Novatel GNSS-301L-A40 User manual

1
GNSS-301L-A40
GM-14915157 Rev 2 February 2019
USER GUIDE
The GNSS-301L-A40 is an active GNSS antenna that receives the GPS L1 1575.42 MHz frequency,
GLONASS L1 1592.95 – 1610.38 MHz frequencies and L-band 1525 – 1560 MHz frequencies.
This guide provides the basic information you need to install and begin using your new antenna.
ADDITIONAL EQUIPMENT REQUIRED
• A device with an antenna input port that both receives the RF signal and provides 3.8 - 6.0 VDC to
the antenna is required for the GNSS-301L-A40. NovAtel GNSS receivers provide the necessary
power through their antenna RF connectors.
• Coaxial cable with a male TNC connector
INSTALLING THE ANTENNA
Both the input DC power and the output RF signal use a single coaxial cable connected to the unit's TNC
female connector.
The antenna attaches to a surface with an ARINC-743 bolt pattern. Four screws pass through the antenna
housing.
To install the antenna:
1. Install the supplied o-ring into the groove on the antenna base.
2. Drill the mounting holes and the connector clearance hole on the mounting surface. See the Mechani-
cal Drawings section for mounting pattern details.
The integrator of this antenna is responsible for ensuring antenna installation meets all the
overall integrated system requirements.
Refer to Section 307 of www.faa.gov/documentLibrary/media/Advisory_Circular/
AC%2043.13-2B.pdf for information about antenna bonding in aircraft applications.
User supplied o-ring grease can hold the o-ring in the groove during installation.

2
3. Use the four supplied mounting screws to attach the antenna to the mounting surface. The o-ring com-
presses and creates a seal between the surface and the antenna.
Ref. # Description
1 Antenna
2 Countersink screws
3 Mounting surface
4 O-ring
5 Pre-drilled mounting holes
4. Remove the dust cap from the antenna’s TNC connector.
NovAtel recommends thread-locker (not included) on the mounting screws.

3
5. Attach the coaxial cable’s male TNC connector to the antenna’s TNC connector.
Ref.# Description
1 Mounted antenna
2 Mounting surface
3 TNC connector
4 Coaxial cable
6. Attach the other end of the coaxial cable to the antenna input port on the receiving device. The
receiving device must be equipped to provide power as detailed in the SPECIFICATIONS section of
this guide. All NovAtel GNSS receivers provide the necessary power through the antenna RF
connectors.

4
This illustration provides examples of where the antenna may be located on an aircraft or vehicle (not to
scale).
ANTENNA CARE
The GNSS-301L-A40 is designed to withstand the elements, including rain, snow and dust. However, to
ensure that the antenna performs optimally, keep the radome clean and brush off any ice or snow. In
addition, ensure the TNC connector remains clean and dry and replace the dust cap when a cable is not
connected.

5
SPECIFICATION
RF
Band L1 GPS L1 GLONASS L-Band
Operational band (typical) 1575.42 ±10 MHz 1609.0 ± 7 MHz 1542.5 ±17.5 MHz
Antenna gain (dBic) Free Space 4-foot Ground
Plane Free Space Free Space
90° zenith +5.5 +4.5 >+3.3 >+2.5
10° elevation -1.2 -1.4 >-3.2 >-4.7
20° elevation +0.3 +1.4 >-1.6 >-3.0
30° elevation +1.8 +2.2 >-0.2 >-2.3
60° – 90° elevation >4.8 >3.8 >+2.5 >+2.0
Beamwidth (dB) 106° 130° 106° 106°
LNA gain 40 dB
Polarization Right-hand circular
Noise figure (typical) 3.0 dB
Nominal impedance 50 
VSWR 2.0 : 1
POWER
Input voltage + 3.8 - 6.0 VDC
Current (typical)  mA @ 5V
PHYSICAL
Radome
diameter x height
7.62 cm (3.0 inches) W x 11.938 cm (4.70 inches) L x 1.303 cm (0.513
inches) H
Weight 184 g (6.5 ounces)
ENVIRONMENTAL
Maximum altitude 21,336 m (70,000 ft.)
Operating / storage
temperature -40° C to +85° C (-40° F to +185° F)
Vibration >30 G
Designed to meet these
standards DO-160D, MIL-C-5541, MIL-E-5400, MIL-I-45208A and MIL-STD-810

6
MECHANICAL DRAWINGS
Dimensions are in inches, followed by [mm]

7
PHASE CENTER
Please refer to the Mechanical Drawings before reading this section.
HEIGHT = Vertical phase center offset from antenna reference point or antenna reference plane (ARP),
see the MECHANICAL DRAWINGS section of this guide.
For relative offset numbers and phase center variation (PCV) tables, please visit the U.S. National
Geodetic Survey (NGS) website at www.ngs.noaa.gov/ANTCAL/. Look for ANTCOM ACC42G1215A_XT1.
Please check our website for updates to this manual at www.novatel.com/Downloads/docupdates.html and
the websites mentioned above.
If you need any further advice on this matter, please visit our website at www.novatel.com. Other methods
of contacting Customer Service can be found on the last panel of this guide.
WEEE
If you purchased a GNSS-301L-A40 antenna in Europe, return it to your dealer or supplier at the end of its
life. The objectives of the European Community's environment policy are, in particular, to preserve, protect
and improve the quality of the environment, protect human health and utilise natural resources prudently
and rationally. Sustainable development advocates the reduction of wasteful consumption of natural
resources and the prevention of pollution. Waste electrical and electronic equipment (WEEE) is a
regulated area. Where the generation of waste cannot be avoided, it should be reused or recovered for its
material or energy. WEEE products may be recognized by their wheeled bin label ( ).1
ROHS
The GNSS-301L-A40 is compliant with the European Union (EU) Restriction of Hazardous Substances
(RoHS) Directive 2011/65/EU.
WARRANTY POLICY
NovAtel Inc. warrants that its Global Navigation Satellite System (GNSS) products are free from defects in
materials and workmanship, subject to the conditions set forth on our web site:
www.novatel.com/products/warranty.
GNSS Antenna™ Modules: One (1) Year
Cables and Accessories: Ninety (90) Days
RETURN INSTRUCTIONS
To return products, refer to the instructions found under the Return Policy Tab on the warranty page:
www.novatel.com/products/warranty.
1. See www.novatel.com/products/compliance/environmental-compliance/ for more information.

8
