Nipson VaryPress 200-10 User manual

MAGNETIC PRINTER
VARYPRESS 200
Site preparation guide
22 A1 13NS REV5

MAGNETIC PRINTER
VARYPRESS 200
Site preparation guide
MATERIEL
Document release:
REV0 July 2004. Creation.
REV1 Jan. 2006. Update with 90 m/min and operating conditions.
REV2 Jan. 2007. Information added about UPS.
REV3 July 2007. Update information about connection to the network.
REV4 Oct. 2007. Update operating conditions.
REV5 Fev. 2008 Update with pressure and ground loading/unit added.
22 A1 13NS REV5
NIPSON SAS
28, rue E. Thierry-Mieg - BP 257 - 90005 Belfort Cedex - France
Tel.: [phone] - Fax: [phone]
http:/www.nipson.com - e-mail: [e-mail]

© NIPSON 2004
All rights reserved
We will be pleased to receive any suggestions concerning the form and content of this manual.
A sheet on which to write your remarks is provided at the end of this manual.
This document is for information purposes only. NIPSON cannot be held responsible for any damage caused by applying
instructions contained within it. Corrections or modifications to the content of this document may be made without notice;
they may be communicated to recipients in later updates.
22 A1 13NS REV5 ii

iii
Site preparation manual
VARYPRESS 200
Return to Start
Table of contents
1. GENERALITIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 CHARACTERISTICS OF THE PRINTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 MACHINE PACKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 TEMPERATURE AND HUMIDITY REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.4 AIR CONDITIONING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.5 PAPER STORAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.6 TONER STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.7 CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.7.1 Cleaning of the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.7.2 Cleaning of the room - dust accumulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.8 SPECIFIC TOOL FOR INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
2. SITE REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 PRINTER PHYSICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2.1 Printer dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2.2 Air conditioning unit for write heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.2.3 Floor space requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.2.4 Raised floor cutouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.2.5 Installing a pumping system at the filtration unit outlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2.2.5.1 Standard filtration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2.2.5.2 Option with internal smoke filtration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
2.2.6 Location of the T.E.D. printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.2.6.1 L-shaped installation (standard) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.2.6.2 U-shaped installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
2.2.6.3 S-shaped installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2.2.6.4 Z-shaped installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
2.2.6.5 I-shaped installation (in line). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2.3 ELECTRICAL REQUIREMENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.3.1 Installation conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.3.2 Leakage current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.3.3 Mains power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.3.4 Main circuit breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
2.3.5 Printer main cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
2.3.6 Pre and post processing ground wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
2.3.7 Air conditioning unit for write heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
2.3.8 Electrical connection of web cleaner option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
2.3.9 T.E.D. motorised loop (U-shaped or S or Z) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29

iv
Site preparation manual
VARYPRESS 200
Return to Start
Table of contents
2.3.10 U.P.S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
2.4 REMOTE MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-31
2.5 INTERFACE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.5.1 Printer with LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.5.1.1 Connection to the factory network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.5.1.2 Connection to the adapted network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
2.5.1.3 Connection to the isolated network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
2.5.2 Connection of the printer to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.5.2.1 VPServer connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.5.2.2 U_NetPSF connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.5.2.3 E_NetPSF connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.5.2.4 OpenPage connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.5.3 Connection to the host system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
2.5.3.1 VPServer connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
2.5.3.2 Connection to PRESS V4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
2.5.3.3 Connection to PRINTNET V3 from GMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
2.5.3.4 Connection to PRINTNET T from GMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-39
2.5.3.5 Connection to OS390 + MVS from IBM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-41
2.5.3.6 Connection to InfoPrintManager from IBM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-43
2.5.3.7 SDP Protocol Network Interface (OpenPage) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-44
2.6 UNPACKING AND INSTALLATION PREPARATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
2.6.1 Unloading the lorry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
2.6.2 Unpacking the modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
2.6.3 Moving the printer to the customer's computer room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
3. PRE / POST PROCESSOR DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 INTERFACE CONNECTOR DEFINITION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.3 INPUT/OUTPUT SIGNALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.3.1 Signals from printer to pre-post processing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.3.2 SIGNALS FROM PRE-POST PROCESSING DEVICE TO PRINTER. . . . . . . . . . . . . . . . . . . . . . 3-5
3.3.3 Signals from camera system to printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
3.3.4 Output signals from printer to camera system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.4 ELECTRICAL SIGNAL SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3.4.1 Signals from printer to the external device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
3.4.2 Signals from the external device to the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
3.5 CABLES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.5.1 Cable between printer and pre/post processor devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.5.2 Common earth connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

