NOMA 151-8409-2 User manual

7' PRE-LIT MICROBRITE SNOW DUSTED PINE
model no. 151-8409-2 | Toll-free number: 1-866-827-4985
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section. Remove the protective cap before inserting it into the
already pre-assembled stand. Before proceeding to the next step, make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) into the lower section(s) until inserting the tree top.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet. Do not plug the adaptor into the wall
outlet until all of the steps below are completed.
2. First assemble the tree stand and place on a level surface. (See Fig. A)
Carefully follow the instructions below to quickly and easily set up your tree.
Tree top
Section 2
Section 1
Fig. B - Tree and Light Assembly
TREE ASSEMBLY INSTRUCTIONS
Fig. A - Tree Stand Assembly
Click
Swivel the legs of the stand until they snap
into position. The legs should be evenly
spaced once this step is complete. Place the
tree stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
Instruction Manual
For indoor use only
Retain carton for storage purposes
IMPORTANT: Please read this manual carefully before assembly and save it for reference.
Control box
Adaptor
To Be Plugged
Into Wall
Outlet
*Electrical Rating For The Tree
(For Indoor Use Only.)
Input: 120 V, 60 Hz, 0.38 A
Output: 29 V DC, 0.62 A
Foot Pedal
On/Off Switch
Do Not Tamper
With Internal Parts
Open the
protective
cover
Do Not Tamper
With Internal Parts
Open the
protective
cover
100S
100S
50S
100S
100S
100S
100S

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch hinges.
7. Plug the adaptor into the wall outlet. (See Fig. B) Your entire tree should now be lit.
8. Begin to shape the branches and tips, working from the bottom to the top. Start with tips farthest from the pole and fan out one to the
right, one to the left and one at the centre of the main stem. (See Fig. C)
9. Once the shaping of the entire tree is completed, slightly upsweep all branch tips so a uniform look may be obtained. Shift branches to
fill any gaps.Your Christmas tree is now complete and ready to be decorated.
Top view Side view
Fig. C
1. For pre-lit trees, first unplug adaptor from the wall outlet, remove all ornaments and decorations. Disconnect light cords between
each section of the tree.
2. Disassemble the tree from the top to the bottom. Start with the tree top: gently lift straight up to remove from section below, and
fold all branches toward the pole.
3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and gently twist the upper pole in
both directions. Lift up the upper pole again.
4. Continue by gently lifting straight up each section from the section below and folding all
branches toward the pole until the bottom section is removed from the tree stand. Put the
protective cap on the poles to avoid damaging the internal parts.(See Fig. D)
5. Carefully place all tree sections into shipping box and tape it shut.
6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your
tree to excessive heat or humidity may damage your tree.
7. Dispose of used batteries per municipal or provincial law.
8. Battery must be recycled or disposed of properly. Dispose of as per the requirements of your local municipality.
9. Keep out of reach of pets and children.
STORAGE INSTRUCTIONS
Press the Selector Button to select from the 7 preset light effects in the following sequence:
1. Steady Glow 2. Slow Fading 3. Fast Fading 4. 3 Speeds Fading
5. Slow Blinking 6. Fast Blinking 7. 3 Speeds Blinking
OPERATING INSTRUCTIONS
You can customize the light functions by using either the Light Controller or the Remote Control.
1. Before using the Remote Control, remove the insulation tab on its rear.
2. Press the Selector Button once on either control and wait for a second to enjoy light effects in the pre-programmed sequence.
There are 5 brightness levels. Simply press the controller buttons to
increase or decrease the brightness to your liking.
Default Timer Function:
Lights stay ON for 8 hours and then turn OFF for 16 hours. Timer function will restart when
any control button is pressed or main power supply to the lights is reconnected.
Memory Function:
If you unplug and reconnect the product to the power outlet, the product will resume
the last light effect and brightness level that was selected before the power was cut out.
Insulation Tab
Remote Control
Light Controller
Selector
Button
Fig. D

Troubleshooting
Warranty
Made in China
Imported by
Noma Canada,Toronto, Canada M4S 2B8
DATE CODE: 22320
For pre-lit trees, if the tree does not illuminate:
1. Please check to make sure that all plugs are properly connected and that the power cord is plugged into the wall outlet. Refer to
assembly guide for instructions. (If the tree comes with a foot pedal, try stepping on the ON/OFF button.)
2.When multiple products are connected together, do not exceed the lowest of the indicated maximum wattage on the cord tag
near the connected product's receptacle.
Each tree includes hinge pins and washers.
If extra parts are needed, please contact our customer service centre.
SPARE PARTS
Loose Hinge Pin
1. Extra hinge pins are included for repairing the hinges.Place the branch into
the slot of the bracket.
2. Insert a new hinge pin through the hole and secure using the retainer
washer. (See Fig. E)
1.This product is powered by a lithium battery. Due to their small size, lithium batteries can easily be swallowed by children.
Ingestion of such batteries has been known to cause death.
2. Do not expose light set to moisture.
3. Remove battery when not used for an extended period of time, or when depleted.
4. Dispose of used battery properly.
5. Use only CR2032 battery for the remote controller.
6. Clean the battery contacts prior to battery installation.
7. Do not dispose of batteries in fire. Batteries may explode or leak.
8. Small parts. Keep batteries out of reach of children.
WARNING
This product carries a five (5) year warranty against defects in workmanship and materials. Noma Canada agrees to replace a
defective product, within the stated warranty period, when returned to the place of purchase with proof of purchase.This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
BATTERY REPLACEMENT OF REMOTE CONTROL
1. Loosen the screw of the battery cover with a screwdriver (not included).
2. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed with the
correct polarity (+ and -).
3. Retighten the screw to close and secure the battery cover.
Cover
Battery
CR2032
Fig. E
CAUTION:
To reduce the risk of fire and electric shock:
a) Use only the power supply that was provided with this product. Using a different adaptor will damage the lights and may
cause fire, or electric shock hazard.
b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal.
c) Do not mount or support strings in a manner that can cut or damage wire insulation.
