Meridian data features Operations and tests
Meridian 1
Meridian data features
Operations and tests
Document Number: 553-2731-300
Document Release: Standard 4.00
Date: April 2000
Year Publish FCC TM
Copyright © 1990–2000 Nortel Networks
All Rights Reserved
Printed in Canada
Information is subject to change without notice. Nortel Networks reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant. This equipment has been tested
and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules, and the
radio interference regulations of Industry Canada. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their own expense.
SL-1 and Meridian 1 are trademarks of Nortel Networks.

Page 3 of 86
Meridian data features Operations and tests
4
Revision history
April 2000 Standard 4.00. This is a global document and is up-issued for X11 Release
25.0x. Document changes include removal of: redundant content; references
to equipment types except Options 11C, 51C, 61C, and 81C; and references
to previous software releases.
December 1994 Standard, release 3.00. Reissued to include editorial changes and indexing.
Due to the extent of the changes, revision bars are not used.
December 1992 Standard, release 2.00.
August 1990 Standard, release 1.00. Reissued for compliance with Nortel Networks
standard 164.0.

Page 4 of 86 Revision History
553-2731-300 Standard 4.00 April 2000

Page 5 of 86
Meridian data features Operations and tests
6
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operation procedures and tests . . . . . . . . . . . . . . 9
Content list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Reference list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Testing procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Hot Line calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Keyboard dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Keyboard dialing from the AIM data station . . . . . . . . . . . . . . . . . 33
Keyboard dialing from the ASIM data station . . . . . . . . . . . . . . . . 42
Keypad dialing from the ASIM data station . . . . . . . . . . . . . . . . . . 54
Performance testing operations . . . . . . . . . . . . . . 61
Content list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Reference List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
In-house transmission performance testing . . . . . . . . . . . . . . . . . . . 62
Interoffice data transmission performance testing . . . . . . . . . . . . . 62
Outbound Modem Pool fault testing . . . . . . . . . . . . . . . . . . . . . . . . 63
Inbound Modem Pool fault testing . . . . . . . . . . . . . . . . . . . . . . . . . 63
AIM and AILC fault testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
ASIM troubleshooting procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Page 6 of 86 Contents
553-2731-300 Standard 4.00 April 2000
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Page 7 of 86
Meridian data features Operations and tests
8
Introduction
This document describes how to operate the Meridian data station and how to
test its on-line transmission performance.
A colocated data station consists of a QSU-type SL-1 telephone and an
Add-on Data Module (ADM) connected to data terminal equipment.
Note: References in this publication to ADMs imply QMT7, QMT8,
and QMT12 ADMs.
The Meridian colocated data station permits data calling and regular
telephone calling to and from a single SL-1 telephone. The data station also
allows several optional calling features associated with the SL-1 telephone to
be used in conjunction with data calling.
Astand-aloneADM,whenconnectedtoadataterminal(forexample,without
a companion SL-1 terminal), provides services associated with Meridian data
calling that do not require user intervention.
Configuring each stand-alone ADM appropriately is critical to the proper
function of Meridian data stations.
The Asynchronous Interface Module (AIM) provides the interface between
an RS-232-C compatible asynchronous Data Terminal Equipment (DTE)
through its Asynchronous Interface Line Card (AILC).
The AIM may be desktop or wall-mounted and is used to originate and to
answer data calls. It supports keyboard dialing.
The Asynchronous/Synchronous Interface Module (ASIM) provides the
interface between an RS-232-C compatible asynchronous or synchronous
DTE and the Meridian 1 system.

Page 8 of 86 Introduction
553-2731-300 Standard 4.00 April 2000
The ASIM is desktop mounted and is used to originate and to answer data
calls. It supports the following:
• Keyboard and keypad dialing for asynchronous calling
• Keypad dialing only for synchronous calling
• Automatic set relocation
A Multi-Channel Data System (MCDS) accesses a multiple port computer
and takes the place of several ADMs. The 4-port MCDS Asynchronous Card
(MCDS-AC) performs the same functions as four separate ADMs.
The operations of the Meridian data station described in this publication
should be performed after installation to ensure that each ADM is functional
and is properly configured to provide the data service the customer requires.

