Nordmende DOI415IX User manual

User Manual
DOI415IX / DOU415IX
Built-in / Built Under
Electric Oven
Read these instructions carefully before using your oven and
keep it carefully.
If you follow the instructions, your oven will provide you
with many years of good service.
SAVE THESE INSTRUCTIONS CAREFU LLY

CONTENTS & INTRODUCTION
CONTENTS
•SAFETY
•USING THE PRODUCT
•CLEANING
•INSTALLATION INSTRUCTIONS
INTRODUCTION
Thank you for buying this
appliance from us.
Thank you for purchasing our product. We hope that you enjoy using the many features
and benefits it provides. This user manual is designed to help you through each step of
owning your new oven, from installation to use. Please read it carefully before you start
using your product, as we have endeavored to answer as many questions as possible and
provide you with as much support as we can.
Alternatively, general information, spares and service information are available from our
website.
www.nordmende.ie
ww.nordmende.co
Keep this manual in a safe place for future reference. Ensure that other people using the
product are familiar with these instructions as well.
Our policy is one of constant
development and improvement, therefore
we cannot guarantee the strict accuracy
of all of our illustrations and
specifications-changesmayhavebeen
made subsequent to publishing.
2

Safety
BEFORE USING THE PRODUCT
Make sure that you have removed all packaging and wrapping. Some of the items
inside this appliance may have additional wrapping.
GENERAL
WARNING! - The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less than 8 years of age
shall be kept away unless continuously supervised. This appliance can
be used by children aged from 8 years and above and persons with reduced physical
sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning the use of the appliance in a safe way and
understand the hazards involved. Children must not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
NEVER try to extinguish a fire with water, but switch off the appliance and then cover
the flame with a lid or damp cloth.
WARNING! - Danger of fire:Donotstoreitemson the cooking surfaces.
WARNING! - Servicing should only be carried out only by authorised personnel.
•The appliance must never be disconnected from the mains supply during use, as
this will seriously affect the safety and performance of the appliance, particularly
in relation to surface temperatures becoming hot. The cooling fan is designed to
run on after the control knob has been switched off.
•Do not spray aerosols in the vicinity of this appliance while it is in operation.
•Do not store or use flammable liquids or items in the vicinity of this appliance.
•Do not modify this appliance.
CAUTION: Ensure that the kitchen is well ventilated especially when the appliance is
in use: Prolonged intensive use of the appliance may call for additional ventilation, for
example opening of a window, or more effective ventilation, for example increasing
the level of mechanical ventilation where present.
WARNING! - Do not operate the appliance without the glass door correctly closed.
WARNING! - Never put items directly on the base of the oven or cover the oven base
with foil, as this can cause the base element to overheat.
WARNING! - Do not modify the outer panels of this appliance in any way.
WARNING! - This appliance must be earthed.
3

Safety
4
WARNING! - Always allow the product to cool down before you change a bulb. There
is a risk of electric shock, so always make sure you have turned off and unplugged
your appliance before starting.
WARNING! - The top element gets extremely hot when in use, so take extra care to
avoid touching the oven and its parts.
WARNING! - Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass as they can scratch the surface, which may well result in shattering of
the glass.
CAUTION: This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
WARNING! - If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
WARNING! - Do not use steam cleaners to clean this appliance.
WARNING! - The appliance must not be installed behind a decorative door, in order
to avoid overheating.
•Always take care when removing food from the oven as the area around the
cavity may be hot.
•Always use oven gloves when handling any utensils that have been in the oven as
they will be hot.
•Always make sure that the oven shelves are resting in the correct position
between two runners. Do not place the oven shelves on top of the highest
runner, as this is not stable and can lead to spillage or injury.
•Always use the minute minder (if fitted)ifyouareleavingtheoven unattended -
this reduces the risk of food burning.
Do Not
•Never place items on the door while it is open.
•Never wrap foil around the oven shelvesorallowfoiltoblocktheair flue.
•Never drape tea towels near the oven whileitison;thiscancauseafire hazard.
•Never pull heavy items, such as turkeys or large joints of meat, out of the oven
on the shelf, as they may become unbalancedand fall.
OVEN / GRILL
Do

