Nite Devil IP-CAM828 User manual

© 2023 System Q Ltd
1
3.6mm IP NiteDevil Hero Mini Eyeball 4K
NiteDevil is a registered trademark of System Q Ltd
Document ref: qIP-CAM828B
NiteDevil.com
IP-CAM828 - Quick Start Guide
User Information
· The camera must not be exposed to
conditions above the IP66 rating.
· Do not touch the camera connections with
wet hands.
· There are no user serviceable parts in the
camera and opening or attempting to repair
the product will void the warranty.
· Only use a regulated 12V DC Supply or a Type
802.3af or above PoE Supply.
· Do not install or use the camera if damaged.
Full Instruction Manual
www.systemq.com/PDF
/manual/xIP-
CAM828.pdf
The NiteDevil Hero can stay in full colour around the clock using its built in white light LEDs to
produce superb full colour images. Up to 25m IR range (true day/night filter) and up to 20m white
light range, 4K (8MP) resolution, built in PoE, H265 and H264 codec.
This model also features blue and red deterrence LEDs which can warn off intruders, similar to law
enforcement strobe lights. *Adjustable with compatible NVR / DVR Firmware.
Powering the camera
Option 1 - Power the camera from 12V
DC (via the 2.1mm DC Socket), the
maximum current consumption is
420mA. The camera is polarity sensitive
so connections must be correctly
made.
www.zipdvr.com/howto/TIP459
-How-To-Add-IP-Cameras.html
Option 2 - Power the camera using a
PoE 48V RJ45 Socket. When connecting
ZIP PoE NVR plug the camera directly
into the NVRs built in PoE switch.
The camera should automatically
become visible after being connected
for approximately 1 minute.
If using a separate PoE switch or an
IPmitter (wireless bridge), the camera
needs to be manually configured, scan
the QR code to the left for the "how to
guide".

This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
© 2023 System Q Ltd
2
3.6mm IP NiteDevil Hero Mini Eyeball 4K
NiteDevil is a registered trademark of System Q Ltd
Document ref: qIP-CAM828B
All specificationsare approximate. System Q Ltd reservesthe right to change product specificationsor featureswithout notice.Whilst every effort is
made to ensure that these instructionsare complete and accurate,System Q Ltd cannot be held responsible for any losses, no matter how they arise,
from errorsor omissionsin these instructions, or the performance or non-performance of the equipment refered to.
Use the ZipFinder tool to search for ZIP IP cameras
on a network via a Windows PC.
www.softcctv.com/store/Item/Zip-Finder-IP-
CCTV-Security-Camera-Discovery-Tool
Default login details are:-
Default IP
192.168.10.1
DCHP
Off
User Name
admin
Password
777777
Resolution
4K (8MP) (3840 x 2160)
Lens Type
Wide Angle 3.6mm Fixed
Video Compression
H264 / H265
Bit Rate
512Kbps ~ 6Mbps
Shutter
1/5 ~ 1/20000s ~ Flickerless
Min. Illumination
Colour 24/7 with White Light LEDs
Day/Night Function
Auto or Scheduled
Microphone
Built-in
IR LEDs
1x High Power
IR Range
Up to 25m
White Light
2x High Power
White Light Range
Up to 20m
Gain Control
Auto
Video Connection
RJ45 Socket
Onvif
Yes
Protocol
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP
Other Protocols
SMTP, NTP, HTTPS
White Balance
Auto / Manual
Input Voltage
12V DC (420mA) / PoE 48V
Consumption
1.2 - 5W
Power Connection
12V – 2.1mm DC Socket / PoE – RJ45
IP Rating
IP66
Build
Metal & Plastic
Dimensions
100mm x (H) 90mm