Page 9 of 86
Meridian data features Operations and tests
60
Operation procedures and tests
Content list The following are the topics in this section:
•Reference list 9
•Prerequisites 9
•Testing procedures 10
•Operating procedures 12
•Hot Line calls 26
•Keyboard dialing 28
•Keyboard dialing from the AIM data station 33
•Keyboard dialing from the ASIM data station 42
•Keypad dialing from the ASIM data station 54
Reference list
The following are the references in this section:
•X11 Features and Services (553-3001-306)
Prerequisites
Ensure that commercial power is supplied at the appropriate outlets. Be sure
the power modules required for any SL-1 set Add-on Data Module—for
example, the QMT—equipped at Meridian data station are installed
according to instructions.
Designate or install a test station to have access to external data test
equipment before testing the Meridian data station or stand-alone ADM.

Page 10 of 86 Operation procedures and tests
553-2731-300 Standard 4.00 April 2000
Testing procedures
The operating procedures specify the manner the Meridian data station and
stand-alone Add-on Data Module (ADM), Asynchronous Interface Module
(AIM), and Asynchronous/Synchronous Interface Module (ASIM) normally
function.
If there are any differences when testing, follow these steps:
1Check the following connections to verify that the data-related
equipment is properly connected.
— ADM, AIM, and ASIM power
— Power Fail Transfer (PFT)
— ADM-to-SL-1 set
— ADM, AIM, and ASIM-to-DTE
— ADM and ASIM-to-Data Communication Equipment (DCE)
— DCE to peripheral equipment (PE)
— Multi-Channel Data System (MCDS) to PE connections to the
connecting block
— Cross-connectionsattheMainDistribution Frame(MDF)forbridge
taps and eliminate
2Verify through the followingsteps that the appropriate assignments have
been made in the database (LD 10 or LD 11) to allow operation:
— Check Data Line Card (DLC) port and Asynchronous Interface Line
Card (AILC) assignments.
— Check ADM, AIM, and ASIM feature assignments.
— Verify SL-1 and ADM, AIM, and ASIM key assignments.
— Check Modem Pool Line Card (MPLC) or 500-set line card
assignments.

Operation procedures and tests Page 11 of 86
Meridian data features Operations and tests
3Verify through the following steps that the ADM and ASIM are properly
configured for connection to the equipment:
— Compare transmission control settings on S2, S3, and S4 of the
ADM to the parameters of the connected data equipment.
— Compare transmission control settings of the ASIM to the
parameters of the connected data equipment.
Note: Do not attempt to change the baud rate while a call is connected.
The connection may lock up.
4Verify through the following steps that the ADM, AIM, ASIM, and
MCDS are not installed out of range from the DTE or the PE:
— Check cable distance between ADM, AIM, ASIM, and MCDS-AC
and DTE.
— Compare wire-gauge selection jumper settings of ADM and
MCDS-AC to the gauge of wire connecting ADM and MCDS-AC
to PE.
— Check cable-distance between ADM, AIM, ASIM, and MCDS-AC
and PE.
Note: In mixed wire-gauge installations, the jumpers should be set to
match the longest wire gauge.
5Verify through the following steps the integrity of the terminal
equipment connected to the ADM, AIM, and MCDS-AC:
— Disconnect ADM from SL-1 terminal and check SL-1 terminal
function.
— Check DTE.
— Check DCE.
6Verify through the following steps that the DLC is properly configured:
— Check option-switch settings for Terminal Number (TN) in
question.
— Check jumper pin positions.
— Check shelf installation (maximum of four DLCs or AILCs per
shelf).

