NorSap NS 1500 Office Standard User manual

BRUKER MANUA
NS 1500 COMFOR & STANDARD
L/USERS MANUAL
FORHANDLER/DEALER.
Tlf:[phone] Fax:[phone]
Mjåvannsveien 35, 4628 Kristiansand, NORWAY
A/S SØRLANDETS ALUMINIUMPRODUKTER
6400 6500, 6510, 6520

13.01.2005.
Solid underlag er nødvendig for sikker montering.
Under lagring eller transport hender det at
teleskopsøyle kan sette seg inedre stilling. Det
kan med letthet trekkes opp ved å skru tilskruen
av sving ,løft opp utløserhendelen samtidig
at hele stolen trekkes opp.5
8
6
Astrong and levelfoundation is required to secure the
installation of the base. It may occur that during
storage or transport that the telescope column
fastens in the lower position. This can easily be
adjusted by fastening the lockable arm for swing ,
lift up the release handle at the same time pull up
the chair.
8
7
6
5
4
3
2
1
8
7
6
5
4
3
2
6
8
5
RELEASE HANDLE (not included on Standard model
Art.No.6400)
UTLØSERSPAK FOR HØYDEREGULERING (Inngår
ikke iStandard modellen Art.nr.6400)
TELESKOPSØYLE (fast høyde på søyle til
Standard modellen Art.nr.6400) TELESCOPE COLUMN (Constant/fixed height on
Standard modelArt.No.6400)
1
FASTLÅSING AV FOTHVILER
ADJUSTABLE ECCENTRIC ARM REST
JUSTERING AV EKSENTRISK ARMHVILER
REGULERING AV SETEVINKEL. REGULATING DEVICE FOR SEAT ANGLE
LOCKABLE ARM FOR SWINGFASTLÅSING AV SVING
LOCKABLE ARM FOR FOOT REST
LOCKABLE TOP GLIDE PLATE
LÅSING AV TOPP GLIDESKINNE
ADJUSTABLE HANDLE FOR THE BACK REST ANGLE
HENDEL FOR JUSTERING AV RYGGVINKEL
5
8
3
4
6
7
2
1
Sign:
Date:
S:/Tekinfo/ns1500 BM/6500-05.dwg
VEKT/WEIGHT: 47KG
BRUKER MANUAL/USERS MANUAL
NOR-SAP 1500
Tlf:[phone] Fax:[phone]
Mjåvannsveien 35, 4628 Kristiansand,NORWAY
A/S SØRLANDETS ALUMINIUMPRODUKTER
e-mail:[e-mail] Internet: www.norsap.no
9
9SETE - FREM OG TILBAKE SLEIDE SEAT - FORWARD LIFT AND SLIDE
9

Pleie og vedlikehold av lær
De fleste lærkvaliteter har fått en eller annen form for
overflatebeskyttelse. Når så møblene blir tatt i bruk,
tilfører man fett fra for eksempel hender og nakke.
Dersom man ikke regelmessig rengjør og beskytter
materialet på nytt, løser kroppsfettet langsomt opp all
beskyttelse i overflaten. Uten slik beskyttelse trenger
fett inn i læret og danner store, mørke fettflekker eller
forårsaker avfarging. Rens med Soft Cleaner helst
månedlig, bruk Leather Protection Cream 2-4 ganger
pr. år. Vær nøye med regelmessig rengjøring og
beskyttelse. Det er Du som bestemmer hvor lenge
møbelet skal vare og hvor lenge den skal beholde sin
eleganse.
-Beskytte læret mot direkte sollys over lengre tid.
-Varmekilde må ikke stå nærmere en 20-30 cm fra
møbelet.
-Fjern støv og smuss fra læret regelmessig med Soft
Cleaner en gang i måneden.
-Ta kontakt med oss eller nærmeste møbelhandler
for mer rengjøringsmiddel eller
rengjøringsdetaljer.
Vår leverandør på rensemiddel er:
Leather Master AS
6220 Straumgjerde
NORWAY
Tlf. [phone]
Fax. [phone]
Internet: leathermaster.no
E-mail: [email protected]
Care and maintenance of
leather
Most leather qualities have originally received one or
another type of surface protection treatment. When the
furniture is taken in use, grease from hand and neck
will be in contact with the leather on a regular basis.
Without proper cleaning the leather will over a period
of time leave grease spots or discoloration’s. To avoid
this clean with Soft Cleaner on a regular basis, we
advise once a month. Use Leather Protection Cream or
a leather cream with impregnation 2-4 times a year.
This will protect against spots, increase wear resistance
and preserve the leathers softness. By following these
instructions you will ensure a long and lasting leather
quality.
-Avoid direct sunlight over a longer period of time.
-Do not place a heat source within a distance of 20-
30 cm.
-Remove dust or vacuum, use Soft Cleaner once a
month.
-Contact us or an authorized leather producer or
Furniture Dealer for more cleaning medium or for
further cleaning details.
Our supplier of cleaning medium is:
Leather Master AS
6220 Straumgjerde
NORWAY
Tlf. [phone]
Fax. [phone]
Internet: leathermaster.no
E-mail: [email protected]

