Nord Drivesystems SK 180E Series User manual

BU 0180 – en
NORDAC®BASE (SK 180E / SK 190E)
Users Manual forFrequency Inverters

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
2 BU 0180 en-4118
Documentation
Title:
BU 0180
Order – No.:
6071802
Series:
SK 1x0E
FI series:
SK 180E, SK 190E
Device types: SK 1x0E-250-112-O ... SK 1x0E-750-112-O 0.25 – 0.75 kW, 1~ 110-120 V, Out: 230 V
SK 1x0E-250-323-B ... SK 1x0E-111-323-B 0.25 – 1.1 kW, 1/3~ 200-240 V
SK 1x0E-151-323-B 1.5 kW, 3~ 200-240 V
SK 1x0E-250-340-B ... SK 1x0E-221-340-B 0.25 – 2.2 kW, 3~ 380-480 V
Version list
Title,
Date
Order number Device
software
version
Remarks
BU 0180,
June 2013
6071802 / 2313 V 1.0 R0 First issue.
BU 0180,
February
2014
6071802/ 0914 V 1.0 R1 Including:
• General corrections
• Additional bus options
• Adaptation of technical data
• 1.5 kW, 3~ 230 V device added
• Revision of EMC chapter incl. addition of EC
conformity declaration
BU 0180,
June 2014
6071802 / 2314 V 1.0 R1 Including:
• General corrections
• Terminal designation corrected from "AGND ‚12" to
"GND/0V ‚40‘"
BU 0180,
March 2015
6071802 / 1115 V 1.0 R1 UL – group fuse protection
• Braking resistor
BU 0180,
March 2015
6071802 / 1315
V 1.0 R1
• ATEX
BU 0180,
March 2016
6071802 / 1216
V 1.2 R0
Including:
• General corrections
• Structural adjustments to document
• New parameters: P240 – 247, 300, 310 - 320, 330,
331, 333, 350 – 370, 746
•
Adaptation of parameters: P001, 003, 105, 108,
109, 110, 200, 219, 401, 418, 420, 434, 480, 481,
502, 509, 513, 535, 740, 741
• PMSM
• PLC
• IP69K
• New presentation of scope of delivery / accessory
overview
• Revisio
n of section "UL/cUL", including for CSA:
voltage limitation filter no longer required (SK CIF)
Module removed from document
• Revision of "Braking resistor" section

Copyright notice
BU 0180 en-4118 3
• Display and operation Connection of multiple
devices to a parametrisation tool (tun
nelling via
system bus)
• Commissioning Selection of operating mode for
motor control added
• Revision of "Technical / Electrical Data“
• Addition of an FAQ list for operational problems
• Removal of detailed descriptions of accessories and
reference to appropriate technical information
• Updating of EC/EU conformity declarations
BU 0180
,
October
2018
6071802
/ 4118 V 1.2 R1 Including:
• General corrections
• Revision of safety information
• Revision of warning information
• Adaptation for ATEX, outdoor installation and brake
resistors
• Addition of EAC EX
• Revision of wall mounting kits and adapter kits for
motor mounting
• Adaptation of parameters: P300, 553, 543, 556,
557
• Parameters: P331, 332, 333 without function, 
deleted
• Updating of EC/EU conformity declarations
• Addition of temperature sensors (PT100, PT1000)
• Correction of standardisation of setpoint and actual
values
• Motor data extended with 100 Hz characteristic
curve
Table 1: Version list
Copyright notice
As an integral component of the device described here, this document must be provided to all
users in a suitable form.
Any editing or amendment or other utilisation of the document is prohibited.
Publisher
Getriebebau NORD GmbH & Co. KG
Getriebebau-Nord-Straße 1 • 22941 Bargteheide, Germany • http://www.nord.com/
Fon +49 (0) 45 32 / 289-0 • Fax [phone]
Member of the NORD DRIVESYSTEMS Group