Page 12 of 86 Operation procedures and tests
553-2731-300 Standard 4.00 April 2000
Operating procedures
Procedures 1 through 11 provide detailed action-and-response sequences for
various types of calls from the ADM.
Procedure 12 provides detailed action-and-response sequences for various
types of actions from the AIM.
Procedures 13 and 14 provide detailed action-and-response sequences for
various types of actions from the ASIM.
However, the procedures are examples and only recommended, not required.
In many of the procedures, especially those involving simultaneousvoice and
data calls, you are not restricted to following the sequences exactly.

Operation procedures and tests Page 13 of 86
Meridian data features Operations and tests
Procedure 1
Originating an intraoffice data station call with a colocated ADM
Step Action Verification Comment
Start condition. POWER lamp on. Data station idle.
Handset on-hook.
1Press Data
Directory Number
(DDN) key.
DDN lamp on.
DATA SHIFT lamp on.
Dial tone on speaker.
Data station shifts to data
mode.
Further SL-1 set key
depressions correspond to
DDN.
2Dial first digit of
called DDN. DIAL tone removed.
3Dial remaining
digits of called
DDN.
RINGBACK tone on speaker.
4Called DDN
answers. CONNECT lamp on. DATA SHIFT lamp off.
RINGBACK tone off.
CONNECT beep on speaker.
RINGBACK removed before
connect beep is heard.
5Press DATA SHIFT
key. DATA SHIFT lamp on.
6Press RLS key. DDN, DATA SHIFT, and
CONNECT lamps off. Call disconnected. Data station shifts to voice
mode.
Note:
Once the called DDN answers and the DATA SHIFT lamp is extinguished, you can use the data
station in voice mode.

Page 14 of 86 Operation procedures and tests
553-2731-300 Standard 4.00 April 2000
Procedure 2
Originating an outgoing data station call (Modem Pool call) (Part 1 of 3)
Step Action Verification Comment
Start condition. POWER lamp on. Data station idle.
Handset on-hook.
1Press DDN key. DDN lamp on.
DATA SHIFT lamp on.
Dial tone on speaker.
Data station shifts to data
mode.
Further SL-1 set key
depressions correspond to
DDN.
Manual Modem
Pool. (Go to step
11 for Automatic
Modem Pooling
[AMP]).
2Dial first digit of
Modem Pool DDN. DIAL tone removed.
3Dial remaining
digits of Modem
Pool DDN.
RINGBACK tone on speaker.
4Modem Pool DDN
answers. RINGBACK tone off. DATA SHIFT lamp off.
MODEM CTRL lamp winks.
CONNECT beep on speaker.
RINGBACK removed before
2-second connect tone is
heard. Winking MODEM CTRL
lamp indicates a modem is
reserved. If the modem is
reserved and an incoming call
appears on voice Directory
Number (DN), lift handset and
answer the call. Put the voice
call on hold and release data
call if necessary. Modem Pool
call can be made using
secondary DN.
5Press Prime
Directory Number
(PDN) key.
PDN lamp on.
DIAL tone on speaker.

Operation procedures and tests Page 15 of 86
Meridian data features Operations and tests
6Dial first digit of
called remote
computer.
DIAL tone off.
7Dial other digits of
called remote
computer.
RINGBACK tone on speaker.
8Modem of remote
computer answers. RINGBACK tone off. CARRIER tone on speaker.
9Press MODEM
CTRL key. MODEM CTRL and CONNECT lamps on.
PDN lamp off.
CARRIER tone off.
Carrier tone removed after brief
interval.
Call established. PDN
automatically released from
connection. PDN lamp goes
dark. Station shifts to voice
mode.
Automated Modem Pool (see note)
10 Dial first digit. DIAL tone removed. All dialing is done from the
DDN at the data station.With
prefix dialing, this is the first
digit of the 1- to 4-digit Modem
Selection Prefix. With default
dialing, this is the first digit of
the trunk access code (TAC).
11 Dial remaining
digits. With Prefix Dialing, this includes the remainder of the
Modem Selection Prefix, trunk
access code, and the remote
DN.With default dialing this is
the remainder of the TAC and
remote DN.
Procedure 2
Originating an outgoing data station call (Modem Pool call) (Part 2 of 3)
Step Action Verification Comment