YOUR OVEN
DOU415IX Under Counter Double Oven - Top Oven Grill & Conventional Oven
- Main Cavity Fan Only
DOI415IX Eye Level Double Oven -Top Oven Grill & Conventional Oven
-Main Cavity Multi Function
This user manual is used for an eye level built-in double oven DOI415IX which is
multi-functional and an under counter double oven which is fan only in the main cavity.
5

USING THE GRILL
Caution: Accessible parts may be
hot when the grill is used - young
children should be kept away.
If you intend on cleaning the grill pan
when it is hot, use oven gloves.
Food for grilling should be positioned
centrally on the trivet.
Using the TOP Oven grill
Important: The grill door must be fully
open when the grill is used.
Open the grill door. Turn the control knob
to the required setting. For best cooking
results, we recommend that you preheat
the single grill for 5 minutes.
Push the grill pan towards the back of the
shelf, to position it under the grill.
Turn the temperature knob to the MAX
position or adjust the heat by selecting a
higher or lower shelf position. For
toasting and for grilling foods such as
bacon, sausages or steaks, use a higher
shelf position. For thicker foods such as
chops or chicken joint pieces, use a
middle to low shelf position.
To switch off, turn the control knob to the
off position.
Using aluminium foil
Using aluminium foil to cover the grill pan,
or putting items wrapped in foil under the
grillcreatesarehazard.
The cooling fan
When the grill is switched on, the cool-
ing fan comes on to keep the fascia and
control knobs cool during grilling.
During use the fan may cycle on and off,
this is normal.
Grill
6

USING THE TOP OVEN
When you are cooking keep children
away from the vicinity of the oven.
Caution: The top element gets
extremely hot when in use, so
take extra care to avoid touch-
ing it.
The top oven is a conventional oven.
Note:Thetopovenisnotcontrolled
bytheprogrammer(iffitted).
To turn on the top oven
Turn the temperature control knob until
the required temperature is selected.
The red thermostat indicator will come on
until the selected temperature is reached,
and then go off; it will turn on and off
periodically as the thermostat operates to
maintain the selected temperature.
To switch off, return the top oven control
knob to the off position.
Important: Never put items directly on
the base of the oven, or cover the oven
base with foil, as this may cause the ele-
ment to overheat. Always position items
on the shelf.
The cooling fan
When the top oven is switched on, you
will hear the cooling fan come on - this
keeps the fascia and control knobs of the
appliance cool during cooking.
Preheating
The oven must be preheated when cook-
ing frozen or chilled foods, and we rec-
ommend preheating for yeast mixtures,
batters,soufflés,andwhiskedsponges.
Preheat the oven until the indicator light
switchesoffforthersttime,thiswill
take up to 15 minutes depending on the
temperature selected.
If you are not preheating the oven, the
cooking times in the following guide may
need to be extended, as they are based
on a preheated oven.
Shelf positions
There are 3 shelf positions which are
counted from the bottom of the oven up-
wards, so shelf position 1 is the lowest.
When cooking frozen or chilled food, use
the highest possible shelf position, while
allowing some clearance between the
food and the top element.
The oven shelf must be positioned with
the up-stand at the rear of the oven and
facing up. Position baking trays and roast-
ing tins on the middle of the shelves, and
leave one clear shelf position between
shelves, to allow for circulation of heat.
When using the top oven
Whenopeningtheovendoor,care should
be taken to avoid any possible contact
with potentially hot air, since this may
cause discomfort to people with sensitive
skin. We recommend that you hold the
underneath of the oven door handle.
7

