Nokia 2720 fold User manual

Nokia 2720 fold User Guide
9216121
Issue 1.0

Contents
Safety 5
Get started 7
Insert SIM card and
battery 7
Charge the battery 8
Antenna 9
Headset 9
Magnets and magnetic
fields 10
Keys and parts 11
Switch on and off 12
Standby mode 12
Volume key functions
when the fold is
closed 13
Keypad lock 14
Functions without a SIM
card 15
Applications running in
background 15
General
information 15
About your device 15
Network services 17
Shared memory 18
Access codes 18
Support 19
Calls 20
Make and answer a
call 20
Loudspeaker 20
Dialling shortcuts 21
Write text 22
Text modes 22
Traditional text input 22
Predictive text input 23
Navigate the
menus 24
Messaging 24
2Contents
© 2009 Nokia. All rights reserved.2

Text and multimedia
messages 25
E-mail 27
Flash messages 29
Nokia Xpress audio
messages 29
Instant messaging 30
Voice messages 30
Message settings 31
Contacts 32
Call log 34
Settings 34
Profiles 34
Tones 35
Display 35
Date and time 35
Shortcuts 36
Synchronisation and
backup 36
Connectivity 37
Call and phone 40
Accessories 41
Configuration 41
Restore factory
settings 42
Operator menu 43
Gallery 43
Media 45
Camera and video 45
FM radio 46
Voice recorder 48
Music player 48
Applications 50
Organiser 52
Alarm clock 52
Calendar and to-do
list 53
Web or Internet 54
Contents 3
© 2009 Nokia. All rights reserved. 3

Connect to a web
service 55
SIM services 55
Nokia original
accessories 56
Practical rules about
accessories 57
Battery 57
Green tips 58
Save energy 58
Recycle 59
Learn more 59
Battery 60
Battery and charger
information 60
Nokia battery
authentication
guidelines 61
Taking care of your
device 63
Recycle 64
Additional safety
information 64
Small children 64
Operating
environment 64
Medical devices 64
Vehicles 65
Potentially explosive
environments 66
Emergency calls 66
Certification information
(SAR) 67
MANUFACTURER’S
LIMITED WARRANTY 68
Index 74
4Contents
© 2009 Nokia. All rights reserved.4

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
Safety 5
© 2009 Nokia. All rights reserved. 5

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
6Safety
© 2009 Nokia. All rights reserved.6

Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
1 Press and slide the back cover towards the bottom of
the phone, and remove it (1).
2 Remove the battery (2).
3 Open the SIM card holder (3), insert the SIM card with
the contact surface facing down (4), and close the
holder (5).
Get started 7
© 2009 Nokia. All rights reserved. 7

4 Insert the battery (6), and replace the back cover (7).
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
8Getstarted
© 2009 Nokia. All rights reserved.8

Antenna
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
The figure shows the antenna area marked in grey.
Headset
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.
Get started 9
© 2009 Nokia. All rights reserved. 9

When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
10 Get started
© 2009 Nokia. All rights reserved.10

Keys and parts
1End/Power key
2Right selection key
3Earpiece
4Main display
5Left selection key
6Navi™ key; hereafter
referred to as scroll key
7Call key
8Keypad
Get started 11
© 2009 Nokia. All rights reserved. 11

9Camera lens
10 Headset connector/Nokia
AV Connector (2.5 mm)
11 Wrist strap eyelet
12 Loudspeaker
13 Charger connector
14 Volume keys
15 Cover display
Switch on and off
Press and hold the power key.
Standby mode
When the phone is ready for use, and you have not entered
any characters, the phone is in the standby mode.
12 Get started
© 2009 Nokia. All rights reserved.12

1Network signal strength
2Battery charge level
3Network name or operator logo
4Functions of selection keys
The left selection key, Go to, allows you to access the
functions in your personal shortcut list. When viewing the
list, select Options > Select options to view the available
functions, or select Options > Organise to arrange the
functions in your shortcut list.
Volume key functions when the fold is closed
Activate the cover display
Press a volume key.
Adjust the volume
Use the volume keys when the cover display is activated.
Get started 13
© 2009 Nokia. All rights reserved. 13

