USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual be ore using
this equipment. Save this man-
ual or uture re erence.
Serial Number Decal
Model No. NETL92130
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Part No. 196689 0703A Printed in USA © 2003 ICON Health & Fitness, Inc.
QUESTIONS?
As a manu acturer, we are com-
mitted to providing complete
customer satis action. I you
have questions, or i there are
missing or damaged parts,
please call:
Or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
ORDERING REPLACEMENT PARTS
To order replacement parts, contact the ICON Health & Fitness Ltd. office, or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4, evie oad Industrial Estate
evie oad
Beeston
Leeds, LS118JG
UK
Tel:
Outside the UK: 0 (044) 113 387 7133
Fax: 0 (044) 113 387 7125
To help us assist you, please be prepared to give the following information:
• The MODEL NUMBE OF THE P ODUCT (NETL92130)
• The NAME OF THE P ODUCT (NordicTrack®4200 treadmill)
• The SE IAL NUMBE OF THE P ODUCT (see the front cover of this manual)
• The KEY NUMBE AND DESC IPTION OF THE PA T(S) (see the PA T LIST on pages 34 and 35 and the
EXPLODED D AWING attached in the centre of this manual)
08457 089 009
08457 089 009
www.iconeurope.com
Visit our website at
Class H Fitness Product
TABLE OF CONTENTS
IMPO TANT P ECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFO E YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE CHEST PULSE SENSO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
OPE ATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HOW TO FOLD AND MOVE THE T EADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
T OUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
PA T LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
O DE ING EPLACEMENT PA TS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED D AWING is attached in the centre of this manual.
Key No. Qty. Description Key No. Qty. Description
101 2 Front Wheel Bushing
102 2 Front Wheel
103 2 Front Wheel Spacer
104 4 Handrail Bolt
105 2 Fan
106 4 Handrail Bushing
107 1 Latch Pin
108 1 Pin Clip
109 1 Latch Pin Collar
110 1 Latch Knob Spring
111 1 Latch Knob Sleeve
112 1 Latch Knob Spacer
113 1 Latch Knob
114* 1 Latch Assembly
115 1 Left Cup Holder
116 1 ight Cup Holder
117 1 ight Fan Housing
118 2 Upright Endcap ( ound)
119 2 Wire Harness
120 2 Upright Hood Mount (Side)
121 4 8” Cable Tie
122 1 iFIT.com Audio Cable
123 1 Jack
124 1 eleaseable Tie
125 1 Catch
126 1 Idler Arm Bushing
127 2 Leveling Foot
128 1 Power Board
129 1 Filter
130 2 Motor Bushing
131 2 oller Adj. Washer
132 1 Chest Pulse Strap
133 1 Chest Pulse Sensor
134 1 Isolator Plate
135 1 Ferrite Box
136 4 Base Pad Screw
137 3 Hood Screw ( ear)
138 2 Frame Pivot Nut
139 1 Transformer
140 1 Ground Screw
141 1 Ground Nut Washer
142 2 Motor Spacer
143 1 Electronics Bracket
144 1 Splitter
# 1 12” Green Wire, 2 ing
# 1 8” Green Wire, F/ ing
# 1 6” Green Wire, 2 ing
# 1 4” Green Wire, F/ ing
# 1 8” Blue Wire, 2F
# 1 4” Blue Wire, 2F
# 1 4” Black Wire, 2F
# 1 8” White Wire, 2F
# 1 User's Manual
* Includes all parts shown in the box
# These parts are not illustrated
235
NordicTrack is a registered trademark of ICON Health & Fitness, Inc.
PART LIST—Model No. NETL92130 0703A
To locate the parts listed below, see the EXPLODED D AWING attached in the centre of this manual.
