NOVAERUS Protect 900 User manual

Protect 900 User Manual
(NV900)
Novaerus, US Inc.
35 Melrose Pl.
Stamford, CT 06902
Phone: [phone]
www.novaerus.com
Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
2
Table of Contents
1. Intended Purpose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Labeling Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. ClassicationofEquipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5. TechnicalSpecications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7. Instructions for Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
8. Wall Mounting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
9. Service and Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
10. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
11. ProductCertications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
12.APPENDIXA.GuidanceandManufacturer’sDeclarations . . . . . . . . . . .11

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 3
1. Intended Purpose
The intended purpose of the Novaerus Protect 900 (NV900) is to improve the
quality of air.
Please read and follow all instructions in this manual.
2. Labeling Symbols
Symbol Meaning
Caution, Consult User’s Manual
Caution, High Voltage
Date of Manufacture
Manufactured for or by
Serial Number
This product has been tested by UL to nationally recognized
safety and sustainability standards.
On (Power)
Off (Power)
Slow Fan Speed (Speed 1)
High Fan Speed (Speed 2)

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
4
Accompanying documents must be consulted
Indicates the temperature limits to which the medical device
can be safely exposed.
Indicates the range of humidity to which the medical device
can be safely exposed.
3. ClassicationofEquipment
Item Classication
Protection of Harmful Ingress of Water IPX0 (No protection, indoor use only)
Mode of Operation Continuous
Oxygen Rich Environments Not intended for oxygen rich
environments
4. Warnings
GeneralWarnings
CAUTION: This High Voltage (HV) Device is not suitable for use within
atmospheres that contain potentially combustible or explosive dusts,
vapors or gases (including oxygen rich environments)
CAUTION: This device should not be operated during environmental sterilization
processes such as fogging and misting. Both the water vapor and
chemical agents may cause internal damage to device componentry
thus invalidating the warranty.
CAUTION: This equipment contains high voltage.
CAUTION: This equipment should be inspected frequently and collected dirt
removed from it regularly to prevent excessive accumulation that may
result in ashover or a risk of re.
CAUTION: To avoid the risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
CAUTION: Do not restrict the air ow of the product.

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 5
CAUTION: Do not open the tamper proof screws on the casing of the unit. No
serviceable parts are contained within.
CAUTION: No modication of this equipment is allowed. Do not modify this
equipment without authorization of the manufacturer.
CAUTION: Do not position the equipment where it is difcult to operate the
power switch.
CAUTION: For continued protection against risk of re, replace the fuse with the
same type and rating, Listed, 120 Vac, 3 Amps.
CAUTION: The non-detachable power supply cord is not eld replaceable by
service personnel. If damaged during inspection, the service should be
immediately disconnected from power and returned to Novaerus.
CAUTION: Do not use outdoors or near water.
CAUTION: Not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
CAUTION: To reduce the risk of electric shock, this equipment has a grounding
type plug that has a third (grounding) pin. This plug will only t into a
grounding type power outlet. If the plug does not t into the outlet,
contact qualied personnel to install the proper outlet. Do not alter
the plug in any way.
CAUTION: Use of this equipment adjacent to or stacked with other equipment
should be avoided because it could result in improper operation. If
such use is necessary, this equipment and the other equipment should
be observed to verify that they are operating normally.
CAUTION: Portable RF communications equipment (including peripherals such
as antenna cables and external antennas) should be used no closer
than 12 inches (30 cm) to any part of the Protect 900, including
cables specied by the manufacturer. Otherwise, degradation of the
performance of this equipment could result.
continued…

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
6
5. TechnicalSpecications
Wall mountable, countertop with
table stand or mounted on portable
high tower stand, supplied with 6.6 ft
power cord
ElectricalRating:
Single Phase, 100-120 VAC, 60 Hz
Fuse Rated at 120 VAC, 3 Amps, Listed
PowerConsumption:
Maximum 14W
ConstructionandColor:
Precision-cut fabricated metal casing
in a white anti-bacterial powder coat
nish
Dimensions:
14.4" (h) × 14.4" (w) × 4.5" (d)
Weight:
Approx. 10.4 lbs
ElectricalConnection:
Switched and fused with a grounded,
molded power cord
FanAirFlowVolume:
SPEED I: 129 CFM
SPEED II: 153 CFM
NoiseLevels:
SPEED I: 40 dB
SPEED II: 45 dB
OperatingConditions:
50 – 95 °F, 10 – 75% Relative Humidity
Shipping/StorageConditions:
41 – 122 °F, Maximum 95% Relative
Humidity
QualityandSafety:
Manufactured under ISO 9001, ISO
14001 & OHSAS 18001
IEC 60601-1, Third Edition
IEC 60601-1-2, Fourth Edition
UL 867 Safety for Electrostatic Air
Cleaners
6. Accessories
Table or High-Tower Stand (Sold Separately).

