Nordmende CTG50LPGBK User manual

OPERATING AND INSTALLATION
INSTRUCTIONS OF
FREESTANDING
GAS DOUBLE OVEN
TM
CTG50LPGBK
CTG50BK

Dear Customer,
Our goal is to offer you products with high quality that exceed your
expectations. Your appliance is produced in modern facilities
carefully and particularly tested for quality.
This manual is prepared in order to help you use your appliance
that is manufactured by the most recent technology, with
confidence and maximum efficiency.
Before using your appliance, carefully read this guide that includes
the basic information for right and safe installation, maintenance
and use please contact to the nearest Authorized Service for the
installation of your product.
CE Declaration of conformity
This appliance has been designed to be used only for cooking. Any
other use (such as heating a room) is improper and dangerous.
This appliance has been designed, constructed, and marketed
incompliance with:
• Safety requirements of the "Gas" Directive 2009/142/EC;
• Safety requirements of the "Low voltage" Directive 2006/95/EC;
• Safety requirements of the "EMC" Directive 2004/108/EC;
• Requirements of the Directive 93/68/EC.

CONTENTS:
1. Part : PRESENTATION AND SIZES OF PRODUCT
2. Part : WARNINGS
3. Part : INSTALLATION AND PREPARATIONS FOR USE
3.1 Environment where the appliance will be installed
3.2 Installation of oven
3.3 Adjustment of feet
3.4 Gas connection
3.5 Electric connection and security
3.6 General warnings and measures
3.7 Gas conversions
4. Part : USE OF YOUR OVEN
4.1 Use of gas burners
4.1.1 Control of hob burners
4.1.2 Control of oven burner
4.1.3 Control of grill burner
4.2 Accessories used in oven
5. Part : CLEANING AND MAINTENANCE
5.1 Cleaning
5.2 Maintenance
6. Part : SERVICE AND TRANSPORT
6.1
6.2 Information related to the transport
Basic troubleshooting before contacting service

1
13
10
11
12
14
1. Part : PRESENTATION AND SIZES OF PRODUCT
PRESENTATION:
List of Components:
1- Cooktop
2- Control Panel
3- Oven Door Handle
4- Supply Leg
5- Oven Door
6- Oven Tray
7- Wire Grid
8- Grill
9- Oven Lamp
10- Semi-Rapid Burner
11- Rapid Burner
12- Auxillary Burner
13- Hob Grids
14- Semi-Rapid Burner
4
1
2
3
5
6
7
9
8
2.Rack
1.Rack
5.Rack
4.Rack
3.Rack
2.Rack
1.Rack
MODEL
CTG50LPGBK
CTG50BK
SIZE (mm)
50 * 60 * 90

2
2. Part : WARNINGS
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR
APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOURAPPLIANCE
MAY NOT HAVE SOME OF THE FEATURES THAT ARE EXPLAINED IN THIS MANUAL. PAY
ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES, WHILE YOUARE READING THE
OPERATING MANUAL.
General Safety Warnings
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
- WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching heating elements.
Children less than 8 years of age shall be kept
away unless continuously supervised.
- WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water,
but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
- WARNING: Danger of fire: do not store items
on the cooking surfaces.

3
2. Part : WARNINGS
- WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of electric
shock.
- For hobs incorporating a lid, any spillage
should be removed from the lid before opening.
And also the hob surface should be allowed to
cool before closing the lid.
- The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
- WARNING: In order to prevent tipping of the
appliance, the stabilizing brackets must be
installed. (For detail information please read the
anti-tilting kit set guide.)
- During use, the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
- During use, handles held for short periods in
normal use can get hot.
- Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass and
other surface since they can scratch the
surface, which may result in shattering of the
glass or damage to the surface.
- Do not use steam cleaners for cleaning the
appliance.