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
4 BU 0180 en-4118

Table of Contents
BU 0180 en-4118 5
Table of Contents
1General.......................................................................................................................................................10
1.1 Overview ..........................................................................................................................................10
1.2 Delivery ............................................................................................................................................13
1.3 Scope of delivery..............................................................................................................................13
1.4Safety, installation and operating instructions..................................................................................17
1.5 Warning and hazard information ......................................................................................................22
1.5.1 Warning and hazard information on the product.................................................................22
1.5.2 Warning and hazard information in the document ..............................................................23
1.6 Standards and approvals .................................................................................................................23
1.6.1 UL and CSA approval.........................................................................................................25
1.7 Type code / nomenclature................................................................................................................27
1.7.1 Name plate .........................................................................................................................27
1.7.2 Frequency inverter type code .............................................................................................28
1.7.3 Type code for option modules ............................................................................................28
1.7.4 Type code, connection unit for technology unit...................................................................29
1.7.5 Adapter Unit type code .......................................................................................................29
1.8 Power rating / Motor size .................................................................................................................29
1.9 Version in protection class IP55, IP66, IP69K..................................................................................30
2Assembly and installation ........................................................................................................................31
2.1 Installation SK 1x0E.........................................................................................................................31
2.1.1 Work procedures for motor installation...............................................................................32
2.1.1.1 Adapters for different motors 33
2.1.1.2 Dimensions, SK 1x0E mounted on motor 34
2.1.2 Wall mounting.....................................................................................................................35
2.2 Installation of optional modules........................................................................................................37
2.2.1 Option locations on device .................................................................................................37
2.2.2 Installation of internal customer unit SK CU4-… (installation) ............................................39
2.2.3 Installation of external technology units SK TU4-… (attachment).......................................40
2.3 Braking resistor (BW) - (from size 2) ................................................................................................41
2.3.1 Internal braking resistor SK BRI4-…...................................................................................41
2.3.2 External braking resistor SK BRE4-... / SK BRW4-… / SK BREW4-…...............................42
2.4 Electrical Connection .......................................................................................................................44
2.4.1 Wiring guidelines ................................................................................................................45
2.4.2 Electrical connection of power unit .....................................................................................46
2.4.2.1 Mains supply (L1, L2(/N), L3, PE) 46
2.4.2.2 Motor cable (U, V, W, PE) 47
2.4.2.3 Braking resistor (+B, -B) – (from size 2) 48
2.4.3 Electrical connection of the control unit ..............................................................................49
2.4.3.1 Control terminal details 50
2.5 Operation in potentially explosive environments..............................................................................53
2.5.1 Operation in potentially explosive environments - ATEX zone 22 3D.................................53
2.5.1.1 Modification of the device for compliance with Category 3D 53
2.5.1.2 Options for ATEX Zone 22, category 3D 54
2.5.1.3 Maximum output voltage and torque reduction 56
2.5.1.4 Commissioning information 56
2.5.1.5 EU conformity declaration - ATEX 58
2.5.2 Operation in potentially explosive environments - EAC Ex.................................................59
2.5.2.1 Modification of the device 59
2.5.2.2 Further Information 60
2.5.2.3 EAC Ex certificate 60
2.6 Outdoor installation ..........................................................................................................................61
3Display, operation and options ................................................................................................................62
3.1 Control and parametrisation options ................................................................................................62
3.1.1 Control and Parametrisation Boxes / Software...................................................................63
3.1.2 Connection of multiple devices to one parametrisation tool................................................64
3.2 Optional modules .............................................................................................................................65
3.2.1 Internal customer interfaces SK CU4-… (installation of modules) ......................................65
3.2.2 External technology units SK TU4-… (module attachment) ...............................................66
3.2.3 plug connectors ..................................................................................................................68

