Nokia IP71 User manual

IP71 User Guide
version 2.0
N450794001 Rev A
October, 2002

ii Nokia IP71 User Guide
COPYRIGHT
©2002 Nokia. All rights reserved.
Rights reserved under the copyright laws of the United States.
RESTRICTED RIGHTS LEGEND
Use, duplication, or disclosure by the United States Government is subject to restrictions as set
forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013.
Notwithstanding any other license agreement that may pertain to, or accompany the delivery of,
this computer software, the rights of the United States Government regarding its use,
reproduction, and disclosure are as set forth in the Commercial Computer Software-Restricted
Rights clause at FAR 52.227-19.
IMPORTANT NOTE TO USERS
This software and hardware is provided by Nokia Inc. as is and any express or implied
warranties, including, but not limited to, implied warranties of merchantability and fitness for a
particular purpose are disclaimed. In no event shall Nokia, or its affiliates, subsidiaries or
suppliers be liable for any direct, indirect, incidental, special, exemplary, or consequential
damages (including, but not limited to, procurement of substitute goods or services; loss of use,
data, or profits; or business interruption) however caused and on any theory of liability, whether in
contract, strict liability, or tort (including negligence or otherwise) arising in any way out of the use
of this software, even if advised of the possibility of such damage.
Nokia reserves the right to make changes without further notice to any products herein.
TRADEMARKS
Nokia is a registered trademark of Nokia Corporation. Other products mentioned in this document
are trademarks or registered trademarks of their respective holders.
Nokia Contact Information
Corporate Headquarters
Web Site http://www.nokia.com
Telephone [phone] or
1-650-625-2000
Fax [phone]
Mail
Address
Nokia Inc.
313 Fairchild Drive
Mountain View, California
94043-2215 USA

Nokia IP71 User Guide iii
Regional Contact Information
Nokia Customer Support
Americas Nokia Inc.
313 Fairchild Drive
Mountain View, CA 94043-2215
USA
Tel: [phone]
Outside USA and Canada: [phone]
email: [e-mail]
Europe Nokia House, Summit Avenue
Southwood, Farnborough
Hampshire GU14 ONG UK
Tel: [phone] or
1+44 (0) 8700 555 777
email: [e-mail]
Asia-Pacific Tel: [phone]
email: ipsecurity.apa[email protected]om
Web Site: https://support.nokia.com/
Email: tac.suppor[email protected]
Americas Europe
Voice: 1-888-361-5030 or
1-613-271-6721
Voice: [phone]
Fax: [phone] Fax: [phone]
Asia-Pacific
Voice: [phone]
Fax: [phone]
021018

iv Nokia IP71 User Guide

Nokia IP71 User Guide 5
Contents
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Document Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cautionary Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
About the IP71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
IP71 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
IP71 Externals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Restoring Factory Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Upgrading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using Nokia Horizon Manager . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Upgrading Using CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Managing the IP71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Secure web-based GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Command-line Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SSH Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SNMP Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Nokia Horizon Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Check Point Management Server . . . . . . . . . . . . . . . . . . . . . . 24

6Nokia IP71 User Guide
2 Installing IP71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Planning Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Planning for your IP71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Obtaining Check Point License . . . . . . . . . . . . . . . . . . . . . . . . 26
Managing Check Point Licenses . . . . . . . . . . . . . . . . . . . . . . . 26
Linking to the IP71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using Console Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using Hyperterminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Using Ethernet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Logging Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3 Configuring IP71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Configuring Through a Secure Web-Based GUI . . . . . . . . . . . . . . 36
Using the Quick Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . 37
Configuring Using the GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Interface Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Admin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Manage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Configuring Through SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Configuring Through SNMP Manager . . . . . . . . . . . . . . . . . . . 51
Accessing CLI Through the GUI. . . . . . . . . . . . . . . . . . . . . . . . 51
Generating Security Certificates. . . . . . . . . . . . . . . . . . . . . . . . 52
Managing Through Nokia Horizon Manager . . . . . . . . . . . . . . 55
Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Syslog. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Check Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Nokia IP71 User Guide 7
DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
ARP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Upgrading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Import and Export. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Snort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Edit Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Configuring Through Console . . . . . . . . . . . . . . . . . . . . . . . . . 72
Configuring Static NAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Configuring Network Objects . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Configuring Security Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Configuring NAT Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Configuring Routing and ARP Entries . . . . . . . . . . . . . . . . . . . 81
Installing the Security Policy. . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Configuring Anti-Spoofing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
4 Configuring a VPN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Defining Network Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Defining IP71 Platforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Setting the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Building VPN Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Installing Policies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