USING THE TOP OVEN
TOP OVEN BAKING GUIDE
Cooking times
These times are based on cooking in a
preheated oven.
These cooking times are approximate,
because the size and type of cooking dish
willinuencetimeaspersonalprefer-
ences.
Shelf positions
As a general guide, when cooking frozen
or chilled food, use the highest pos-
sible shelf position, while allowing some
clearance between the food and the top
element. Follow the instructions given on
packaging.
Item Temperature
(°C)
Shelf
Position
Approximate cooking time
Small cakes
Victoria sandwich
(2x180mm/7”)
Swiss roll
Semi rich fruit cake
(180mmx7”)
Scones
Meringues
160 - 170
160
200
140
215
90 - 100
1
1
1
1
1
20 - 25mins
20 - 25 mins
8 - 12 mins
2¼ - 2¾ hours
10 - 15 mins
2 - 3 hours
Shortcrust pastry
Puff/akypastry
Choux pasrty
200 - 210
200 - 210
200 - 210
1
1
1
Depends on size & type of cook-
ingdish&alsothelling
Biscuits
Sponge pudding
Milk pudding
160 - 200
150
140
2
1
1
10 - 20 mins
30 - 45 mins
2 - 2½ hours
Cooking temperatures
The temperature settings and time given
in the baking guide table below are based
on dishes made with block margarine. If
soft tub margarine is used, it may be
necessary to reduce the temperature
setting. If a recipe gives a different
temperature set-ting to that shown in the
guide, the recipe instruction should be
followed.
Because the top oven is more compact, it
may be necessary to reduce cooking
temperaturesspecifiedinrecipesbyupto
20°C.
Use the baking guide as a reference for
determining which temperatures to use.
2
8
TOP OVEN BAKING GUIDE TABLE

USING THE MAIN OVEN
Accessible parts may be
hot when the oven is used.
Young children should be
kept away.
To switch on the oven
Turntheovencontrolknob(s)tothe
required setting.
Theredthermostatindicator(iftted)will
come on until the selected temperature
is reached and then go off; it will turn
on and off periodically as the thermostat
operates to maintain the selected tem-
perature.
To switch off, return the control knob to
the off position.
When using the oven
As part of the cooking process, hot air
is expelled through a vent in the oven.
When opening the oven door, care should
be taken to avoid any possible contact
with potentially hot air, since this may
cause discomfort to people with sensitive
skin. We recommend that you hold the
underneath of the oven door handle.
PREHEATING
Fan oven
When cooking sensitive items such as
souffléandYorkshirepuddingsor,when
cooking bread, we recommend that the
oven is preheated until the light switches
offforthefirsttime.Foranyothertypes
of cooking preheating may not be
required.
Conventional oven
Preheating is always required
Manual Operation (fan only)
The cooling fan
The cooling fan may operate when the
main oven is on and may continue to op-
erate for a period after the oven has been
switched off.
OVEN FURNITURE
Oven shelves
The oven shelf must be positioned with
the upstand at the rear of the oven and
facing upwards.
Position baking trays and roasting tins on
the middle of the shelves.
Baking tray and roasting tins
For best cooked results and even brown-
ing, the recommended size baking trays
and roasting tins that should be used are
as follows;
Baking tray 473mm x 370mm
We recommend that you use good quality
cookware. Poor quality trays and tins may
warp when heated, leading to uneven
baking results.
10

USING THE MAIN OVEN
Aluminum foil
Use foil only to cover food or cooking
dishes, using foil to cover the shelves or
ovenbasecreatesafirehazard.
Cooking with a fan oven
As this is a high efciency oven,
you may notice the emission of
steam from the oven when the door
is opened. Please take care when
opening the door.
If you are used to cooking with a conven-
tionalovenyouwillndanumberofdif
ferences to cooking with a fan oven which
willrequireadifferentapproach:
There are no zones of heat in a fan oven
as the convection fan at the back of
the oven ensures an even temperature
throughout the oven.
This makes it ideal for batch baking - eg;
when planning a party as all the items will
be cooked within the same length of time.
Foods are cooked at a lower temperature
than a conventional oven, so conven-
tional recipe temperature may have to be
reduced. Please refer to the conversion
chart.
Preheating is generally not necessary as a
fan oven warms up quickly.
When batch baking foods that will rise
during cooking - eg; bread - always
ensure that enough space has been left
between the shelves to allow for the rise.
Notes:
When 2 or more shelves are being used, it
may be necessary to increase the cooking
time slightly.
Because the 2 oven shelves are wider
than in many ovens, it is possible to cook
2 items per shelf - eg; 2 victoria sand-
wiches or 2 casseroles.
Although you need to keep in mind the
points ‘To help the air circulate freely’
with careful choice of dishes and tins, it
is possible to cook a complete meal, and
perhaps something else for the freezer, in
the oven at the same time.
When roasting meats, you will notice that
fat splashing is reduced, which is due in
part to the lower oven temperatures, and
will help keep cleaning of the oven to a
minimum.
Because a fan oven has an even tem-
perature throughout the oven, there is no
need to follow the shelf positions given in
the baking guide.
11

