Nordson EcoDry Series Reference guide

Nordson EcoDryrSeries
Induction Dryers with
Touch Screen Controls
Customer Product Manual
Part 1601306−02
Issued 3/14
NORDSON CORPORATION •AMHERST, OHIO •USA
For parts and technical support, call the Industrial Coating
Systems Customer Support Center at [phone] or
contact your local Nordson representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com for the latest version.

Part 1601306−02 E2014 Nordson Corporation
tents tents
Table of Contents
Safety 1.......................................
Qualified Personnel 1.........................
Intended Use 1...............................
Regulations and Approvals 2...................
Personal Safety 2............................
Fire Safety 3.................................
Action in the Event of a Malfunction 3...........
Disposal 3...................................
Description 4..................................
Dryer Components 5.........................
Theory of Operation 6.........................
Specifications 8..............................
Manufacturing Date Code 8.................
Operating Parameters 8....................
Power Supply Requirements 8...............
System Weight (Crated) 8...................
Operating Sound Levels 8..................
Installation 9..................................
Inspection 9.................................
Lift Points 9.................................
System Positioning and Mounting 10............
Flow Direction 10...........................
Clearances 10.............................
Mounting and Line Connections 10...........
Coil and Tube Installation 12....................
System Wiring 14..............................
Schematics and Wiring Diagrams 14..........
Power Input 14.............................
Customer Interlock 16.........................
Optional Status Contact 17.....................
Motion Sensor 17..............................
Rear Access Panel 18.........................
Magnetic Separator (Optional) 18...............
Exhaust Ducting (Optional, Customer−Supplied) 18
Return Shipping Instructions 18.................
Domestic/USA 18..........................
Export 18.................................
Setup 19.......................................
Preparation 19................................
Motion Sensor Sensitivity Adjustment 20.........
Operator Interface 21..........................
Navigation Screen 22........................
Ramp Mode Power Level Adjustment 23.......
Ramp Timer Setting 24......................
Motion Timer Setting 25.....................
Motion Detect Sensitivity Setting 26...........
External Interlock Timer Setting (Optional) 27..
Temperature Setup 28......................
Offset / Limits Setup 29.....................
PID Settings 30...............................
Configuration Screen 31........................
Fault Page Screen 32..........................
PLC I/O Screen 33............................
Manual Mode Screen 34........................
Operation 35...................................
Dryer Controls 35.............................
Startup 36....................................
Shutdown 36..................................
Maintenance 37................................
Monthly 37...................................
Quarterly 37..................................
Troubleshooting 38.............................
Repair 40......................................
Coil and Coil Tube Replacement 40.............
Thermocouple Replacement 42.................
Air Filter Replacement 42......................
Spare Parts 43..................................
Service and Parts Ordering Information 43........
Field Service Call Procedure 43.................
Parts Ordering Information 43..................
Temperature Conversions 44....................
Celsius−Fahrenheit Temperature Table 44........
Conversion Equations 44.......................
NOTE: Insert application-specific data that was shipped
with the system in the tabbed sections of this manual.
Contact Us
Nordson Corporation welcomes requests for information, comments, and
inquiries about its products. General information about Nordson can be
found on the Internet using the following address:
http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
555 Jackson Street
Amherst, OH 44001
Notice
This is a Nordson Corporation publication which is protected by copyright.
Original copyright date 2012. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Nordson Corporation. The information contained
in this publication is subject to change without notice.
Trademarks
Nordson and the Nordson logo are registered trademarks
of Nordson Corporation.
All other trademarks are the property of their respective owners.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 1
Part 1601306−02
E2014 Nordson Corporation
Nordson EcoDryrSeries Induction Dryers
with Touch Screen Controls
Safety
Read and follow these safety instructions. Task- and equipment-specific
warnings, cautions, and instructions are included in equipment
documentation where appropriate.
Make sure all equipment documentation, including these instructions, is
accessible to persons operating or servicing equipment.
Qualified Personnel
Equipment owners are responsible for making sure that Nordson equipment
is installed, operated, and serviced by qualified personnel.
WARNING: The control enclosure and coil tray contain high voltages and
high power levels that can be fatal. Allow only qualified personnel to access
these enclosures.
Qualified personnel are those employees or contractors that
Shave experience operating and maintaining high-power and high-voltage
electrical equipment.
Scan safely perform their assigned tasks.
Sare familiar with all relevant safety rules and regulations and are
physically capable of performing their assigned tasks.
Intended Use
Use of Nordson equipment in ways other than those described in the
documentation supplied with the equipment may result in injury to persons
or damage to property.
Some examples of unintended use of equipment include
Susing incompatible materials and atmospheres
Smaking unauthorized modifications
Sremoving or bypassing safety guards or interlocks
Susing incompatible or damaged parts
Susing unapproved auxiliary equipment
Soperating equipment in excess of maximum ratings