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
6 BU 0180 en-4118
3.2.3.1 Plug connectors for power connections 68
3.2.3.2Plug connectors for control connection 69
3.2.4 Potentiometer adapter, SK CU4-POT.................................................................................71
4Commissioning .........................................................................................................................................72
4.1 Factory settings................................................................................................................................72
4.2 Selecting the operating mode for motor control ...............................................................................73
4.2.1 Explanation of the operating modes (P300) .......................................................................73
4.2.2 Overview of control parameter settings ..............................................................................73
4.2.3 Motor control commissioning steps ....................................................................................74
4.3 Starting up the device ......................................................................................................................76
4.3.1 Connection .........................................................................................................................76
4.3.2 Configuration ......................................................................................................................76
4.3.2.1 Parameterisation 76
4.3.2.2 DIP switches (S1, S2) 77
4.3.3 Commissioning examples...................................................................................................78
4.4 Temperature sensors.......................................................................................................................79
4.5 AS Interface (AS-i) ...........................................................................................................................82
4.5.1 The bus system ..................................................................................................................82
4.5.2 Features and technical data ...............................................................................................82
4.5.3 Bus structure and topology.................................................................................................83
4.5.4 Commissioning ...................................................................................................................84
4.5.4.1 Connection 84
4.5.4.2 Displays 85
4.5.4.3 Configuration 85
4.5.4.4 Addressing 86
4.5.5 Certificate ...........................................................................................................................87
5Parameter...................................................................................................................................................88
5.1 Parameter overview .........................................................................................................................90
5.2 Description of parameters ................................................................................................................92
5.2.1 Operating displays..............................................................................................................93
5.2.2 Basic parameters................................................................................................................94
5.2.3 Motor data / Characteristic curve parameters...................................................................101
5.2.4 Speed control ...................................................................................................................109
5.2.5 Control terminals ..............................................................................................................114
5.2.6 Additional parameters.......................................................................................................133
5.2.7 Information........................................................................................................................149
6Operating status messages ...................................................................................................................160
6.1 Display of messages ......................................................................................................................160
6.2 Diagnostic LEDs on device ............................................................................................................161
6.3 Messages.......................................................................................................................................162
6.4 FAQ operational problems .............................................................................................................169
7Technical data .........................................................................................................................................171
7.1 General data for frequency inverter................................................................................................171
7.2 Electrical data ................................................................................................................................172
7.2.1 Electrical data 1~ 115 V....................................................................................................173
7.2.2 Electrical data 1/3~230 V..................................................................................................174
7.2.3 Electrical data 3~ 400 V....................................................................................................176
8Additional information ............................................................................................................................178
8.1 Setpoint processing........................................................................................................................178
8.2 Process controller ..........................................................................................................................179
8.2.1 Process controller application example ............................................................................179
8.2.2 Process controller parameter settings ..............................................................................180
8.3 Electromagnetic compatibility (EMC) .............................................................................................181
8.3.1 General Provisions ...........................................................................................................181
8.3.2 EMC evaluation ................................................................................................................182
8.3.3 EMC of device ..................................................................................................................183
8.3.4 EU Declaration of Conformity ...........................................................................................185
8.4 Reduced output power ...................................................................................................................186
8.4.1 Increased heat dissipation due to pulse frequency...........................................................186
8.4.2 Reduced overcurrent due to time .....................................................................................187
8.4.3 Reduced overcurrent due to output frequency..................................................................188
8.4.4 Reduced output current due to mains voltage ..................................................................189

Table of Contents
BU 0180 en-4118 7
8.4.5 Reduced output current due to the heat sink temperature................................................189
8.5 Operation with FI circuit breakers...................................................................................................190
8.6 System bus ....................................................................................................................................191
8.7 Energy Efficiency ...........................................................................................................................194
8.8 Motor data - characteristic curves ..................................................................................................195
8.8.1 50 Hz characteristic curve ................................................................................................195
8.8.2 87 Hz characteristic curve (only 400V devices)................................................................197
8.8.3 100 Hz characteristic curve (only 400 V devices).............................................................198
8.9 Standardisation of setpoint / target values .....................................................................................200
8.10 Definition of setpoint and actual value processing (frequencies) ...................................................201
9Maintenance and servicing information................................................................................................202
9.1 Maintenance Instructions ...............................................................................................................202
9.2 Service notes .................................................................................................................................203
9.3 Abbreviations .................................................................................................................................204

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
8 BU 0180 en-4118
List of illustrations
Figure 1: Device with internal SK CU4-... .............................................................................................................. 11
Figure 2: Device with external SK CU4-... ............................................................................................................. 11
Figure 3: Name plate ............................................................................................................................................. 27
Figure 4: Example of motor size adaptation .......................................................................................................... 33
Figure 5: Option locations, size 1 .......................................................................................................................... 37
Figure 6: Option locations, size 2 .......................................................................................................................... 37
Figure 7: Jumpers for mains adaptation ................................................................................................................ 47
Figure 8: SimpleBox, handheld, SK CSX-3H......................................................................................................... 63
Figure 9: ParameterBox, handheld, SK PAR-3H................................................................................................... 63
Figure 10: internal customer units SK CU4 … example ........................................................................................ 65
Figure 11: external technology units SK TU4-… (example)................................................................................... 66
Figure 12: Examples of devices with connectors for connecting the power........................................................... 68
Figure 13: Connection diagram for SK CU4-POT, example of SK 1x0E ............................................................... 71
Figure 14: Connecting terminals AS-i .................................................................................................................... 84
Figure 15 Setpoint processing............................................................................................................................. 178
Figure 16: Process controller flow diagram ......................................................................................................... 179
Figure 17: Wiring recommendation...................................................................................................................... 184
Figure 18: Heat losses due to pulse frequency ................................................................................................... 186
Figure 19: Output current due to mains voltage................................................................................................... 189
Figure 20: Energy efficiency due to automatic flux optimisation .......................................................................... 194
Figure 21: 50 Hz characteristic curve .................................................................................................................. 195
Figure 22: 87 Hz characteristic curve .................................................................................................................. 197
Figure 23: 100 Hz characteristic curve ................................................................................................................ 198