Dat e
Filename:
6350-XXXXUL
6351-XXXXUL
630
615
545
80 103
545 50
103
DØRKSKINNE NEDFELTOGPÅMONTERT
KANTPROFIL MEDBØRSTE.
DØRKSKINNE PÅMONTERT
ANTI-SNUBLE LISTMEDBØRSTE.
1
2
ANTI-TRIPSKIRTINGBOARD
DECKRAIL WITH BRUSHES
FLUSH MOUNTEDDECKRAIL
WITH BRUSHES.
1
2
MONTERING:
NB! VIKTIG
Underlaget måværeplant og hagodt
festefor skruer. Glideskinne/hjulspor må
værefri for metallrester eller andresmå
deler.
MOUNTING
NB! IMPORTANT
Astrong and level foundation is required
to securetheinstallation of thedeckrail.
Gliding/wheel tracks must befree from
scraps of metal or other items.
BRUKER MANUAL / USERS MANUAL
GLIDESKINNE / DECKRA IL
Art. No. 6350-XXXXUL
Art. No. 6351-XXXXUL
S:/Tekinfo/NS1500 BM/6350-01.dft
1
2
DO NOTUSEGREASEINSIDETHEWHEEL
TRACKS. THISWILL ATTRACTUNDESIRABLE
PARTICLESAND OBSTRUCTTHEWHEELS.
IKKEBRUK SMØREFETT I HJUL
SPORENE. DETTEVIL TILTREKKE
UØNSKETPARTIKLER OGHINDRE
HJULENE.
06.06.01

Date
Filename:
S:\Tekinfo\NS1500 BM\6500-06.dft 25.02.00.
SECURING SEATCOVER:
To secure seatcover, place velcroue
tape on the lower back restand
underneath the seatas illustrated above.
SECURING SEATCOVER
NS1500 PILOT CHAIR
FESTE FOR SETE TRE KK:
For å sikre setetrekket, settes
borrelås nederstpå ryggen og under
setetsom illustrert ovenfor.
VELCROUE TAPE
BORRELÅS TAPE
FESTE FOR SETETREKK TIL
NS1500 STOL
Art.no.6470 Seatcover w/armrestin fabric.
Art.no.6451 Seatcover w/armrestin water
repellent.
Art.nr.6470 Setetrekk m/armlen i stoff.
Art.nr.6451 Setetrekk m/armlen i
vannavstøtende.

06.06. 01 Grethe
S:\Tekinfo \Ns1 500 BM\ 650 0+ 635 0-15 00UL.df tN\A
NORSAP1500 MOUNTINGOF
LOCKFROM SITTINGPOSITION
6500+6350-1500ULA-2
Postboks 7005, 467 4 Kr istiansand NORWAY
Tlf:+ 47 38 18 5 2 00 Fax: [phone]
Title:
Drg.no.
Date DRN.
Si gn.
Mod./ Vers. Rev. Filename :
e-mail:sale@ norsap.no Int ernet: www.norsap.n o
RE VISION I SSUED FO R:RE V: Chk. Approved
V02
Scale:
Date Date
A-1 FOR INFORMAT ION
08.01. 02 Grethe
A-2 FOR INFORMAT ION