4
2. Part : WARNINGS
- WARNING: Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
- CAUTION: Accessible parts may be hot when
the cooking or grilling is in use. Young children
should be kept away.
• Your appliance is produced in accordance with all applicable local and international standards and
regulations.
• Maintenance and repair work must be made only by authorized service technicians. Installation and
repair work that is carried out by unauthorized technicians may endanger you. It is dangerous to alter
or modify the specifications of the appliance in any way.
• Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure
or electricity voltage and frequency) and the requirements of the appliance are compatible. The
requirements for this appliance are stated on the label.
• CAUTION: This appliance is designed only for cooking food and is intended for indoor domestic
household use only and should not be used for any other purpose or in any other application, such
as for non-domestic use or in a commercial environment or room heating.
• Do not try to lift or move the appliance by pulling the door handle.
• This appliance is not connected to a combustion products evacuation device. It shall be installed
and connected in accordance with current installation regulations. Particular attention shall be given
to the relevant requirements regarding ventilation.
• If after 15 s the burner has not lit, stop operating the device and open the compartment door and/or
wait at least 1 min before attempting a further ignition of the burner.
• These instructions are only valid if the country symbol appears on the appliance. If the symbol does
not appear on the appliance, it is necessary to refer to the technical instructions which will provide
the necessary instructions concerning modification of the appliance to the conditions of use of the
country.
• All possible security measures have been taken to ensure your safety. Since the glass may break,
you should be careful while cleaning to avoid scratching. Avoid hitting or knocking on the glass with
accessories.
• Ensure that the supply cord is not wedged during the installation. If the supply cord is damaged, it
must be replaced by the manufacturer, its service agent or similarly qualified persons in order to
prevent a hazard.
• While the oven door is open, do not let children climb on the door or sit on it.
Installation Warnings
• Do not operate the appliance before it is fully installed.
• The appliance must be installed by an authorized technician and put into use. The producer is not
responsible for any damage that might be caused by defective placement and installation by
unauthorized people.
• When you unpack the appliance, make sure that it is not damaged during transportation. In case of
any defect; do not use the appliance and contact a qualified service agent immediately. As the
materials used for packaging (nylon, staplers, styrofoam...etc) may cause harmful effects to children,
they should be collected and removed immediately.
•Protectyourapplianceagainstatmosphericeffects.Donotexposeittoeffectssuchassun,rain,snow
etc.
• The surrounding materials of the appliance (cabinet) must be able to withstand a temperature of min
100°C.

5
2. Part : WARNINGS
During usage
• When you first run your oven a certain smell will emanate from the insulation materials and the
heater elements. For this reason, before using your oven, run it empty at maximum temperature for
45 minutes. At the same time you need to properly ventilate the environment in which the product is
installed.
• During usage, the outer and inner surfaces of the oven get hot. While opening the oven door, step
back to avoid the hot steam coming out of the oven. There may be a risk of burns.
•Donotputflammableorcombustiblematerials,inorneartheappliancewhenitisoperating.
•Alwaysuseovenglovestoremoveandreplacefoodintheoven.
• Do not leave the cooker while cooking with solid or liquid oils. They may catch fire on condition of
extremeheating.Neverpourwaterontoflamesthatarecausedbyoil.Coverthesaucepanorfryingpan
withitscoverinordertochoketheflamethathasoccurredinthiscaseandturnthecookeroff.
•Alwayspositionpansoverthecentreofthecookingzone,andturnthehandlestoasafepositionsothey
cannotbeknockedorgrabbed.
• If you will not use the appliance for a long time, plug it off. Keep the main control switch off.Also when
youdonotusetheappliance,keepthegasvalveoff.
•Makesuretheappliancecontrolknobsarealwaysinthe"0"(stop)positionwhenitisnotused.
• The trays incline when pulled out. Be careful not to let hot liquid spill over.
•CAUTION:Theuseofagascookingapplianceresultsintheproductionofheat,moistureandproducts
of combustion in the room in which it is installed. Ensure that the kitchen is well ventilated especially
when the appliance is in use, keep natural ventilation holes open or install a mechanical ventilation
device(mechanicalextractorhood).
• Prolonged intensive use of the appliance may call for additional ventilation, for example opening of
a window, or more effective ventilation, for example increasing the level of mechanical ventilation
where present.
• While using the grill burner, keep the oven door open and always use the grill deflector shield
supplied with the product. Never use the grill burner with the oven door closed.
• CAUTION: Glass lids may shatter when heated.
Turn off all the burners before shutting the lid.
The hob surface should be allowed to cool before closing the lid.
• When the door or drawer of the oven is open, do not leave anything on it. You may unbalance your
appliance or break the cover.
• Do not put heavy things or flammable or ignitable goods (nylon, plastic bag, paper, cloth...etc) into
the drawer. This includes cookware with plastic accessories (e.g. handles).
• Do not hang towels, dishcloths or clothes from the appliance or its handles.
During cleaning and maintenance
• Always turn the appliance off before operations such as cleaning or maintenance. You can do it
after plugging the appliance off or turning the main switches off.
• Do not remove the control knobs to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE ORIGINAL SPARE PARTS AND TO CALL ONLY OUR AUTHORIZED
SERVICE AGENTS IN CASE OF NEED.