List of tables
BU 0180 en-4118 9
List of tables
Table 1: Version list................................................................................................................................................. 3
Table 2: Warning and hazard information on the product...................................................................................... 22
Table 3: Standards and approvals......................................................................................................................... 23
Table 4: Standards and approvals for explosion hazard environments ................................................................. 24
Table 5: Assignment of braking resistors to frequency inverter ............................................................................. 43
Table 6: Connection data ...................................................................................................................................... 46
Table 7: external bus modules and IO expansions SK TU4- … ............................................................................ 67
Table 8: external modules with power supply SK TU4-24V- … / SK TU4-POT- … ............................................... 67
Table 9: external modules – maintenance switch SK TU4-MSW- …..................................................................... 67
Table 10: Temperature sensors, adjustment ......................................................................................................... 79
Table 11: AS Interface, connection of signal and supply lines............................................................................... 85
Table 12: FAQ operational problems................................................................................................................... 170
Table 13: EMC comparison between EN 61800-3 and EN 55011....................................................................... 182
Table 14: Overview according to product standard EN 61800-3 ........................................................................ 184
Table 15: Overcurrent relative to time ................................................................................................................. 187
Table 16: Overcurrent relative to pulse and output frequency............................................................................. 188
Table 17: Processing of setpoints and actual values in the frequency inverter ................................................... 201

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
10 BU 0180 en-4118
1 General
The SK 1x0E series is based on the tried and tested NORD platform. The devices are characterised
by their compact design and optimum control characteristics, and have uniform parametrisation.
The devices have sensor-less current vector control with a wide range of settings. In combination with
suitable motor models, which always provide an optimised voltage/frequency ratio, all three-phase
asynchronous motors that are suitable for inverter operation and permanently excited synchronous
motors can be driven. For the drive unit, this means very high starting and overload torques with
constant speed.
The performance range extends from 0.25 kW bis 2.2 kW.
The use of modular modules means that the device series can be adapted to individual customer
requirements.
This manual is based on the device software as stated in the version list (see P707). If the frequency
inverter uses a different software version, this may cause differences. If necessary, the current manual
can be downloaded from the Internet (http://www.nord.com/).
Additional descriptions for optional functions and bus systems exist (http://www.nord.com/).
Information Accessories
The accessories mentioned in the manual are also subject to change. Current details of these are summarised in
separate data sheets, which are available at www.nord.com under the heading Documentation → Manuals →
Electronic Drive Technology → Techn. Info / Data Sheet. The data sheets available at the date of publication of
this manual are listed by name in the relevant sections (TI ...).
Installation directly on a motor is typical of this device series. Alternatively, optional accessories are
also available for mounting the devices close to the motor, e.g. on the wall or on a machine frame.
In order to have access to all parameters, the internal RS232 interface (access via RJ12 connection)
can be used. Access to the parameters takes place via an optional SimpleBox or ParameterBox, for
example.
The parameter settings modified by the operator are backed up in the integrated, non-volatile memory
of the device.
1.1 Overview
This manual describes all of the possible functions and equipment. The equipment and functionality
are limited according to the type of device.
Basic characteristics
• High starting torque and precise motor speed control setting by means of sensorless current vector
control
• Can be installed directly on, or close to the motor.
• Permissible ambient temperature -25°C to 50°C (please refer to technical data)
• Integrated EMC mains filter for limit curve B, Category C1, motor-mounted (not with 115 V devices)
• Automatic measurement of stator resistance and determination of the exact motor data possible
• Programmable direct current braking
• Size 2 only: Built-in brake chopper for 4 quadrant operation, optional braking resistors (internal /
external)
• 2 analogue inputs (switchable between current and voltage operation), which can also be used as
digital inputs.
• 3 digital inputs