Page 16 of 86 Operation procedures and tests
553-2731-300 Standard 4.00 April 2000
12 Modem of remote
computer answers. CONNECT lamp on. MODEM CTRL lamp on.
PDN lamp off.
CARRIER tone off.
Call established.
PDN automatically released
from connection.
Station shifts to voice mode.
Data station shifts to data
mode.
Note:
If it is necessary to initiate data features during the call, press the DATA SHIFT key to transfer to the
DDN, initiate the feature, and then press the DATA SHIFT key to shift back to the voice DN.
Disconnect data call
13 Press DATA SHIFT
key. DATA SHIFT lamp on. Data station shifts to data mode.
14 Press RLS key. DDN, DATA SHIFT,
CONNECT, and MODEM
CTRL lamps off.
Call disconnected.
Station idle.
Note:
A data user may use either prefix or default dialing to access and connect the modem automatically.
Prefix dialing allows the data user to choose the modem pool used to select the modem. The user dials a 1
to 4-digit Modem Selection Prefix, a TAC, and the remote computer port DN. If all resources are available, a
data path is established between the data user and the host, and the connect lamp is lit. If either the modem
pool or the trunk route is busy, Ring Again is applied. If the data call is incomplete because the remote port
is unavailable or the call is misdialed, no call progress tones are received to indicate the problem source.
Default dialing assumes that some data users normally wish to connect to the same modem pool for each
call. In this case a default trunk route associated with a Modem Selection Prefix is stored against the user’s
TN. The user only needs to dial the TAC and the remote computer DN. The Meridian 1 system does the rest
and treats the call as if the user had dialed the Modem Selection Prefix. The stored default Modem
Selection Prefix can always be overridden by dialing another Modem Selection Prefix.
When a completely digital path is available from the data station to the remote computer port, an all Digital
Connection Prefix can be designated if the Digital Trunk Interface (DTI) package is equipped. If the DTI
prefix is used, a modem is not connected when the outgoing route is digital. Overflow tone is returned if the
user attempts to use a voice frequency trunk to set up the call.
Procedure 2
Originating an outgoing data station call (Modem Pool call) (Part 3 of 3)
Step Action Verification Comment

Operation procedures and tests Page 17 of 86
Meridian data features Operations and tests
Procedure 3
Establishing simultaneous voice and data calls as viewed from an originating station
(Part 1 of 2)
Step Action Verification Comment
Start condition,
Data Station A. POWER lamp on. Data station idle. Handset on-hook.
Station A = originating station.
Station B = called station.
1Lift handset at
Data Station A. PDN lamp on. DIAL tone on handset.
2Dial first digit of
Data Station B
PDN and Voice
Directory
Number.
DIAL tone off. Dial tone removed.
3Dial remaining
digits of Data
Station B PDN
and VFDN.
RINGBACK on handset.
4Data Station B
answers. RINGBACK tone off. RINGBACK removed. Two-way conversation.
5PressDDNkeyat
Data Station A. DDN and DATA SHIFT lamps on.
PDN lamp flashes.
DIAL tone on handset.
PDN call automatically placed on
hold.
Data station shifts to data mode.
6Dial first digit of
Data Station B
DDN.
DIAL tone off. Whenequipped, AMP procedures
may be used instead of steps 6
and 7 (see Procedure 2, steps
11–14).
7Dial remaining
digits of Data
Station B DDN.
RINGBACK tone on handset.
8Data Station B
DDN answers. DATA SHIFT lamp off. CONNECT lamp on.
RINGBACK off.
CONNECT BEEP on
handset.
PDN call is still on hold.