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 7
7. Instructions for Use
The product should be placed in a dry location and connected to a suitable
grounded outlet. The product is intended to be wall mounted or placed on a
stand. Please follow the wall mounting instructions included in this document.
Once the product is installed, turn the power switch to the on position. The
device is now operating and the blue light will be illuminated. The product
includes a fan speed switch to allow the product to be set on a slow or high
speed. Roman numeral I indicates slow speed, Roman numeral II indicates high
speed.
8. Wall Mounting Instructions
The mounting of this product shall be conducted by a person that is experienced
with the proper use of standard installation tools such as a drill, screw driver,
tape measure and level. The unit should be installed approximately two third’s up
the wall.
The product can be wall mounted using suitable fasteners for the corresponding
wall type. Fix the screws horizontally with a spacing of 7-1/8" (180 mm). Leave
the screw head protruding no more than 0.5" (12 mm) from the wall for hanging.
Ensure screws are tightly secured into the wall and a solid connection is made
between the screws and the unit. Ensure the product is level. Follow these
instructions depending upon mounting surface:
Hollow Wall Construction
For hollow wall installations studded with metal or wood framing and sheathed
with drywall, plaster, or plywood, an appropriate hollow wall xing such as a #10
re-usable anchor should be used.
Each of the two re-usable anchors used must be rated for a 20.0 lb. (9.1 kg)
rating minimum, and be the appropriate size for the sheathing thickness. Use #10
size minimum.
Typical drill size is 3/8" (9.5 mm) for the #10 re-usable anchor shown. Follow
manufacturer’s instructions.

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
8
For Concrete or Masonry Wall Construction
Use purposed 3/16" (4. 8 mm) concrete screws.
Each of the two screws must be rated for 20.0 lb (9.1 kg) minimum.
Typical drill size is 5/32" (4 mm) for the 3/16" (4.8 mm) concrete screw. Follow
manufacturer’s instructions and recommendation for drill depth for screws being
used.
Various types of concrete inserts are available that are adequate for use in
concrete, such as conical lead or anged polypropylene that will be adequate for
installation of the rack mount bracket. They must be individually rated to support
20.0 lb (9.1 kg) minimum.
Use sizes that support a #10 screw minimum.
Typical drill size is 5/16" (8 mm) for the #10 conical lead anchor for concrete.
Follow manufacturer’s instructions and recommendation for drill depth for insert
being used.
Typical drill size is 1/4" (6.35 mm) for the #10 anged polypropylene anchor for
concrete. Follow manufacturer’s instructions and recommendation for drill depth
for insert being used.
For Plywood Wall Construction
Use #10 1" (25 mm) screw. Each of the two screws must be rated for 20.0 lb (9.1
kg) minimum.

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 9
9. Service and Maintenance Instructions
Clean the body of the Protect 900 regularly to prevent dust from collecting.
1. Wipe away dust from the body of the device with a soft dry cloth.
2. Clean the air outlet with a soft dry cloth.
Air Intake Screen
Cleaning of the air intake screen is recommended monthly. To clean the air
intake screen, use a standard vacuum cleaner brush or compressed air in an open
ventilated area to blow the dust off the screen.
Use a bowl of soapy water to hand wash the scrim. While wearing gloves,
remove the scrim and soak for 5 minutes. Pat dry before replacing the scrim and
dispose of gloves.
It is recommended that the user inspect the air intake screen bi-weekly in the
rst 2 months of use to determine the most appropriate cleaning period for its
facility. If dust and debris has collected on the intake screen sufcient enough to
cause a signicant decrease in airow, more frequent cleaning may be required.
The air intake screen can be removed by pulling on the
cloth tab attached to the screen frame. The air intake
screen is removed from the top of the device. See image
with arrow indicating location of screen tab.
Replacingthescreen
When replacing the screen, please ensure that the screen is pushed down in the
track completely to ensure the air intake is completely covered by the screen.
You will feel the screen stop once it is fully inserted; no part of the screen frame
should be sticking out from the top of the unit.