1 General
BU 0180 en-4118 11
• 2 digital outputs
• Separate temperature sensor input (TF+/TF-)
• NORD system bus for connecting additional modules, with switchable terminating resistance and
address which can be set using DIP switches.
• Four separate parameter sets, switchable online
• LEDs for diagnosis
• RS232/485 interface via RJ12 plug
• Operation of three-phase current Asynchronous Motors (ASM) and Permanent Magnet
Synchronous Motors (PMSM)
• Integrated PLC (BU 0550)
Additional features of the SK 190E
• Integrated AS Interface
Option modules
Option modules are used to extend the functionality of the device.
These options are available as an installation variant, the so-called SK CU4-… customer unit, and also
as an attachment variant, the so-called SK TU4-… technology unit. As well as the mechanical
differences, the installation and attachment variants also have some functional differences.
Figure 1: Device with internal SK CU4-... Figure 2: Device with external SK CU4-...
Attachment variant
The external technology unit (Technology Unit SK TU4-…) is externally attached to the device and
is therefore easy to access.
A technology unit basically requires the use of a suitable SK TI4-TU-… connection unit.
The power supply and signal lines are connected using the screw clamps of the connection unit.
Depending on the version, additional connections for connectors (e.g. M12 or RJ45) may be available.
The optional wall mounting kit SK TIE4-WMK-TU also allows the technology units to be mounted away
from the starter.
Built-in variant
The internal customer unit (Customer Unit, SK CU4-...) is integrated in the device. The power
supply and signal lines are connected using screw clamps.

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
12 BU 0180 en-4118
The SK CU4-POT potentiometer adapter is an exception among the "SK CU4 Modules", since it is not
integrated in the device but attached to it.
Communication between "intelligent" option modules and the device takes place via the system bus.
Intelligent option modules are modules with their own processor and communication technology, as is
the case with field bus modules, for example.
The frequency inverter can manage the following options via its system bus:
1 x ParameterBox SK PAR-3H and (via an RJ12 connector)
1 x field bus option (e.g. Profibus DP), internal or external and
2 x I/O extension (SK xU4-IOE-…), internal and / or external
Up to 4 frequency inverters with their appropriate options can be connected to a system bus.

1 General
BU 0180 en-4118 13
1.2 Delivery
Check the equipment immediately after delivery / unpacking for transport damage such as
deformation or loose parts.
If there is any damage, contact the carrier immediately and carry out a thorough assessment.
Important! This also applies even if the packaging is undamaged.
1.3 Scope of delivery
NOTICE Defect in the device
Use of unapproved accessories and options (e.g. options from other device series (SK CSX-0)) may result in
defects of the interconnected components.
Only use options and accessories which are explicitly intended for use with this device and are stated accordingly
in this manual.
Standard version: • IP55 version of device (optionally IP66, IP69K)
• Operating instructions as PDF file on CD ROM including NORD CON, (PC
parametrisation software)
Available accessories:
Designation Example Description
Control and parametrisation options
Parametrisation units for
temporary connection to the
device, handheld
For commissioning, parametrisation and control
of the device.
Model SK PAR-3H, SK CSX-3H
Section 3.1 "Control and parametrisation
options "
Hand-held control units
For controlling the device,
Model SK POT- …
Section 3.1 "Control and parametrisation
options "
NORD CON
MS Windows ® - based
software
For commissioning, parametrisation and control
of the device.
Refer to www.nord.com
NORD CON
(Free download)

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
14 BU 0180 en-4118
Bus interface
Internal bus interfaces
Customer unit for installation device for:
CANopen, DeviceNet, EtherCAT, Ethernet/IP,
Powerlink, Profibus DP, Profinet IO
Model SK CU4- …
Section 3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
External bus interfaces
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for: CANopen, DeviceNet, EtherCAT,
Ethernet/IP, Powerlink, Profibus DP, Profinet IO,
Model SK TU4- …
Section 3.2.2 "External technology units
SK TU4-… (module attachment)"
Braking resistors
Internal braking resistors
Braking resistor for installation in the device for
leading away generated heat from the drive
system caused by conversion to heat. Energy is
generated by the braking processes or
downward movement of loads,
Model SK BRI4- …
Section 2.3.1 "Internal braking resistor SK
BRI4-…"
External braking resistors
Refer to:
Internal braking resistors,
but for attaching to the device
Model SK BRE4- …
Section 2.3.2 "External braking resistor SK
BRE4-... / SK BRW4-… / SK BREW4-…"
I/O expansions
Internal I/O expansion
Customer unit for installing in the device for
extending the analogue and digital inputs and
outputs.
Model SK CU4-IOE…
Section 3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
Internal signal converter
Customer unit for installation in the device for
converting bipolar analogue signals to unipolar
analogue signals, e.g. digital signals on relays
Model SK CU4-REL-…
Section 3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
External I/O extension
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for extending the analogue and digital
inputs and outputs.
Model SK TU4-IOE-…
Section 3.2.2 "External technology units
SK TU4-… (module attachment)"