Page 18 of 86 Operation procedures and tests
553-2731-300 Standard 4.00 April 2000
9Press DATA
SHIFT key at
Data Station A.
DATA SHIFT lamp on. Data Station A shifts to data
mode.
10 Press RLS key. DDN, DATA SHIFT, and
CONNECT lamps off. Data call disconnected. Voice call still on hold.
11 Press PDN key. PDN lamp on. Voice connection reestablished.
12 Ask Data Station
B to place a call
to your DDN at
Data Station A.
Data Station B DDN makes a data
call to Data Station A DDN. (This
places voice call from Data
Station B PDN on hold.)
13 AsDataStationB
completesdialing
DDN of Data
Station A.
DDN lamp winks.
DATA BUZZ on handset.
14 Press DDN key
(ADM set to
MANUAL
answer).
DDN lamp on.
CONNECT lamp on.
PDN lamp flashes.
DATA BUZZ off.
Data buzz removed after 2 s or
when called ADM answers. (No
DDN key depression is required if
ADM is set to auto-answer.) PDN
call was automatically placed on
hold. (Two-way hold now exists
between data stations in this
case.) See step 12.
15 Press PDN key
on Data Station
B.
PDN lamp on. Simultaneousvoiceand data calls
established between Data
Stations A and B.
16 Press RLS key. PDN lamp off. PDN call disconnected; PDN
lamp goes dark.
17 Press DATA
SHIFT key. DATA SHIFT lamp on. Data Station A shifts to data mode.
18 Press RLS key. DDN, DATA SHIFT, and
CONNECT lamps off. DDN call disconnected. All ADM lamps go dark except POWER.
Data station idle.
Procedure 3
Establishing simultaneous voice and data calls as viewed from an originating station
(Part 2 of 2)
Step Action Verification Comment

Operation procedures and tests Page 19 of 86
Meridian data features Operations and tests
Procedure 4
Answering voice calls during data call setup (Part 1 of 2)
Step Action Verification Comment
Start condition. DDN, DATA SHIFT, and
POWER lamps on. DDN call setup in progress.
1Incoming call
presented to
PDN and VDN.
PDN and VFDN lamps flash.
2Press RLSF key. DDN and DATA SHIFT lamps
off. Data call setup abandoned.
3Lift handset. PDN lamp on. Two-way conversation on PDN.
4Place PDN on
hold. PDN lamp flashes. PDN on hold.
5Press VDN key
associated with
flashing lamp.
VDN lamp on. Two-way conversation on VDN.
PDN call on hold.
6Press HOLD key. VDN lamp flashes. VDN call placed on hold.
7Press DDN key. DDN and DATA SHIFT lamps
on.
DIAL tone on handset.
Data station shifts to data mode.
8Dial first digit of
required DDN. DIAL tone off.
9Dial remaining
digits of DDN. RINGBACK tone on handset.
10 Called DDN
answers. CONNECT lamp on. RINGBACK off.
CONNECT BEEP on
handset.
Data call established.
11 Press PDN key. PDN lamp on. Voice call reestablished.
12 Press RLS key. PDN lamp off. PDN call disconnected
PDN lamp goes dark.

Page 20 of 86 Operation procedures and tests
553-2731-300 Standard 4.00 April 2000
13 Press VFDN key
next to flashing
lamp.
VDN lamp on. VDN call reactivated.
Simultaneous voice and data
call.
14 Press RLS key. VDN lamp off. VDN call disconnected.
15 Press DATA
SHIFT key. DATA SHIFT lamp on. Data station shifts to data mode.
16 Press RLS key. DDN, DATA SHIFT, and
CONNECT lamps off. DDN call disconnected. Data station idle.
17 Replace handset.
Procedure 4
Answering voice calls during data call setup (Part 2 of 2)
Step Action Verification Comment
