Nobles Strive ReadySpace User manual

Nobles | 701 N. Lilac Drive | P.O. Box 1452 | Minneapolis MN 55440-1452 | 800.553.8033 | www.nobles.com | [email protected]
Specifications subject to change without notice. REV 8.14.06
Solution System ReadySpace Restorative Extraction
Solution tank capacity 21 gal / 72 L
Nominal solution flow rate 0.33 gpm / 1.3 L /min 1 gpm / 3.8 L /min
Solution pump – psi 100 psi / 6.9 bar
Nozzle configuration (2) Quick release nozzles
Recovery System
Recovery tank capacity 21 gal / 72 L
Vacuum shoe size 22 in / 560 mm 23 in / 580 mm
Airflow 65 cfm / 1.84 m3per min
Waterlift 120 in / 3050 mm
Vacuum motor Hp (2) 0.64 HP / 0.48 KW
Vacuum motor stages 3 stage
Productivity
Recommended cleaning speed 100 fpm / 30.5 mpm 50 fpm / 155 mpm
Maximum per hour 13,200 ft2/ hr / 1,226 m2/ hr 5,500 ft2/ hr / 510 m2/ hr
Typical range per hour 6,000-10,000 ft2/ hr 560 – 930 m2/ h 2,000-4,000 ft2/ hr 185 – 370 m2/ hr
Brush System
Roller / Brush length 22 in / 560 mm
Roller / Brush material Nylon
Motor Hp (2) 0.625 HP / 0.315 KW
Motor RPM 700
Drive System
Top transport speed Up to 250 fpm / 76 mpm
Max. ramp while cleaning 3 degree
Max. ramp while transporting 11 degree
Transaxle Hp 0.2 HP / 0.104 KW continuous
Power System
System voltage 24 V
Total power consumption 65 amps
Battery run time 2.5 hours
Battery configuration 4-6 volt 235 AH batteries
Roller / Brush circuit breaker 17 A
Drive circuit breaker 20 A
Dimensions / Weight / Sound level
Length 60 in / 1520 mm
Width 28 in / 710 mm
Height 42 in / 1070 mm
Net weight 590 lb / 268 kg (includes batteries)
Sound Level 72 dBA
Warranty 3 years/2500 hrs on parts and labor (excluding batteries).
10 years on rotationally-molded polyethylene tanks.
Please contact the company for more warranty information.
Strive™w/ReadySpace
specifications
