Nortek Bike BRO User manual

PRH Issue 1.1 28/6/17
Bike BRO User Guide
Contents
1.0 WIRING DIAGRAM (3 Wire System) ............................................................................................................................ 3
1.1 WIRING DIAGRAM (4 Wire System) ............................................................................................................................ 4
1.2 DVR LAYOUT / OVERVIEW ........................................................................................................................................... 5
1.3 COMPONENT LAYOUT ................................................................................................................................................. 6
1.4 IMAGE ORIENTATION / LEVELLING ............................................................................................................................. 6
2.0 INSTALLATION ............................................................................................................................................................. 7
3.0 NORMAL OPERATION .................................................................................................................................................. 8
3.1 Main Display ............................................................................................................................................................ 8
3.2 Powering ON / OFF.................................................................................................................................................. 8
3.3 Recording Mode ...................................................................................................................................................... 8
3.4 Record Sound .......................................................................................................................................................... 8
3.5 Camera Preview ...................................................................................................................................................... 8
4.0 MENU SYSTEM ............................................................................................................................................................ 9
4.1 Menu Buttons ......................................................................................................................................................... 9
4.2 Video Menu ........................................................................................................................................................... 10
4.2.1 Video Size (Resolution) .................................................................................................................................. 10
4.2.2 Rec Sound ....................................................................................................................................................... 10
4.2.3 G-Sensitivity ................................................................................................................................................... 10
4.2.4 Parking Mode ................................................................................................................................................. 10
4.2.5 Brightness ....................................................................................................................................................... 10
4.3 Setup Menu 1 of 2 ................................................................................................................................................. 11
4.3.1 Format ............................................................................................................................................................ 11
4.3.2 Screensaver .................................................................................................................................................... 11
4.3.3 Language ........................................................................................................................................................ 11
4.3.4 Auto Off .......................................................................................................................................................... 11
4.3.5 Sys. Reset ....................................................................................................................................................... 11
4.4 Setup Menu 2 of 2 ................................................................................................................................................. 12
4.4.1 Light Freq. ...................................................................................................................................................... 12
4.4.2 Date Input ...................................................................................................................................................... 12
4.4.3 Timezone ........................................................................................................................................................ 12
4.4.4 GPS INFO ........................................................................................................................................................ 12
4.4.5 Version ........................................................................................................................................................... 12

PRH Issue 1.1 28/6/17
5.0 FILE SYSTEM .............................................................................................................................................................. 13
6.0 PC GPS Player Application ......................................................................................................................................... 13
7.0 TROUBLESHOOTING .................................................................................................................................................. 14
** IMPORTANT NOTES ON SD CARDS **
1) This DVR requires a Class 10 MLC Card, suitable for DVR use and capable of writing at
least 14mb/s.
2) It is standard practise when using SD cards in DVR’s to format the card periodically.
For heavy use this can be typically every 2 weeks.
3) SD cards are a consumable items and have a finite number of write cycles. Depending
on usage, we suggest replacing the card every 12 months.
4) Symptoms of an incompatible or worn SD card include: DVR stopping & starting
recording erratically, sound out of sync with video, jumping video, sections of footage
missing, blocking or graining of recorded image.
5) Only buy genuine SD cards from a reputable supplier. EBay is full of counterfeit cards.
6) Recommended cards:
Transcend High Endurance
Lexar High Endurance

PRH Issue 1.1 28/6/17
1.0 WIRING DIAGRAM (3 Wire System)
Note: GPS and Manual Capture button are optional extras.

PRH Issue 1.1 28/6/17
1.1 WIRING DIAGRAM (4 Wire System)
Note: GPS and Manual Capture button are optional extras.

PRH Issue 1.1 28/6/17
1.2 DVR LAYOUT / OVERVIEW

PRH Issue 1.1 28/6/17
1.3 COMPONENT LAYOUT
1.4 IMAGE ORIENTATION / LEVELLING
To adjust the camera image angle, unscrew the lens cap a quarter turn, then rotate the camera body to the
correct orientation. Tighten the lens cap when done.

PRH Issue 1.1 28/6/17
2.0 INSTALLATION
 Connect the system as shown in the Wiring Diagram above.
 It’s advised to charge the DVR using the supplied USB cable before installing on the bike.
 Connect the PSU to a suitable accessory / switched battery feed.
 A headlight or taillight is a recommended “live” feed (Providing these are not monitored on the
CAN bus like some modern bikes)
 NOTE: DO NOT connect directly to the battery, as the unit draws current even when switched off
to charge the DVR internal battery and recording may continue even after the bike is parked. This
could lead to a flat battery over time.
 Place the DVR unit under a seat, or panel in a dry area. The DVR is splash proof but NOT
waterproof.
 Camera’s, GPS, Manual Capture and connectors are all waterproof.
 GPS module ideally needs to see the sky and won’t work under a seat. Some experimentation may
be required to find the best place to locate the sensor on your bike. When the DVR has a GPS lock,
the Lat / Lon is displayed on the screen and the word GPS stops flashing. The time and date for the
DVR is taken from the GPS data, therefore the Timezone may need to be adjusted to correct any
Daylight Saving Time differences.
 Line up the arrows on the connectors
 Be careful with the connectors, they contain very small wires and can be broken if roughly handled!

