NoiseKen 01-T1880 User manual

INSTRUCTIONMANUAL
Radiation immunity checking patch antenna
MODEL 01-T1880
NOISE LABORATORY CO., LTD.
1.01 edition
AEY00062-00E-0B

NOTICE
• The contents of this instruction manual (the “Manual”) are subject to change
without prior notice.
• No part of the Manual may be reproduced or distributed, in any form or by any
means, without the authorization of Noise Laboratory Co., Ltd. (the
“Company”).
• The contents of the Manual have been thoroughly examined. However, if
you find any problems, misprints, or missing information, please feel free to
contact our sales agent who you purchased our product from.
• The Company assumes no responsibility for any loss or damage resulting
from improper usage, failure to follow the Manual, or any repair or
modifications of this product undertaken by a third party other than the
Company or the agent authorized by the Company.
• The Company assumes no responsibility for any loss or damage resulting
from remodeling or conversion solely undertaken by the user.
Please note that the Company cannot be held responsible for any
consequences arising from the use of this product.

1
1.IMPORTANTSAFETYPRECAUTIONS
The following instructions are very important for safe handling of the
01-T1880 (hereinafter “the Unit ). They must be kept strictly to prevent
users of the Unit from receiving harm or damage through using the Unit.
Read them carefully before use.
1. A person who has a pacemaker on should not operate the Unit
and also should not enter the area where it is operating.
It may result in a fatal or serious accident.
2. A number of safety recommendations are listed in the later chapter
"BASIC SAFETY PRECA TIONS". Be sure to read them before test
environment settings, connecting relating equipment and testing.

Memorandum
2

3
2.APPLICATIONFORMFORINSTRUCTIONMANUAL
We place an order for an instruction manual.
Model: 01-T1880
Serial No.:
Applicant:
Company name:
Address:
Department:
Person in charge:
Tel No.:
Fax No.
Cut off this page “APPLICATION FORM FOR INSTRUCTION
MANUAL” from this volume and keep it for future use with
care.
When an INSTRUCTION MANUAL is required, fill in the above Application
Form and mail or fax it to the following sales department of our company.
To: NOISE LABORATORY CO., LTD.
1-4-4 Chiyoda, Chuo-Ku, Sagamihara City, Kanagawa Pref.
252-0237 Japan
Tel: [phone] Fax: [phone]
Cut line
Cut line

Memorandum
4

5
3.TABLEOFCONTENTS
１．IMPORTANT SAFETY PRECAUTIONS ..................................... 1
２．APPLICATION FORM FOR INSTRUCTION MUNUAL ....................... 3
３．TABLE OF CONTENTS .................................................... 5
４．PREFACE ................................................................. 6
５．BASIC PRECAUTIONS FOR OPERATION .................................. 7
６．MAIN UNIT AND ACCESSORIES .......................................... 9
７．SPECIFICATIONS ........................................................ 10
８．HOW TO CONNECT EQUIPMENT・OPERATION .......................... 11
９．MEASUREMENT DATA .................................................. 12
１０.WARRANTY ............................................................. 14
１１.MAINTENANCE ......................................................... 16
１２．NOISE LABORATORY SUPPORT NETWORK ............................ 17

6
4.PREFACE
We thank you for your purchase of radiation immunity checking patch antenna (01-T1880).
This manual contains how to use the 01-T1880 and other important information. In order
to obtain the highest performance from your 01-T1880, thoroughly understand the contents
of this manual and use as ready reference for operation.
This Instruction Manual will help operators handle and utilize radiation immunity
checking patch antenna 01-T1880 in safety.
Keep this Instruction Manual in a place where it is readily available.
§ Features
1. Thisitemisthetestartifacttopre-checktheoutputofequipmentforradiationimmunitytest.
2. The patch antenna outputs detected electromagnetic field RF signal. Also diode
detected DC signal can be outputted.
3. Electric field up to 200 V/m can be monitored by connecting attenuator in accessory.