Key No. Qty. Description Key No. Qty. Description
1 1 Allen Wrench
2 2 ear Wheel Bolt
3 1 ear Endcap (Left)
4 2 oller Star Washer
5 2 ear oller Adj. Bolt
6 2 ear Wheel
7 4 U-nut
8 8 Endcap Bolt
9 1 oller Guard (Left)
10 1 oller Guard ( ight)
11 1 ear Endcap ( ight)
12 8 Endcap Nut
13 8 Endcap Washer
14 1 ear oller
15 1 Warning Decal
16 2 Foot ail Cover
17 1 Pulse eceiver
18 2 Belt Guide
19 1 Choke
20 2 Frame Pivot Bolt
21 2 Frame Pivot Washer
22 1 Left Foot ail
23 1 Walking Belt
24 1 Walking Platform
25 1 ight Foot ail
26 1 Front Endcap (Left)
27 1 Ground Wire
28 4 Support Bracket Screw
29 1 Support Bracket
30 1 Front oller/Pulley
31 1 Magnet
32 1 Motor Belt
33 1 Motor
34 2 Frame Pivot Bushing
35 2 Frame Pivot Spacer
36 1 eed Switch Clip
37 1 eed Switch
38* 1 Idler Assembly
39 1 Idler Pulley Bolt
40 1 Pulley Bushing
41 1 Idler Pulley
42 8 Lift Motor Nut/Idler Nut
43 4 Tension Washer
44 2 Incline Motor Bolt (Top)
45 1 Idler Arm Bearing
46 1 Idler Arm
47 1 Idler Spring
48 9 Hood Mount Screw
49 5 Hood Mount
50 1 Incline Motor
51 1 Incline Motor Bolt (Bottom)
52 1 Incline Motor Bracket
53 1 Front oller Adj. Bolt
54 1 Front oller Nut
55 2 Motor Bolt
56 1 Pulse Wire
57 1 Lift Leg
58 1 Left Fan Housing
59 2 Large Cage Nut
60 2 Plastic Stand-off
61 1 Front Endcap ( ight)
62 1 Motor Hood
63 2 Hood Clip
64 1 Controller
65 1 Controller Bracket
66 1 Motor Controller Wire
67 2 Euro Power Cord
68 1 eceptical
69 1 Circuit Breaker
70 1 12” Audio Wire
71 1 Audio Wire Nut
72 1 On/Off Switch
73 2 Static Decal
74 1 Belly Pan
75 4 Tie Holder
76 1 Belly Pan Bracket
77 2 Support Bracket Screw
78 1 Filter Wire
79 1 Console Ground Wire
80 1 Console Base
81 1 Console
82 1 Book Holder
83 1 Handrail
84 2 Handrail Endcap
85 1 Hand Grip Pulse
86 21 Screw
87 26 Console Screw
88 4 2” Console Screw
89 1 Console Back
90 1 Base Plate Bumper
91 1 Base Plate
92 3 Base Plate Screw
93 9 Base Screw
94 1 Wire Track
95 4 Base Pad
96 3 Cage Nut
97 2 Upright Endcap
98 1 Key/Clip
99 1 Upright
100 2 Front Wheel Bolt
34
1. It is the responsibility o the owner to ensure
that all users o this treadmill are adequately
in ormed o all warnings and precautions.
2. Use the treadmill only as described in this
manual.
3. Place the treadmill on a level sur ace, with at
least 2.5 m (8 t.) o clearance behind it and
0.5 m (2 t.) on each side. Do not place the
treadmill on any sur ace that blocks air open-
ings. To protect the loor or carpet rom dam-
age, place a mat under the treadmill.
4. Keep the treadmill indoors, away rom mois-
ture and dust. Do not put the treadmill in a
garage or covered patio or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age o 12 and pets
away rom the treadmill at all times.
7. The treadmill should not be used by persons
weighing more than 135 kg (300 lbs.).
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended or
both men and women. Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. When connecting the power cord (see page 9),
plug the power cord into an earthed circuit. No
other appliance should be on the same circuit.
When replacing the use, an ASTA approved
BS1362 type should be itted to the use car-
rier. A 13 amp use should be used.
