Nilfisk-Advance WT3SPD User manual

1

TABLE OF CONTENTS
Safety Precautions 3
Machine Operation 4
Machine Maintenance & Storage 4
Parts List 5---9
Wiring Diagram 1 0
2

SAFETY PRECAUTIONS
!!! This machine must be grounded!
Grounding provides a path of least resistance
for electrical current. To reduce the risk of
electrical shock should the machine
malfunction, the machine has a special
grounding plug. Don’t remove the ground pin
under any circumstances!
This machine is intended for commercial use.
It is constructed for use in an indoor
environment and is not intended for any other
use. Use only recommended accessories.
All operators shall read, understand and
exercise the following safety precautions:
1] Do not operate machine:
-Unless trained and authorized.
-Unless you have read and understand
operators manual.
-In flammable or explosive areas.
-With a damaged cord or plug.
-If not in proper operating condition.
-In outdoor areas.
-In standing water
-With the use of extension cords.
2] Before operating machine:
-Make sure all safety devices are in
place and operate properly.
3] When using machine:
-Do not run machine over cord.
-Do not pull machine by cord or plug
-Do not pull cord around sharp edges or
corners.
-Do not unplug by pulling on the cord.
-Do not stretch cord.
-Do not handle plug with wet hands.
-Keep cord away from heated surfaces.
-Do not pick up burning or smoking
debris such as cigarettes, matches or
hot ashes.
-Report machine damage of faulty
operation immediately.
4] Before leaving or servicing machine:
-Turn off machine.
-Unplug cord from outlet.
5] When servicing machine:
-Unplug cord from outlet.
-Use manufacturer supplied or approved
replacements parts.
3

Operation of Air Mover
* Read operators manual thoroughly prior
to operating or servicing this machine.
BASIC OPERATION
1] Check machine for any obstructions in fan
prior to operation.
* If an item blocks the intakes of the blower,
this will hurt the performance of the blower, and
could cause the motor to overheat.
2] Adjust machine to desired position for
operation by either pulling it back to it’s
preset height adjustments, or by lowering
the “kick stand” and setting the machine on
the stand.
3] Plug power cord into a grounded outlet.
* Do not use an extension cord in
conjunction with the standard power cord.
4] This machine has three power settings Turn
the power knob to the desired speed. Low =
1, Med = 2 & High = 3.
5] To stop the machine at any time, simply turn
the power knob to the “off” position.
* Never stick any object into the air inlet
vents or the air outlet vent.
MAINTENANCE
To keep the machine performing well for many
years, please follow the following maintenance
procedures.
* Always confirm that the machine is
unplugged prior to performing any
maintenance or repairs.
1] Unplug machine as soon as you are done
using it.
2] Wrap the power cord around the carrying
handle.
3] Check power cord for any damage. If any
damage is detected, replace the cord
immediately.
4] If you have the wheel kit, lubricate wheels
with a water resistant lubricant every
month.
5] Check machine for loose or missing nuts
and bolts, and replace as necessary.
6] Clean the outside of the machine with a mild
cleaner.
STORAGE
1] Unplug machine from power source.
2] Store in upright position in a dry area.
4

5

DIA
NO PART NUMBER NO REQ'D
1 VV13649 SCREW,SELF-TAPPING,ST,M4X25 4
2 VV30107 LEFT NET,VENT,INTAKE 1
3 VV30102 BLOCK,STAND,RIGHT FRONT 2
4 VF13613 SCREW,M5X20 8
5 VF14070 SCREW,M4X25 1
6 VV13647 RIVET,M4.8X18 4
7 VV13653 WASHER,PLAIN,M3.5XM10X1.0 15
8 VV13645 RIVET,M3.2X16 4
9 VV30124 RUBBER,BLOCK,STAND 2
10 VV20352 RIVET,M4X12 2
11 VV30119 CONNECTING PLATE 1
12 VA13482 WASHER,PLAIN,M5.0XM11X1.0 4
13 VV30112 NET,VENT,OUTLET 1
14
VV
ROTATOR SWITCH KIT
1
DESCRIPTION
PARTS LIST
14
30015
ROTATOR
,
SWITCH
,
KIT
1
15 VV13658 SCREW,SWITCH,M5X20 2
16 VV30103 PLATE 1
17 VV30180 SWITCH 1
18 VV13608A SCREW,SELF-TAPPING,ST,M4X12 6
19 VV13656 SCREW,M8X16 1
20 VV13609 NUT,M4 1
21 VV30143 CAPACITOR,30UF/300V 1
22 VV30014 CLAMP,CAPACITOR 1
23 VV13642 SCREW,M4X8 1
24 VV30115 STAND 2
25 VA13475 SCREW,M5X25 4
26 VV13662 WASHER,PLAIN,M5XM12X1.0 8
27 VV30114-1 RUBBER,STAND,38mm 2
28 VV30117 SLEEVE,RUBBER 2
29 VV30118 PLATE,CHAMBER 1
30 VV30200 BLOCK,STAND,LEFT FRONT 2
31 VV30100A HOUSING,LEFT 1
32 GT13022 NUT,LOCK,M5 15
6

DIA
NO PART NUMBER NO REQ'D
DESCRIPTION
PARTS LIST
33 VV13640
SCREW,SELF-TAPPING,ST,M4X16
4
34 VV30110 RIGHT NET,VENT,INTAKE 1
35 VV13655 RIVET,M3.2X12 9
36 VV30114 RUBBER,STAND,48mm 2
37 VV13648 RIVET,M6.4X18 4
38 VV30011 CLAMP,MOTOR 1
39 VV13657 SCREW,M8X25 1
40 VF13503 NUT,LOCK,M8 1
41 VV30116 GASKET,MOTOR 1
42 YQ61000 MOTOR,120V,3/4HP 1
43 VV30010 IMPELLER,9" 1
44 VA21570 CABLE,200mm 1
45 VV30118A PLATE,CHAMBER 1
46
VF13527
WASHER TOOTH M4
3
46
VF13527
WASHER
,
TOOTH
,
M4
3
47 VV20249 NUT,M4 4
48 VV30101A HOUSING,RIGHT 1
49 VV30202 READ MANUAL,LABEL 1
50 VV30505U SERIAL TAG 1
51 VV30182 POWER BUSHING 1
52 VV30183 POWER CORD 1
53 VV13636 SCREW,M5X30 3
54 VV30529 LABEL,SWITCH 1
55 VV30122 COVER,AXLE 2
7

8

1 VV30120 SEAT,HANDLE 1
2 VV30130 RELEASE BUTTON 1
3 VV30121 COVER,HANDLE SEAT 1
4 VV30106A TUBE,AL 1
5 VV30132 PLASTIC HANDLE 1
6 VV30134 COVER,HANDLE 1
7 VV13640 SCREW,SELF-TAPPING,ST,M4X16 3
8 VV30123 RUBBER COVER,HANDLE 1
9 VV30133 BOTTOM,HANDLE 1
10 VV30109B HANDLE ASSEMBLY 1
11 VV30131 SPRING,RELEASE BUTTON 1
12 VV13661 SCREW,M4X12 4
13 VV13664 WASHER,PLAIN,M4XM12X1 4
14 VF47027 WASHER,LOCK 2
15 VF47055 WHEEL,6.4" 2
16 VA96851 CAP,AXLE 2
17 VV30111 AXLE 2
PARTS LIST
DIA
NO PART NUMBER NO REQ'D
DESCRIPTION
9
