Nordic Propeye OY1210 User manual

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
Product manual
version
1.
0
January 24, 2023
[email protected]

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
Table of contents
1 Disclaimer ..................................................................................................................... 3
1.1 Technical support .................................................................................................. 3
1.2 EU Declaration of conformity ................................................................................. 3
2 Warnings ....................................................................................................................... 4
3 Environmental ............................................................................................................... 5
4 Product Description ...................................................................................................... 6
5 Installation and activation ............................................................................................. 7
6 The sensor consists of a bottom piece, the electronic board and the top cover.
Remove the top cover by pressing it upwards and outwards. The electronics are removed
by releasing the plastic latch on the top. .............................................................................. 7
6.1 LoRaWAN Configuration ....................................................................................... 8
6.2 Sensor states and state check .............................................................................. 9
7 Specification ............................................................................................................... 11
8 Product life length ....................................................................................................... 13
9 Security ....................................................................................................................... 13
10 Protocol ................................................................................................................... 13
10.1 LoRaWAN standard commands .......................................................................... 13
10.2 Unsolicited uplink status commands ................................................................... 13
10.3 Periodic measurement reports ............................................................................ 14
10.4 Downlink commands and queries ........................................................................ 15
10.5 Commands .......................................................................................................... 16
10.6 Uplink query response ......................................................................................... 18

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
1 Disclaimer
This document represents information on products at the time of publication and is subject
to change without prior notice due to product improvements or other reasons. Nordic
Propeye makes no warranties based on the accuracy or completeness of the contents of
this document and reserves the right to make changes to specifications and product
descriptions at any time without notice. Nordic Propeye reserves all rights to this document
and the information contained herein.
1.1 Technical support
Please visit www.nordicpropeye.com for additional information, or contact
[email protected]
1.2 EU Declaration of conformity
EC DECLARATION OF CONFORMITY
certify that the design and manufacturing of this product
WIRELESS CO2 SENSOR /
FUNK-CO2 SENSOR /
TRÅDLÖS CO2 SENSOR /
TRÅDØS CO2 SENSOR /
DRAADLOZE CO2 SENSOR
OY1210 EU868
conforms to the following directives and standards
The Radio Equipment Directive (2014/53/EU),
EN 300 220-1 V2.4.1, EN 300220-2 V2.4.1,
EN 301 489-1 V1.9.2, EN 301 489-3 V2.1.1,
EN 60950-1:2006+A11+A1+A12+A2
EN 62479:2010
RoHS 2.0 Directive 2011/65/EU
European Delegated Directive (EU) 2015/863
REACH regulation 1907/2006 EU
This product was CE marked in year -19
2019-09-10 ___________________
Managing Director Stefan Lindgren

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
2 Warnings
The following safety precautions must be observed during all phases of the operation,
usage, service or repair of this Nordic Propeye product.
• Read the product manual.
• Do not modify the product.
• The product should not be exposed to extreme heat or open flame.
• The device must not be exposed to harsh chemical agents or solvents.
• The labelling of the product may not be changed, removed or made unrecognizable.

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
3 Environmental
This symbol on the product or on its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to dispose of
your waste by taking it to a collection point designated for the recycling of electrical and
electronic appliances. Separate collection and recycling of your waste at the time of
disposal will contribute to conserving natural resources and guarantee recycling that
respects the environment and human health. For further information concerning your
nearest recycling center, please contact your nearest local authority/town hall offices, your
household waste collection company or the shop where you bought the product.

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
4 Product Description
The OY1210 LoRaWAN CO2 meter is designed to measure carbon dioxide, temperature
and humidity in indoor environments. The sensor is intended for indoor climate control, air
quality monitoring and energy optimizations. It is optimized for reliable and secure
measurements with more than 5 years life length on batteries.
The standard measurement interval is every minute and standard reporting interval is
every 20 measurements (resulting in a measurement report transmitted every 20 minutes).
The fast measurement interval makes it possible to insert additional transmissions when
large changes in the CO2 level are detected, resulting in low reporting latency. By default,
CO2 level changes larger than +/-100ppm from the last transmitted measurement report
causes an additional measurement report over the LoRa uplink channel. If the absolute
CO2 level is below a certain threshold, by default 750ppm, these additional reporting
events are however omitted. All these parameters can be adjusted using LoRa downlink
commands if needed.

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
5 Installation and activation
6 The sensor consists of a bottom piece, the electronic board and the top cover.
Remove the top cover by pressing it upwards and outwards. The electronics are
removed by releasing the plastic latch on the top.
The bottom piece is mounted on the wall with the “UP” arrow upwards. It can be mounted
either with screws or adhesive tape, both included in the package. The hole pattern
matches a standard junction box.

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
Configure the device in the LoRaWAN server, according to chapter 5.1, and insert the
batteries. The sensor starts and flashes 2 + 6 times during the boot-up sequence. The
sensor is activated by pressing the push button for 3 seconds until the red LED makes two
short flashes.
When the device has successfully joined the LoRaWAN network there will be a 2-second-
long flash.
Attach the electronic board to the bottom piece and attach the plastic cover.
6.1 LoRaWAN Configuration
Configuration on the network server is done with
AppEUI: 70-B3-D5-D7-2F-F8-18-00 (a.k.a. JoinEUI)
It is possible to order a batch of devices configured with a customer unique AppEUI from
the Nordic Propeye OUI range.
The device is configured with device unique DevEUI and AppKey
The device is default configured for OTA provisioning. Contact the Nordic Propeye team
for ABP configuration. The device follows the LoRaWAN standard related Join
configuration parameters, such as RX1 and RX2 windows, RX2 downlink frequency etc.
The default setting is ADR enabled.

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
6.2 Sensor states and state check
The sensor has five states: Booting, Initial, Joining, Configure and Operational state.
Figure 1: Device states
When the unit is initially powered, it flashes 2 times with the LED, after a few seconds the
unit enters initial state automatically. This is indicated by flashing 4 times.
To check the device state, press the button and hold it pressed until the red LED starts
flashing after 0.5s.

Product manual, version 1.0, January 25, 2023, www.nordicpropeye.com
OY1210 LoRaWAN® CO2 meter
State
Description
LED response
Initial
Low power state during transport. Radio not active.
1 short flash (0.5 sec)
Joining
Trying to join a LoRaWAN network. The device will
remain in this state until successfully joined a LoRaWAN
network
2 short flash (0.5 sec)
Configure
Enables quick over-the-air configuration, by polling
server after configuration commands during 2 minutes.
This is done by sending uplink status command (0x20).
1 long flash (2 sec)
Operational
Joined to a LoRaWAN network, measures temperature
and humidity periodically, and sends measurement
reports toward a LoRAWAN network.
1 long flash (2 sec)
6.2.1 Re-join functionality
The device supervises its connectivity to the network, by monitoring that periodic downlink
messages are received.
The device tries to re-join the network if it has not heard anything from the network for 288
uplinks (4 days @ 20-minute message interval). The device requests and normally gets a
downlink ever 64th uplink due to the ADRAckReq functionality.