11. I an extension cord is needed, use only a 3-
conductor, 1mm2(14-gauge) cord that is no
longer than 1.5 m (5 t.).
12. Keep the power cord away rom heated sur-
aces.
13. Never move the walking belt whilst the power
is turned o . Do not operate the treadmill i
the power cord or plug is damaged, or i the
treadmill is not working properly. (See
BEFORE YOU BEGIN on page 5 i the tread-
mill is not working properly.)
14. Never start the treadmill whilst you are stand-
ing on the walking belt. Always hold the
handrails whilst using the treadmill.
15. The treadmill is capable o high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
16. The pulse sensors are not medical devices.
Various actors, including the user's move-
ment, may a ect the accuracy o heart rate
readings. The pulse sensors are intended
only as exercise aids in determining heart
rate trends in general.
17. Never leave the treadmill unattended whilst it
is running. Always remove the key, unplug
the power cord and move the on/o switch to
the o position when the treadmill is not in
use. (See the drawing on page 5 or the loca-
tion o the on/o switch.)
18. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 25.) You
must be able to sa ely li t 20 kg (45 lbs.) in
order to raise, lower, or move the treadmill.
19. Do not change the incline o the treadmill by
placing objects under the treadmill.
20. When olding or moving the treadmill, make
sure that the storage latch is ully closed.
21. When using iFIT.com CDs and videos, an
electronic “chirping” sound will alert you
when the speed and/or incline o the treadmill
is about to change. Always listen or the
“chirp” and be prepared or speed and/or in-
cline changes. In some instances, the speed
and/or incline may change be ore the per-
sonal trainer describes the change.
WARNING: To reduce the risk o burns, ire, electric shock, or injury to persons, read the
ollowing important precautions and in ormation be ore operating the treadmill.
IMPORTANT PRECAUTIONS
3
22. When using iFIT.com CDs and videos, you
can manually override the speed and incline
settings at any time by pressing the speed
and incline buttons. However, when the next
“chirp” is heard, the speed and/or incline will
change to the next settings o the CD or video
program.
23. Always remove iFIT.com CDs and videos rom
your CD player or VCR when you are not
using them.
24. Inspect and properly tighten all parts o the
treadmill regularly.
25. Never insert or drop any object into any
opening.
26. DANGER: Always unplug the power
cord immediately a ter use, be ore cleaning
the treadmill, and be ore per orming the main-
tenance and adjustment procedures de-
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorised service representative. Servicing
other than the procedures in this manual
should be per ormed by an authorised service
representative only.
27. This treadmill is intended or in-home use
only. Do not use this treadmill in any commer-
cial, rental, or institutional setting.
WARNING: Be ore beginning this or any exercise program, consult your physician. This
is especially important or persons over the age o 35 or persons with pre-existing health problems.
Read all instructions be ore using. ICON assumes no responsibility or personal injury or property
damage sustained by or through the use o this product.
SAVE THESE INSTRUCTIONS
The decal shown at the right has been placed on your treadmill. I the decal is
missing or illegible, please call our Customer Service Department, toll- ree, to
order a ree replacement decal (see ORDERING REPLACEMENT PARTS on the
back cover o this manual). Apply the decal in the location shown.
Note: The decal is not shown at actual size.
433
NOTES
Thank you for selecting the revolutionary NordicTrack®
4200 treadmill. The 4200 treadmill offers an im-
pressive array of features to make your home work-
outs more enjoyable and effective. And when you’re
not exercising, the unique 4200 can be folded up, re-
quiring less than half the floor space of other treadmills.
For your bene it, read this manual care ully be ore
using the treadmill. If you have questions after read-
ing this manual, please call our Customer Service
Department at 08457 089 009. To help us assist you,
please note the product model number and serial num-
ber before calling. The model number of the treadmill
is NETL92130. The serial number can be found on a
decal attached to the treadmill (see the front cover of
this manual for the location).
Before reading further, please familiarise yourself with
the parts that are labelled in the drawing below.
