Dometic HiPro3000 User manual

HiPro3000, HiPro4000, HiPro4000Vision, HiPro6000
Minibar
Installation and Operating Manual
EN
MINIBAR
HIPRO
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 1 Mittwoch, 17. März 2021 1:37 13

© 2021 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 2 Mittwoch, 17. März 2021 1:37 13

HiPro
3
HiPro 3000
HiPro 4000
HiPro 6000
4
3
2
1
5
HiPro 4000
Vision
13
2
HiPro 4000
Vision
13
2
HiPro 4000
4
3
5
1
2
1
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 3 Mittwoch, 17. März 2021 1:37 13

HiPro
4
1
2
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 4 Mittwoch, 17. März 2021 1:37 13

HiPro
5
AB
CD
≥ 200 cm²
≥ 200 cm²
≥ 200 cm²
≥ 200 cm²
≥ 20 mm
≥ 200 cm²≥ 200 cm²
3
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 5 Mittwoch, 17. März 2021 1:37 13

HiPro
6
1.
5.
4.
5.
4.
6.
AB
2. 3.
4
1.
2.
HiPro 4000
HiPro 4000 Vision
5
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 6 Mittwoch, 17. März 2021 1:37 13

HiPro
7
3.
4.
1.
2.
6
2. 1.
7
1.
2.
8
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 7 Mittwoch, 17. März 2021 1:37 13

HiPro
8
3.
1.
2.
9
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 8 Mittwoch, 17. März 2021 1:37 13

HiPro
9
1-2
6-8
≤ 40
HiPro 3000
HiPro 4000
HiPro 6000
0
HiPro 3000
HiPro 4000
HiPro 6000
1.
2.
a
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 9 Mittwoch, 17. März 2021 1:37 13

HiPro
10
HiPro 3000
HiPro 4000
HiPro 6000
1.
2.
b
HiPro 3000
A
294,5 mm
311,5 mm
376,5 mm
B
418 mm
452 mm
475 mm
C
492 mm
524 mm
533 mm
HiPro 4000
HiPro 6000
A≤ 2
Ø 23,5
C
62
HiPro 3000
HiPro 4000
HiPro 6000
c
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 10 Mittwoch, 17. März 2021 1:37 13

HiPro
11
2.
3.
1.
d
1.
2.
3.
e
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 11 Mittwoch, 17. März 2021 1:37 13

HiPro
12
1.
2.
3.
f
g
HiPro 3000, HiPro 4000, HiPro 6000
1.
2.
h
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 12 Mittwoch, 17. März 2021 1:37 13

HiPro
13
5 °C 7 °C 12 °C3 °C
3x 5x 7x 12x
1
2
5
3
4
i
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 13 Mittwoch, 17. März 2021 1:37 13

HiPro
14
HiPro 4000
A
405 mm
405 mm
B
472 mm
484 mm
C
601 mm
601 mm
HiPro 4000 Vision
HiPro 3000
A
388 mm
405 mm
490 mm
405 mm
B
418 mm
452 mm
475 mm
464 mm
C
527 mm
559 mm
568 mm
559 mm
HiPro 4000
HiPro 6000
HiPro 4000 Vision
AB BA
C C
HiPro 3000
HiPro 4000
HiPro 6000
HiPro 4000
HiPro 4000 Vision
j
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 14 Mittwoch, 17. März 2021 1:37 13

EN
HiPro Explanation of symbols
15
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and that you understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit
dometic.com.
Table of contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7 Setting up and connecting the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . .21
8 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
1 Explanation of symbols
D
!
DANGER!
Safety instruction: Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 15 Mittwoch, 17. März 2021 1:37 13

EN
Safety instructions HiPro
16
!
A
I
2 Safety instructions
2.1 General safety
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• Ensure that the minibar has been installed by a qualified technician in
accordance with the Dometic installation manual.
• Do not operate the minibar if it is visibly damaged.
• If this minibar's power cable is damaged, it must be replaced by the
manufacturer, service agent or a similarly qualified person in order to
prevent safety hazards.
• This minibar may only be repaired by qualified personnel. Inadequate
repairs may cause serious hazards.
Fire hazard
• The refrigerant in the refrigerant circuit is highly flammable.
In the event of any damage to the refrigerant circuit:
– Switch off the minibar.
– Avoid naked flames and sparks.
– Air the room well.
Explosion hazard
• Do not store any explosive substances, such as spray cans with
propellants, in the minibar.
Health hazard
• Never open the absorber unit. It is under high pressure and can cause
injury if it is opened.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 16 Mittwoch, 17. März 2021 1:37 13