USING THE MAIN OVEN
There is no need to interchange dishes
onto different shelves part way through
cooking, as with a conventional oven.
To help the air circulate freely
Position the shelves evenly within the
oven and maintain a clearance from the
oven roof and base.
If more than one cooking dish or bak-
ing tray is to be used on a shelf, leave a
gap of at least 25mm between the items
themselves and the oven interior.
Defrosting and cooling in the
main oven
To defrost frozen foods, turn the main
oven control to the defrost position, place
the food in the centre of the oven and
close the door.
To cool foods after cooking prior to refrig-
erating or freezing, turn the main oven
control to the defrost position and open
the door.
Defrosting times
Smallorthinpiecesoffrozenshormeat
- eg;shlets,prawns&mincewilltake
approximately 1 - 2 hours.
Placing the food in a single layer will
reduce the thawing time.
A medium sized casserole or stew will
take approximately 3 - 4 hours.
A 1½kg/3lb oven ready chicken will take
approximately 5 hours, remove the giblets
as soon as possible.
Be safe
Do not defrost stuffed poultry using this
method.
Do not defrost larger joints of meat and
poultry over 2kg/4lb using this method.
Never place uncooked food for defrosting
next to cooked food which is to be cooled,
as this can lead to cross contamination.
Defrostingmeat,poultry,andshcanbe
accelerated using this method but make
sure they are completely thawed before
cooking thoroughly. Place meat and poul-
try on a trivet in a meat tin.
MAIN OVEN BAKING GUIDE
Cooking times & temperatures
The temperature settings and times given
in the baking guide are based on dishes
made with block margarine. If soft tub
margarine is used it may be necessary to
reduce the temperature setting.
Allow enough space between shelves for
food that will rise during cooking.
Do not place items on the oven base as
this will prevent air circulating freely.
12

USING THE MAIN OVEN
Note:Thisisahighefficiencyoven,
therefore some adjustment will have to
be made to conventional cooking
temperatures. The table below shows
conventionalcookingtemperature versus,
‘A’efficiencytemperatures. For optimum
results conventional temperatures
need to be convertedto‘A’efficiency
temperatures.
For example, an item which would
normally be cook at a conventional
temperature of 180°C, should be cooked
at the ‘A’ efficiencytemperatureof160°C.
Conventional temperature
(°C)
‘A’ Efciency Oven
(°C)
100
110
130
140
150
160
180-190
200
220
230
250
100
110
120
130
140
150
160
170
180
190
200
Food Type Temperature
settings (°C)
Time
Approx.
Shelf
Position
Cakes
Small cakes
Victoria sandwich
Semi rich fruit cake
Christmas cake
Conv
170
180
150
150
Fan
160
160
125
125
15 - 25
20 - 30
2.5HRS - 3HRS
2.5HRS - 3HRS
3
3
2
2
Puddings
Bread and butter pud-
ding
Fruit crumble
170
200
150
175
45 - 1hr
40 - 1hr
3
3
Miscellaneous
Yorkshirepudding:
Large
Small
Shortcrust pastry
220
220
200
200
200
180
40 - 48
15 - 20
Depends on
the filling
4 - 5
4 - 5
4 - 5
13

