NOVOTEST TP-1M User manual

COATING THICKNESS GAUGE
NOVOTEST TP-1M
OPERATION MANUAL
2018

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
1
CONTENTS
1. General instructions: 2
1.1. Purpose of the device 2
1.2. Operation conditions 3
2. Specifications 3
3. Packing list 7
4. Labeling and packaging 9
5. The circuit diagram, principles of operation, indicators
and controls 9
5.1. Block-diagram 9
5.2. Operation principles 9
5.3. Device display 10
5.4. Device keyboard 10
6. Device Usage 11
6.1. Preparation and Set up 11
6.1.1. Operation with batteries 11
6.1.2. Charging batteries 12
6.2. Turning on 12
6.3. Measurements 13
6.4. Average values of measurements 14
6.5. Measured value scales 15
6.6. Calibration 16
6.7. Turning off 18
7. Safety precautions 19
8. Transportation and storage 19
9. Device testing 19
10. Testing certificate 20

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
2
The following operation manual explains the preparation,
setup, principles of operation, usage, and troubleshooting of
the Coating Thickness Gauge NOVOTEST TP-1M, the
Device thereafter.
1 General instructions
1.1 Purpose of the Device
The device is designed for measuring:
The thickness of:
dielectric and conducting non-ferromagnetic,
except for nickel, electrolytic covering on conducting
ferromagnetic base material with the use of
inductive converters F;
thick dielectric (bituminous, mastic and the
others) on ferromagnetic and non-ferromagnetic
base materials with use of parametric converters M;
dielectric covering on conductive non-
ferromagnetic base materials with use of parametric
converters NF;
conductive non-ferromagnetic coverings on
conductive non-ferromagnetic base materials with
use of converters NF;
Environmental conditions:
temperature of metal surface with the use of the
converter ST;
temperature of air, air moisture, dew-point with
use of the converter STMD;

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
3
Also for the slot dept measuring, and
estimation of the surface roughness with the use
of converters DSH.
1.2 Operation conditions
temperature of the air
from -5 to +40С
temperature for the
converters
-20 to +40С
relative air moisture
- 98% at the
temperature of + 35С
2 Specifications
2.1 Measuring range of the surface thickness
- The inductive converters F(non-ferromagnetic surfaces on
ferromagnetic base materials):
Type of the probe
Measuring range, µm
F-0,5
0-500
F-2
0-2000
F-5
0-5000
- The parametric converters NF (dielectric coverings on the
conductive non-ferromagnetic base materials):
Type of the probe
Measuring range, µm
NF-0,5
0-500
NF-2
0-2000

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
4
- The parametric converters M(dielectric coverings on the
conducting ferro- and non-ferromagnetic base materials):
Type of the probe
Measuring range, µm
M12
0-12000
M30
0-30000
2.2 Measuring range of the slot depth and
estimation of the surface roughness:
Type of the probe
Measuring range, µm
DSH1
0-300
2.3 Measuring range of the temperature,
moisture and the dew-point:
- Temperature indication of the metal surface:
Type of the probe
Measuring range, С
ST
-50…+125 С
- Temperature indication of the air, air moisture, and the
dew-point:
Type of the probe
Measuring range
STMD
air moisture: 0 - 100%
temperature: -50…125°С
dew-point: -15 - +40°С

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
5
2.4 Measurement accuracy of the covering
thickness with the roughness of surface
Ra≤1±0,1 µm:
Type of the probe
Measurement accuracy, mm
F-0,5
±(0,03h + 0,001)
F-2
±(0,03h + 0,002)
F-5
±(0,03h + 0,002)
NF-0,5
±(0,03h + 0,001)
NF-2
±(0,03h + 0,002)
M12
±(0,03h + 0,01)
M30
±(0,03h + 0,02)
h –rated value of the depth , mm
2.5 Limits of the tolerable error of the slot
depth measuring and estimation of the surface
roughness:
Type of the probe
Measurement accuracy, mm
DR1
±(0,03h + 0,002)
h –rated value of the slot depth, mm
2.6 The Measurement accuracy of the covering
thickness at temperature ranging from
-10Сto + 40С:
Type of the probe
Measurement accuracy, mm
F-0,5
±(0,02h + 0,002)
F-2
±(0,02h + 0,002)
F-5
±(0,02h + 0,002)

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
6
NF-0,5
±(0,02h + 0,002)
NF-2
±(0,02h + 0,002)
M12
±(0,02h + 0,1)
M30
±(0,03h + 0,1)
h –rated value of the thickness, mm
2.7 The additional error limits of the slot depth
measuring and estimation of the surface
roughness at temperature ranging from
-10Сto + 40С:
Type of the probe
Measurement accuracy, mm
DSH
±(0,03h + 0,002)
h –rated value of the slot depth, mm
2.8 Overall dimensions:
Name
Overall dimensions, mm
Information
processing unit
120х60х25
F-0,5
Ø10х35
F-2
Ø12х40
F-5
Ø18х40
NF-0,5
Ø15х60
NF-2
Ø15х60
M12
Ø18х40
M30
Ø25х60
DSH
Ø18х40