8Nokia IP71 User Guide
A Obtaining a Check Point License . . . . . . . . . . . . . . . . . . . . . . . 95
B Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Management Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Hardware Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Copyrights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
C Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
FCC Notice (US) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
D Warranty and Software License . . . . . . . . . . . . . . . . . . . . . . . . 113
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Nokia IP71 User Guide 9
About This Guide
This IP71 User Guide version 2.0 is intended for administrators and network
installation engineers. This User Guide provides an overview of the
installation process and covers all the features of Nokia IP71.
The information in this guide addresses PC users only. Unless otherwise
mentioned, Windows refers to Windows 95, Windows 98, Windows 2000/ NT.
This guide provides information and procedures for installing and using the
Nokia IP71 v2.0 network security platform (NSP), including instructions for
configuring the Check Point NG Firewall.
The Nokia IP71 version 2.0 can be remotely managed using Nokia Horizon
Manager v1.2 Service Pack 1.
Document Organization
This guide is organized into the following chapters:
nChapter 1, “Overview” provides basic information about IP71 and things
that you need before you install the IP71.
nChapter 2, “Installing IP71” describes how to install the IP71.
nChapter 3, “Configuring IP71” describes how to configure the IP71.
nChapter 4, “Configuring VPN” describes how to configure a virtual
private network (VPN) between an IP71 with a Check Point Management
Server or another IP71 located elsewhere.

10 Nokia IP71 User Guide
nAppendix A, “Obtaining a Check Point License” describes the procedure
to obtain a Check Point license.
nAppendix B, “Technical Specifications” provides hardware and software
specifications information.
nAppendix C, “Compliance Information” provides compliance and
regulatory information.
nAppendix D, “Warranty and Software License” describes the Nokia
warranty terms and conditions.
Document Conventions
The following sections provide document conventions including notices,
menu items, and IP address notation conventions used throughout this guide.
Cautionary Icons
Warning
Warnings advise the user that bodily injury might occur because of a
physical hazard.
Note
Notes provide information of special interest or recommendations.

Nokia IP71 User Guide 11
Overview
This chapter provides an overview of the features and functionality of the
IP71 and tells you what you need before you can set up the IP71 and use it to
connect to the Internet.
About the IP71
The IP71 is an Ethernet-to-Ethernet network security platform (NSP) with
four 10/100 Ethernet LAN ports and a 10BaseT WAN port. You can connect
the IP71 to any Internet access device that has an Ethernet interface, such as a
DSL router, a T1 router, or a DSL modem.
The IP71 incorporates the Check Point NG SMB Firewall-1 that enables the
IP71 to function as a security firewall and as a VPN gateway, thus protecting
a small office LAN from unauthorized access.
The IP71 Small Office license is installed on the IP71 and is managed by a
Check Point management server. Security policies are created at the
management server and pushed to the IP71. A single management server on
the WAN side of the IP71 can manage multiple IP71 platforms at various
remote sites. For information on how to configure the IP71 and Managing
Check Point Licenses, see Chapter 2.

1Overview
12 Nokia IP71 User Guide
Features
The Nokia IP71 has the following features:
nSecure Web-based GUI for configuration
nCheck Point NG Firewall -1 / VPN -1, VPN Net for SmallOffice
nDHCP Server
nDynamic WAN IP support through DHCP client and PPPoE client
nLogging
nSecure remote access for configuration (using digital certificates)
nImport and Export of configuration
nFirmware Upgrading
nARP (Static NAT)
nDiagnostics
nManaging Through Nokia Horizon Manager
IP71 Package Contents
The IP71 shipping box includes the following items:
nIP71 device
nA universal power supply
nA country-specific power cord for the universal power supply
nAn Ethernet straight-through cable
nAn Ethernet crossover cable, labeled Crossover
nAn RS-232 console (serial) cable
nThe IP71 CD. The IP71 CD includes the following documents needed to
set up and use the IP71:
nIP71 User Guide
nIP71 Quick Start Guide
nIP71 CLI Reference Guide

