NISBETS ESSENTIALS DC439 User manual

Ice maker
Instruction manual
Model • Modèle • Modell • Modello • Modelo • Malli:
DC439
DC439_UK_A5_v1_20191223.indb 1 2019/12/23 14:54

2
UK Telephone Helpline: 0845 146 2887
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT immerse in water, or use steam/jet washers to
clean the unit.
• DO NOT cover the appliance when it is operating.
• Always carry, store and handle the appliance in a vertical
position.
• ONLY use drinking or potable water when making ice cubes.
• Replace any unused water in the tank at least once every 24
hours.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local
authorities.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by
children without supervision.
DC439_UK_A5_v1_20191223.indb 2 2019/12/23 14:54

3
UK
Telephone Helpline: 0845 146 2887
• If the power cord is damaged, it must be replaced by a
Nisbets Essentials agent or a recommended qualified
technician in order to avoid a hazard.
• Nisbets Essentials recommends that this appliance should
be periodically tested (at least annually) by a Competent
Person. Testing should include, but not be limited to: Visual
Inspection, Polarity Test, Earth Continuity, Insulation
Continuity and Functional Testing.
• The appliance is intended to be used in household and
similar applications.
Warning: Risk of fire / flammable materials
• Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of this
machine will provide the best possible performance from your Nisbets Essentials product.
Pack Contents
The following is included:
• Ice Maker
• Removable ice basket
• Ice scoop
• Instruction manual
DC439_UK_A5_v1_20191223.indb 3 2019/12/23 14:54

4
UK Telephone Helpline: 0845 146 2887
Nisbets Essentials prides itself on quality and service,
ensuring that at the time of packaging the contents
are supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your Nisbets Essentials dealer
immediately.
Installation
Note: If the unit has not been stored
or moved in an upright position, let
it stand upright for approximately 12
hours before operation. If in doubt
allow to stand.
1. Remove the appliance from the packaging and
the protective film from all surfaces.
2. When positioning the ice maker, maintain a
distance of 20cm between the unit and walls or
other objects for ventilation. NEVER LOCATE
NEXT TO OR NEAR A HEAT SOURCE.
WARNING: When positioning the
appliance, ensure the supply cord is
not trapped or damaged.
WARNING: Do not locate multiple
portable socket-outlets or portable
power supplies at the rear of the
appliance.
Operation
Control Panel
SMALL ice cube
indicator
ADD WATER indicator
ICE FULL indicator
POWER button
SELECT button
CLEAN button
LARGE ice tube indicator
Making Ice
Note: Before using for the first time,
clean the water tank, ice basket
and ice basket shelf. Use the first
3 ice making cycle to flush out the
system. Discard the water and ice
created from the first 3 cycles.
Each time the appliance is refilled, the first ice making
cycle is used to reduce the water temperature.
This results in uneven ice cube production which is
perfectly normal. You may wish to discard ice created
in the first two production cycles.
1. Lift the access lid and fill the water tank up the
level of the ice basket shelf.
2. Connect the appliance to the power and press
the “POWER” button.
3. Press the “SELECT” button repeatedly to scroll
through the ice cube sizes. Stop when the
required size is illuminated.
Note: The ice making cycle will
vary depending on the size of cube
selected. Larger cubes will take
longer to produce.
4. The appliance will run a start-up routine and then
begin ice production.
Note: If the water level is too low,
the ADD WATER indicator lights up
and the appliance stops working. Fill
the water tank and the appliance will
restart automatically.
5. When the cubes reach the ice sensor the
appliance will stop production. Production
resumes once ice has been removed.
Cleaning, Care &
Maintenance
• Always switch off and disconnect the power
supply before cleaning.
• Warm, soapy water is recommended for cleaning.
Cleaning agents may leave harmful residues.
DO NOT wash the base unit, instead wipe the
exterior with a damp cloth.
DC439_UK_A5_v1_20191223.indb 4 2019/12/23 14:54