07.01.05
Grethe
S:\Tekinfo\Ns1500 BM\R-0010.dft
1:10
SEAT FRAME NS1500 B1,B2.B3
AND STANDARD MOD.2000A
ASSEMBLY
R-0010 A-4
Postboks 7005, 4674 Kristiansand
Tlf: 38 18 52 00 Fax: [phone]
Tittel / Title:
Tegn.nr: / Drg.nr.
Dato / Date
Tegn. / Drw. Godkjent for
produksjon /
Sign. / Sign.
Målestokk / Scale:
Versj. / Rev.
Filnavn / Filename:
Dato: Sign:
Approved for
production e-mail:[email protected]
Kontr. / Check Internett: www.norsap.no
1
2
3
4
4
5
6
7
10
10
10
11 12
18
36
37
13
14
15
16
16
17
17
19
20
20
21
21
22
23
23
23
24
25
26 7
27
28 29
30
31
32
33 33
33
23
33
34
35
28
39
8
41
42
46
44
44
45
43
47
48
45
44
44
50
49
51
51
49
38
Spare part nr. Item name Qty.
Pos.Nr.
GAS-021 GAS SUSPENSION KOB1K-3-055-215/600N 1 1
PLA-0501 DISTANCE PIECE ø25x8,2x5 2 2
B757-M8S HEX NUT PROTECTION CAP M8 BLACK DIN 1587 2 3
B413-M8X30 ROUND HEAD SQ.NECK CARR.BOLT M8x30 2 4
RATT-004 HAND REGULATOR M8 2 5
SAP-0087 BACK REST PLATE 1 6
B463-M6 HEX.NUT M6 SELFLOCK DIN6923 4 7
B481-M8 ROUND WASHER FLAT M8 DIN125A 5 8
MP145 EXTENSION PIECE ø20x8.5x30 BLACK 2 9
B434-4,2x25 COUNTERS.SELF.TAPP.SCR. 4,2x25 A4 10 10
DEL-128H ARMREST NS1500 RIGHT SIDE 1 11
BES04M10X52 SAFEKEEPING NET BLACK 1 12
PLA-11D4 COVER PLUG ø4 BLACK 4 13
SAP-0089V HINGE FOR ARMREST LEFT SIDE 6mm 1 14
SAP-0089H HINGE FOR ARMREST RIGHT SIDE 6mm 1 15
B413-M10X60 ROUND HEAD SQ.NECK CARR.BOLT M10X60 2 16
B420-M8X30 HEX.COUNTERS. HEAD SCR. M8x30 DIN7991 2 17
DEL-128V ARMREST NS1500 LEFT SIDE 1 18
B413-M6X20 ROUND HEAD SQ.NECK CARR.BOLT M6X20 4 19
RATT-029 GRIP HANDLE ø60 M10x60 2 20
SAP-0051 PRESSURE CASING 2 21
SAP-0090 SEAT PLATE 1 22
SAP-0009 ROUND WASHER FLAT ø55x2 4 23
STL-001 HEIGHT ADJ.SCREW Ø30 M10x52 2 24
DEL-098 SEAT FRAME NS1500 1 25
DEL-125 GLIDE RAIL HOLDER 2 26
B480-M8 ROUND WASHER FLAT M8 (8,4x25x2) 2 27
B780-M8 ROUND WASHER FLAT NYLON M8 DIN 9021 3 28
PLA-0701 COVER PLUG INSERT ø25 2 29
B462-M8 HEX. NUT NYLOC M8 DIN 985 2 30
SAP-0084 ECCENTRIC REGULATOR 2 31
PLA-0901 NYLON BALL ø8 2 32
B413-M8X60 ROUND HEAD SQ.NECK CARR.BOLT M8X60 4 33
SAP-0085 SPACER ROUND ø16 2 34
FJR-001 SPRING ø10x22x1.5 2 35
PUTE-001 BACK REST NS1500 1 36
PUTE-002 SEAT REST NS1500 1 37
B472-M8K POPNUT M8 8X16 1 38
PLA-028X12X16 COVER PLUG WITH COLLAR 8X12X16X2 PA66 1 39
B463-M8 NUT SELFLOCK M8 2 40
GASDEL-002 RELEASE FITTING FOR GAS SUSPENSION 1 41
GASDEL-003 RELEASE STICK FOR REGULATING BACK REST 1 42
SAP-1055 RANGE CASING FOR GAS SUSPENSION 1 43
B462-M10 HEX NUT M10 NYLOC 4 44
B481-M10 ROUND WASHER FLAT M10 2 45
B424-M10X35 HEX.SOCKET SET SCR.W/FLAT POINT M10X35 1 46
B420-M8X20 HEX.COUNTER.HEAD SCR.M8X20 DIN7991 1 47
SAP-0781 REG.PLATE FOR BACKREST 1 48
SAP-1292 BUSHING PLATE 8mm 2 49
PLAST-040 PEG COVER 8x40 1 50
B781-M10 ROUND WASHER FLAT M10 NYLON DIN125 2 51
SAP-1759 SLIDER KNOB 3 52
SAP-1758 LOCKING KNOB 1 53
B415-M6X20 HEX SOCKET CAP SCREW M6X20 4 54
R-0010 SEAT FRAME NS1500 B1,B2,B3 98A PILOT CHAIR
5254
53