v
Site preparation manual
VARYPRESS 200
Return to Start
Table of contents
3.6 TIMINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.6.1 Timing of the printer speed change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
3.6.2 start/stop signal steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3.7 REQUIREMENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.1 Using a pre processor device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.2 Using a post processor device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.7.3 Using a post processor device with a printer in S.E.D. mode . . . . . . . . . . . . . . . . . . . . . . . . 3-15
4. ST20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1 PRODUCT PACKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 PHYSICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
4.2.1 Standard ST20 stacker dimensions and clearance areas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.2 Dimensions and clearance areas of ST20 90° . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4.2.3 Raised floor cutouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.3 ELECTRICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.3.1 Mains voltage supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.3.2 Mains connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.3.3 Main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.4 AMBIENT OPERATING CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.5 INTERFACE SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
4.5.1 Interface connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.5.2 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4.5.3 Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4.5.4 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
4.5.5 Electric specification of the signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4.5.6 Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
5. PAGE PRINTER IMPLEMENTATION PLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

vi
Site preparation manual
VARYPRESS 200
Return to Start
Table of contents

1-1
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
1. Generalities
1.1 CHARACTERISTICS OF THE PRINTER
The NIPSON printer is a non impact printer which uses a magnetographic printing process.
It is a page printer accepting continuous fanfold paper.
The VaryPress 200 printer is available in 3 speed models.
1. VaryPress 200-30:
the speed can be set at a speed ranging between 30 and 90 m/min (by step of 1m/min) or speed
can vary automatically between 30 and 90 m/min.
2. VaryPress 200-20:
the speed can be set at a speed ranging between 30 and 70 m/min (by step of 1m/min) or speed
can vary automatically between 30 and 70 m/min.
3. VaryPress 200-10:
the speed can be set at a speed ranging between 30 and 50 m/min (by step of 1m/min) or speed
can vary automatically between 30 and 50 m/min.
The pinless printer accepts caroll pinfeed paper and pinless paper.
The S.E.D. printer is composed of a printer and a paper turning system.
The first side (recto) is printed on the first passage of the sheet, then the second side is printed
(verso) after the paper has passed under the printer and been turned and the paper width shifted
horizontally. The first side is placed on the operator side.
The T. E . D . p ri n t e r is composed of two printers. The first side (recto) is printed on theNipson
upstream printer, and the second side on the downstream printer after mechanical turning of the
paper.
VP200-10 VP200-20 VP200-30 -10 SED -20 SED
Simplex printing XXXXX
Duplex printing Option TED Option TED Option TED X X
Paper Pin-fed XXX
(up to 70m/min) XX
Paper Pinless Option Option X Option
(simplex)
Option
(simplex)

1-2
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
The main printing characteristics are:
- Paper weight:
- for standard printer, 64 to 160 g/m2
- for pinless using: with roll, 64 to 160 g/m2
fanfold, 64 to 90 g/m2
these ranges can be increased from 40 to 250 g/m2 after tests at NIPSON
- Resolution: 600 DPI : 600 x 600 dots/square inch (555 dots/mm2)
300 DPI : 300 x 300 dots/square inch (140 dots/mm2)
- Printing orientation: 0º, 90º, 180º or 270º with respect to paper folds,
- Maximum print width: 18,45"
- Paper of different standard formats:
*This height can be increased to 24" after test and if required the addition of the multi-loop
option.
1.2 MACHINE PACKING
Each module of the machine is secured to a pallet and covered with a sealed bag.
Each assembly is packed in a cardboard box which is fixed to the pallet.
The unpacking leaflet is fixed outside the packaging.
NOTE: Printer unpacking, without packaging destruction requires a free height of at least 3.50 m.
Machine Mini length Maxi length Mini width Maxi width
Simplex
Pin-fed
3"
76 mm
36"
915 mm
6.5"
165 mm
20.5"
520 mm
Simplex Pinless 6"
152 mm
24"
610 mm
6.5"
165 mm
20.5"
520 mm
TED Pinless & Pin-
fed
6"
152 mm
18" *
457 mm
6.5"
165 mm
20.5"
520 mm
SED 6"
152 mm
18"
457 mm
7.5"
190 mm
9.9"
251 mm
with ST20 6"
152 mm
17"
432 mm
6.5"
165 mm
20.5"
520 mm
Dimensions of pallets Printing module Fixing module
Length 1700 mm 1780 mm
Depth 1600 mm 1130 mm
Height 1720 mm 1900 mm