5
UK
Telephone Helpline: 0845 146 2887
• A Nisbets Essentials agent or qualified technician should carry out repairs if required.
• Clean the water filter regularly with a small brush, particularly in hard water areas. The water filter is
located in the pump inlet at the bottom of the water tank, remove by pulling out with fingers.
• If the appliance is to be left unused for longer than 24 hours, loosen the drain screw and drain the water
from the tank.
• The inner removable parts and water tank should be cleaned regularly.
Automatic cleaning
• Remove the ice basket. Then add dilute cleaner into the water tank. Note: Choose ice maker specific
cleaner and follow the manufacturer’s instructions.
• Press the “CLEAN” button. The “CLEAN” indicator flashes and auto cleaning cycle starts. After auto-
cleaning done, the “CLEAN” indicator will go out.
• Turn the unit off and disconnect from power supply. Loosen the drain screw to drain the solution.
Note: After auto-cleaning, use the first 3 ice making cycles to flush out the system. Discard the water
and ice created from these initial cycles.
Troubleshooting
If your Nisbets Essentials appliance develops a fault, please check the following table before making a call to
the Helpline or your Nisbets Essentials dealer.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call Nisbets Essentials agent or qualified
Technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call Nisbets Essentials agent or qualified
Technician
Appliance is noisy or
works intermittently
Power fluctuations Turn off the ice maker and restart after 3
minutes
Add Water
indicator is lit
Water level is low or tank is empty Refill water tank and restart
Water filter is blocked Clean water filter and restart appliance
Ice Full
indicator is lit
Ice basket full Empty the ice basket
All indicators flash
simultaneously
Water box is blocked by ice Disconnect from the power supply.
Remove some of the ice cubes and gently
tilt the water box by hand. Restart the
appliance after 3 minutes. If the unit fails to
work after above operations, call Nisbets
Essentials agent or qualified Technician
The motor stops working suddenly
Ice cubes are sticking
together
Ice making cycle is too long Reset the ice cube size and restart the
appliance
Water tank temperature is too low Empty water tank and refill
Compressor runs but no
ice is made
Refrigerant leak or block in the
refrigerant system
Call Nisbets Essentials agent or qualified
technician
DC439_UK_A5_v1_20191223.indb 5 2019/12/23 14:54

6
UK Telephone Helpline: 0845 146 2887
Technical Specifications
Model Voltage Power Bin
Storage
Max. Ice Making
Capacity Refrigerant Dimensions H x W x D mm Weight
DC439 220-240V~
50Hz
150W 0.7kg 20kg/24 hours R600a 327 x 270 x 365 10.6kg
Electrical Wiring
Nisbets Essentials appliances are supplied with a 3 pin BS1363 plug and lead.
The plug is to be connected to a suitable mains socket.
Nisbets Essentials appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency disconnection
being required they must be readily accessible.
Disposal
EU regulations require refrigeration product to be disposed of by specialist companies who remove or recycle
all gasses, metal and plastic components.
Consult your local waste collection authority regarding disposal of your appliance. Local authorities are not
obliged to dispose of commercial refrigeration equipment but may be able to offer advice on how to dispose
of the equipment locally.
Alternatively call the Nisbets Essentials helpline for details of national disposal companies within the EU.
Compliance
The WEEE logo on this product or its documentation indicates that the product must not
be disposed of as household waste. To help prevent possible harm to human health and/
or the environment, the product must be disposed of in an approved and environmentally
safe recycling process. For further information on how to dispose of this product correctly,
contact the product supplier, or the local authority responsible for waste disposal in your
area.
Nisbets Essentials parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and federal
authorities.
Nisbets Essentials products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission of Nisbets Essentials.
Every effort is made to ensure all details are correct at the time of going to press, however, Nisbets Essentials reserve the right to change
specifications without notice.
DC439_UK_A5_v1_20191223.indb 6 2019/12/23 14:54

DECLARATION OF CONFORMITY
•Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement •
Gerätetyp •Tipo di apparecchiatura • Tipo de equipo • Tipo de
equipamento
Ice maker - 20kg
Model • Modèle • Modell • Modello • Modelo • Malli
DC439
Application of Council Directives(s)
Toepassing van Europese Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare EU-Richtlinie(n) •
Applicazione delle Direttive • Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do Conselho
Low Voltage Directive (LVD) 2014/35/EC
EN 60335-1:2012 + A11:2014 + A12:2017 + A13:2017
EN 60335-2-24:2010 + A1:2019 +A2:2019
EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU
EN 55014-1:2006 +A1:2009 +A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Producer Name • Naam fabrikant • Nom du producteur • Name
des Herstellers • Nome del produttore • Nombre del fabricante •
Nome do fabricante
Nisbets Essentials
Producer Address • Adres fabrikant • Adresse du producteur •
Anschrift des Herstellers • Indirizzo del produttore • Dirección
del fabricante • Morada do fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point Business
Park
New Mallow Road
Cork
Ireland
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and
Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de
bovenstaande Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n)
und Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s)
anterior(es) Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data • Fecha • Data
4th December 2019
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom • Vollständiger Name •
Nome completo • Nombre completo • Nome por extenso Ashley Hooper
Position • Functie • Fonction • Position • Qualifica • Posición • Função
Technical & Quality Manager
DC439_UK_A5_v1_20191223.indb 7 2019/12/23 14:54

DC439_ML_A5_v1_20191223
http://www.nisbets.com/
DC439_UK_A5_v1_20191223.indb 8 2019/12/23 14:54
