PNEU ZELT CUBE
SETUP MANUAL
Pneu Werbemittel | Pneu Zelte | Pneu Möbel | MAX Säulen | Bögen | Specials | Zelte, Info Bars | Walker | Wände, Würfel, Tower |
Sky Dancer | Sky Ads, Helium | Spiele, Fun Action Games | The Others

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
GENERAL SCHEME
GENERAL SCHEME
inflaon valves
overpressure valves
20 pcs.

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
INFLATION
Clean an area, where the tent should be placed. Mainly sharp objects and chemicals have to be
removed. Use of protecon blanket is recommended.
1.
Remove tent from the bag, place it to its one
of possible posions.
2.
Check posion and funcon of all six valves.
Due to an order of central inflaon system,
all four black inflaon valves (on each
corner), must be installed on posion
signed with black arrow. A base part of
black valve must be properly ghted (check
a valve seal before use), small black cap
must stay open.
Red overpressure valves must be installed
on other two posions (central legs), well
ghted to prevent air leak.
In a case tent was not used for longer me
period, it is recommended to check
funconing of all overpressure
valves by pushing the spring with a finger or
blowing through the valve.Paralelly, seats of
all valves shall be checked to avoid sand
3. red overpressure
valves
black inflatable
valves
black arrow
posion
CUBE SETUP MANUAL
Walls and banners should be installed
before inflaon of tent.
4.
FRONT (recommended posion) TOP
Clean an area, where the tent should be placed. Mainly sharp objects and chemicals have to be
1.
Remove tent from the bag, place it to its one
2.
all four
corner)
signed with black arrow . A base part of
a valve seal before use), small black cap
must stay open.
Red overpressure valves must be installed
period, it is recommended to check
valves by pushing the spring with a finger or
blowing through the valve.Paralelly, seats of
all valves shall be checked to avoid sand
3. red overpressure
valves
black inflatable
valves
black arrow
CUBE SETUP MANUAL
Walls and banners should be installed
4.
FRONT TOP

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
hose of pump
Connect a hose of pump to the one of black
valve and start inflaon.
5.
Continue an ination within whole structure gets rigid, ideally till the moment when overpressure valves
would open automatically. Overpressure valves are calibrated to the maximum allowable pressure, do
not overpressure your tent more as necessary.
Do not disable overpressure valves, it may cause a bladder rupture!
8.
CUBE SETUP MANUAL
When tent is erected, put the legs to the
future posion.
If the tent can´t erect, help the whole tent
to erect and put it to the future posion.
7.
Aer releasing an inflaon hose, do not
forget to close and ght the small cap of
each inflaon valve.
9.
Tent has erected itself.
6.

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
DEFLATION
Open one of inflaon valve.
1.
Once tent start to fall down push the center
of middle leg inwards.
2.
Push to center of middle leg on other side to
achieve the same shape as before ination.
3.
CUBE SETUP MANUAL
Open rest ve valves.
4.
Once some air is released and internal
pressure in the legs decrease, pull right (or
left) half of tent to the transverse one.
5.
FRONT (recommended posion)
1.
Once tent start to fall down push the center
of middle leg inwards.
2.
Push to center of middle leg on other side to
3.
CUBE SETUP MANUAL
4.
Once some air is released and internal
pressure in the legs decrease, pull right (or
left) half of tent to the transverse one.
5.
FRONT

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
Rolling the tent. In this way you will release
the rest of air out of the structure. Unroll it and
roll again to get a compact package, tting
into the trolley bag. A last step before putting
the package into the bag is to screw all valves
back into their position.
5.
CUBE SETUP MANUAL
Steel spikes must be packed in an extra pouch, which is included in a delivery.Put a pouch into separate
pocket in a trolley bag. Put spare parts and a repair kit into another separate pocket in a trolley bag. When
all parts including side walls etc are in a trolley bag, zip it on smoothly. If the volume is too big, use
support tapes with trident buckles to bing the bag, decrease avolume and help the zipper to prevent its
damage.
5.

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
ANCHORING
SCHEME
CUBE SETUP MANUAL
ANCHORING
SCHEME
anchoring in a calm wind
anchoring in a strong wind
anchoring on hard surface

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
Anchor each leg by using four steel spikes
(point C) through aluminium buckles in 45°
to the ground. Check right position of legs to
avoid stress on zippers or weaved side
walls. In a case of strong wind it is
recommended to anchor wall base with steel
spikes through eyelets too.
1.
There are main ropes attached to points A
directly from the factory. Those ropes must
be anchored with steel spikes. An optimum
angle of spikes to the ground is 45°, an
optimum angle of ropes to the tent can see in
anchoring schema.
2.
Push triangular plastic cleats towards to the
roof to tighten all ropes.
3.
ANCHORING TO THE STRONG WIND : Repeat a procedure of basic anchoring, just add four more ropes to be
attached by quick links to points B. Additional ropes are included in a package.
Adjust an additional rope length in a way, that it is 5-10cm shorter as a distance between point B and D.
Once adjusted, hitch the loop on the spike of point E. As the rope is shorter, it is well tensioned to help a tent
to resist a strong wind.
4.
ANCHORING ON HARD SURFACE (TO THE LIGHT WIND / by using ballast bags) Fill ballast bags with water
through dismounted valve. After water  lling screw the valve including top cap to avoid water
leak.Warning: Ballast bag is designed for pouring water, not to be pressurized with hose! Do not in ate
ballast bags with an air pump! When carrying full bags, never throw it to the surface. By ground impact an
internal pressure increase, what can lead to the bag rupture. Lay bags to the ground to ideal positions of
legs. Side to lay down is a side with hooks. A valve is place on a top side. Hooks must be directed diagonally
to the tent, facing to aluminium buckles of tent.
5.
CUBE SETUP MANUAL
B
A
C
D

WIR BLASEN AUF. SIE FALLEN AUF. www.noproblaim.at
NOTE
Aufbauvideo Pneu Zelt
https://www.youtube.com/user/noproblaimvideos
NOTE
Avoid open ame, sharp objects and chemicals.
Clean by water, technical alcohol and detergent (no aggressive) only! Do not use aggressive dissolvent!
Store dry!
Tent is made from 100% polyester and polyurethane bladder.
It can be damaged by rough handling!
1.
Do not overpressure!
By exposing to sun, internal pressure is naturally increasing.
Overpressure is released by RED overpressure valve, there must be placed on right position.
Once the air comes cooler (mainly in the evening), internal pressure goes down.
There can be the necessity to rell missing air.
2.
Use all walls, visors and tunnels after purchase. Residual chemical substances from sublimation process can
continue and cause migration of color. These chemicals have to be separated. Risk of further migration of
color has been reduced by using or ventilation of walls visors and tunnels.
3.
Always screw all valves back into their position before putting the tent into the bag! Unscrew valves in bag
can damage valve bases.
4.