USING THE MAIN OVEN
Traditional fruit cakes
It should be remembered that ovens can
vary over time, therefore cooking times
canvary,makingitdifculttobeprecise
when baking fruit cakes.
It is necessary therefore, to test the cake
beforeremovalfromtheoven.Useane
warmed skewer inserted into the centre of
the cake. If the skewer comes out clean,
then the cake is cooked.
•Follow the temperatures suggested
in the recipe and then adjust accord-
ingly to the conversion table.
•Do not attempt to make Christmas
cakes larger than the oven can cope
with, you should allow at least 25mm
(1”)spacebetweentheovenwalls
and the tin.
•Always follow the temperatures rec-
ommended in the recipe.
•To protect a very rich fruit cake dur-
ing cooking, tie 2 layers of brown
paper around the tin.
•We recommend that the cake tin is
not stood on layers of brown paper,
as this can hinder effective circulation
of air.
•Do not use soft tub margarine for
richfruitcakes,unlessspeciedin
the recipe.
•Always use the correct size and
shape of tin for the recipe quantities.
Roast turkey
Roasting turkey involves cooking two
different types of meat - the delicate light
breast meat, which must not be allowed
to dry out, and the darker leg meat,
which takes longer to cook.
The turkey must be roasted long enough
for the legs to cook, so frequent bast-
ing is necessary. The breast meat can be
covered once browned.
•Always make sure that the turkey is
completely thawed and that the gib-
lets are removed before cooking.
•Turkeysshould be roasted at 160°C
- 180°C(fan)or180°C-200°C
(conventional)for20minutesper
450g(1lb),plus20minutes,unless
packaging advises otherwise.
•The turkey can be open roasted,
breast side down, for half of the
cooking time, and then turned over
for the remainder of the cooking time.
•If the turkey is stuffed, add 5 minutes
per450g(1lb)tothecookingtime.
•If roasting turkey covered with foil,
add5minutesper450g(1lb)tothe
cooking time.
To test if the turkey is cooked, push a
neskewerintothethickestpartofthe
thigh. If the juices run clear, the turkey
is cooked. If the juices are still pink, the
turkey will need longer cooking.
14

USING THE MAIN OVEN
Roasting guide
The times given in the roasting guide
are only approximate, because the size
andageofthebirdwillinuencecooking
times as will the shape of a joint and the
proportion of the bone.
Frozen meat should be thoroughly thawed
before cooking. For large joints it is advis-
able to thaw over night.
Frozen poultry should be thoroughly
thawed before cooking. The time required
depends on the size of the bird - eg; a
large turkey may take up to 48 hours to
thaw.
Use of a trivet with a roasting tin will
reduce fat splashing and will help to keep
the oven interior clean. Alternatively, to
help reduce fat splashing, potatoes or
other vegetables can be roasted around
the meat/poultry.
Notes:
•When cooking stuffed meat or poultry
calculate the cooking time from the
total weight of the meat plus the
stuffing.
•For joints cooked in foil or covered
roasters and for lidded casseroles,
add5minutesper450g(1lb)tothe
calculated cooking time.
•Smaller joints weighing less than
1.25kg(2½lb)mayrequire5minutes
per450g(1lb)extracookingtime.
•Position the oven shelf so that the
meat or poultry is in the centre of the
oven.
•It is recommended that the appliance
is cleaned after open roasting.
Cook in main oven at:
160°C - 180°C (fan)
180°C - 200°C (conventional)
Approximate Cooking Time
(preheated oven)
Beef Rare
Medium
Well done
20minutesper450g(1lb),plus20minutes
25minutesper450g(1lb),plus25minutes
30minutesper450g(1lb),plus30minutes
Lamb Medium
Well Done
25minutesper450g(1lb),plus25minutes
30minutesper450g(1lb),plus30minutes
Pork 35minutesper450g(1lb),plus35minutes
Poultry 20minutesper450g(1lb),plus20minutes
15

using the OVen/gRiLL - muLti-functiOn
Oven & Grill Functions
The chart below details all of the functions which are available in the DOI415IX
multi-functional oven. This is not applicable to the DOU415IX under counter fan
only oven.
Symbol Function /
Feature
Recommended Uses
This function cooks food from the top and is ideal for a
range of food from toast to steaks. As the whole grill
is workingand you can cook large quantities of food.
Fan Grill
The fan allows heat to circulate around the food. Ideal
for thinner foodssuchasbacon,shandgammon
steaks. Foods do not require turning. Use with the oven
door closed
Conventional Grill
This function is ideal for traditional roasting. The meat is
placed in the middle of the oven, roast potatoes towards
the top.
 