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
2
Part 1601306−02 E2014 Nordson Corporation
Regulations and Approvals
Make sure all equipment is rated and approved for the environment in which
it is used. Any approvals obtained for Nordson equipment will be voided if
instructions for installation, operation, and service are not followed.
Refer to the CE Declaration of Conformity for approvals standards.
WARNING: Never disarm diagnostic devices including but not limited to:
SCurrent sensor
SOvertemperature switches
SAir pressure switch
SCoil tray lid safety switches
Disarming diagnostic devices will void the warranty and may cause
equipment failure.
Personal Safety
To prevent injury follow these instructions:
SDo not operate or service equipment unless you are qualified.
SDo not operate equipment unless safety guards, doors, or covers are
intact and automatic interlocks are operating properly. Do not bypass or
disarm any safety devices.
SMake sure that the ventilation system is operating properly to prevent
dangerous concentrations of volatile particles or vapors.
SKeep clear of moving equipment. Before adjusting or servicing moving
equipment, shut off the power supply and wait until the equipment
comes to a complete stop. Lock out power and secure the equipment to
prevent unexpected movement.
SDisconnect, lock out, and tag switches before servicing electrical
equipment.
SKeep parts of your body and metal implements away from the induction
heating zone while the system is energized. Metal objects will heat up
very quickly. Remove all jewelry, watches, and rings.
SObtain and read Material Safety Data Sheets (MSDS) for all materials
used. Follow the manufacturer’s instructions for safe handling and use
of materials, and use recommended personal protection devices.
STo prevent injury, be aware of less-obvious dangers in the workplace
that often cannot be completely eliminated, such as hot surfaces, sharp
edges, energized electrical circuits, and moving parts that cannot be
enclosed or otherwise guarded for practical reasons.
SHearing protection is recommended.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 3
Part 1601306−02
E2014 Nordson Corporation
Fire Safety
To avoid a fire or explosion, follow these instructions:
SAll equipment must be grounded and bonded to the building ground.
SDo not heat materials to temperatures above those recommended.
Make sure heat monitoring and limiting devices are working properly.
SProvide adequate ventilation to prevent dangerous concentrations of
volatile particles or vapors. Refer to local codes or your material MSDS
for guidance.
SDo not disconnect live electrical circuits while working with flammable
materials. Shut off power at a disconnect switch first to prevent
sparking.
SKnow where emergency stop buttons, shutoff valves, and fire
extinguishers are located.
SClean, maintain, test, and repair equipment according to the instructions
in your equipment documentation.
SUse only replacement parts that are designed for use with original
equipment. Contact your Nordson representative for parts information
and advice.
Action in the Event of a Malfunction
If a system or any equipment in a system malfunctions, shut off the system
immediately and perform the following steps:
SDisconnect and lock out system electrical power.
SIdentify the reason for the malfunction and correct it before restarting the
system.
Disposal
Dispose of equipment and materials used in operation and servicing in
accordance with applicable laws, regulations, or codes.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
4
Part 1601306−02 E2014 Nordson Corporation
Description
The Nordson EcoDry Series Induction Dryers provide simple, efficient, and
uniform drying of water-based end-sealing compounds applied to can ends.
The dryers use solid-state induction heating to generate heat within the can
ends to dry the sealing compound, at line speeds of up to 500 ends a
minute. The dryers can be designed for can end diameters from 57 to
170 mm.
The dryers are available with single or dual channels and can be configured
to mate to almost any line height. Each dryer is designed to handle a
particular can end size and material, according to the customer’s
specifications.
Figure 1 Typical EcoDry Series Induction Dryer
EcoDry Features
Instant On/Off When the line starts, heating within the can ends instantly starts. Since heat is
created directly within the ends, there is no thermal inertia. When the line
stops, heating instantly stops. This produces a very uniform product.
No Jams The short length of the dryer and straight-through design minimizes jams.
Energy Savings Solid state induction heating is extremely efficient. Greater than 80% of the
power consumed is directly realized as heat in the can ends. When the line
stops, almost no power is consumed.
Reliability The solid-state design of the dryers minimizes downtime. There are few
moving parts to wear out.
Small Footprint Because induction drying is so fast, the dryer is much smaller than
conventional ovens.
Temperature Control The dryer continuously monitors the temperature of the can ends as they exit
the dryer and adjusts coil power to maintain the desired setpoint temperature,
providing uniform control of product quality.
Magnetic Separator An optional magnetic separator can be installed at the dryer exit.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 5
Part 1601306−02
E2014 Nordson Corporation
Dryer Components
See Figure 2.
Item Description
1Coil Tray—Contains the induction coil, glass tube, heater blower, and exhaust blower. The
can ends travel through the glass tube and are heated by the induction coil. The heater heats
the dryer cooling air and blows it through the tube to help carry off the moisture vaporizing out
of the sealing compound. The exhaust blower draws the heated air and moisture out of the
tube. The coil tray attaches to the customer infeed and outfeed system.
2Motion Sensor—A laser sensor that monitors the movement of can ends at the entrance to
the dryer. The controller will only apply power to the induction coil when the motion sensor
detects can ends moving through the dryer.
3Operator Control Console—Contains the system On/Off/E-Stop controls and touchscreen
operator interface.
4Control Enclosure—Contains the system controller (PLC), cooling air filters and fan, and
power inverter devices and circuit boards.
5Temperature Sensor—Low-mass type K thermocouple. As the can ends exit the coil tray they
pass by the temperature sensor, which sends the can end temperature to the temperature
controller. The power applied to the induction coil is regulated to produce the desired can end
exit temperature.
1
2
CH AL
3
4
5
67
EcoDry
Figure 2 Typical EcoDry Series Induction Dryer Shown with Optional Magnetic Separator
1. Coil tray
2. Motion sensor
3. Operator panel
4. Control enclosure
5. Thermocouple
6. Magnetic separator (optional)
7. Coil and coil tube