7
5.BASICSAFETYPRECAUTIONS
1. Safety Warning Signs and Their Meanings
ＷＡＲＮＩＮＧ 警告
！ Indicates Warning.
Failure to follow this safety information can lead to a
potentially hazardous situation resulting in death
or serious injury.
ＣＡＵＴＩＯＮ 注意
！
Indicates Caution.
Failure to follow this safety information can lead to a
potentially hazardous situation resulting in a minor
injury or moderate damage.
2. Basic Safety Precautions
ＷＡＲＮＩＮＧ 警告
！
1. Do not allow people with pacemakers or other electronic medical devices to operate this
unit and to enter the testing area while this unit is operating. Failure to observe this can
result in malfunctions in the electronic medical device and endanger personal safety.
(Precaution regarding personal safety and operation)
2. Noise Laboratory and our affiliated dealers are not liable for any injuries or equipment
damage due to improper operation of this unit or for any resulting incidental damages.
(Precaution regarding personal safety, operation, environment, and connection)
ＣＡＵＴＩＯＮ 注意
！
3. In the measurement environment, strong electromagnetic field will be generated, so
do not touch the Unit. (Precautionregardingpersonalsafety,operation,andenvironment)
4. Do not wipe the unit with thinner, or other solvents. If the unit is dirty, wipe with a cloth
dipped in neutral detergent after it is fully wrung out. Wiping with a solvent can damage the
unit surface. (Precaution regarding manipulation)
5. Do not give strong impact to the Unit. (Precaution regarding manipulation)
6. Please use the unit within the range of humidity 25% to 75%.In the event that
condensation forms, be sure that the unit is fully dried before starting operation. Avoid using
the unit in locations with high humidity or exposed to large amounts of dust
. (Precaution
regarding environment)

8
7. Do not use or store in environments with extremely hot or cold temperatures. If you cannot
maintain a suitable operating environment (temperature: 15°C to 35°C, humidity: 25% to
75%) (Precaution regarding environment)
8. Any required repairs, maintenance, and internal adjustment for this unit must be performed
only by service engineers authorized by Noise Laboratory.

9
6.MAINUNITANDACCESSORIES
A B
C D,E F
Mark Item Quantity
A Patch antenna １
B Detector １
C Coaxial cable SMA-N（L type）2 m １
D Attenuator 3dB（N type connector）１
E Attenuator 20dB（N type connector）１
F Instruction manual １

10
7.SPECIFICATION
Item Specification ／ characteristics Remark
Patch antenna
Dimension 104 mm×80 mm
Pattern dimension 100 mm×76 mm
Termination resistor 10.3 Ω
Output connector SMA
Detector
Through part：
Input N type connector
Output N type connector
Diode detector part：
Input N type connector
Output BNC connector（detecting output）
Built-in Diode detector frequency characteristic
10 MHz~33 GHz
Dimension 130 mm×80 mm×33 mm
Diagram
10 kΩ
Detector
Patch antenna

11
8.HOWTOCONNECTEQUIPMENT・
・・
・OPERATION
Connect the patch antenna and detector by coaxial cable in accessory. Insert the attenuator
according to measurement electric field strength. Insert 3dB attenuator when electric field
strength up to 25 V/m. Insert 20dB attenuator when electric field strength up to 200 V/m.
Select ‘THROUGH’ or ‘DIODE DETECTOR’ according to measurement purpose.
‘THROUGH’ is to output the high frequency signal (RF) received by patch antenna without
any change, so it is observed by spectrum analyser, power meter, etc. ‘DIODE DETECTOR’
detects the RF signal internally, so it is output by direct current level signal according to
electric field strength.
Spectrum analyzer
etc
Oscilloscope
Multimeter
etc
Attenuator
3dB / 20dB
Detector
Patch antenna

Set the patch antenna into G
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
and 20dB attenuator.
Set the patch antenna into G
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
and 20dB attenuator.
9
Set the patch antenna into G
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
and 20dB attenuator.
RF OUTPUT CONNECTOR
RF OUTPUT CONNECTOR
9
.
MEASUREMENTDATA
Set the patch antenna into G
-
TEM Cell. Generate the electric field
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
RF OUTPUT CONNECTOR
RF OUTPUT CONNECTOR
12
MEASUREMENTDATA
TEM Cell. Generate the electric field
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
RF OUTPUT CONNECTOR
（
1MHz
RF OUTPUT CONNECTOR
（
1MHz
MEASUREMENTDATA
TEM Cell. Generate the electric field
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
1MHz
～
1GHz 25V/m
1MHz
～
1GHz 200V/m
MEASUREMENTDATA
TEM Cell. Generate the electric field
（
25 V/m and 200 V/m
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
1GHz 25V/m
）
1GHz 200V/m
）
25 V/m and 200 V/m
from 1 MHz (10 MHz) to 1 GHz. These are monitored measurement example of each
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator
25 V/m and 200 V/m
）
OUTPUT connector of detector. And the output value is the data revising 3dB attenuator

