Nova Nova FF6.5 User manual

Nova
Power From The Heavens
Nova FF6.5
Front Firing
Powered
Subwoofers
Operation
Manual
&
Technical
Guide
www.earthquakesound.com Sound That Will Move You.

WARNING: This product is capable of
generating high sound pressure
levels. You should exercise caution
when operating these speakers. Long
term exposures to high levels of
sound pressure will cause permanent
damage to your hearing. Sound pressure levels
exceeding 85dB can be dangerous with constant
exposure, set your audio system to a comfortable
loudnesslevel.EarthquakeSoundCorporationdoes
not assume liability for damages resulting from the
direct use of Earthquake subwoofers , and urges
userstoplayvolumeatmoderatelevels.
FF6.5 Front Firing Subwoofer
-2-
Table of Contents
Introduction ..............................................................
Warranty Guideline .................................................
Specifications & Performance ..................................
Product Overview ....................................................
Control Panel Overview ..........................................
Subwoofer Placement .............................................
Connecting Your Subwoofer ...................................
2
3
4
5
6
6
7
DearValuedCustomer,
Welcome to the eclectic world of Earthquake High Fidelity sound systems; you are about to experience the FF6.5
subwoofer. This system is designed to dramatically enhance your enjoyment of music and films at home, by adding power
and impact to lowfrequencysoundeffects.
EarthquakeSoundCorporation islocatedintheheartofthe Silicon Valley. It specializesinmanufacturinghighend
home and car audio products ranging from the smallest driver to the loudest subwoofer system. In its dedication to
excellence, Earthquake has maintained extensive programs in research and development to provide you with the highest
qualityaudioproducts.
This owners manual is designed to better acquaint you with the Nova FF6.5 subwoofer system and guide you
through the phases of system design and application. It is imperative that you read this manual in its entirety. Simply call 1-
800-576-7944 for EARTHQUAKE technicians and staff to answer any questions you might have in regards to the FF6.5
subwoofer.
Professor Joseph J. Sahyoun
President & Chief Engineer

-3-
Five (5) Years Limited Warranty.
Earthquake warrants the original purchaser that all Factory Sealed New Audio Products to be free from defects in material and
workmanship under normal and proper use for a period of five (5) years from the date of purchase (as shown on the original original sales
receiptwithserialnumberaffixed/writtenonit).
The five (5) year warranty period is valid only if an authorized Earthquake dealer properly installs the product and the warranty
registrationcard is properlyfilled out andsent to EarthquakeSound Corporation. Ifa non-authorized partyinstalls the product,a ninety (90)
daywarrantyperiodwillbeapplied.
(A)Five(5)yearslimitedwarrantyplancoverageguidelines:
!Firstyear:Earthquakepaysforlabor,parts,andgroundfreight(onlyinUSmainland,notincludingAlaskaandHawaii.Shippingtousis
notcovered).
!Second,third,fourth&fifthyear:Earthquakepayslaboronly.Customermustpayforpartsandfreightbothways.
(B)Warning:
Products(sentforrepair)thataretestedbyEarthquaketechniciansanddeemedtohavenoproblem(s)willnotbecoveredbythefive(5)
year limited warranty. Customer will be charged a minimum of one (1) hour of labor (at the ongoing rates) plus shipping charges back to
customer.
(C)Earthquakewillrepairorreplace atouroption alldefectiveproducts/partssubjecttothefollowingprovisions:
!Defectiveproducts/partshavenotbeenalteredorrepairedbyotherthananEarthquakefactory-approvedtechnicians.
!Products/parts are not subjected to negligence, misuse, improper use or accident, damaged by improper line voltage, used with
incompatible products or have its serial number or any part of it altered, defaced or removed, or have been used in any way that is
contrarytoEarthquake'swritteninstructions.
(D)WarrantyLimitations:
Warrantydoesnotcoverproductsthathavebeenmodifiedorabused,includingbutnotlimitedtothefollowing:
!Damagestospeakercabinetandcabinetfinishduetomisuse,abuseorimproperuseofcleaningmaterials/methods.
!Bentspeakerframe,brokenspeakerconnectors,holesinspeakercone,surround&dustcap,burntspeakervoicecoil.
!Fadingand/ordeteriorationofspeakercomponents&finishduetoimproperexposuretoelements.
!Bentamplifiercasing,damagedfinishonthecasingduetoabuse,misuseorimproperuseofcleaningmaterial.
!BurnttracersonPCB.
!Product/partdamagedduetopoorpackagingorabusiveshippingconditions.
!Subsequentdamagetootherproducts.
Awarranty claim will not be valid if the warranty registration card is not properly filled & returned to Earthquake with a copy of the sales
receipt.
(E)ServiceRequest:
To receive product service, contact Earthquake Service Department at [phone] and request an RMAnumber (Return Material
Authorization).ItemsshippedwithoutavalidRMAnumberwillberefused.Makesureyouprovideuswithyourcomplete/correctshipping
address, a valid phone number, and a brief description of the problem you are experiencing with the product. In most cases, our
techniciansmightbeabletoresolvetheproblemoverthephone,thuseliminatingtheneedtoshiptheproduct.
(F)ShippingInstructions:
Product(s) must be packaged in its original protective box(es) to minimize transport damage and prevent repackaging cost (at the
ongoing rates). Shipper claims regarding items damaged in transit must be presented to carrier. Earthquake Sound Corporation
reservesthe right torefuse improperly packedproduct. Original billof sale mustaccompany product returnedto service. Weencourage
youtoincludewiththepackageawrittendescriptionoftheproblem.Shipproductto:
Earthquake Sound Corp.
2727 McCone Avenue, Hayward, CA 94545.
Tel: [phone].
YouareresponsibleforthecostofshippingtheproducttoEarthquakeSoundCorporation.
(G)DisputesResolution:
Alldisputes betweenclientsandEarthquakeSoundCorporation resultingfromthefive(5)yearlimitedwarrantypolicymustberesolved
accordingtothelaws&registrationofthecountyofAlameda California.
PRODUCTREGISTRATION
This Earthquake product can be registered by returning the Product Registration card attached to this manual. Please also retain sales
receipt,whichrepresentsproofofpurchase.