IP71 Externals
Nokia IP71 User Guide 13
nfpgen.exe (a tool that generates fingerprints)
nNokia IPSO SOS MIB
nA TFTP Server
nAdobe Acrobat Reader
You can run the CD on a Windows computer with a CD drive.
IP71 Externals
This section provides an overview of the IP71 hardware. Figure 1 shows the
front view of the IP71.
Figure 1 IP71 Front View
Note
The WAN port operates at 10 mbps and must be set to the appropriate
duplex setting with the IP71 command-line interface. The LAN port auto
senses the appropriate speed (10/100 mbps) and duplex setting.
SECURED BY
CHECK POINT
Power Status
Link Tx
WAN
Rx
12
10M=Amber 100M=Green
10/100 Ethernet Switch
3 4
Power
Status Link
Rx
Tx
10/100 Ethernet
LAN ports
One 10BaseT
WAN port

1Overview
14 Nokia IP71 User Guide
The LEDs on the IP71 tell the state of your connection:
LED Description
Power LED When the IP71 is connected to the power source, this LED is
green. When there is no power or when the IP71 power is not
plugged in, the LED is off.
Status LED The IP71 performs a series of diagnostic checks at start up.
During these checks and after their successful completion, this
LED is green; if any of the checks fails, the LED turns amber.
The LED turns off during operating system (OS) bootup and is
green after a successful OS bootup.
10/100 Ethernet
LEDs
Each LED shows the activity on the Ethernet line connected to
the specific port.
If your computer has a 10BaseT network card connected to the
Ethernet line, the LED for that port is amber.
If your computer has a 100BaseT network card attached to the
line, the LED is green.
When there is no data activity on the Ethernet line, the
associated LED glows steady. When there is data activity, the
LED blinks.
If the light is turned off , there is no connection to the associated
port.
WAN Link When there is a WAN connection, this LED is green. But if there
is no WAN connection, the LED remains off.
WAN Tx
(Transmit)
When the IP71 transmits data on the Ethernet WAN line, this
LED turns green and blinks. When there is no outgoing activity
on the line, the LED remains off.
WAN Rx
(Receive)
When the IP71 receives data on the Ethernet WAN line, this
LED turns green and blinks. When there is no incoming activity
on the line, the LED remains off.

Restoring Factory Defaults
Nokia IP71 User Guide 15
Figure 2 shows the rear panel of IP71.
Figure 2 IP71 Rear View
Restoring Factory Defaults
Restore Defaults button is inside a hole on the back panel of the IP71. To
press the button, use a straightened paper clip or pin. Pressing the Restore
Defaults button restores all IP71 settings back to factory defaults. The button
works only after booting is complete, and the green light must be illuminated
to activate the button. The status light goes off while defaults are being
restored, and re-lights after defaults are restored and the IP71 begins to
reboot. It takes over 2 minutes to restore defaults. After the defaults are
restored and the IP71 has rebooted, you will be able to connect only through
the console.
Before You Begin
For simplicity, this guide assumes you are using a DSL ISP account. The IP71
also works with any Internet access device that supports an Ethernet interface,
such as routers that use analog, cable, ISDN, or T1 lines.
To set up the IP71 to connect to the Internet, you need
nAn installed line (DSL or T1) with an ISP account
nAn IP address and a Net Mask address for your IP71
nAn Internet access device such as an analog, cable or ISDN DSL modem/
router or T1 router with an Ethernet port for the LAN
nA Check Point NG SMB certificate key to obtain the NG license
Ethernet LAN Restore Defau
lts
DC 12V
4ConsoleEthernet WAN 321
Console
EthernetWAN

1Overview
16 Nokia IP71 User Guide
nA Check Point management server
nA computer with the following attributes (to configure using console):
nany Operating System that has an SSH client (optional) or a VT100
terminal emulator program installed, such as HyperTerminal
nan available COM port
nA RS-232 serial cable
Upgrading
Upgrading your IP71 (v1.5 or earlier) to v2.0 involves two stages:
1. Upgrade your IP71 to v1.6 firmware
2. Upgrade your IP71 to v2.0 firmware
Ensure that your IP71 is upgraded through both the stages. Nokia
recommends that you use your IP71 using version 2.0 firmware.
Ensure that you have both the firmwares, version 1.6 and version 2.0, are with
you before you proceed with the upgrade.
You can upgrade your IP71 with any of the following methods:
nCommand-line interface (CLI)
nGraphic user interface (GUI)
nNokia Horizon Manager
When you upgrade the IP71 to firmware v2.0, you need to replace your
existing firewall license and security policy with a Check Point NG firewall
license and push a new Check Point NG security policy on to your IP71 from
the Check Point management server.
Upon upgrade, if you change the IP71 to dynamic WAN, you need to create a
new a IP71 device on NHM using the host name of the IP71.