bake only
The base heat can be used to provide additional brown-
ing for pizzas, pies and quiche. Use this function towards
the end of cooking.
Fanned Oven The even temperature in the oven makes this function
suitable for batch baking, or batch cooking foods.
Intensive Bake Suitable for food with a high moisture content, such as
quiche, bread and cheese cake. It also eliminates the
need for baking pastry blind.
Defrosting and Cool-
ing
To defrost foods, such as cream cakes/gateaux, use
with the oven door closed. For cooling dishes prior to
refrigeration, leave the door open.
Oven Temperature
Control Use to select the oven temperature.
Lights Only Use when the oven is switched off and cold to aid
cleaning the oven.
Grill, large area

For grilling steaks, sausages, toastand pieces of fish. The
wholearea below the grill heating element becomes hot.
16
Grill, small area

(i) Turnthecontrolknobto the small
area grill setting.
(ii)Turntheoventemperaturecontrol
knob to the full on setting.
Fan grill
The door must be closed when the
fan grill is used.
When opening the door, take care to
avoid skin coming into contact with
any steam which may escape from
the cooking.
(i) Turnthecontrolknobto the fan grill
setting.
(ii)Turntheoventemperaturecontrol
knob to the desired temperature setting.
When the fan grill is selected, only the
inner element will come on.
USING THE OVEN/GRILL - MULTI-FUNCTION
Grill, large area
The door must be closed when the large
area grill is used.
When opening the door, take care to
avoid skin coming into contact with any
steam which may escape from the
cooking.
When the large area grill is selected, only
the inner element will come on.
Caution: Accessible parts may
be hot when the oven is
used, young children should be
kept away.
The main oven is a multi-function oven,
and may be used as a conventional oven
or a fan oven. It may also be used as a
grill, or with one of the other oven
functions.
Manual operation
The programmer must be set to manual
operation before the main oven or grill
functionscanbeused.
To turn on the main oven
Step 1 - Select the function
Turn the selector control knob in either
direction, until the function you require
appears in the window.
Step 2 - Set the main oven control
Once you have selected a cooking
function, then simply turn the main oven
temperature control knob to the required
temperature - this brings on the thermo-
stat indicator light, which will stay on until
the oven reaches the required
temperature. To switch off the main oven,
return the control knob to the off position.
17
GRILLING IN THE MAIN OVEN
The main oven grill & fan grill are a fixed
settingsusingtheinnerelementonly.
Make sure that the programmer is set to
manual before grilling. When using either
grill function, invert the grill pan trivet
and preheat for 5minutes.
Grill, small area
The door must be closed when the grill is
used. It is suitable for grilling over a small
area.
Grill, large area
The door must be closed when the large
area grill is used.
When opening the door, take care to
avoid skin coming into contact with any
steam which may escape from the
cooking.
(i) Turnthecontrolknob to the grill,
large area setting.
(ii)Turntheoventemperaturecontrol
knob to the desired temperature setting.