1 General
BU 0180 en-4118 15
Wall mounting
Wall mounting for the device
Set for mounting the device, separate from the
motor (e.g. to a wall).
Model SK TIE4-WMK-…
(Section 2.1.2 "Wall mounting")
Wall mounting for SK TU4-…
modules
Set for mounting a technology unit, SK TU4-...,
separate from the device (e.g. to a wall).
Model SK TIE4-WMK-TU
(Section 3.2.2 "External technology units
SK TU4-… (module attachment)")
Switches and potentiometers
Switch / potentiometer unit
(L – OFF – R / 0 – 10 V)
Customer unit for attaching to the device for
ease of control of the device using switches and
potentiometers
Model SK CU4-POT
Section 3.1 "Control and parametrisation
options "
ATEX potentiometer
(0 – 10 V)
Potentiometer with ATEX capability for attaching
to the device for ease of control of the device
Model SK ATX-POT
Section 0 "SK ATX-POT"
Potentiometer
(0 – 10 V)
Potentiometer for attaching to the device for
ease of control of the device
Model SK TIE4-POT
Section 3.1 "Control and parametrisation
options "
Switch
(L – OFF – R)
Switch for attaching to the device for simple
control of the device
Model SK TIE4-SWT
Section 3.1 "Control and parametrisation
options "
Maintenance switch
(0 – I)
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for safely insulating the device from the
AC power supply.
Model SK TU4-MSW- …
Section 3.2.2 "External technology units
SK TU4-… (module attachment)"
Setpoint adjuster
(L – 0 – R / 0 – 100 %)
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for simple control of the device using
buttons and potentiometers, including power
supply for generating a 24 V DC control voltage.
Model SK TU4-POT- …
Section 3.2.2 "External technology units
SK TU4-… (module attachment)"

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
16 BU 0180 en-4118
Plug connector
Power connection
(for power input, power output,
motor output)
AC Power connector for attaching to the device
for making a detachable connection for supply
lines (e.g. mains supply line)
Model SK TIE4-…
Section 3.2.3 "plug connectors"
Control line connection
System connector (M12) for attaching to the
device, for making a detachable connection for
control lines
Model SK TIE4-…
Section 3.2.3 "plug connectors"
Adapter
Adapter cable
Different adapter cables
(Link)
Mounting Adapter
Various adapter kits for attaching the device to
different motor sizes
Section 2.1.1.1 "Adapters for different
motors"
Miscellaneous
Internal electronic brake
rectifier
Customer unit for installing in the device for
direct actuation of an electro-mechanical brake
Model SK CU4-MBR-…
Section 3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
Software (Free download)
NORD CON
MS Windows ® - based
software
For commissioning, parametrisation and control
of the device.
Refer to www.nord.com
NORD CON
ePlan macros
Macros for producing electrical circuit diagrams
Refer to www.nord.com
ePlan
Device master data
Device master data / device description files for
NORD field bus options
NORD fieldbus files
S7 standard modules for
PROFIBUS DP and
PROFINET IO
Standard modules for NORD frequency
converters
Refer to www.nord.com
NORD S7_files
Standard modules for the TIA
portal for PROFIBUS DP and
PROFINET IO
Standard modules for NORD frequency
converters
Available on request.