6
3. Part : INSTALLATION AND PREPARATIONS FOR USE
This modern, functional and practical oven, that was manufactured with the
parts and materials of highest quality, will meet your cooking needs in every
aspect. You must surely read this manual so that you don't have any problem in
future and to be able to have satisfactory results. The following information are
the required rules for right installation and service processes. It must be read
especially by the technician who will install the appliance
Contact To Authorized Service For Installation Of Your Oven
Your oven must be set up and used in a place where it will always have
ventilation
While operating, this appliance needs
There must be a natural ventilation enough to provide the gas to be used in
the environment. The average air flow must directly come in through the air
holes that will be opened on the walls that are opened towards outside.
.
3.1 Environment where your appliance will be installed
• .
3
• 2m /h air per kw input.
•
2
These air holes must have at least the effective cross section of 100cm for
fresh air circulation (One or more air holes can be opened.). This hole (or
holes) must be opened so that they are not blocked. Preferably they must be
placed close to the bottom and at opposite side of the smokes of the burned
gases that were emptied. If it seems not possible to open these ventilations
in the place where the appliance is set up, the needed air can also be
obtained through the next room, provided that this place is not a bed room
or a dangerous place. In this case this “next room” must also be ventilated
as required.
Emptying of the Burned Gases from Environment
The cooking appliances that operate with gas, throw the burned gas wastes out
directly to the outside or through the cooker hoods that are connected to the a
chimney that opens directly to the outside. If it seems not possible to install a
cooker hood, it is required to set an electric fan on the window or wall that has
Air inlet section
2
min. 100cm
Air inlet section
2
min. 100cm
Figure 1 Figure 2

7
access to fresh air. This electric fan must have the capacity to change the air of the
kitchenenvironment 4-5times of its own volumeof air per hour.
3. Part : INSTALLATION AND PREPARATIONS FOR USE
Cooker hood flue Electrical ventilator
Air inlet section
2
min. 100cm
Min. 60cm
COOKER HOOD
Min. 42cm
Min. 42cm
Min. 65cm(with hood)
Min. 70cm(without hood)
Air inlet section
2
min. 100cm
Figure 5
Figure 3 Figure 4
3.2 Installation of oven
.
•
.
There are some factors that must be paid attention to while installing your
oven. Surely be very careful to while installing your oven. Pay attention to our
below instructions in order to be able to prevent any problems and/or
dangerous situations that may occur later
The appliance can be placed close to other furniture on condition that in the
area where the oven is set up, the furniture's height does not exceed the
height of the cooker panel

3. Part : INSTALLATION AND PREPARATIONS FOR USE
8
•
.
• .
•
.
3.3 Adjustment of feet
.
3.4 Gas connection
Pay attention not to place it near the refrigerator, there must be no
flammable or inflammable materials such as curtain, waterproof cloth, etc.
that will begin to burn quickly
It is required that there must be least a 2cm blank space around the oven for
air circulation
If the kitchen furniture are higher than the hob plate of the oven, it must be
at least 10cm away from the oven's side.
The minimum heights from the oven's pan and wall cupboards and cooker
hoods with fan over the oven, are shown as above. Thus, the cooker hood must
be at minimum 65cm height from the cooker pan. If there is no cooker hood,
this height must not be less than 70cm.
Your oven stands on 4 adjustable feet. When the oven is placed where it will be
used, check if the oven is balanced. If it is not balanced, you can make the
adjustment by turning the feet clockwise if required. It is possible to raise the
appliance maximum 30mm by the feet. If the feet are adjusted appropriately, it
is required not to move the appliance by dragging, it should be moved by lifting
it up
The connection of the appliance should be performed in accordance with local
and international standards and regulations applicable. You can find the
information related to appropriate gas types and appropriate gas injectors on
technical data table. If the pressure of used gas is different than these values
stated of the or not stable in your area, it may be required to assemble an
available pressure regulator on the gas inlet. It is certainly required to contact
to the authorized service to make these adjustments.
The points that must be checked during flexible hose assembly
If the gas connection is made by a flexible hose that is fixed on the gas inlet of
appliance, it must be fixed by a pipe collar as well. Connect your appliance with
a short and durable hose that is as close as possible to the gas source. The
hose's permitted maximum length is 1.5m. The hose that brings gas to the
appliance must be changed once a year for your security.
The hose must be kept clear from areas that may heat up to temperatures in
0
excess of 50 C. The hose must not be ruptured, bent or folded. The hose must
be kept clear of sharp corners, moving things, and should not be defective.
Before assembly, it must be checked whether there is any production defect.