BEFORE YOU BEGIN
Handrail
Console
Fan
Latch Knob
Book Holder
Key/Clip
On/Off
Switch
Circuit Breaker
Walking Belt
Flexible Walking Platform
Foot ail
ear oller
Adjustment Bolts
Water Bottle Holder*
Pulse Sensor
RIGHT SIDE
LEFT SIDE
*No water bottle is included.
532
NOTES
ASSEMBLY
Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench
and your own lat-bladed screwdriver , wire cutters , and adjustable
spanner .
Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a
small amount of lubricant may be transferred to the top of the treadmill or the shipping carton. This is a normal
condition and does not affect treadmill performance. If there is lubricant on top of the walking belt or foot pads,
simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
2. With the help of a second person, carefully raise both
Uprights (99) to a vertical position. Press the Latch Knob
Sleeve (111) into the left Upright and hold the Latch Knob
Spacer (112) against the left Upright.
emove the Latch Knob (113) from the Latch Pin (107).
Make sure that the Latch Pin Collar (109) and the Spring
(110) are on the Latch Pin. (Note: If there are two Latch
Pin Collars, place one on each side of the Spring.) Insert
the Latch Pin into the Latch Knob Sleeve (111) and the
Left Upright (99).
Tighten the Latch Knob (113) onto the Latch Pin (107).
99
112
111
113
110
109
107
2
31
1. Slide the treadmill out of the box. Insert the three Cage
Nuts (96) into the three indicated holes in the treadmill.
To insert each Cage Nut (96), first hook one side of the
Cage Nut into the hole and then use a flat-bladed screw-
driver to press the other side into the hole, as shown.
96
96
1
3. With the help of a second person, raise the Walking
Platform (24) to the storage position and make sure that
the latch pin is engaged as described on page 25.
Position the Base Plate (91) on the treadmill as shown.
Attach the Base Plate with the three Base Plate Screws
(92). Note: It may be helpful if a second person tips the
treadmill slightly as you tighten the Screws.
If the treadmill rocks slightly, turn one or both of the
Levelling Feet (127) under the Uprights (99) until the
rocking motion is eliminated. Carefully lower the Walking
Platform (24) to the floor as described on page 26. 91
24
92
99
127
127
3
6
SUGGESTED STRETCHES
The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce.
1. Toe Touch Stretch
Stand with your knees bent slightly and slowly bend forward from
your hips. Allow your back and shoulders to relax as you reach
down toward your toes as far as possible. Hold for 15 counts, then
relax. epeat 3 times. Stretches: Hamstrings, back of knees and
back.
2. Hamstring Stretch
Sit with one leg extended. Bring the sole of the opposite foot to-
ward you and rest it against the inner thigh of your extended leg.
each toward your toes as far as possible. Hold for 15 counts,
then relax. epeat 3 times for each leg. Stretches: Hamstrings,
lower back and groin.
3. Cal /Achilles Stretch
With one leg in front of the other, reach forward and place your
hands against a wall. Keep your back leg straight and your back
foot flat on the floor. Bend your front leg, lean forward and move
your hips toward the wall. Hold for 15 counts, then relax. epeat 3
times for each leg. To cause further stretching of the achilles ten-
dons, bend your back leg as well. Stretches: Calves, achilles ten-
dons and ankles.
4. Quadriceps Stretch
With one hand against a wall for balance, reach back and grasp
one foot with your other hand. Bring your heel as close to your
buttocks as possible. Hold for 15 counts, then relax. epeat 3
times for each leg. Stretches: Quadriceps and hip muscles.
5. Inner Thigh Stretch
Sit with the soles of your feet together and your knees outward.
Pull your feet toward your groin area as far as possible. Hold for
15 counts, then relax. epeat 3 times. Stretches: Quadriceps and
hip muscles.
1
2
3
4
5
WARNING: Do not plug in the power
cord until the treadmill is completely assembled.
6. Make sure that all parts are properly tightened be ore you use the treadmill. Keep the included allen
wrench in a secure place. The allen wrench is used to adjust the walking belt (see page 28). To protect the
loor or carpet rom damage, place a mat under the treadmill.