1 General
BU 0180 en-4118 17
1.4 Safety, installation and operating instructions
Before working on or with the device, please read the following safety instructions extremely carefully.
Please pay attention to all other information from the device manual.
Non-compliance can result in serious or fatal injuries and damage to the device or its surroundings.
These safety instructions must be kept in a safe place!
1. General
Do not use defective devices or devices with defective or damaged housings or missing covers (e.g.
blind plugs for cable glands). Otherwise there is a risk of serious or fatal injuries caused by electric
shock or bursting electrical components such as powerful electrolytic capacitors.
Unauthorised removal of covers, improper use, incorrect installation or operation causes a risk of
serious personal injury or material damage.
During operation and depending on the protection class of the devices, there may be live, bare,
moving or rotating parts or hot surfaces.
The device operates with a dangerous voltage. Dangerous voltage may be present at the supply lines,
contact strips and PCBs of all connecting terminals (e.g. mains input, motor connection), even if the
device is not working or the motor is not rotating (e.g. caused by electronic disabling, jamming of the
drive or a short circuit at the output terminals).
The device is not equipped with a mains switch and is therefore always live when connected to the
power supply. Voltages may therefore be connected to a connected motor at standstill.
Even if the drive unit has been disconnected from the mains, a connected motor may rotate and
possibly generate a dangerous voltage.
If you come into contact with dangerous voltage such as this, there is a risk of an electric shock, which
can lead to serious or fatal injuries.
The device and any power plug connectors must not be disconnected while a voltage is applied to the
device. Failure to comply with this may cause arcing, which in addition to the risk of injury, also results
in a risk of damage or destruction of the device.
The fact that the status LED or other indicators are not illuminated does not indicate that the device
has been disconnected from the mains and is without voltage.
The heat sink and all other metal components can heat up to temperatures above 70 °C.
Touching these parts can result in local burns to the body parts concerned (cooling times and
clearance from neighbouring components must be complied with).
All work on the device, e.g. transportation, installation, commissioning and maintenance work must be
carried out by qualified experts (observe IEC 364 or CENELEC HD 384 or DIN VDE 0100 and
IEC 664 or DIN VDE 0110 and national accident prevention regulations). In particular, the general and
regional installation and safety regulations for work on high voltage systems (e.g. VDE) must be
complied with as must the regulations concerning correct use of tools and the use of personal
protection equipment.
During all work on the device, take care that no foreign bodies, loose parts, moisture or dust enter or
remain in the device (risk of short circuit, fire and corrosion).
Further information can be found in this documentation.

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
18 BU 0180 en-4118
2. Qualified experts
For the purposes of these basic safety instructions, qualified personnel are persons who are familiar
with the assembly, installation, commissioning and operation of this product and who have the
relevant qualifications for their work.
Furthermore, the device and the associated accessories may only be installed and started up by
qualified electricians. An electrician is a person who, because of their technical training and
experience, has sufficient knowledge with regard to
• switching on, switching off, isolating, earthing and marking power circuits and devices,
• proper maintenance and use of protective devices in accordance with defined safety standards.
3. Correct purpose of use – general
The frequency inverters are devices for industrial and commercial systems used for the operation of
three-phase asynchronous motors with squirrel-cage rotors and Permanent Magnet Synchronous
Motors – PMSM. These motors must be suitable for operation with frequency inverters, other loads
must not be connected to the devices.
The devices are components intended for installation in electrical systems or machines.
Technical data and information for connection conditions can be found on the rating plate and in the
documentation, and must be complied with.
The devices may only be used for safety functions which are described and explicitly approved.
CE-labelled devices fulfil the requirements of the Low Voltage Directive 2014/35/EU. The stated
harmonized standards for the devices are used in the declaration of conformity.
a. Supplement: Correct purpose of use within the European Union
When installed in machines, the devices must not be commissioned (i.e. commencement of
proper use) until it has been ensured that the machine fulfils the provisions of EC Directive
2006/42/EC (Machinery Directive); EN 60204-1 must also be complied with.
Commissioning (i.e. start-up of proper use) is only permitted if the EMC directive (2014/30/EU)
has been complied with.
b. Supplement: Correct purpose of use outside the European Union
The local conditions of the operator for the installation and commissioning of the device must be
complied with at the usage location (see also "a) Supplement: Correct purpose of use within the
European Union").
4. Phases of life
Transport, storage
The information in the manual regarding transport, storage and correct handling must be complied
with.
The permissible mechanical and climatic ambient conditions (see technical data in the manual for the
device) must be complied with.
If necessary, suitable, adequately dimensioned means of transport (e.g. lifting gear, rope guides) must
be used.