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
6
Part 1601306−02 E2014 Nordson Corporation
Theory of Operation
See Figures 3 and 4.
The can ends move through a glass tube inside the coil tray. The tube is
surrounded by the induction coil. As can ends enter the dryer, the motion
sensor at the entrance signals the controller. The controller causes the
power inverter to apply alternating current to the coil windings. The coil
windings generate an alternating magnetic field that creates large eddy
currents in the can ends. The resistance to the eddy currents generates
heat within the can ends and dries the sealing compound. If the can end
line stops, the motion sensor signals the controller, which shuts off power to
the coil windings.
The temperature sensor (thermocouple) at the exit senses the can end
temperature and signals the temperature controller, which adjusts the power
going to the coil windings to maintain the temperature at the setpoint. The
controller uses a PID (Proportional-Integral-Derivative) loop that
automatically adjusts the amount of power supplied to the coil to eliminate
temperature variations due to line voltage fluctuations, applied compound
weight, and can end start temperature.
A blower in the controller/power inverter enclosure pulls in room air and
directs it over the electrical components to cool them. The air then flows
into the coil tray and over the coil to cool it. An air heater mounted on the
tube hub at the entrance end of the coil tray interior then heats the air as it
enters the coil tube to carry off moisture vaporizing out of the sealing
compound. An exhaust blower mounted in the tube exit hub draws the air
out of the tube and exhausts it out into the room. If an optional magnetic
separator is installed at the tube exit, heated air is also ducted directly into
the separator.
Safety interlocks include door interlock switches, thermocouples, and a
pressure switch. A customer interlock is also provided. Interlock status is
indicated on the operator control panel.
WARNING: Never disarm diagnostic devices including but not limited to:
SCurrent sensor
SOvertemperature switches
SAir pressure switch
SCoil tray lid safety switches
Disarming diagnostic devices will void the warranty and may cause
equipment failure.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 7
Part 1601306−02
E2014 Nordson Corporation
Coil Tray
CH AL
Controller and Power
Inverter Enclosure
Coil and Tube
Assembly
Motion
Sensor
Thermocouple
Feed Direction
Entrance
Exit EcoDry
Figure 3 Theory of Operation
Coil Windings
Can Ends
Eddy Current
Coil Current
Figure 4 Coil Operation

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
8
Part 1601306−02 E2014 Nordson Corporation
Specifications
Manufacturing Date Code
Serial Number: BK X X X X −X X X
year month
Operating Parameters
Ambient Temperature Range: -5 to 35 _C (40−95 _F).
Humidity: 0−70% for full system functionality
Elevation (Altitude): Less than 1524 meters (5000 ft)
Above 5000 ft system must be de-rated.
Contact your Nordson representative.
Power Supply Requirements
380−480 Vac, 3 phase, 50/60 Hz at 30 amperes
Class J fusing required.
System Weight (Crated)
340 kg (750 lbs) to 500 kg (1100 lbs)
Operating Sound Levels
39.40” [1.00M]
39.40” [1.00M]
39.40” [1.00M]
74 DB
74 DB 72 DB
74 DB
39.40” [1.00M]
TOP VIEW
Measurements taken 1.6 m (5 ft-4 in.) from floor
Figure 5 Operating Sound Levels