30 7
5. Insert two Handrail Bolts (104) with Handrail Bushings
(106) into the right Upright (99) and the right Handrail
(83). Be care ul not to pinch the wires. Make sure
that the Handrail Spacers are flush against the right
Upright, with the thick sides facing the centre of the
treadmill, as shown in the inset drawing. Next, lift the
right Handrail (83) slightly and align the Bolts with the
holes in the Handrail. Thread the Bolts into the
Handrail. Do not tighten the Bolts yet.
Attach the left Handrail (not shown) in the same way.
Then, tighten all our Handrail Bolts (104).
5
104
106
Thick
Side
99
106
4. Have a second person hold the Handrails (83) near the
Uprights (99). Connect the Upright Wire Harness (119) to
the wires extending from the Console Base (80) (see the
inset drawing). The connectors should slide together
easily and snap into place. I they do not, turn one
connector and try again. Then, insert the connectors
and the Upright Wire Harness into the hole in the right
Upright.
Set the Handrails on the Uprights, being careful not to
pinch the wires.
119
99
80
83
4
83
CONDITIONING GUIDELINES
The following guidelines will help you to plan your ex-
ercise program. For more detailed exercise informa-
tion, obtain a reputable book or consult your physician.
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your
cardiovascular system, the key to achieving the
desired results is to exercise with the proper intensity.
The proper intensity level can be found by using your
heart rate as a guide. The chart below shows recom-
mended heart rates for fat burning and aerobic exercise.
To find the proper heart rate for you, first find your age
near the bottom of the chart (ages are rounded off to
the nearest ten years). Next, find the three numbers
above your age. The three numbers define your “train-
ing zone.” The lower two numbers are recommended
heart rates for fat burning; the higher number is the
recommended heart rate for aerobic exercise.
To measure your heart rate during exercise, use the
pulse sensor on the console.
Fat Burning
To burn fat effectively, you must exercise at a relatively
low intensity level for a sustained period of time.
During the first few minutes of exercise, your body
uses easily accessible carbohydrate calories for en-
ergy. Only after the first few minutes does your body
begin to use stored fat calories for energy. If your goal
is to burn fat, adjust the speed and incline of the tread-
mill until your heart rate is near the lowest number in
your training zone.
For maximum fat burning, adjust the speed and incline
of the treadmill until your heart rate is near the middle
number in your training zone.
Aerobic Exercise
If your goal is to strengthen your cardiovascular sys-
tem, your exercise must be “aerobic.” Aerobic exercise
is activity that requires large amounts of oxygen for
prolonged periods of time. This increases the demand
on the heart to pump blood to the muscles, and on the
lungs to oxygenate the blood. For aerobic exercise,
adjust the speed and incline of the treadmill until your
heart rate is near the highest number in your training
zone.
WORKOUT GUIDELINES
Each workout should include the following three parts:
A Warm-up—Start each workout with 5 to 10 minutes
of stretching and light exercise. A proper warm-up in-
creases your body temperature, heart rate and circula-
tion in preparation for exercise.
Training Zone Exercise—After warming up, increase
the intensity of your exercise until your pulse is in your
training zone for 20 to 60 minutes. (During the first few
weeks of your exercise program, do not keep your
pulse in your training zone for longer than 20 minutes.)
Breathe regularly and deeply as you exercise—never
hold your breath.
A Cool-down—Finish each workout with 5 to 10 min-
utes of stretching to cool down. This will increase the
flexibility of your muscles and will help prevent post-ex-
ercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, complete three
workouts each week, with at least one day of rest be-
tween workouts. After a few months, you may com-
plete up to five workouts each week if desired. The key
to success is to make exercise a regular and enjoyable
part of your everyday life.
WARNING: Be ore beginning this
or any exercise program, consult your physi-
cian. This is especially important or individu-
als over the age o 35 or individuals with pre-
existing health problems.
The pulse sensors are not medical devices.