PRH Issue 1.1 28/6/17
3.0 NORMAL OPERATION
3.1 Main Display
3.2 Powering ON / OFF
Press Power ON / OFF button on the DVR.
or
Press and hold the manual capture button for 2 seconds.
3.3 Recording Mode
Once setup, the unit will begin recording straight after power on.
NOTE: To enter the Menu System, the recording must be stopped first. Recording Time will go WHITE and
show 00:00:00
Press to START / STOP the recording.
3.4 Record Sound
Make sure Record Sound is ON in the menu system AND the sound symbol is not crossed out on the
display!
A short press of from the camera view screen toggles the sound ON/OFF.
3.5 Camera Preview
Pressing or changes the camera shown on the main screen.
Video Quality
Sound ON / OFF
SD Card Inserted
GPS
Satellites
Found
Lat / Lon
Recording Time
CAM1 Preview
CAM2 Preview

PRH Issue 1.1 28/6/17
4.0 MENU SYSTEM
NOTE: To ente the menu system recording must be stopped first by pressing the Mode button.
See Section 3.3 for more info.
Press and hold the Menu button to enter the menu system.
4.1 Menu Buttons
In the menu system the buttons operate as follows:
BUTTON FUNCTION
Back or Cancel, or Setting Menu (From Video menu)
Up / Down list options
Enter / OK

PRH Issue 1.1 28/6/17
4.2 Video Menu
4.2.1 Video Size (Resolution)
HD 1280 * 720
D1 720 * 480
VGA 640 * 480
4.2.2 Rec Sound
ON, OFF NOTE: Short press of MENU button will toggle sound recording
ON/OFF when in the Main display.
4.2.3 G-Sensitivity
Off, High, Med, Low Force required to trigger a G-event. High (3G), Med (2.5G), Low (2G).
Causes an EVE_XXXX.avi file to be saved. See Section 5.0 for more
info.
4.2.4 Parking Mode
ON, OFF Reduces recording frame rate to 1 FPS after 3 mins of inactivity.
NOTE: DVR is still running and if left for long periods may discharge
bike battery.
4.2.5 Brightness
1-20 Allows each camera brightness to be adjusted.
NOTE: Pressing the Menu button once from the Video Menu will take you to the Setup Menu’s.

PRH Issue 1.1 28/6/17
4.3 Setup Menu 1 of 2
4.3.1 Format
Cancel, Execute Select Execute and press OK to erase and format the SD card.
4.3.2 Screensaver
OPEN, 1, 3, 5 min Screen Blank time. OPEN = Screen ON permanently
4.3.3 Language
Various Languages
4.3.4 Auto Off
1, 3, 5 min, OFF Switches off the DVR if the SD card is not inserted.
4.3.5 Sys. Reset
Cancel, Execute Restore to Factory defaults.
NOTE: Pressing the Menu button once from the Setup Menu will exit the menu system.

PRH Issue 1.1 28/6/17
4.4 Setup Menu 2 of 2
4.4.1 Light Freq.
60Hz, 50Hz Shutter refresh rate
4.4.2 Date Input
Off, Set Menu button to change field.
dd / mm / yyyy
mm / dd / yyyy
yyyy / mm / dd
4.4.3 Timezone
Cancel, Set Menu button to change field.
GMT+/- 00:00
4.4.4 GPS INFO
Displays a bar graph showing number of satellites found and signal strength.
4.4.5 Version C6,70321G3PCLG,EN
NOTE: Pressing the Menu button once from the Setup Menu will exit the menu system.

PRH Issue 1.1 28/6/17
5.0 FILE SYSTEM
The Card uses FAT32 and can be read by Windows XP/7/10 OS.
32GB SD Card give approximately 3 hours of video footage.
Files are stored with different prefixes according to the reason they were saved as follows:
FILENAME TYPE REASON
EVE_XXXX.avi G-Shock triggered event
REC_XXXX.avi Normal recording
KEY_XXXX.avi Manual Capture pressed
EVE_XXXX and KEY_XXXX files are not overwritten by loop recording. Once the card is full, the oldest
REC_XXXX file is deleted and replaced with the current. Periodically erase the EVE_XXXX and KEY_XXXX
files otherwise the card will become full, plus the loop time will decrease as the card fills with these events.
6.0 PC GPS Player Application
A PC application “GPS Player” is required to play the SD card video and GPS data and is available for free
download at:
http://www.nortek.co.uk/bike-bro-dual-camera-motorcycle-dvr/

PRH Issue 1.1 28/6/17
7.0 TROUBLESHOOTING
PROBLEM SOLUTION
No Sound Press MENU button and check sound icon on the screen
Check Rec Sound is ON in the Video Menu
Can’t access menu’s Stop the recording first, see Section 3.3.
GPS wont lock on Make sure GPS has a view of the sky.
Check GPS connection is pushed in fully.
Lots of EVE_XXXX saved Check G-Sensitivity setting and change to “HIGH”. Hard accelerating or
braking can cause an event. The more powerful the bike, the higher the risk
of false triggering, so the setting should be adjusted accordingly.
Jerky AVI file playback Use class 10 DVR suitable SD card. (Available from Nortek Bike Bro website)
or Sound / GPS out of sync
Memory Full Too many event files on the SD card. Reduce the G Shock sensitivity or switch
it off. Too many KEY_ events from pressing the manual capture button.
Erase the SD card on a PC, or Format it from the menu system.
END OF DOCUMENT.