DETECTED OUTPUT CONNECTOR
DETECTED OUTPUT CONNECTOR
DETECTED OUTPUT CONNECTOR
DETECTED OUTPUT CONNECTOR
※
Detected signal output is MINUS polarity.
DETECTED OUTPUT CONNECTOR
DETECTED OUTPUT CONNECTOR
Detected signal output is MINUS polarity.
13
DETECTED OUTPUT CONNECTOR
※
DETECTED OUTPUT CONNECTOR
※
Detected signal output is MINUS polarity.
※
（10MHz
～
※
（10MHz
～
Detected signal output is MINUS polarity.
MEASUREMENT DATA
～
1GHz 25V/m
～
1GHz 200V/m
Detected signal output is MINUS polarity.
MEASUREMENT DATA
1GHz 25V/m
）
1GHz 200V/m
）
MEASUREMENT DATA

14
10.WARRANTY
Servicing terms
The following terms are applicable to servicing by Noise Laboratory Co., Ltd., (hereafter
referred to as the Company) provided to maintain the intended performance of its
products.
1. Scope
The following terms shall apply only to products made by the Company.
2. Technical servicing fee
In the event of a failure of a product within the warranty period (see warranty
section), the Company will repair a product without charge. After the warranty
expires, repairs will be billed at a nominal cost.
3. Ownership of defective parts
Any defective part exchanged under the Company’s servicing belongs to it.
4. Limited liability
In the event that damages resulting from servicing by the Company are intentional
or caused by negligence, the Company will pay the cost but at the purchase value of
the relevant product maximum. But, notwithstanding the foregoing, the Company
shall not be responsible for any incidental or consequential damages of any nature,
including without limitation thereof loss of would-be profit or compensation
demanded from a third party
5. Refusal to offer servicing
The company may not accept a repair order in the following cases:
More than 5 years have passed since the product discontinued
More than 8 years have passed after delivery
Required component for servicing already discontinued and no alternative is
available.
Product changed, repaired or remodeled without obtaining a prior permission
from the Company.
Product severely damaged to the extent it has lost its original form

WARRANTY
15
Limited warranty
Noise Laboratory Co., Ltd. (hereafter referred to as the Company) warrants its products
to be free from defects in materials and workmanship under normal use and service for
a period of one year from date of delivery. In the event of failure of a product covered by
this warranty, the Company will repair the product or may, at its option, replace it in lieu
of repair without charge.
Not withstanding the foregoing, the Company shall not be responsible for any incidental
or consequential damages of any nature, including without limitation thereof loss of
would-be profit or compensation demanded from a third party. This warranty is valid
only in Japan.
1. Scope
This warranty shall only apply to products made by the Company.
2. Period
One year from date of delivery. The warranty may be valid in 6 months after
servicing if the same failure on the same component has repeated.
3. Exclusions
The followings are exclusions from this warranty:
Consumable parts (including HV relay)
Failure caused by misuse, neglect, accident or abnormal conditions of operation
Failure caused by remodeling on the user side without prior permission from the
Company
Failure caused by servicing by unauthorized personnel by the Company
Failure due to force majeure including but not limited to, acts of God, fire, war,
riot, rebellion and others
Failure due to shock or drop in or after transit
Failure due to operation in environment being out of ambient specifications.
A unit shipped to overseas.

16
11.MAINTENANCE
1. When repair, maintenance or internal adjustment of the unit is required, a qualified
service engineer takes charge of such work.
2. Maintenance on the user side is restricted to the outside cleaning and functional
check of the unit.
3. When checking or replacing the fuse, turn off the switch of the unit and disconnect
the plug socket beforehand.
4. When cleaning the unit, turn off the switch of this unit and the connected equipment
and disconnect the plug socket beforehand.
5. Avoid using chemicals for cleaning. Otherwise, the coating of the unit may peel off
or the sight glass may be broken.
6. Do not open the cover of this unit.

17
12.NOISELABORATORYSUPPORTNETWORK
 If a symptom which seems a trouble is found, inform the model name and
serial number of the product together with the symptom to Noise Laboratory
or your nearest sales agent of Noise Laboratory.
When the product is returned to Noise Laboratory, write the state of the
trouble, contents of your request, model name and serial number in a repair
order, and pack the product and repair order sheet in the former package of
equivalent suitable for transit and send them back.
NOISE LABORATORY CO., LTD.
SALES DEPT. TEL: [phone] FAX [phone]
E-mail: [email protected]
http://www.noiseken.com

NOISE LABORATORY CO., LTD.
1-4-4, Chiyoda, Chuo-ku, Sagamihara City, Kanagawa Pref., 252-0237, Japan
TEL: [phone] FAX: [phone]
URL: http://www.noiseken.co.jp Printed in Japan
