DKU-5 Data Cable Installation and Configuration Guide
Legal notices
Part No. 9355802, Issue No. 1
Copyright © 2002 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and Nokia original accessories
logos are trademarks or registered trademarks of Nokia
Corporation. Printed in the USA December, 2002. Electronic
document created December 16, 2002.
Reproduction, transfer, distribution, or storage of part or all of
the contents in this document in any form without the prior
written permission of Nokia is prohibited.
Nokia operates a policy of ongoing development. Nokia
reserves the right to make changes and improvements to any
of the products described in this document without prior
notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE
FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.”
EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,
RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA
RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR
WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
TRADEMARKS
Product names and/or brands mentioned herein are trademarks or
registered trademarks of their respective holders.
EXPORT CONTROLS
This product contains commodities, technology or software
exported from the United States in accordance with the Export
Administration regulations. Diversion contrary to U.S. law is
prohibited.
FCC/INDUSTRY CANADA NOTICE
Your phone may cause TV or radio interference (for example, when
using a telephone in close proximity to receiving equipment). The
FCC or Industry Canada can require you to stop using your
telephone if such interference cannot be eliminated. If you require
assistance, contact your local service facility. This device complies
with part 15 of the FCC rules. Operation is subject to the condition
that this device does not cause harmful interference.
Tested To Comply
With FCC Standards
FORHOMEOROFFICEUSE
DKU5_install.book Page ii Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Contents of the sales package . . . . . . . . . . . . . . . . . . . . .1
Install software first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Use your DKU-5 connection . . . . . . . . . . . . . . . . . . . . . .2
Locate additional information . . . . . . . . . . . . . . . . . . . . . 3
2 Software/hardware installation . . . . . . . . . . . . . . . . 4
Install the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Install the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Confirm installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connect your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Contact Nokia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DKU5_install.book Page iii Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

iv DKU-5 Data Cable Installation and Configuration Guide
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
DKU5_install.book Page iv Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

1
1 Introduction
• WELCOME
Thank you for your purchase of the Nokia DKU-5
Data Cable! You now have the ability to connect
your compatible Nokia phone to your PC (desktop or
laptop) using an available USB port.
SYSTEM REQUIREMENTS
In order to use this cable, you need:
• the Nokia software CD-ROM
• a compatible Nokia phone
• a USB-equipped Pentium-class PC or laptop
computer
• Windows 98 (Second Edition), Windows
Millennium Edition (ME), Windows 2000
Professional, or Windows XP (Home or
Professional)
Warning: When connecting your phone or
this cable to any other device, read the
device’s user guide for detailed safety
instructions. Do not connect incompatible
products.
• CONTENTS OF THE SALES PACKAGE
The DKU-5 Data Cable sales package contains the
following items:
•DKU-5DataCable
•softwareCD-ROM
• installation guide
• warranty information
DKU5_install.book Page 1 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

2 DKU-5 Data Cable Installation and Configuration Guide
• INSTALL SOFTWARE FIRST
Important: The data cable software must be
installed before
you connect the cable for the
first time. Only after the software has been
installed can Windows successfully install
and configure the cable.
The DKU-5 Data Cable requires software drivers in
order to communicate with your PC and phone
properly.
Please follow the instructions in this guide for
proper installation of the software and cable.
• USE YOUR DKU-5 CONNECTION
Once the cable has been installed and configured by
Windows, the following options are available:
USE NOKIA PC SUITE
Nokia PC Suite allows you to manage your phone’s
settings, create new ringing tones or graphics, and
synchronize your phone’s data with some of the
most popular PIM (Personal Information
Management) applications.
PC Suite and all related modem software is provided
to you free of charge and can be downloaded from
the PC software downloads section of:
http://www.nokia.com/us (US)
http://www.nokia.ca (Canada)
USE YOUR PHONE AS A WIRELESS MODEM
Your phone can function as a wireless modem for
use with your PC or laptop computer, depending on
the types of digital data/fax services supported by
your phone and wireless service provider.
DKU5_install.book Page 2 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com
all-guides.com

3
You may be able to use you phone as a wireless
modem to:
• access the Internet and browse the World Wide
Web, send and receive e-mail, etc.
• remotely access corporate networks
• send and receive faxes
For those phones supporting high-speed packet
data, the DKU-5 Data Cable provides the maximum
bandwidth for data throughput.
Important: The DKU-5 Data Cable software
and hardware must be installed before
installing PC Suite or performing the wireless
modem installation.
Note: Digital data/fax calls are available
only if your network supports these features.
A subscription to these services may be
required. Internet access may also require a
subscription to services from an internet
service provider (ISP). Please check with your
wireless service provider for more
information.
• LOCATE ADDITIONAL INFORMATION
For more information on PC Suite and wireless
modem installation and configuration, please refer
to your phone’s PC Suite User Guide and PC/PDA
Connectivity Guide. This document can be
downloaded from the PC software downloads
section of:
http://www.nokia.com/us (US)
http://www.nokia.ca (Canada)
DKU5_install.book Page 3 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