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 9
Part 1601306−02
E2014 Nordson Corporation
Installation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
Inspection
The EcoDry system is shipped fully assembled, except for the glass coil
tube and coil, which are packed separately to prevent breakage. Unpack
and carefully inspect the dryer, coil tube, and coil for obvious shipping
damage and shortages. If you see any damage or shortages, notify the
shipper and your Nordson representative immediately.
NOTE: A 5/16-inch hex wrench is required to unlock and lock the coil tray lid
and control enclosure doors.
Lift Points
ECODRYt
INDUCTION TECHNOLOGY
Lift Point Lift Point
Lift points with or without Magnetic Separator
Maximum Weight (Uncrated) 325 Kg (715 lbs)
EcoDry
Figure 6 Lift Points for EcoDry Series Induction Dryer (Shown with Optional Magnetic Separator)

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
10
Part 1601306−02 E2014 Nordson Corporation
System Positioning and Mounting
See Figure 6 for lift points and uncrated weight.
Flow Direction
The dryer must be positioned so that can ends pass through it in the correct
direction. When moving the dryer into position in the production line, note
the position of the motion sensor head. This is the dryer entrance. A flow
direction arrow is also located inside the coil tray.
NOTE: Optional magnetic separators are always installed at the exit end of
the dryer.
Clearances
Provide clearances around dryer as follows:
SMake sure blower intake (filters), and vents are not obstructed.
SProvide enough space in the rear of the dryer to remove the access
panel for power and interlock connections and repairs.
SProvide enough space in front of the dryer to open the enclosure doors.
Mounting and Line Connections
The dryer legs are made at the factory to the height listed in the purchase
order. Level the dryer and bolt it to the floor.
See Figure 7. Six evenly spaced 1/4−20 NCB threaded holes are provided
in the dryer exit and entrance hubs. Secure your can end rod cages or
trays to the entrance and exit hubs as required.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 11
Part 1601306−02
E2014 Nordson Corporation
105 mm (4.13 in.)
to 175 mm (6.89 in.)
End Sizes
100 mm (3.94 in.)
End Sizes
Up to 83 mm (3.26 in.)
End Sizes
1/4−20 NCB
Threaded Insert
(6) holes eq. sp.
on 9.00 B.C.
1/4−20 NCB
Threaded Insert
(6) holes eq. sp.
on 6.50 B.C.
1/4−20 NCB
Threaded Insert
(6) holes eq. sp.
on 5.50 B.C.
60_
60_
60_
Figure 7 Entrance and Exit Hub Mounting Hole Pattern

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
12
Part 1601306−02 E2014 Nordson Corporation
Coil and Tube Installation
See Figure 8. Install the coil and glass tube as follows:
1. Remove the screws securing the rear access panel with a hex wrench.
2. Remove the screws (1) securing the air heater and exhaust vent to the
entrance and exit hubs. Move the air heater and exhaust vent away
from the hubs.
3. Remove the slotted nylon screws (2) from the entrance and exit hubs.
4. Unpack the coil and tube. Carefully insert the glass tube (3) through
the coil (4).
5. Carefully install the coil and tube assembly in the coil tray, positioning
the ends of the tube into the hubs. It does not matter which end of
the coil is at the entrance or exit unless the coil is marked with the
flow direction.
6. Re-install the two nylon slotted screws into the entrance and exit hubs.
7. Route the coil wires through the hole that has a grommet and is located
in the bottom of the coil tray.
8. Re-install the heater blower and exhaust vent on the entrance and
exit hubs.
9. Connect the coil wiring to the bus bar terminals (5) (no polarity).

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 13
Part 1601306−02
E2014 Nordson Corporation
Coil and Tube Installation (contd)
1
2
3
4
5
Figure 8 Coil and Tube Installation
1. Screws (4 on each hub)
2. Nylon slotted screws (1 on each hub)
3. Glass tube
4. Coil
5. Bus bar terminals