04.03.03
Grethe
S: \Teki nfo\Ns 1500 BM \DEL- 049. dft
1:5
SQUARETOP NS1500 C OMFORT
Art.No. 6500,6510,6520 AND
STANDARDMOD.Art.No. 6400
ASSEMBLY
DEL-049A-4
Postboks 7005, 4 674 Kristiansand NO RWAY
Tlf:[phone] Fax:+ 47 38 18 2 0 86
Tittel / Title:
Tegn.nr: / Drg.nr.
Dato / D at e
Tegn. / Drw.
Godkjentfor
produksj on /
Sign. / Sign.
Målestokk / Scale:
Versj. / Rev.
Filnavn / Filename:
Dato: Sign:
Approved for
production e-mail:[email protected]
Kontr. / Ch eck Internett: www.norsap.no
1
2
5
7
8
4
4
6
4
4
13
13
6
6
6
11
3
DEL-049
THESE ITEMSARE NOTINCLUDEDON THE
STANDARDMODEL Art.No.6400, 6410.
Item nr.
Item name
Qty.
Pos.Nr.
SAP-0054
EXTENSION CASING ø10x1,5 L=9mm
1
1
B783-M6
ROUND WASHER FLAT M6 CLEAR/SOFT
1
2
SAP-0091
RELEASE HANDLE
1
3
B463-M6
HEX.NUT M6 SELFLOCK DIN6923
4
4
B480-M6
ROUND WASHER FLAT M6 (6,4x18x1,6)
1
5
B413-M6X25
ROUND HEAD SQ.NECK CARR.BOLT M6X25
4
6
B481-M6
ROUND WASHER FLAT M6
1
7
B411-M6X20
HEAD HEX.SET SCREW M6x20
1
8
MP161
CASING
1
9
RATT-028
GRIP HANDLE Ø60 M10 BLACK w/SAP LOGO BLACK
1
10
SAP-0064
TUBE ø25x3,5 L=134mm
1
11
B313-M10X260
ROUND HEAD SQ.NECK CARR.BOLT M10X260
1
12
MP156
GLIDE RAIL BLACK
2
13
DEL-049
SQUARE TOP NS1500 PILOT CHAIR
910
12