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
10
The metal frame grid should be facing towards the rear of device as shown in the
image below.
An additional screen has been provided for each unit to allow for rotation during
the cleaning process. The Protect 900 unit should not be operated without the
air intake screen in place.
Service
Do not open the tamper proof screws on the casing of the unit. No serviceable
parts are contained within. The units should be opened by qualied Novaerus
personnel only.
10. Troubleshooting
Should the unit sustain severe damage and an increase in noise from the internal
parts is observed, discontinue use of the unit and contact a representative of
the Novaerus technical team for assistance. This product is not intended to be
repaired in the eld.
Should the unit not power on, or the fan stops working, check to ensure that the
fuse located on top of the unit is secured tightly in its socket. If, once the fuse is
replaced and the unit or fan does not turn on, immediately discontinue use.
11. ProductCertications
IEC 60601-1, Third Edition
IEC 60601-1-2, Fourth Edition
UL 867 Safety for Electrostatic Air Cleaners

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 11
12. APPENDIXA.Guidanceand
Manufacturer’sDeclarations
Table 201 – Guidance and manufacturer’s declaration – electromagnetic
emissions – for all equipment and systems
Guidance and manufacturer’s declaration – electromagnetic immunity
The Protect 900 is intended for use in the electromagnetic environment
specied below. The customer or the user of the Protect 900 should assure that
it is used in such an environment.
Emissionstest Compliance
RF Emissions
CISPR 11 EN 55011: 2009
+ A1: 2010
Group 1
The Protect 900 must emit
electromagnetic energy in order
to perform its intended function.
Nearby electronic equipment
may be affected.
RF Emissions
CISPR 11 EN 55011 Class B The Protect 900 is suitable for
use in all establishments including
domestic and those directly
connected to the public low-
voltage power supply network
that supplies buildings used for
domestic purposes.
Harmonic emissions EN
61000-3-2 Complied
Voltage uctuations /
icker emissions
EN 61000-3-3
Complied

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
12
Table 202 – Guidance and manufacturer’s declaration – electromagnetic
immunity – for all equipment and systems
Guidance and manufacturer’s declaration – electromagnetic immunity
The Protect 900 is intended for use in the electromagnetic environment
specied below. The customer or the user of the Protect 900 should assure that
it is used in such an environment.
Immunity
test
IEC60601
Test level
Compliance
level
Electromagnetic
environment - guidance
Electrostatic
discharge
(ESD)
EN 61000-
4-2
+/- 8 kV
contact +/- 15
kV air
+/- 2, 4, 6 & 8
kV contact
+/- 2, 4, 8 & 15
kV air
Floors should be wood,
concrete or ceramic tile.
If oors are covered with
synthetic material, the
relative humidity should be
at least 30%.
Electrical fast
transient/
burst
EN 61000-
4-4
+/- 2kV for
power supply
lines +/-1 kV
for input/
output lines
+/- 2kV for
power supply
lines +/- 1kV
for input/
output lines
Mains power quality
should be that of a typical
commercial or hospital
environment.
Surge EN
61000-4-5
+/- 1kV
differential
mode +/- 2 kV
common mode
+/- 0.5 & 1kV
differential
mode
+/- 0.5, 1 & 2
kV common
mode
Mains power quality
should be that of a typical
commercial or hospital
environment.
Voltage
dips, short
interruptions
and voltage
variations on
power supply
input lines
EN 61000-
4 -11
<5 % Ut (>95
% dip in Ut) for
0.5 cycle @ 0°,
45°, 90°, 135°,
180°, 225°,
270°, 315°
70 % Ut (30 %
dip in Ut) for
25 cycles
<5 % Ut (>95
% dip in Ut) for
5 sec
<5 % Ut (>95
% dip in Ut) for
0.5 cycle @ 0°,
45°, 90°, 135°,
180°, 225°,
270°, 315°
70 % Ut (30 %
dip in Ut) for
25 cycles
<5 % Ut (>95
% dip in Ut) for
5 sec
Mains power quality
should be that of a typical
commercial or hospital
environment. If the user of
the Protect 900 requires
continued operation during
power mains operation, it
is recommended that the
Protect 900 be powered
from an uninterruptible
power supply or battery.

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 13
Power
frequency
(50/60 Hz)
magnetic
eld
EN 61000-
4-8
30 A/m 30 A/m
Power frequency magnetic
elds should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE: Ut is the a.c.mains voltage prior to application of the test level.
continued…