3. Part : INSTALLATION AND PREPARATIONS FOR USE
9
As gas is turned on, all connection parts and hose must be checked with soapy
water or leakage fluids. Do not use naked flame to check gas leakage. All metal
components used during gas connection must be clear of rust. Also check the
expirydates of components used.
The points that must be checked during Fixed gas connection assembly
To assemble a fixed gas connection (gas connection made by threads, e.g. a nut),
there are different methods used in different areas. The most common parts are
alreadysupplied with your appliance. Any other partcan be supplied asspare part.
During connections always keep the nut on the gas manifold fixed, while rotating
the counter-part. Use spanners of appropriate size for safe connection. For all
surfaces between different components, always use the seals provided in the spare
set. The seals used during connection should also be approved to be used in gas
connections.Do not use plumbing sealsfor gas connections.
Remember that this appliance is prepare to be connected to gas supply in the
country for which it has been produced. The main country of destination is
marked on the rear cover of the appliance. If you need to use it in another
country, any of the connections in the figure below can be required. In such a
case, learn the appropriate connection parts and obtain those parts to perform
a safe connection.
It is required to call the authorized service to be able to make the gas
connections appropriately and in compliance with safety standards..
Surely do not use any match and lighter for control of gas
leakage
ATTENTION!
.
Adapter
Gas Pipe Gas Pipe Gas Pipe Gas Pipe
Seal
Seal
Seal
Hose
Fitting
Gas Hose
with Collar
Mechanical
Gas Hose
Mechanical
Gas Hose
Mechanical
Gas Hose
Figure 6

3. Part : INSTALLATION AND PREPARATIONS FOR USE
10
3.5 Electric connection and security
.
• .
• .
• .
•
• .
• .
• .
During the electric connection, follow the instructions stated in the user
manual
The earthing cable must be connected to the earth terminal
You have to ensure the power cord with suitable insulation to be connected
to the power source during the connection If there is no appropriate earthed
electric outlet in accordance with regulations in the place where the
appliance will be installed, immediately contact to our authorized service.
The earthed electric outlet must be close to the appliance.
Do not use an extension cord
The power cord must not touch to the hot surface of the product.
In case the cord is damaged, contact Authorized Service to have it changed
Any wrong electric connection may damage your appliance, as well as
endangering your safety, rendering your guarantee invalid
The appliance is adjusted for 230V 50Hz electricity. If the network electricity
is different than this value, immediately contact your authorized service
L
N
BROWN
YELLOW+GREEN
BLUE
Figure 7
•
•
.
The supply cord should be kept away from hot parts of appliance. Otherwise
the cord may be damaged, causing short circuit.
The producer firm declares that it has no responsibility against any kind of
damages and losses that are caused by improper connections that are
performed by unauthorized people

3. Part : INSTALLATION AND PREPARATIONS FOR USE
11
3.6 General warnings and measures
•
•
.
•
.
•
.
•
• .
•
•
•
•
3.7 Gas conversions
:
Your appliance is produced in accordance with the local and international
standards and regulations applicable.
The maintenance and repair works must be made only by authorized service
technicians. The installation and repair works without following proper
knowledge may endanger you
While your appliance operates, its outside surfaces heat up. The interior
surfaces of oven, and the flue outlets are quite hot. Even if the appliance is
turned off, these parts keep its heat for a specific time. Do not touch onto
hot surfaces, and keep children away
Do not leave the cooker while cooking with solid or liquid oils. They may
catch fire on condition of extreme heating. Never pour water to the flames
that are caused by oil. Cover the saucepan or frying pan with its cover in
order to choke the flame that has occurred in this case and turn the cooker
off
The oven and heat adjustment switches must be adjusted for cooking in your
oven. Otherwise the oven does not operate.
When the door or drawer of oven is open do not leave anything on it . You
may unbalance your appliance or break the cover
Do not put heavy things or flammable or ignitable goods (nylon, plastic
bag,paper,cloth...etc) into the lower drawer. This includes cookware with
plastic accessories (e.g. handles).
Plug the appliance off the electrical network when you do not use the
appliance and keep the gas valve off.
Protect your appliance against atmospheric effects. Do not leave it to effects
such as sun, rain, snow, powder etc.
Remember that this appliance is designed for indoor use.
Caution : The following procedures must be undertaken by authorized
service personnel.
Your appliance is adjusted to be operated with NG/LPG gas. The gas burners
can be adapted to different types of gas, by replacing the corresponding
injectors and adjusting minimum flame length suitable to the gas in use. For
this purpose, following steps should be performed