4 DKU-5 Data Cable Installation and Configuration Guide
2 Software/hardware
installation
Before you can use the DKU-5 Data Cable (also
known as Nokia Connectivity Cable DKU-5), you
must install the necessary software and drivers for
use by Windows Plug and Play.
The Nokia software installation program loads the
correct device drivers and software. These files are
used by Windows to configure your system
automatically the first time you connect the cable.
• INSTALL THE SOFTWARE
Please make sure no other applications are running.
1Insert the Nokia CD-ROM into your computer’s drive.
2Select the software installation option from the CD’s
menu.
If the Nokia CD’s menu does not appear or your CD-
ROM drive’s autorun option is disabled, double-click
index.htm (found on the CD-ROM).
3Click Next to begin the software installation.
4Click Finish to complete the software installation.
Windows 98/ME users, please reboot your computer
when prompted to complete installation.
DKU5_install.book Page 4 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

5
• INSTALL THE HARDWARE
After you have performed the software installation
as described earlier, please connect only the DKU-5
Data Cable to your PC’s available USB port.
Windows automatically detects the data cable when
you connect it for the first time. Windows installs
the cable and also configures a virtual
communications port for use by the data cable.
FOR WINDOWS 98/ME USERS
Windows 98 and ME locates the drivers and
software that you previously installed and
completes the hardware installation automatically.
FOR WINDOWS 2000 USERS
Windows 2000 automatically locates the drivers and
software that you previously installed. During the
installation process, the Digital Signature Not
Found message may be displayed.
Please click Yes if this dialog box is displayed to
complete the hardware installation.
FOR WINDOWS XP USERS
When the cable is detected, Windows XP activates
the Found New Hardware Wizard to assist you with
the installation of both the cable adapter and the
virtual COM port.
Complete the installation wizards for both devices,
clicking Continue Anyway if the Windows logo error
message is displayed.
DKU5_install.book Page 5 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

6 DKU-5 Data Cable Installation and Configuration Guide
• CONFIRM INSTALLATION
Use Windows Device Manager to confirm that the
DKU-5 Data Cable has been installed properly.
Also, please make note of the virtual COM port
number assigned to the DKU-5 Data Cable. This
information may be required when configuring your
data/fax software, or when installing Nokia PC Suite.
ACCESS WINDOWS DEVICE MANAGER
To access your computer’s Device Manager, double-
click the System icon located in the Control Panel.
Then follow the instructions below for your
operating system.
WINDOWS 98/ME
Click the Device Manager tab on the System
Properties window.
WINDOWS 2000/XP
Click the Hardware tab, then click the Device
Manager button.
Example: Windows 98 and Me
DKU5_install.book Page 6 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com

7
• CONNECT YOUR PHONE
Once you complete the DKU-5 Data Cable software
and hardware installation, you can connect your
phone to the cable.
If the Windows Add New Hardware Wizard begins
when you plug the phone into the cable, please refer
to your phone’s PC Suite User Guide and PC/PDA
Connectivity Guide for installation instructions.
Consult your phone's user guide for safety and
operating instructions.
Example: Windows 2000 and XP
DKU5_install.book Page 7 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com
all-guides.com

8 DKU-5 Data Cable Installation and Configuration Guide
3 Contact Nokia
Nokia Customer Care
Register your accessory
Make sure to register your DKU-5 Data Cable at
www.warranty.nokiausa.com or 1-888-NOKIA-2U
(1-888-665-4228) so that we can serve your needs
better if you should need to call the center or have
your cable repaired. (US customers only)
E-newsletters
When you register your data cable, you can sign up
for Nokia's e-newsletter Nokia Connections if you
would like. You will receive tips and tricks on using
your phone, accessory information, and special
offers. (US customers only)
Customer Care
Center, USA
Nokia Mobile Phones
7725 Woodland Center Blvd.,
Suite #150
Tampa, Florida 33614
Tel: 1-888-NOKIA-2U
(1-888-665-4228)
Fax: [phone]
TTY/TDD Users Only:
1-800-24-NOKIA
(1-800-246-6542)
Customer Care
Centre, Canada
Nokia Products Ltd.
601 Westney Road South
Ajax, Ontario L1S 4N7
Tel: 1-888-22-NOKIA
(1-888-226-6542)
1-905-427-1373
Fax: [phone]
DKU5_install.book Page 8 Monday, December 16, 2002 12:07 PM
All manuals and user guides at all-guides.com