1 General
BU 0180 en-4118 19
Installation and assembly
The installation and cooling of the device must be implemented according to the regulations in the
corresponding documentation. The permissible mechanical and climatic ambient conditions (see
technical data in the manual for the device) must be complied with.
The device must be protected against impermissible loads. In particular, components must not be
deformed and/or insulation distances must not be changed. Touching of electronic components and
contacts must be avoided.
The device and its optional modules contain electrostatically sensitive components, which can be
easily damaged by incorrect handling. Electrical components must not be mechanically damaged or
destroyed.
Electrical Connection
Ensure that the device and the motor are specified for the correct supply voltage.
Installation, maintenance and repair work must not be carried out unless the device has been
disconnected from the voltage and at least 5 minutes have elapsed since the mains was switched off!
(Due to charged capacitors, the equipment may continue to carry hazardous voltages for up to
5 minutes after being switched off at the mains). Before starting work it is essential to check by
measurement that all contacts of the power plug connections or the connection are voltage-free.
The electrical installation must be implemented as per the applicable regulations (e.g. cable cross-
section, fuses, earth lead connections). Further instructions can be found in the documentation or
manual for the device.
Information regarding EMC-compliant installation such as shielding, earthing, location of filters and
routing of cables can be found in the documentation for the devices and in the technical information
manual TI 80-0011. CE marked devices must also comply with these instructions. Compliance with the
limit values specified in the EMC regulations is the responsibility of the manufacturer of the system or
machine.
In case of a fault, insufficient earthing may cause an electric shock with possibly fatal consequences if
the device is touched.
The device may only be operated with effective earth connections which comply with local regulations
for large leakage currents (> 3.5 mA). Detailed information regarding connections and operating
conditions can be obtained from the technical Information manual TI 80-0019.
The voltage supply of the device may directly or indirectly put it into operation, or touching electrically
conducting components may then cause an electric shock with possible fatal consequences.
All phases of all power connections (e.g. power supply) must always be disconnected.
Set-up, troubleshooting and commissioning
When working on live devices, the applicable national accident prevention regulations must be
complied with (e.g. BGV A3, formerly VBG 4).
The voltage supply of the device may directly or indirectly put it into operation, or touching electrically
conducting components may then cause an electric shock with possible fatal consequences.
The parametrisation and configuration of the devices must be selected so that no hazards can occur.
With certain setting conditions, the device or the motor which is connected to it may start automatically
when the mains are switched on. The machinery which it drives (press / chain hoist / roller / fan etc.)
may then make an unexpected movement. This may cause various injuries, including to third parties.
Before switching on the mains, secure the danger area by warning and removing all persons from the
danger area.

NORDAC BASE (SK 180E / SK 190E) – Users Manual for Frequency Inverters
20 BU 0180 en-4118
Operation
Where necessary, systems in which the devices are installed must be equipped with additional
monitoring and protective equipment according to the applicable safety requirements (e.g. legislation
concerning technical equipment, accident prevention regulations, etc.).
All covers must be kept closed during operation.
With certain setting conditions, the device or the motor which is connected to it may start automatically
when the mains are switched on. The machinery which it drives (press / chain hoist / roller / fan etc.)
may then make an unexpected movement. This may cause various injuries, including to third parties.
Before switching on the mains, secure the danger area by warning and removing all persons from the
danger area.
Due to its operation, the device produces noises within the audible frequency range. These noises
may cause long-term stress, discomfort and fatigue, with negative effects on concentration. The
frequency range or the noise can be shifted to a less disturbing or almost inaudible range by
adjustment of the pulse frequency. However, this may possibly result in derating (lower power) of the
device.
Maintenance, repair and decommissioning
Installation, maintenance and repair work must not be carried out unless the device has been
disconnected from the voltage and at least 5 minutes have elapsed since the mains was switched off!
(Due to charged capacitors, the equipment may continue to carry hazardous voltages for up to
5 minutes after being switched off at the mains). Before starting work it is essential to check by
measurement that all contacts of the power plug connections or the connection are voltage-free.
For further information, please refer to the manual for the device.
Disposal
The product and its parts and accessories must not be disposed of as domestic waste. At the end of
its life, the product must be properly disposed of according to the local regulations for industrial waste.
In particular, this product contains integrated semiconductor circuits (PCBs and various electronic
components, including high power capacitors). In case of incorrect disposal there is a risk of formation
of toxic gases, which may cause contamination of the environment and direct or indirect injuries (e.g.
chemical burns). In the case of high power capacitors, there is also a risk of explosion, with the
associated risk of injury.
5. Potentially explosive environment (ATEX, EAC Ex)
In order to operate or carry out installation work in potentially explosive environments (ATEX,
EAC Ex), the device must be approved and the relevant requirements and notes from the manual of
the device must be complied with.
Failure to comply can result in the ignition of an explosive atmosphere and fatal injuries.
• Only persons who are qualified, i.e. trained and authorised for all assembly, service,
commissioning and operation work on association with explosion hazard environments may work
with the devices described here (including the motors, geared motors, any accessories and all
connection technology).