3. Part : INSTALLATION AND PREPARATIONS FOR USE
12
Figure 8
Figure 9 Figure 10

3. Part : INSTALLATION AND PREPARATIONS FOR USE
13
Adjusting The Reduced Flame Position
The flame length in the minimum position is adjusted with a flat screw located
on the valve. For valves with FFD, the screw is located on the side of the valve
spindle. For valves without FFD, the screw is located inside the valve spindle.
For easier reduced flame adjustment, we advise to remove the control panel
(and microswitch, if present) during adjustment.The position the by pass screw
must be loosened in transformation from LPG to NG. In transformation from NG
to LPG, the same screw must be fastened. Make sure that the appliance is
unplugged from the electric current and the gas feed is open.
To determine the min. position, ignite the burners and leave them on in minimum
position. Remove the knobs because the screws are accessible only when the
knobs are removed. With the help of a small screwdriver fasten or loosen the by
pass screw around 90 degrees. When the flame has a length of at least 4mm, the
gas is well distributed. Make sure that the flame does not die out when passing
from the maximum position to the minimum position. Create an artificial wind with
your hand toward the flame to see if the flames are stable. For oven burner, operate
the oven burner at min. position for 5 minutes, then open and close the oven door
for2-3 times to checkthe flame stability of theburner.
For some countries, the gas inlet type can be different for NG/LPG gases. In
such a case, remove the current connection components and nuts (if any) and
connect the new gas supply accordingly. In all conditions, all components used
in gas connections should be approved by local and/or international authorities.
In all gas connections, refer to the “ASSEMBLY OF GAS SUPPLY AND LEAKAGE
CHECK” clause explained before.
:
Changing the gas inlet:
Figure 11

3. Part : INSTALLATION AND PREPARATIONS FOR USE
14
Adjusting the reduced flame position
The flame length in the minimum position is adjusted with a flat screw located
on the valve. For valves with flame failure device, the screw is located on the
side of the valve spindle(Figure 14). For easier reduced flame adjustment, it is
advised to remove the control panel (and microswitch, if present) during
adjustment.
To determine the minimum position, ignite the burners and leave them on in
minimum position. Remove the with the help of a small screwdriver fasten or
loosen the bypass screw around 90 angular degrees. When the flame has a
length of at least 4mm, the gas is well distributed. Make sure that the flame
does not die out when passing from the maximum position to the minimum
position. Create an artificial wind with your hand toward the flame to see if the
flames are stable.
:
Figure 14
Bypass Screw
Valve with flame failure device
For oven burner, operate the oven burner at minimum position for 5 minutes,
then open and close the oven door for 2-3 times to check the flame stability of
the burner.
Reduced flame position adjustment is not required for grill burners.
The position the bypass screw must be loosened for conversion from LPG to NG.
For conversion from NG to LPG, the same screw must be fastened. Make sure
that the appliance is unplugged from the electric mains and the gas supply is
open.
Figure 16
Bypass Screw
Thermostatic oven valve