Upgrading
Nokia IP71 User Guide 17
Using Nokia Horizon Manager
You can upgrade your IP71 from Nokia Horizon Manager (NHM). NHM
enables you to simultaneously upgrade a large number of IP71 devices.
To upgrade using Nokia Horizon Manager, you need firmware in .tgz files.
You can download the firmware .tgz files from the Nokia Support site.
Upgrading the IP71 (v1.5 or earlier) to v2.0 involves two stages:
1. Upgrade your IP71 to v1.6 firmware
2. Upgrade your IP71 to v2.0 firmware
Ensure that the IP71 is upgraded through both the stages. Nokia recommends
that you use your IP71 with v2.0 firmware.
To upgrade your IP71 using NHM, select the devices the you want to upgrade.
Perform an OS Install action. Select the firmware and click Start.
Using GUI
You can upgrade your IP71 with the latest version of firmware through the
GUI. The procedures to upgrade using the GUI are described in Chapter 3,
Upgrading. To access the Upgrade section in the GUI, follow the path from
the navigation bar choose Advanced > Upgrade.
Upgrading Using CLI
You can use CLI to upgrade your IP71 to the latest version of Firmware. To
upgrade to the new firmware, do the following as shown in Figure 3:
On the console, enter set upgrade.

1Overview
18 Nokia IP71 User Guide
Figure 3 Upgrade using CLI
Note
The SSH host fingerprint must be configured for SCP to work. The set
command is not executed unless you enter the command=start
command.
Configure the parameters for TFTP/SCP and enter set command=start
to upgrade.
Note
Users with IP71 v1.0 or v1.1, use CLI to upgrade the IP71. Use HTTPS-
based GUI using after you upgrade to v1.6 or later.
set upgrade
Use this command to set the upgrade values like file name,
server address etc.
Syntax:set upgrade file= <file (0...250)>ipaddress=
<ip_address> protocol=<SCP/TFTP>user=<user=(0...250)>
password=<password(0...250)>command=start
Options:File=File name of the binary.
IP address=IP address of the TFTP or SCP server.
Protocol=TFTP or SCP
User=Username of SCP server (If you select SCP)
Password=Password of the SCP server for the user.(If you
select SCP)
Command=start (After configuring all above parameters,
start the upgrade)
Example: Set upgrade file=ip71fr0115.bin
ipaddress=192.168.2.10 protocol=scp user=mchris
password=chris command=start

Managing the IP71
Nokia IP71 User Guide 19
Managing the IP71
You can access the IP71 and manage in many modes:
nUsing the Secure web-based GUI
nUsing the CLI
nUsing the console
nUsing an SSH client
nUsing an SNMP manager
nFrom the Check Point NG management server
nFrom Nokia Horizon Manager
Secure web-based GUI
You can access the IP71 securely through the HTTPS-based GUI to configure
the IP71. You can configure the IP71 in two ways:
Figure 4 shows the main components of the GUI.
Using Quick Setup Wizard Configure the most common settings required
for the IP71 to be up and running
Using Advanced GUI Configure the various advanced features
provided in the IP71
No. Component Description
1. Navigation Bar Access various feature sets in the IP71
2. Tabs Bar Access and configure all features in the IP71
3. Wizard Setup the IP71 with the most common settings quickly.
4. Status Bar Status after a specific configuration
5. Help Online help to assist you in configuring the IP71

1Overview
20 Nokia IP71 User Guide
For a configuration to take effect, make sure you click Submit.
Figure 4 GUI Map
The following table explain the various sections of the Navigation Bar and
their features.
Table 1 Navigation Bar
Main Tab Secondary Tabs Description
System Status displays details of all current configuration
Interface configure the LAN and WAN interfaces
Interface Options configure advanced interface information
Date/ Time set the device date and time
Admin configure the Session Timeout, HTTPS
Encryption type and to change the access
password