22.04.2004
Grethe
S:\Tekinfo\Ns1500 BM\R-0002.dft
1:10
TELESCOPICCOLUMN NS1500
B1,B2,B3 V-02
ASSEMBLY
R-0002
Postboks 7005, 4674 Kristiansand
Tlf: 38 18 52 00 Fax: [phone]
Tittel / Title:
Tegn.nr:
Dato / Date
Tegn. / Drw. Godkjent for
produksjon /
Sign. / Sign.
Målestokk / Scale:
Versj. / Rev.
Filnavn / Filename:
Dato: Sign:
Approvedfor
production e-mail:[e-mail]
Kontr. / Check Internet: www.norsap.no
R-0002 R-0003 R-0004
(R-0003expBM.cfg)
(R-0002expBM.cfg) (R-0002expBM.cfg)
Spare part nr. Item name Qty. Pos.Nr.
B361-M10 HEX.NUT M10 FOR GAS SUSPENSION 1 1
B420-M6X30 HEX.COUNTERSUNK HEAD SCREW M6x30 2 2
B420-M6X20 HEX.COUNTERSUNK HEAD SCREW M6x20 4 3
B424-M8X8 HEX.SOCK.SET SCR.w\FLST POINT M8x8 DIN913 4 4
MP151 CAST BUSHING NS1500 INNER TUBE 1 5
R-0002 SPARE COLUMN FOR 6500 (B1) 1 6
R-0003 SPARE COLUMN FOR 6510 (B2) 1 7
R-0004 SPARE COLUMN FOR 6520 (B3) 1 8
GAS-001 GAS SUSPENSION FOR 6500 (B1) 1 9
GAS-002 GAS SUSPENSION FOR 6520 (B3) AND 6510 (B2) 110
SAP-1559 BUSHING 111
FJR-009 SPIRAL SPRING L=120mm 112
SAP-1558 PLUG 113
SAP-0796-090 EXTENSION PIECE L=90mm 114
SAP-1157 EXTENSION TUBE FOR GAS SPRING L=400mm 115
SAP-0149 EXTENSION TUBE FOR GAS SPRING L=300mm 116
R-0002, R-0003, R-0004 TELESCOPIC COLUMN NS1500 B1,B2,B3 V-02 PILOT CHAIR
2
2
2
1
1
1
5
5
5
4
3
3
44
3
9
10 10
11
11
11
12
12
12
13
13
13
14
15
15
16
2
2
2

00.01.27
Grethe
S:\Tekinfo\Ns1500 bm\R-0 007.d ft
1:10
COLUMN FOR NS1500 STANDARD Art.No.6400
ASSEMBLY
R-0007
Postboks 7005, 4 674 Kristiansand S
Tlf: 38 18 52 0 0 Fax: [phone]
Tittel / Title:
Tegn.nr: / Drg.nr.
Dato / D at e
Tegn. / Drw.
Godkjen tfor
produks jon /
Sign. / Sign.
Målestokk / Sca le:
Versj. / Rev.
Filnavn / Filename:
Dato: Sign:
Approved for
production e-mail:[email protected]
Kontr. / Ch eck Internett: www.norsap.no
R-0007
Item nr. Item name Qty. Pos.Nr.
R-0007 SPARE COLUMN FOR NS1500 STANDARD Art.No.6400 1 1
SAP-0101 THRUST PLATE 1 2
B290-3X18 PIN SPRING Ø3x18 3 3
2
3
3
3

28.04.04.
Harald
S:\Tekinfo\NS1500 BM\DEL-085.dft
n/a
FOOT REST CASTED for NS1500
B1,B2,B3 AND STANDARD
ASSEMBLY
DEL-085 A-6
Tittel / Title:
Tegn.nr: / Drg.nr.
Dato / Date
Tegn. / Drw. Godkjent for
produksjon /
Sign. / Sign.
Målestokk / Scale:
Versj. / Rev.
Filnavn / Filename:
Dato: Sign:
Approved for
production
Kontr. / Check
Del-085exp1.cfg
9
3
4
1
2
8
7
6
Pos.Nr Qty. Item Description Item Nr. Rev.
1 1 MOLD PARTS NORSAP 1500 FOTREST DEL.687 A-1
2 1 FOOT REST PLATE DEL-136 A-2
3 1 Foot Rest Fore SAP-1566 A-1
4 2 Rivet for Hinge SAP-1822 A-1
6 2 ROUND WASHER FLAT M10NYLON DIN125B781-M10
7 2 HEX.NUT M10 NYLOC B462-M10
8 1 GRIPHANDLE M8x80 RATT-018-80 A-1
9 1 CASING ø13mm L=51mm SAP-0576_51 A-1
10 1 Hex Socket Cap Screw M8x35 B415-M8X35
11 6 RAISED COUNTERS.SELF TAPP.SCR.5,5x19 B432-5.5X19
12 2 ROUND HEAD SQ.NECK CARR.BOLT M10X45 B413-M10X45
4
6
7
11
11
11
11
11
11
10
12