preheating is not necessary as a fan oven
warms up quickly. Preheat the oven until
the indicator light switches off for the
firsttime;thiswilltakebetween5-15
minutes, depending on the temperature
selected.
To help the air circulate freely
•Position the shelves evenly within the
oven and maintain a clearance from
the oven roof and base.
•If more than one cooking dish or
baking tray is to be used on a shelf,
leave a gap of at least 25mm
between the items themselves and
the oven interior.
•Allow enough space between shelves
for food that will rise during cooking.
•Do not place items on the oven base
as this will prevent air from
circulating freely.
Main oven functions
Conventional oven
(i) Turnthecontrolknobtothe
conventional oven symbol.
(ii)Turnthemainovencontrolknobto
the required temperature.
The temperature you select corresponds
to the temperature in the middle of the
oven. The top heat comes from the outer
element of the grill, and the base heat is
under the oven base.
Base heat only
(i) Turntheselectorcontrolknobtothe
base heat symbol.
(ii)Turnthemainovencontrolknobto
the required temperature.
USING THE OVEN/GRILL - MULTI-FUNCTION
Automatic operation
See ‘Programmer / Clock’ section.
Using the main oven
Caution: Accessible parts may
be hot when the appliance is in
use - keep children away from
the vicinity of the oven.
Never put items directly on the base of the
oven or cover the oven base with foil, as
this can cause the base element to
overheat.
Manual operation
Set the programmer to manual operation.
See ‘Programmer / Clock’ section. Turn the
control knob to the symbol for the desired
oven function. Turn the main oven
temperature control knob to the desired
temperature. The red thermo-stat
indicator light will come on and will stay
until the selected temperature is reached
and then go off; it will turn on and off
periodically as the thermostat operates to
maintain the selected temperature.
To switch off the main oven, return the
main oven control knob to the off position.
Automatic operation
See ‘Programmer / Clock section.
Preheating
Always use the fan oven setting for
preheating to save time and electricity.
After the oven has been preheated on the
fan oven setting, turn the control knob to
the oven setting you require. The oven
must be preheated when cooking frozen
or chilled food, and we recommend
preheating for yeast mixtures, batters,
soufflésandwhiskedsponges,otherwise
18

Fan oven
(i) Turnthecontrolknobtothe fan
oven symbol.
(ii)Turnthemainovencontrolknobto
the required temperature.
When the fan oven function is selected it
circulates the hot air around the oven to
give a fairly even temperature throughout
the oven.
Intensive bake
(i) Turnthecontrolknob tothe
intensive bake symbol.
(ii)Turnthemainovencontrolknob
tothe required temperature.
Defrosting and cooling
(i) Turntheselectorcontrolknobto
defrost symbol.
(ii)Turnthemain ovencontroltothe
light symbol.
To defrost frozen foods, place food in the
centre of the oven and close
the door.
To cool foods after cooking prior to
refrigeration or freezing, place food in the
centre of the oven with the door open.
Be safe
•Do not defrost stuffed poultry using
this method.
•Do not defrost larger joints of meat
or poultry over 2kg / 4lb using this
method.
•Never place uncooked food which is
to be defrosted next to cooked food
which is to be cooled, as this can lead
to cross contamination.
Please refer to the cooking guide for
more information on using the defrost
function.
USING THE OVEN/GRILL - MULTI-FUNCTION
19

UsInG tHe clock/pRoGRaMMeR
After powering on this oven, ‘0:00’ and
the clock icon will flash on the screen,
press any button to quit.
Button Functions -
Button 1: Clock, Alarm, Duration,
2) If there is no operation for 2 minutes
the buzzing will stop. The alarm function
is for warning purposes only, it is up to
the user to turn off the oven.
Duration setting
1) Press , choose "duration"
function and the icon will begin to flash
and “0:00” will display. Press the "+"
and "-" button to set the duration time,
adjusting range is between “0:01-23:59”.
After waiting for 5 seconds to confirm
setting, the duration time will be set
but the time shown on the screen will
be back to the time of day. The
duration time will be counting down
internally and when finishing the count
down, the power will turn off directly
and the “Duration” icon will flash to
get your attention. Also, “0:00” will be
shown on the screen and it will start
buzzing 2 times every 5 seconds. Press
any button to stop.
2) During the cooking duration, by
pressing you can check and change
the the cooking duration.
20
Duration, End Time
Button 2: (-) Minus
Button 3: (+) Plus
Button 4: Lock
Set alarm
1) Press and the alarm icon will begin
to flash which means the alarm function
has been chosen “0:00” will display. Press
the "+" and "-" button to set alarm time.
The time can be adjusted between
“0:01~23:59”. Press once on plus or minus
1, and hold for 3 seconds for quick-adjust.
After waiting for 5 seconds to confirm
setting, the alarm icon will be displayed and
the alarm time will be shown on the screen.
You will then see the time counting down on
the screen. When the countdown is finished,
“0:00” will be shown on the screen and it
will start buzzing 4 times every 5 seconds.
Press any button to stop.
End time
Clock
Alarm
D uration
Lock
Function Minus Plus Lock
