´abri de la poussière,
de la harpie, des heveux et de tout e qui pourrait réduire le flux de l´air.
*N´utilisez pas ette ma hine sur des rampes ou des plans in linés de plus de 5 degrés.
*Lors de l´utilisation de ette ma hine, assurez - vous que des tiers, parti ulièrement des enfants, ne soient pas en danger.
*Avant d´entreprendre toute fon tion d´entretien, lisez attentivement toutes les instru tions se rapportant à ette fon tion.
*Ne laissez pas la ma hine sans attention sans avoir d´abord tourné la lé sur (O) pour l´éteindre, avoir enlevé la lé et serré le
frein à main.
*Tournez la lé sur la position arrêt (O) avant de hanger le disque, et avant d´ouvrir tout panneau d´a ès.
*Prenez les pré autions né essaires pour éviter que les heveux, bijoux et vêtements amples ne soient pris dans les parties
mobiles.
*Ne l´utilisez pas sans que le sa de poussière et / ou les filtres ne soient en pla e.
*Ne vous appuyez pas sur la hambre du disque.
*Cette ma hine n´est pas onçue pour le ramassage de poussière dangereuse à la santé.
CONSERVEZ CES INSTRUCTIONS

6 - FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
WARNING!
Use extreme aution when working with batteries. Sulfuri a id in batteries an ause severe injury if allowed to onta t the skin or
eyes. Explosive hydrogen gas is vented from inside the batteries through openings in the battery aps. This gas an be ignited by any
ar , spark or flame.
WHEN SERVICING BATTERIES...
•Remove all jewelry.
•Do not smoke.
•Wear safety glasses, rubber gloves and a rubber apron.
•Work in a well-ventilated area.
•Do not allow tools to tou h more than one battery terminal at a time.
CAUTION!
Ele tri al omponents in this ma hine an be severely damaged if the batteries are not installed and onne ted properly. Batteries
should be installed by your lo al Nilfisk-Advan e dealer or by a qualified ele tri ian.
Your Whirlamati omes from the fa tory with battery ables to onne t three 12 volt batteries.
Six 6 volt batteries may be used (instead of the 12 volt batteries) to extend the running time of the ma hine. To install these batteries, you will need the following
additional parts:
QTY PART NO. DESCRIPTION
3 56363936 BATTERY CABLES
6 56372673 BATTERY BOOTS
6 56478246 TIE STRAPS
These items an be ordered from your lo al Nilfisk-Advan e Distributor.
To Install the Batteries...
1Release the two lat hes (12) at the ba k of the ma hine, tip the over shroud forward and lift it off of the ma hine. Remove the battery ables from the battery
tray.
2If you are using three 12 volt batteries, arefully lift them into the battery tray, arranged as shown in Figure 1. Install the battery retaining strap as shown,
to hold the batteries toward the rear of the ma hine.
If you are installing six 6 volt batteries, lift the battery tray out of the ma hine and turn it around so that the ribbed area fa es toward the front of the ma hine,
as shown in Figure 2. Carefully pla e the batteries into the battery tray, arranged exa tly as shown. Dis ard the battery retaining strap - it is not required when
six 6 volt batteries are used.
3Make sure that the Master Swit h (6) is in the OFF position.
4Install the battery ables as shown in Figure 1 or Figure 2, with the terminals marked “P” on the positive battery posts and the terminals marked “N” on the
negative battery posts. Position the ables so that the aps an be easily removed when it is ne essary to add water to the batteries.
5Tighten the nut on ea h battery terminal just enough to keep the terminal from being turned on the battery post. Then tighten the nut one more full turn.
Do not over-tighten the nuts, or it will be very diffi ult to remove the terminals for future servi e.
6Coat all of the terminals and posts with grease, petroleum jelly or spray-on battery oating (available at most auto parts stores).
7Put one of the bla k rubber “boots” over ea h of the terminals and use the plasti tie straps to hold them in pla e.
BATTERY INSTALLATION
Retaining Strap
Ribbed Area of Battery Tray
FIGURE 2FIGURE 1

FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20 - 7
1
23
45
6
7
8
9
10
11
12
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
1 Hand Grip
2 Battery Meter
3 Power-ON Light
4 Motor “Needs Service” Light
5 Pad Pressure Meter
6 Master Switch
7 Pad Lower Lever
8 Pad Lift Pedal
9 Control Circuit Breaker
10 Motor Circuit Breaker
11 Pad Pressure Lever
12 Cover Shroud Latch
KNOW YOUR MACHINE

8 - FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
INSTALLING A PAD
Your lo al Nilfisk-Advan e Distributor an provide the proper pads and floor finishes for use with this ma hine.
CAUTION!
Using the wrong kind of pad on this ma hine an damage the floor.
1Lower the pad drive assembly onto the floor, using the Pad Lower Lever (7) on the ba k of the ma hine. Then push the ba k of the ma hine down until the
support stand tou hes the floor.
WARNING!
Do not pull down on the front of the ma hine while installing or removing the pad.
2Turn the pad retainer clockwise to remove it from the pad holder. Carefully enter a burnishing pad on the pad holder. If the pad is not entered properly,
the ma hine will vibrate when the pad motor is started.
3Install the pad retainer by turning it counter-clockwise. Tighten the pad retainer se urely.
4Put your foot on the support stand and gently lower the front of the ma hine to the floor.
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
INSTALLING DUST COLLECTOR BAGS
1Lower the pad drive assembly onto the floor, using the Pad Lower Lever (7) on the ba k of the ma hine. Then push the ba k of the ma hine down until the
support stand tou hes the floor.
2Install two dust olle tor bags (Nilfisk-Advan e part number 56391185) on top of the dust ontrol housing. Rea h in from the sides of the ma hine and push
the bag opening over ea h of the two tubes.
3Put your foot on the support stand and gently lower the front of the ma hine to the floor.
The dust olle tion system will not operate properly if the olle tor bags are full, if just one bag is installed, or if one or both bags are torn.
PREPARING THE MACHINE FOR USE

FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20 - 9
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
OPERATING THE MACHINE
1Turn the Master Swit h (6) ON. The green Power-On Light (3) will ome on.
2 Model 56393500: Push the ma hine forward and twist the Hand Grips (1) to start the pad motor. Push the ma hine as slow as is ne essary to obtain the
desired shine.
Model 56393600: Twist the Hand Grips (1) to start the pad motor and propel the ma hine forward.
3Make long, straight passes whenever possible. Overlap ea h pass about 2 in hes (5 m).
4 Model 56393500: Whenever you stop moving, release the Hand Grips immediately to stop the pad motor.
Model 56393600: When you release the Hand Grips, the pad motor will stop and the drive motor will stop propelling the ma hine.
CAUTION!
The floor may be damaged if travel of the ma hine is stopped with the pad down and running.
5Wat h the Pad Pressure Meter (5) as you operate the ma hine. The Pad Pressure Lever (11) is adjusted properly when the meter stays in the green area
most of the time, with o asional readings in the red area.
If the meter reads in the red area, pull the Pad Pressure Lever (11) upward.
If the meter reads in the bla k area, move the Pad Pressure Lever (11) downward.
NOTE: It is normal for the reading on the Pad Pressure Meter (5) to hange as the ma hine moves over an uneven floor.
6If the Cir uit Breaker (10) for the pad motor trips, raise the Pad Pressure Lever (11) a little, reset the Cir uit Breaker and resume operation.
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
AFTER USE
1Turn the Master Swit h (6) OFF and tip the ma hine ba k on its support stand.
2Che k the bags on top of the dust ontrol housing. Repla e them if they are more than half full or if they are damaged.
3Che k the skirt around the dust ontrol housing. The skirt should be repla ed if it is worn out or torn.
4Remove the pad from the pad holder and lean it thoroughly with soap and water. Allow pads to dry ompletely before using them again.
5Gently lower the front of the ma hine onto the floor.
6Remove dust and dirt from the outside of the ma hine by wiping with a damp loth.
7Store the ma hine in a lean, dry pla e.
CAUTION!
DO NOT store your Whirlamati outdoors.
_____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
MAINTENANCE SCHEDULE
MAINTENANCE ITEM DAILY MONTHLY
Charge Batteries •
Che k/Repla e Dust Bags •
Che k/Repla e Skirt •
Clean Pad •
Lubri ation •
Che k/Servi e Pad Motor Brushes •
OPERATING THE MACHINE / AFTER USE

10 - FORM NO. 56041227 - Whirlamati ™ UHSB 20 / UHSBD 20
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
BATTERY MAINTENANCE AND CHARGING
Charge the batteries ea h time the ma hine is used for 1 hour or longer, or whenever the Battery Meter reads in the red area.
To Charge the Batteries...
1Remove the over shroud and pull the gray battery onne tors apart.
2Push the onne tor from the harger into the onne tor from the batteries.
3Follow the instru tions on the battery harger.
4Che k the fluid level in all battery ells after harging the batteries. Add distilled water, if ne essary, to bring the fluid level up to the bottom of the filler tubes.
CAUTION!
To avoid damage to floor surfa es, wipe water and a id from the top of the batteries after harging.
CAUTION!
A id an spill onto the floor if the batteries are overfilled.
_____________________________________________________________________________________________________________________________
LUBRICATION
Lubri ate all pivot points of the pad raise/lower assembly with a dry film sili one lubri ant.
Grease the fittings on the front asters and on the rear wheels on e a month.
_______________________________________________________________________________________________________________________________________________
PAD MOTOR BRUSHES
A Red Light (4) on the ontrol panel indi ates when the arbon brushes in the pad drive motor need to be repla ed. When this light glows, STOP USING THE
MACHINE and onta t your lo al Nilfisk-Advan e distributor to have the brushes servi ed.
CAUTION!
The pad drive motor an be damaged beyond repair if the ma hine is used with the red light glowing.
IMPORTANT!
Motor damage resulting from failure to servi e arbon brushes is not overed under warranty. See the Limited Warranty statement.
_______________________________________________________________________________________________________________________________________________
DRIVE MOTOR BRUSHES - MODEL 56393600 ONLY
Have your lo al Nilfisk-Advan e distributor he k the brushes on e a year.
_____________________________________________________________________________________________________________________________
TROUBLESHOOTING
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
MACHINE VIBRATION
1Pad is not entered properly. Remove the pad and reinstall.
2Defe tive pad. Repla e.
_____________________________________________________________________________________________________________________________
SWIRL MARKS
1Pad is too aggressive for the floor finish.
2Pad is dirty. Che k and repla e.
_____________________________________________________________________________________________________________________________
REDUCED RUNNING TIME
1Pad pressure too high. Che k the Pressure Meter (5) adjust the Pad Pressure Lever (11) so the Pressure Meter stays in the green area most of the time.
2Batteries need to be harged.
3Batteries need water. Add just enough to over the plates in ea h ell. Then harge the batteries and he k the water level again.
MAINTENANCE / TROUBLESHOOTING

Nilfisk-Advance, Inc.
14600 21st Avenue North
Plymouth, MN, 55447-3408
www.nilfisk-advance.com
Phone: [phone]
Fax: [phone]
©2000 Nilfisk-Advance, Inc.,
Plymouth, MN 55447-3408
Printed in the U.S.A.