22.11.00.
GRE
S: \Teki nfo\NS 1500 B M\6375. dft
1:5
RELEASE FROM SITT ING POSITION
FOR NS 1500
ASSEMBLY
6375 A-1
Tittel / Title:
Tegn.nr: / Drg.nr.
Dato / Date
Tegn. / Drw.
Godkjent for
produksjon /
Sign. / Sign.
Målestokk / Scal e:
Versj. / Rev.
Filnavn / Filename:
STOP FOR SWING
2
6375
Item 7 to be
mounted ont he side
of t he foot rest.
12
12
12
12
16
16
13
19
20
36
8
7
5
4
21
21
21
1
22
21
A
DETAIL A-A
14
10
10
10
9
17
11
14
Spare part nr.
Item name
Qty.
Pos.Nr.
SAP-0322
PROTECTION CAP
1
1
B424-M8X25
HEX.SOCKET HEAD SCREW M8X25 DIN916
1
2
B415-M6X20
HEX.SOCKET CAP SCREW M6X20
1
3
B415-M8X30
HEX.SOCKET CAP SCREW M8X30
1
4
B480-M8
WASHER ROUND FLAT M8
1
5
PLA-12D16
FLEXIBLE TUBE HOLDER
1
6
SAP-0545 FLEXIBLE TUBE GUIDER 1 7
SLA-002
FLEXIBLE TUBE
1
8
DEL-042
CASING FOR BRAKE SYSTEM
SAP-0559
HINGE BOLT
1
9
PLA-0301
TUBE SLEEVE WITH COLLAR ø10x12x16
3
10
SAP-0546
BRAKE BLOCK
1
11
B420-M6X30
SOCKET COUNTERS.HEAD SCR.M6x30
4
12
SAP-0294
CASING FOR FLEXIBLE TUBE
1
13
B420-M6X20
HEX.COUNTERSUNK HEAD SCREW M6x20
1
14
SAP-0353H CASING FOR BRAKE 1 15
B420-M5X16
HEX COUNTERSUNK HEAD SCREW M5X16
2
16
SAP-0287H BRAKE ARM PLATE 1 17
DEL-048
FORK ,WIRE AND SADDLE
WIRE003 FORK FOR WIRE 1 18
WIRE002
WIRE SADDLE
1
19
WIRE004
CONTROL CABLE WITH NUT
1
20
DEL-047
JOYSTICK FOR BRAKE
B420-M5X25
HEX COUNTERSUNK HEAD SCREW M5X25
4
21
SPAK-001
HANDLE FOR BRAKE
1
22
6375 RELEASE FROM SITTING POSITION NS1500

15. 11. 00. Grethe
S:\Tekinfo\NS1500 B M\6350-XXXX UL.dft none
DECK RAIL F OR NS1500 WITH ANT I-TRIP
SK IRTING BOAR D AND RELEASE FROM
SITTING POSITION ASSEMBLY
6350-(Length)UL A-2
Postboks 7005, 467 4 Kristiansand NORWAY
Tlf:[phone] Fax:[phone]
Title:
Drg.no.
Date DRN.
Sig n.
Mod./Vers. Rev. Filename:
e-mail :[email protected] Internet:www.no rsap.no
RE VI SION ISSUED FOR:RE V: Chk. Approved
V-01
Scale:
Date Date
Issued for informationA-1
8
1
35
18
17
16
12 10
14
13
11
4
6
2
77
9
Artikkelen inngår ikke i standard dørkskinne.
Denne artikkelen brukes samme n me d
NS1500 stol med motor og for stoler som
krever kabel gjennomgang i dørk.
This item is not included on t he standard deck
rail. This item is used by NS1500 pilot chair
with motor driven carriage and for chairs with
required cable passage through deck rail.
15
Spare part nr. Item name Qty.
Pos.Nr.
DEL-150 WHEEL CARRIAGE COMPLETE
DEL-410 BRAKE PLATE 1 1
SAP-0739 GLIDE SUPPORT CASTORS 4 2
DEL-177 DRAWBACK BLOCK WITH FILT 4 3
KLA-002 RUBBER COATED WHEELS WITH BALL BEARINGS 6 4
B420-M8X40 HEX COUNTERSUNK HEAD SCREW M8X40 10 5
SAP-0007 AXLE FOR WHEEL 6 6
B463-M8 HEX.NUT M8 SELFLOCK DIN6323 10 7
B415-M10X30 HEX SOCKET CAP SCREW M10X30 6 8
6375 RELEASE FROM SITTING POSITION 1 9
ANTI TRIP SKIRTING BOARDS
SAP-0259-(Length) BRUSHES L= AS REQUIRED BY CUSTOMER 210
SAP-0259-0480 BRUSHES L=480mm 211
SAP-0257-(Length) ANTI-TRIP SKIRT.BOARD L=AS REQ. BY CUSTOMER 212
SAP-0258-0628 ANTI-TRIP SKIRTING BOARD L=628mm 213
DECK RAIL
DEL-316-(Length) RUBBER COATED MIDDLE PLATE L=AS REQ.BY CUSTOMER 114
DEL-315-(Length) RUBBER COATED MIDDLE PLATE WITH SLOT L=AS REQ. 15
SAP-0268-(Length) GLIDE RAIL PROFILE L=AS REQ. BY CUSTOMER 216
END PLATES
SAP-0269-0457 END PLATE 217
B420-M8X20 HEX COUNTERSUNK HEAD SCR.M8X20 DIN7991 418
6350-(Length)
DECK RAIL WITH ANTI TRIP SKIRTING BOARD NS1500