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
14
Part 1601306−02 E2014 Nordson Corporation
System Wiring
Schematics and Wiring Diagrams
System wiring is application-specific. Refer to the schematics and wiring
diagrams that shipped with the system.
Power Input
See Figure 9 for connections. Service requirement is 380−480 Vac, 3
phase, 50/60 Hz at 30 amperes. Class J fusing required.
WARNING: If plant supply is not through current limiting Class I 30 amp
fusing, customer is required to follow arc flash hazard criteria and label
appropriately.
WARNING: Install a locking breaker or disconnect in the electrical supply
line ahead of the dryer so that power to the dryer can be disconnected and
locked out when making repairs. All electrical connections must be made
according to code, including a proper ground connection. Failure to
observe this warning could result in severe personal injury or death from
electrical shock.
Line power is supplied to the system through a 3/4-in. (1.9-cm) conduit fitting
in the lower left-hand corner of the exit end of the dryer.
1. Route three 10 AWG (5.3 mm2) wires to the L1, L2, and L3 terminals on
the input side of the line filter.
2. Route one 10 AWG (5.3 mm2) ground wire to the cabinet grounding
terminal (PE).
WARNING: DANGER! Line filter terminals remain live when dryer main
disconnect is in the Off position.

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 15
Part 1601306−02
E2014 Nordson Corporation
L3
L2
L1
GND
Figure 9 Power Connections

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
16
Part 1601306−02 E2014 Nordson Corporation
Customer Interlock
The customer interlock requires an external 24 Vdc source at 100 mA to
power an internal relay coil (refer to Note). This indicates to the dryer
system that the production line is running. Without this signal, the controller
will not apply power to the induction coil.
Note: This relay coil is relay CR6. Optional relay voltages available as
special order are: 6, 12, and 48 Vdc, and 6, 12, 24, and 120 Vac, 50/60 Hz.
The interlock terminals are located behind the control enclosure doors, in
the front of the enclosure.
CAUTION: Nordson engineering recommends that the customer interlock
be connected and activated for safety. Without the interlock connection,
random line motion can cause the controller to apply power to the coil while
the line is stopped. Stationary can ends inside the coil could be overheated
and damaged.
See Figure 10.
1. Drill a hole or use a knockout tool to bring your interlock cable into the
enclosure. Install a properly sized strain relief or conduit connector in
the knockout.
2. Connect your interlock wiring to the terminals.
1
2
Figure 10 Customer Interlock Connections
1. Interlock terminals (#19, input) 2. Status contact (#20, output)

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls 17
Part 1601306−02
E2014 Nordson Corporation
Optional Status Contact
See Figure 10. The status contact is used in conjunction with the customer
interlock. The contact indicates when the dryer is off or in a fault condition.
The contact is off when:
SThe dryer has not been started (turned off).
SAny fault on the operator panel is activated.
SA run signal is received and motion is not detected by the Motion Sensor
before the External Interlock Timer expires. Refer to page 27 for timer
setting instructions.
Status Contact Connection: Terminal 20 Output Contact (output)
Motion Sensor
See Figure 11. The motion sensor mounting is designed to locate the
sensor in either of the two positions shown. Use the 12-O’clock position
when possible. If a rod cage entry is used with a rod at 12-O’clock or if an
overhead guide interferes with the sensor line of sight, reposition the motion
sensor to the 30_position as shown.
Remove the protective cap from the bottom of the motion sensor head.
Leave the cap attached to the sensor head for future use.
Adjust the motion sensor sensitivity as described in Motion Sensor
Sensitivity Adjustment on page 20.
30_
Position
12-O’Clock
Position
Sensor
Head
Cap
Figure 11 Motion Sensor Position and Cover

Nordson EcoDryrSeries Induction Dryers with Touch Screen Controls
18
Part 1601306−02 E2014 Nordson Corporation
Rear Access Panel
To complete the dryer installation, install the rear access panel. This panel
does not need to be removed again unless you are replacing an electrical
component or the coil.
Magnetic Separator (Optional)
Refer to the Magnetic Separator Adjustments instruction sheet, part number
1040053, for instructions on adjusting the magnetic separator for correct
operation.
Exhaust Ducting (Optional, Customer−Supplied)
Small amounts of water vapor and hot air are released from the exhaust
vents located on the entrance end and rear. Exhaust hoods and ducting is
not required but can be installed if desired. Do not restrict the air flow from
the exhaust vents.
Return Shipping Instructions
Refer to page 9 for lift points and uncrated weight.
Domestic/USA
1. Remove glass coil tube and carefully pack the tube separately.
2. Remove the leveling pads and place the system on a heavy duty
shipping skid. Bolt the system to the skid through the leveling pad
mounting holes.
3. Wrap the system with plastic wrap or shrink wrap.
Export
Prepare using steps in Domestic/USA return shipping instructions. In
addition, do the following:
SFully crate the system with all sides protected with 13 mm (1/2in.)
minimum OSB material or equivalent.
SIf shipping by ocean freight add silica gel to the shipping crate.