Specifications & Performance
-4-
Typical Near Field Measurements
Specifications
Performance
Power: 150 watts
Frequency Response: 28-180Hz
Dimensions
Power Line Voltage: 115-230~AC / 50/60Hz
Output Levels:
Height: 9-15/16" (252.4mm) - including 3/8” (10.4mm) legs
Width: 7-11/16” (194mm)
Depth: 14-1/4" (361mm) - including amplifier controls
Weight: 16.5 lbs / 7.5 kgs
Greater than 100dB peak SPL (includes room gain) from 40Hz to 135Hz.

Product Overview
Class "A/B" Amp
!
!
!
!
150 Watts Class "A/B" high efficiency power amplifier
12dB/Octavevariablefilterfrom40Hzto180Hz
Automatic signal detection circuitry. When "ON", it
automatically turns on the subwoofer when an audio
signal is detected. It also shuts the subwoofer off after
30minutesifnosignalisdetected
Lowlevel(RCA)audioinputs
-5-
115 / 230V power
connector with
built-in fuse for
maxprotection.
115/230Vselector
Signal detection circuitry.
W h e n " O N " , i t
a u t o m a t i c a l l y
shuts off the amplifier in
30 minutes if music is not
detected.
Volume control to manually
adjust the subwoofer’s sound
level. Always start at the MIN
position and increase slowly
untildesiredvolumeisreached.
0-180° Phase switch for
precision bass response
control.
Powerlightindicator.
RED:Standby
GREEN:ON
Variable 12dB per
octave, low pass filter.
R a n g e 4 0 - 1 8 0 H z
Recommended general
settingat2o'clock.
Low level (RCA)
audio input,
in high pass
mode@100Hz.
FF6.5 Transmission Line Design

Positioning Your Subwoofer
-6-
FF6.5 Subwoofer
More Bass Output; Least even bass response
FF6.5 Subwoofer
Moderate Bass Output; More even bass response
FF6.5 Subwoofer
Lowest Bass Output; Most even bass response
SubwooferPlacement
There is no argument among audio
professionalsthattheloudestbassoutput
from a subwoofer comes from corner
placement. The sound flaring outward
from a room corner focuses low
frequencies giving them no place to go
but toward you. In the case of
subwoofers,thereisnoautomaticpenalty
in giving overall balance for this peak
bass, since your main speakers can be
located elsewhere. It still may be too
much bass for your room or (more
particularly) your favorite listening spot in
the room, but unless you are seated in a
“void” spot, where sound from the sub is
cancelled or diminished by out-of-phase
reflections from elsewhere, there should
beplentyofbassfromcornerplacement.
If you are seated in such a void spot, your
only real choices are to move either the
subwoofer or your listening position until
the bass returns to the point that satisfies
yourlisteningcriteria.Turningup the level
control or changing the crossover point
almost certainly won't help much. But
flipping the phase control 180 degrees
sometimes may make a difference,
especially if the void is a product of
cancellations caused by interaction with
lowfrequenciesfromyour
mainspeakers.
UsingTwoSubwoofers
If you choose the use two woofers, the
sound output will double (an increase of
5dB).Locatethewooferswithoneineach
corner and experiment with the location
and phase control to achieve the best
bassresponse.
Always drive each woofer through the
Left/Mono input even though you are
driving one woofer on a right channel
drive and the other with a left channel
drive. If your pre-amplifier has a single
Sub/LFE output, use a 'Y' cable to split it
intotwooutputs.

Connecting Your Subwoofer
-7-
LowLevel(RCA)InputConnection
1.LocatetheLINEINRCAontheFF6.5amplifier.
2. Connect the FF6.5 to the signal source, i.e.AV receiver. Even though there is no need to have both
RCAs to the signal source since the subwoofer is often operated in mono signal, we recommend
connectingthereceivertobothRCAinputsinordertoobtainhighersignallevel.
3.If needed, connect the LINE OUTRCAto another amplifier to drive satellite speakers (front or rear).
TheLINEOUTRCAhashighpassfilteredsignalatabout70Hz(5dB/Octavecutoff).
SUB / LFE
OUT L. SPKR
+ - + - + -
R. SPKRCENTER
Amplifier or
Receiver
FF6.5 Amplifier
Plate