Various actors, including the user's move-
ment, may a ect the accuracy o heart rate
readings. The pulse sensors are intended
only as exercise aids in determining heart rate
trends in general.
298
HOW TO PUT ON THE CHEST PULSE SENSOR
The chest pulse sensor consists of two components:
the chest strap and the sensor unit (see the drawing
below). Insert the tab on one end of the chest strap into
one end of the sensor unit, as shown in the inset draw-
ing. Press the end of the sensor unit under the buckle
on the chest strap. The tab should be flush with the
front of the sensor unit.
Next, wrap the
chest pulse sen-
sor around your
chest, and attach
the other end of
the chest strap to
the sensor unit.
Adjust the length
of the chest strap,
if necessary. The
chest pulse sen-
sor should be under your clothes, tight against your
skin, and as high under the pectoral muscles or
breasts as is comfortable. Make sure that the logo on
the sensor unit is facing forward and is right-side-up.
Pull the sensor unit away from your body a few inches
and locate the two electrode areas on the inner side
(the electrode areas are covered by shallow ridges).
Using saline solution such as saliva or contact lens so-
lution, wet both electrode areas. eturn the sensor unit
to a position against your chest.
CHEST PULSE SENSOR CARE AND MAINTENANCE
• Thoroughly dry the chest pulse sensor after each
use. The chest pulse sensor is activated when the
electrode areas are wetted and the heart rate
monitor is put on; the chest pulse sensor shuts off
when it is removed and the electrode areas are
dried. If the chest pulse sensor is not dried after
each use, it may remain activated longer than nec-
essary, draining the battery prematurely.
• Store the chest pulse sensor in a warm, dry place.
Do not store the chest pulse sensor in a plastic bag
or other container that may trap moisture.
• Do not expose the chest pulse sensor to direct
sunlight for extended periods of time; do not expose
it to temperatures above 50° Celsius (122°
Fahrenheit) or below -10° Celsius (14° Fahrenheit).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest
strap may be hand washed and air dried.
CHEST PULSE SENSOR TROUBLESHOOTING
The instructions on the ollowing pages explain
how the chest pulse sensor is used with the con-
sole. I the chest pulse sensor does not unction
properly, try the steps below.
• Make sure that you are wearing the chest pulse sen-
sor as described at the left. Note: If the chest pulse
sensor does not function when positioned as de-
scribed, move it slightly lower or higher on your chest.
• Use saline solution such as saliva or contact lens
solution to wet the two electrode areas on the
sensor unit. If heart rate readings do not appear until
you begin perspiring, re-wet the electrode areas.
• As you walk or run on the treadmill, position your-
self near the centre of the walking belt. For the
console to display heart rate readings, the user
must be within arm’s length o the console.
• The chest pulse sensor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical
conditions such as premature ventricular contrac-
tions (pvcs), tachycardia bursts, and arrhythmia.
• The operation of the chest pulse sensor can be
affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
this is a problem, try relocating the treadmill.
• The C 2032 battery may need to be replaced (see
page 29).
Chest Strap
Tabs
Sensor Unit
Tab
Sensor
Unit Buckle
HOW TO USE THE CHEST PULSE SENSOR PROBLEM: The incline o the treadmill does not change correctly or does not change when iFIT.com
CDs and videos are played
SOLUTION: a. With the key in the console, press one of the Incline buttons. Whilst the incline is changing, re-
move the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the
maximum incline level and then return to the minimum level. This will recalibrate the incline system.