Mute the ringing tone of an incoming call
Press a volume key.
Reject an incoming call
Press and hold a volume key.
Keypad lock
Lock the keypad
Select Menu, and press *within 3.5 seconds to lock the
keypad.
Unlock the keypad
Select Unlock, and press *within 1.5 seconds. If the
security keyguard is activated, enter the security code
when requested.
Set automatic keypad lock
Select Menu > Settings > Phone > Automatic
keyguard > On, and set the length of time, after which
the keypad locks.
14 Get started
© 2009 Nokia. All rights reserved.14

Answer a call when the keypad is locked
Press the call key. When you end or reject the call, the
keypad locks automatically.
When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.
Functions without a SIM card
Some functions of your phone may be used without
inserting a SIM card, such as Organiser functions and
games. Some functions appear dimmed in the menus and
cannot be used.
Applications running in background
Leaving applications running in the background increases
the demand on battery power and reduces the battery life.
General information
About your device
The wireless device described in this guide is approved for
use on the EGSM 900 and 1800 MHz networks. Contact your
service provider for more information about networks.
General information 15
© 2009 Nokia. All rights reserved. 15

Your device may have preinstalled bookmarks and links for
third-party internet sites and may allow you to access
third-party sites. These are not affiliated with Nokia, and
Nokia does not endorse or assume liability for them. If you
access such sites, take precautions for security or content.
Warning:
To use any features in this device, other than the alarm
clock, the device must be switched on. Do not switch the
device on when wireless device use may cause interference
or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some
images, music, and other content from being copied,
modified, or transferred.
Make back-up copies or keep a written record of all
important information stored in your device.
When connecting to any other device, read its user guide
for detailed safety instructions. Do not connect
incompatible products.
16 General information
© 2009 Nokia. All rights reserved.16

The images in this guide may differ from your device
display.
Refer to the user guide for other important information
about your device.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make
specific arrangements with your service provider to use
them. Network services involve transmission of data. Check
with your service provider for details about fees in your
home network and when roaming on other networks. Your
service provider can explain what charges will apply. Some
networks may have limitations that affect how you can use
some features of this device requiring network support
such as support for specific technologies like WAP 2.0
protocols (HTTP and SSL) that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu
names, menu order, and icons.
General information 17
© 2009 Nokia. All rights reserved. 17

Shared memory
The following features in this device may share memory:
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may
reduce the memory available for the remaining features.
If your device displays a message that the memory is full,
delete some of the information stored in the shared
memory.
Access codes
The security code helps to protect your phone against
unauthorised use. The preset code is 12345. You can create
and change the code, and set the phone to request the
code. Keep the code secret and in a safe place separate
from your phone. If you forget the code and your phone is
locked, your phone will require service and additional
charges may apply. For more information, contact a Nokia
Care point or your phone dealer.
The PIN code supplied with the SIM card protects the card
against unauthorised use. The PIN2 code supplied with
some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your service provider.
18 General information
© 2009 Nokia. All rights reserved.18

The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
To set how your phone uses the access codes and security
settings, select Menu > Settings > Security.
Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, see the user guide or see the support pages at
www.nokia.com/support or your local Nokia website, or
with a mobile device, www.nokia.mobi/support.
If this does not resolve your issue, do the following:
•Restart the device: switch off the device, and remove
the battery. After about a minute, replace the battery,
and switch on the device.
•Restore the original factory settings as explained in the
user guide.
If the issue remains unsolved, contact Nokia for repair
options. See www.nokia-asia.com/repair. Before sending
General information 19
© 2009 Nokia. All rights reserved. 19

your device for repair, always back up the data in your
device.
Calls
Make and answer a call
Make a call
Enter the phone number, including the country and area
code if necessary, and press the call key.
Answer an incoming call
Press the call key.
Reject a call
Press the end key.
Adjust the volume
During a phone call, use the volume keys.
Loudspeaker
If available, you may select Loudsp. or Normal to use the
loudspeaker or the earpiece of the phone during a call.
20 Calls
© 2009 Nokia. All rights reserved.20