EN
HiPro Safety instructions
17
• This minibar can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the minibar in a safe way and understand
the hazards involved.
• Children shall not play with the minibar.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and unload the
minibar.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Risk of crushing
• Do not put your fingers into the hinge.
Health hazard
• Foodstuff may only be stored in its original packaging or in suitable
containers.
ANOTICE! Damage hazard
• Check that the voltage specification on the type plate is the same as
that of the power supply.
• The minibar is not suitable for storing substances which are caustic or
contain solvents.
• The insulation of the cooling device contains flammable cyclopentane
and requires special disposal procedures. Deliver the cooling device
at the end of its life-cycle to an appropriate recycling center.
• Keep the drainage outlet clean at all times.
• Do not open the refrigerant circuit under any circumstances.
• Only carry the minibar upright.
2.2 Operating the minibar safely
DDANGER! Failure to obey these warnings will result in death or
serious injury.
Electrocution hazard
• Do not touch exposed cables with your bare hands.
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 17 Mittwoch, 17. März 2021 1:37 13

EN
Scope of delivery HiPro
18
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Electrocution hazard
• Before starting the minibar, ensure that the power supply line and the
plug are dry.
Health hazard
• Make sure that you only put items in the minibar which may be chilled
at the selected temperature.
• Food may only be stored in its original packaging or in suitable
containers.
• Opening the door for long periods can cause significant increase of
the temperature in the compartments of the minibar.
• Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
• If the minibar is left empty for long periods:
– Switch off the minibar.
– Defrost the minibar.
– Clean and dry the minibar.
– Leave the door open to prevent mould developing within the
minibar.
ANOTICE! Damage hazard
• Do not use electrical devices inside the minibar unless they are recom-
mended by the manufacturer for that purpose.
• Do not place it near naked flames or other heat sources (heaters, direct
sunlight, gas ovens etc.).
• Ensure that the ventilation vents are not covered.
• Never immerse the minibar in water.
• Protect the minibar and the cable against heat and moisture.
• Make sure that foodstuffs do not touch the walls of the cooling area.
3Scopeofdelivery
Quantity Description
1 Minibar
2Shelf
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 18 Mittwoch, 17. März 2021 1:37 13

EN
HiPro Accessories
19
4Accessories
Available as accessories (not included in the scope of delivery):
5 Intended use
The refrigeration appliance (also referred to as minibar) is designed for operation in
enclosed buildings, such as:
• In staff kitchens in stores, offices and other work areas
• In the agricultural sector
• In hotels, motels and other accommodations
• In bed and breakfast establishments
• In catering businesses or similar wholesaler operations
The minibar is not suitable for installation in caravans or mobile homes.
The minibar is intended to be used either as a built-in appliance or as freestanding
refrigeration appliance. Refer to the installation instructions.
The minibar is designed exclusively for cooling and storing of beverages and foods
in closed containers.
The minibar is not suitable for storing fresh foods and medicine or freezing food-
stuffs.
2 Door rack (not for HiPro4000Vision)
1 Installation and operating manual
Description Explanation
Remote control For door opening monitor and temperature regulation
Reflector For door opening monitor
Keys For versions with lock
Sliding hinge For simultaneous opening of cabinetry door and refrigerator door
Cooler lid and high
device feet
For HiPro4000 and HiPro4000Vision, as free-standing versions
Quantity Description
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 19 Mittwoch, 17. März 2021 1:37 13

EN
Technical description HiPro
20
This minibar is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the minibar. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
6 Technical description
The minibar is a refrigerator with absorption cooling. Ammonia is used as the refrig-
erant. All materials used are compatible for use with foodstuffs. The refrigerantcircuit
is maintenance-free.
The minibar (except for HiPro4000Vision) has two shelves and two door racks. The
lower door rack (fig. 14, page 3) is intended for bottles. A 1.5 l bottle can be
stored in the door rack for bottles. The upper door rack (fig. 15, page 3) is
intended for smaller bottles or snacks.
The HiPro4000Vision minibar has two shelves and a transparent acrylic door without
door racks.
The HiPro4000 and HiPro4000Vision minibars can optionally be used as free-stand-
ing versions with a cooler lid and high device feet.
6.1 Control elements on the refrigerator
No. in
fig. 1, page 3 Explanation
1 Interior light
2 LED of the door opening monitor (optional)
DometicHiPro3000-4000-6000-Vision_IOM_4445102742_APAC(en)_202x-xx-xx.book Seite 20 Mittwoch, 17. März 2021 1:37 13