1-3
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
1.3 TEMPERATURE AND HUMIDITY REQUIREMENTS
The conditions described here correspond to the current printers which are delivered with graphite
drums.
the old versions of printers with CrC drums have different operating conditions, those are described in
§ 6.3.2.2 of the product manual.
-Temperature: 15ºC to 26ºC (optimum 20ºC),
-Relative humidity: 5% to 70% (optimum 45-50%).
-Absolute ambient humidity: 1 to 9 gH2O/Kgdry air
However maximal values of temperature and relative humidity must not be reached together (see
below).
-Atmospheric pressure must be between 562 and 780 mm Hg.
-Heat dissipation
The printer room must be able to remove heat generated by the printer.
CAUTION: Since the T.E.D. printer is composed of two standard printers, the heat given off
is double that of the standard machine.
Average heat dissipation
Print speed
50 m/min 70 m/min 90 m/min
heat dissipation
with air extraction
50 KBTU/h 50 KBTU/h 50 KBTU/h
12 Mcal/h 12 Mcal/h 12 Mcal/h
heat dissipation
without air extraction
60 KBTU/h 84 KBTU/h
15 Mcal/h 21 Mcal/h
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
(°C)
(%)
15° dew point
11° dew point
Tolerated operating conditions with risks of
degradation of the print quality.
It may be necessary to reduce the print speed
or perform more preventive maintenances.
Recommended
operating
conditions
Relative humidity

1-4
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
1.4 AIR CONDITIONING
The air-conditioned room must be built according to current building standards and respect the
following points:
- Controlling and adjusting the temperature :
Temperature gradient should not exceed ± 4 ºC/h.
- Controlling and adjusting the relative humidity.
Relative humidity gradient should not exceed ± 8 %/h.
- Filtering the circulated air.
Signalling for conditions which are out of tolerance.
- Introduction of new air and evacuation of old air with rate determined according to the following
criteria:
-70m
3/h per printer at 60 m/min and 100 m3/h per printer at 90 m/min
or
-45m
3/h per person working in the room
or
- according to current legislation for the locality.
The maximum value from the three values determined above will be chosen as the minimum
air renewal rate required.
- The printer will be installed below an air outlet.

1-5
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
1.5 PAPER STORAGE
Toner is supplied in sealed containers which should be stored with cap upward.
Storage conditions
- Paper must not be removed from its original packaging.
- Isolate the cartons and rolls from the floor.
- To avoid a thermal shock, do not store the rolls and the cartons close to a heat source or
opened windows.
- The paper should be protected from physical shocks.
- The packaging must be opened only when the paper is to be used.
- Climatic conditions must be as close as possible to utilization conditions:
- temperature: 18 ºC to 30ºC,
- Humidity: 30 % to 70 % relative humidity.
Storage conditions outside these limits may be followed by a suitable stabilization period
before use.
- In case paper is stored in an area where the temperature is different from the printer room
temperature by more than 5ºC , it is necessary to respect minimum storage times for paper
brought into the printing room, according to the following table:
Difference of temperature Minimum stabilization
between paper storage time before use
room and printing room
6ºC to 12ºC 2 days
12ºC to 18ºC 3 days
18ºC to 22ºC 5 days
22ºC to 28ºC 7 days
The time required to eliminate a relative humidity difference in the paper depends on its
packaging and must be determined by measurements with hygrometric knife.
1.6 TONER STORAGE
Toner is supplied in sealed containers which should be stored with cap upward.
Storage conditions:
- Temperature: 18° to 30°C,
with a maximum temperature, even for short duration
(some hours), of 38º C.
- Relative humidity (RH): < 70 %.