PROBLEM: The heart rate monitor does not unction properly
SOLUTION: a. If the heart rate monitor does not function properly, see CHEST PULSE SENSO T OUBLE-
SHOOTING on page 8.
b. If the heart rate monitor still does not function properly, the battery
should be changed. To replace the battery, locate the battery cover
on the back of the sensor unit. Insert a coin into the slot in the cover
and turn the cover counterclockwise to the “open” position. emove
the cover.
emove the old battery from the sensor unit. Insert a new CR 2032
battery, making sure that the writing is on top. In addition, make sure
that the rubber gasket is in place in the sensor unit. eplace the bat-
tery cover and turn it to the closed position. Battery
ubber
Gasket
Battery Cover
b
Battery
Cover
28 9
PROBLEM: The walking belt slows when walked on
SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm2(14-gauge) cord that is no longer
than 1.5 m (5 ft.).
b. If the walking belt is overtightened, treadmill perfor-
mance may decrease and the walking belt may be-
come damaged. emove the key and UNPLUG THE
POWER CORD. Using the allen wrench, turn both
rear roller adjustment bolts counterclockwise, 1/4 of a
turn. When the walking belt is properly tightened, you
should be able to lift each side of the walking belt
8–10cm (3–4 in.) off the walking platform. Be careful
to keep the walking belt centred. Plug in the power
cord, insert the key, and run the treadmill for a few
minutes. epeat until the walking belt is properly tight-
ened.
c. If the walking belt still slows when walked on, call our Customer Service Department, toll-free.
PROBLEM: The walking belt is o -centre or slips when walked on
SOLUTION: a. If the walking belt is off-centre, first remove the key and
UNPLUG THE POWER CORD. I the walking belt has
shi ted to the le t, use the allen wrench to turn the left
rear roller bolt clockwise 1/2 of a turn; i the walking belt
has shi ted to the right, turn the bolt counterclockwise
1/2 of a turn. Be careful not to overtighten the walking
belt. Plug in the power cord, insert the key, and walk on
the treadmill for a few minutes. epeat until the walking
belt is centred.
b. If the walking belt slips when walked on, first remove the
key and UNPLUG THE POWER CORD. Using the allen
wrench, turn both rear roller bolts clockwise, 1/4 of a turn.
When the walking belt is correctly tightened, you should
be able to lift each side of the walking belt 8–10cm (3–4
in.) off the walking platform. Be careful to keep the walk-
ing belt centred. Plug in the power cord, insert the key,
and walk on the treadmill for a few minutes. epeat until
the walking belt is properly tightened.
PROBLEM: The treadmill rocks during use
SOLUTION: a. If the treadmill rocks slightly during use, turn one or
both of the Levelling Feet (127) under the Upright (99)
until the the rocking motion is eliminated. Note: If nec-
essary, tip the treadmill forward and use a phillips
screwdriver to turn the Levelling Feet.
ear oller Adjustment Bolts
8–10cm
b
a
b
127
127
a
99
OPERATION AND ADJUSTMENT
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with PE FO MANT LUBETM, a high-performance lubricant. IMPOR-
TANT: Never apply silicone spray or other substances to the walking belt or the walking plat orm. Such
substances will deteriorate the walking belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
This product must be earthed. If it should malfunction or break
down, earthing provides a path of least resistance for electric cur-
rent to reduce the risk of electric shock. This product is equipped
with a power cord having an equipment-earthing conductor and a
earthing plug.
Two power cords are included. Select the one that will it your
outlet. Re er to drawing 1. Plug the indicated end o the power
cord into the socket on the treadmill. Next, li t the tab on the
errite box and clamp the errite box around the power cord.
Fasten the included plastic tie just behind the errite box and
cut o the excess plastic tie. The plastic tie will prevent the er-
rite box rom sliding along the power cord. Re er to drawing 2.
Plug the power cord into an appropriate outlet that is properly
installed and earthed in accordance with all local codes and or-
dinances. Important: The treadmill is not compatible with GFCI-
equipped outlets.
Important: If the power cord is damaged, it must be replaced with a
manufacturer-recommended power cord.
DANGER: Improper connection o the equipment-earthing conductor can result in an in-
creased risk o electric shock. Check with a quali ied electrician or serviceman i you are in doubt as
to whether the product is properly earthed. Do not modi y the plug provided with the product—i it will
not it the outlet, have a proper outlet installed by a quali ied electrician.