4. Part : USE OF YOUR OVEN
15
4.1 Use of gas burners
•
:
•
.
Ignition of the burners
To determine which knob controls which burner, check the position symbol
above the knob.
Manual Ignition of the Gas Burners
If your appliance is not equipped with any ignition aid or in case there is a
failure in the electricity network, follow the procedures listed below
For Hob Burners: To ignite one of the burners, press and turn its knob
counter-clockwise so that the knob is in max. position, approach a match, taper
or another manual aid to its upper circumference. Move the ignition source
away as soon as you see a stable flame.
For Oven Burners: To ignite the oven burner, press and turn the oven control
knob counter-clockwise so that the knob is in max. position, approach a match,
taper or another manual aid to the ignition hole that is located on the front left
corner of the burner. Move the ignition source away as soon as you see a stable
flame.
For Grill Burners: To ignite the grill burner, turn the grill valve in the clockwise
position until the marker on the knob points at the grill sign. Then, keep the knob
pressed and approach a match, taper or another manual aid to the holes that are
situated on the burner. Move the ignition source away as soon as you see a stable
flame.
Electrical Ignition
Electrical ignition of gas burners can be done in two ways; depending on the
configuration of your appliance
Ignition by Spark Button: Press the valve of the burner you want to operate
and turn the valve in the counter-clockwise direction so that the knob is in max.
position and with your other hand, press the ignition button at the same time.
Press the ignition button immediately, because if you wait, a build up of gas
may cause the flame to spread. Continue pressing the ignition button until you
see a stable flame on the burner.
Ignition Through Hob Valve (micro switch): Press the valve of the burner
you want to operate and turn the valve in the counter clockwise direction
(clockwise for the grill burner) so that the knob is in max. position while
keeping the knob pressed. The spark plugs will generate sparks as long as you
keep the control knob pressed. The micro switch placed under the knob will
automatically create sparks through the spark plug of the burner. Continue

4. Part : USE OF YOUR OVEN
16
pressing the knob until you see a stable flame on the burner.
Hob Burners (If your hob is equipped with gas safety device)
Hobs equipped with flame failure device provide security in case of accidentally
extinguished flame. If such a case occurs, the device will block the burners gas
channels and will avoid any accumulation of unburned gas. Wait 90 seconds
before re-igniting an extinguished gas burner
Regardless of the model of your appliance, all oven burners are equipped with a
gas safety device. For this reason, during ignition, keep the oven knob pressed
until you see stable flames. If the flames are cut out after you release the knob,
repeat the procedure again. If the oven burner does not ignite after you keep
the burner knob pressed for 30 seconds, open the oven door and do not
attempt re-ignition for at least 90 seconds. When oven flames go out
accidentally, repeat the same procedure
The knob has 3 positions: Off (0), max (big flame symbol) and min (small
flame symbol). After you ignite the burner in max. position; you can adjust the
flame length between max. and min. positions. Do not operate the burners
when the knob position is between max. and off positions.
After the ignition, check the flames visually. If you see yellow tip, lifted or
unstable flames; turn the gas flow off, and check the assembly of burner caps
and crowns. Also, make sure that no liquid has flown into the burner cups. If
the burner flames go out accidentally, turn the burners off, ventilate the kitchen
with fresh air, and do not attempt re-ignition for 90 sec.
When turning the hob off, turn the knob in the clockwise direction so that the
knob shows "0" position or the marker on the knob points upwards.
Your hob has burners of different diameters. The most economic way of using
gas is too choose the correct size gas burners for your cooking pan size and to
bring the flame to minimum position once the boiling point is reached. It is
recommended to always cover your cooking pan.
In order to obtain maximum performance from the main burners, use pots with
the following flat bottom diameters. Using smaller pots than the minimum
dimensions stated below will cause energy loss.
Flame safety device:
.
Oven / Grill Burners
.
4.1.1 Controlof the hob burners

4. Part : USE OF YOUR OVEN
17
.
Rapid Burner: 22-26cm
Medium Burner: 14-22cm
Auxiliary Burner: 12-18cm
Make sure that the tips of the flames do not spread out of the outer
circumference of the pan, as this may also harm the plastic accessories around
the pan (handles etc.)
When the burners are not in use for prolonged periods, always turn the main
gas control valve off..
WARNING:
Use only flat pans and with a sufficiently thick base
• Ensure that the base of the pan is dry before placing it on the burners.
• The temperature of accessible parts may be high when the appliance is
operating. So it is imperative to keep children and animals out of the reach
of the burners during and after cooking.
• After use, the hob remains very hot for a prolonged period of time, do not
touch it and do not place any object on top of the hob.
• Never place knives, forks, spoons and lids on the hob as they will get hot
and could cause serious burns.
4.1.2 Control of the Oven Burner
After you ignite the oven burner as explained before, you can adjust the
temperature inside the oven as you require, using the numbers on the control
panel or knob ring: Bigger numbers mean higher temperatures, while smaller
numbers mean lower temperatures. If your oven is equipped with an oven
thermostat; refer to the temperature table below for the temperature
references of those numbers. Do not operate the appliance between "Off"
position and first temperature marker in the counter-clockwise direction. Always
use the oven between max. and min. numbers on the serigraphy. When turning
the oven off, turn the knob in the clockwise direction so that the knob shows
"0"position.
Figure 12