14 .1 1.00 .Grethe
S:\Tekinfo\NS 1500 BM\6 351-XXXXUL.d ft none
DECK RAILF OR NS1500 WITHF LUSH
SKIRTINGBOARDSANDRELEASE
FROMSITTINGPOSITIONASSEMBLY
6351-(Length)UL A-2
Postboks 700 5, 467 4 Kr istiansand NO RW AY
Tlf:+ 47 3 8 18 5 2 00 Fax :[phone]
Title :
Drg.no.
Date DRN.
Si gn.
Mod./ Vers. Rev. Filename:
e-mai l:sale@ norsap.no I nternet :www. norsap.no
RE VI SION I SSUED FOR:RE V: Chk. Approved
V-01
Scale:
Date Date
Issued for informationA-1
8
35
12
10
11
642
77
1
9
14
Artikkelen inngår ikkei standard dørkskinne.
Denneartikkelen brukes sammen med
NS1500 stol med motor og for stoler som
krever kabel gjennomgang i dørk.
This itemis not included on thestandard deck
rail. This itemis used byNS1500 pilot chair
with motor driven carriageand for chairs with
required cablepassagethrough deckrail.
17
16 13
15
Spare part nr. Item name Qty.Pos.Nr.
DEL-150 WHEEL CARRIAGE COMPLETE
DEL-410 BRAKE PLATE 1 1
SAP-0739 GLIDE SUPPORT CASTOR 4 2
DEL-177 DRAWBACK BLOCK WITH FILT 4 3
KLA-002 RUBBER COATED WHEEL WITH BALL BEARING 6 4
B420-M8X40 HEX COUNTERSUNK HEAD SCREW M8X40 10 5
SAP-0007 AXLE FOR WHEEL 6 6
B463-M8 HEX.NUT M8 SELFLOCK DIN6323 10 7
B415-M10X30 HEX SOCKET CAP SCREW M10X30 6 8
6375 RELEASE FROM SITTING POSITION 1 9
FLUSH DECK RAIL WITH SKIRTING BOARDS
SAP-0259-(Length) BRUSHES L= AS REQUIRED BY CUSTOMER 2 10
SAP-0025-(Length) FLAT SKIRTING BOARD PROFILE L=AS REQ.BY CUST. 2 11
SAP-1002-0717 FLAT PROFILE L=717mm 2 12
DEL-316-(Length) RUBBER COATED MIDDLE PLATE L=AS REQ.BY CUSTOMER 1 13
DEL-315-(Length) RUBBER COATED MIDDLE PLATE WITH SLOT L=AS REQ.BY CUST. 1 14
SAP-0268-(Length) GLIDE RAIL PROFILE L=AS REQ. BY CUSTOMER 2 15
END PLATES
SAP-0269-0457 END PLATE 2 16
B420-M8X20 HEX COUNTERSUNK HEAD SCR.M8X20 DIN7991 4 17
6351-(Length) DECK RAIL FOR NS1500 WITH FLUSH MOUNTED SKIRTING BOARDS