Socket on treadmill
Outlet
1
2
Ferrite Box
Tab
Plastic Tie
10 27
FEATURES OF THE CONSOLE
The advanced console offers an impressive array of
features designed to help you get the most from your
exercise. When the manual mode is selected, the
speed and incline of the treadmill can be changed with
a touch of a button. As you exercise, the console will
provide continuous exercise feedback. You can even
measure your heart rate using the built-in pulse sensor
or the chest pulse sensor.
In addition, the console offers six preset workout pro-
grams and two heart rate programs. Each program au-
tomatically controls the speed and incline of the tread-
mill to give you an effective workout. You can even
create your own custom workout programs and store
them in memory for future use.
The console also features iFIT.com interactive technol-
ogy. Having IFIT.com technology is like having a per-
sonal trainer in your home. Using the included audio
cable, you can connect the treadmill to your home
stereo, portable stereo, or computer and play special
iFIT.com CD and videocassette programs (iFIT.com
CDs and videocassettes are available separately).
iFIT.com CD and videocassette programs automatically
control the speed and incline of the treadmill as a per-
sonal trainer guides you through every step of your
workout. High-energy music provides added motivation.
To purchase iFIT.com CDs and videocassettes,
visit our Web site at www.iFIT.com.
With the treadmill connected to your computer, you
can even go to our Web site at www.iFIT.com and
access programs directly from the internet. See
www.iFIT.com or more in ormation.
To use the manual mode o the console, follow the
steps beginning on page 11. To use a preset program,
see page 13. To create and use a custom program,
see pages 15 and 16. To use a heart rate program,
see page 17. To use an iFIT.com CD or video pro-
gram, refer to page 21. To use an iFIT.com program
directly rom our Web site, see page 23.
Pulse
Sensor
Pulse
Sensor
Clip
Key
Program
Display
Main
Display
Note: If there is a thin sheet
of clear plastic on the face
of the console, remove it.
TROUBLESHOOTING
Most treadmill problems can be solved by ollowing the steps below. Find the symptom that applies, and
ollow the steps listed. I urther assistance is needed, please call our Customer Service Department.
PROBLEM: The power does not turn on
SOLUTION: a. Make sure that the power cord is plugged into a properly earthed outlet. (See page 9.) If an exten-
sion cord is needed, use only a 3-conductor, 1 mm2(14-gauge) cord that is no longer than 1.5 m
(5 ft.). Important: The treadmill is not compatible with GFCI-equipped outlets.
b. After the power cord has been plugged in, make sure that the key is fully inserted into the console.
c. Check the circuit breaker located on the treadmill
near the power cord. If the switch protrudes as
shown, the circuit breaker has tripped. To reset the
circuit breaker, wait for five minutes and then press
the switch back in.
d. Check the on/off switch located on the treadmill near
the power cord. The switch must be in the on position.
PROBLEM: The power turns o during use
SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the
circuit breaker has tripped, wait for five minutes and then press the switch back in.
b. Make sure that the power cord is plugged in. If the power cord is plugged in, unplug it, wait for
five minutes, and then plug it back in.
c. emove the key from the console. einsert the key fully into the console.
d. Make sure that the on/off switch is in the on position.
e. If the treadmill still will not run, please call our Customer Service Department.
PROBLEM: The displays o the console do not unction properly
SOLUTION: a. emove the key from the console and UNPLUG THE
POWER CORD. emove the indicated Screws (48)
from the Hood (62). Carefully rotate and lift the Hood.
Locate the eed Switch (37) and the Magnet (31) on
the left side of the Pulley (30). Turn the Pulley until the
Magnet is aligned with the eed Switch. Make sure
that the gap between the Magnet and the Reed
Switch is about 3mm (1/8 in.). If necessary, loosen
the Screw (86) and move the eed Switch slightly.
etighten the Screw. e-attach the hood, and run the
treadmill for a few minutes to check for a correct
speed reading.
31
48
62
48
a
Top
View
3 mm
37
86 30
Tripped
c
eset
On
Position
d