1-6
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
1.7 CLEANING
1.7.1 Cleaning of the printer
The printer should be maintained and cleaned regularly to remove paper and toner particles which
may adhere to it.
For printer cleaning and toner box emptying, the customer must use a vacuum cleaner equipped
with an external absolute filter.
This vacuum cleaner can be ordered with the printer or be provided by the customer and placed at
the field engineer’s disposal during his intervention.
The main characteristics of the vacuum cleaner are:
- 100% main filter.
- Paper waste recovery bag with a capacity of 4-5 liters.
-Vacuum>
1.80 m column of water.
- Flexible hose with an external diameter of 32 mm.
Example: NILFISK vacuum cleaner (No. 3970-39).
It has the following accessories, which can be ordered separately under the following
references:
- Paper bag No. 815300.
- Absolute filter No. 115-650.
- Flexible hose No. 115-435.
1.7.2 Cleaning of the room - dust accumulation
It is recommended that the room of the machines and the associated systems answer the
specifications of the class ISO 8 of standard NF IN ISO 14644-1 relating to the cleanrooms
(corresponding about to the class 100 000 of the Federal Standard 209E).
The table below points out information of the classes concerned.
If this recommendation is not respected, that will generate adaptations of the frequencies and
maintenance actions.
The cleaning of the system room and the surrounding areas must be made daily with a particular
care, preferably when the printer is not active, with suitable hardware (for example
NILFISK vacuum cleaner (see above)).
A thorough cleaning under the raised floor and of the suspended ceiling should be planned to allow
clean passage of air and cables.
This should be done twice per year by professional cleaners.
Standard and class number Maximum permissible concentrations (particles/m3of air) in
particles of size equal or higher than that given below
0,5 μm1 μm5 μm
Standard NF EN ISO 14644-1
Class ISO 8
3 520 000 832 000 29 300
Federal Standard 209E
class 100 000
3 530 000 24 700

1-7
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
1.8 SPECIFIC TOOL FOR INSTALLATION
To install the printer, the field engineer needs in addition with the standard tools (Allen wrenches,
screwdriver...):
- a pipe wrench of 22 mm
- a wrench of 27mm (flat type, open end)
- a wrench 1" 1/8 and 30 mm (No. 47291681-001)

1-8
Go to "Table of contents"
Site preparation manual
VARYPRESS 200

2-1
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
2. Site requirements
2.1 INTRODUCTION
This section provides the information required for the development of a layout of the printer
installation. This layout must be ready before the delivery of the printer.
The following subjects are covered:
- Physical specifications.
- Electrical specifications.
- Channel attachment.
2.2 PRINTER PHYSICAL SPECIFICATIONS
2.2.1 Printer dimensions
See figures page 2-2 and page 2-3 for standard printers, page 2-4 and page 2-5 for S.E.D. printer.
The printer is suitable for mounting on concrete or other non-combustible surface only.
Dimensions and weights of units
Length
mm
Depth
mm
Height
mm
Weight
Kg
Packed
weight
Kg
Ground
loading
Kg/m2
Pressure
under
casters
Kg/cm2
Printing
module 850 1600 1425 540 600 400 240
Fixing module 1410 1073 1720 600 900 400 270
Footbridge 1030 860 150 95 125
Unfolder 320 640 1600 80 120
Air-
conditioning
unit
940 740 1230 120 190 200
Dust remover 840 790 1260 60 135

2-2
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
STANDARD PRINTER
Print
module
Fixing
module
Footbrige
1030
1000
790
410
3310
Unfolder
80
1720
1425

2-3
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
STANDARD PRINTER
POST-PROCESSING
FLASH
FIXING
MODULE
PRINT
MODULE
FOOTBRIDGE / UNWINDER
1000790
2260
410
EXTRACTION
1600
1073
840
EXTRACTION
60

2-4
Go to "Table of contents"
Site preparation manual
VARYPRESS 200
S.E.D. PRINTER
1030
1000
790
500
3400
80
1720
1425
Print
module
Fixing
module
Footbrige
Unfolder
