C-band PLL LNB
Internal & External Reference Model
Model No. NJS8486 series
Model No.
RF Frequency
Local Frequency
IF Frequency
NJS8486 series
3.4 to 4.2 GHz
5.15 GHz
950 to 1,750 MHz
NJS8487 series
3.625 to 4.2 GHz
5.15 GHz
950 to 1,525 MHz
NJS8488 series
4.5 to 4.8 GHz
5.76 GHz
960 to 1,260 MHz
Local Reference Type: Internal / External Reference
Local Stability: H-type, +/- 10 ppm (+/- 50 kHz typ.)
S-type, +/- 3 ppm (+/- 15 kHz typ.)
U-type, +/- 1 ppm (+/- 5 kHz typ.)
E-type, Same as External Reference Stability
RF Input Interface: Waveguide, CPR-229G
IF Output Interface: N-type / F-type, Female Connector
DC Power Input: IF Output Interface Connector
DC Power Voltage Range: +12 to +24 V