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
14
Table 203 – Guidance and manufacturer’s declaration – electromagnetic
immunity – for equipment and systems that are not life-supporting
Guidance and manufacturer’s declaration – electromagnetic immunity
The Protect 900 is intended for use in the electromagnetic environment specied
below. The customer or the user of the Protect 900 should assure that it is used
in such an environment.
Immunity
Test
IEC60601Test
Level Compliance Level Electromagnetic environment - guidance
Conducted
RF
EN 61000-
4-6
Radiated
RF EN
61000-4-3
3 Vrms outside
industrial, scientic
and medical (ISM)
and amateur radio
bands.
6 Vrms in ISM and
amateur radio bands
150 kHz to 80 MHz
10 V/m 80 MHz to
2.7 GHz
27 V/m, 18 Hz PM
385 MHz
28 V/m, 50 %18 Hz
PM 450 MHz
9 V/m, 217 Hz PM
710 MHz
9 V/m, 217 Hz PM
745 MHz
9 V/m, 217 Hz PM
780 MHz
28V/m, 18 Hz PM
810 MHz
28 V/m, 18 Hz PM
870 MHz
28 V/m, 18 Hz PM
930 MHz
28V/m, 217 Hz PM
1720 MHz
28 V/m, 217 Hz PM
1845 MHz
6 Vrms 150 kHz
to 80 MHz
150 kHz to 80
MHz
10 V/m 80 MHz
to 2.7 GHz
27 V/m, 18 Hz PM
385 MHz
28 V/m, 50 %18
Hz PM 450 MHz
9V/m,217HzPM
710 MHz
9V/m,217HzPM
745 MHz
9V/m,217HzPM
780 MHz
28V/m, 18 Hz PM
810 MHz
28V/m,18HzPM
870 MHz
28V/m,18HzPM
930 MHz
28V/m, 217 Hz PM
1720 MHz
28 V/m, 217 Hz
PM 1845 MHz
28 V/m, 217 Hz
PM 1970 MHz
27 V/m, 217 Hz
PM 2450 MHz
Portable and mobile
RF communications
equipment should be
used no closer to any
part of the Protect
900, including cables,
than the recommended
separation distance
calculated from the
equation applicable to
the frequency of the
transmitter.
Recommended
separation distance
d = [1.17] Sqrt P
d = [1.17] Sqrt P...80MHz
to 800 MHz d = [2.33]
Sqrt P...800 MHz to
2.5GHz.
Where P is the
maximum output power
rating of the transmitter
in Watts (W), according
to the transmitter
manufacturer, and d
is the recommended
separation distance
in meters (m), eld
strengths from xed
RF transmitters, as
determined by an
electromagnetic site
survey a, should be less

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US 15
28 V/m, 217 Hz PM
1970 MHz
9V/m, 217 Hz PM
5240 MHz
9 V/m, 217 Hz PM
5500 MHz
9 V/m, 217 Hz PM
5785 MHz
5240 MHz
9 V/m, 217 Hz PM
5500 MHz
9 V/m, 217 Hz PM
5785 MHz
than the compliance level
in each frequency range
b.
Interference may occur in
the vicinity of equipment
marked with the
following
symbol:
NOTE1:At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2:These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reection from structures, objects and
people.
a. Field strengths from xed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio, AM
and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to xed
RF transmitters, an electromagnetic site survey should be considered. If
the measured eld strength in the location in which the Protect 900 is
used exceeds the applicable RF compliance level above, the Protect 900
should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as re-orientating or
relocating the Protect 900.
b. Over the frequency range 150 kHz to 80 MHz, eld strengths should be less
than [V1]V/m.
continued…

Document No. NOV-MNL-104
COPYRIGHT ©2021 Novaerus, US
16
Table 204 – Recommended separation distances between portable and mobile
RF communications equipment and the equipment and system – for equipment
and systems that are not life supporting
Recommended separation distances between portable and mobile RF
communication equipment and the Protect 900.
The Protect 900 is intended for use in an electromagnetic environment in
which radiated RF disturbances are controlled. The customer or the user of the
Protect 900 can help prevent electromagnetic interference by maintaining a
minimum distance between portable and mobile RF communications equipment
(transmitters) and the Protect 900 as recommended below, according to the
maximum output power of the communications equipment.
Rated maximum
output power of
transmitter W
Separation distance according to frequency of transmitter
m
150 kHz to 80
MHz d = [1.17]
Sqrt P
80 MHz to 800
MHz d = [1.17]
Sqrt P
800 MHz to
2.5GHz d =
[2.33] Sqrt P
0.01 0.12 0.12 0.23
0.1 0.37 0.37 0.75
11.17 1.17 2.33
10 3.70 3.70 7.36
100 11.7 0 11. 70 23.30
For transmitters rated at a maximum output power not listed above, the
recommended separation distance d in meters (m) can be estimated using
the equation applicable to the frequency of the transmitter, where P is the
maximum output power rating of the transmitter in watts (w) according to the
transmitter manufacturer.
NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reection from structures, objects and
people.