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
7
2.9 Weight:
Name
Weight, kg
Information
processing unit
0,25
Probes
0,1
2.10 Power supply and the time of the
continuous operation:
2.10.1Power supply is provided by 2 NiMH
rechargeable batteries or cells with the voltage
rating 1,5V.
2.10.2Time of the continuous operation from
recharged batteries, no less than 20 hours.
2.10.3The device is turned off automatically 1 minute
after the last measurement was made.
3 Packing list:
3.1 Information processing unit –1 pc.
3.2 Probes:
Type
Number
Measuring
range of the
thickness
Purpose
F-0,5
0-500 µm
Control of the paint and
galvanic covering
F-2
0-2000 µm
Control of the paint and
galvanic covering
F-5
0-5000 µm
Control of the paint and

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
8
mastic covering
NF-0,5
0-500 µm
Control of the anodic-
oxide films and paint
and galvanic coverings
on low-sized and short
radius parts
NF-2
0-2000 µm
Control of the anodic-
oxide films and paint
and galvanic coverings
M12
0-12 µm
Control of the mastic
covering
M30
0-30 µm
Control of the mastic
covering
DSH
0-300 µm
Control of the surface
roughness after sanding
and bead-bloating
ST
-50…+125 С
Control of the
temperature
STMD
moisture:
0 - 100%
temperature:
-50…125°С
dew-point:
-15 - +40°С
Control of the
temperature, moisture
and the dew-point
3.3 Set of reference thickness samples –1 pc.
3.4 Rechargeable battery –2 pcs.
3.5 Charger –1 pc.
3.6 Operation manual.
3.7 Case

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
9
4 Labeling and packaging
The following information is on the case:
Manufacturer name and logo;
Serial number and the manufacturing date located
on the back cover plate.
The information processing unit and the probes are
kept in a case that protect from transformation
damage.
5 The circuit diagram, principles of operation,
indicators and controls
5.1 Block-diagram
The device includes the electronic module and
probe, attached with the connector. Detachable
connector is on the upper front surface of the case.
Navigation buttons are on the front panel, as well as
the graphic indicator. The battery located in the
lower back spot of the case under the cover in the
compartment for batteries.
5.2 Operation principles
Operation of the device is based on measuring
oscillator frequency with coil of eddy current
parametric converter in the circuit. The frequency of
the oscillation depends on covering thickness. The
result of the measuring is indicated on the display.

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
10
5.3 Device display
Display indicates the measured thickness of coating
in mm or µm. The charging level of batteries and the
type of the connected probe also shown on the
display.
5.4 Device keyboard
Keyboard:
Keys function:
5.4.1.1 - turn on/off.
5.4.1.2 - set zero.
5.4.1.3 - the measuring scale
options.

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
11
6 Device Usage
6.1 Preparation for use
6.1.1 Operation with batteries
Connect the probe to the connector on the
panel of the information processing unit.
1. Install batteries in the battery compartment
using polarity.
2. For checking the charge of the batteries
press and hold the button .
3. The Level of the batteries charging is shown
on the left upper corner of the display as a small
battery icon. The dark battery color means the
batteries is fully charged. During discharging the
battery icon segments disappear consecutively,
from left to the right. One dark segment or
absence of segments means that the batteries
needs recharging. The battery icon is present on
the display in any mode of the device operation.
4. For charging the batteries turn off the device
pressing the button .After that take off
the batteries from the battery compartment and
charge it according to p.6.1.2.
5. After installing the recharged batteries in the
battery compartment turn on the device.

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
12
6.1.2 Charging the batteries
For charging the batteries:
install the batteries to the charger;
connect the charger to the mains power
supply.
The batteries will be fully charged in
approximately 14 hours. It is forbidden to leave
the charger alone during charging. After long
storage period the batteries need recharging
once every 2 months, even if it was not used.
6.2 Turning on the device
Prepare the device for use according to p.6.1 and
turn on it pressing the button .
Logo appears on the display after pressing the
button:
After that the device is ready for operation and on
the display the following information will appear:

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
13
F-2 —type of probe
0,000 —thickness of the covering value
The device is ready for measurements.
6.3 Measurements
6.3.1Prepare the device to operation in accordance
with p.6.1. and turn on the device in accordance
with p.6.2.
6.3.2Install the probe perpendicularly on the surface
and press it steadily.
6.3.3Wait for constant value of thickness of the
covering on the display.
6.3.4Lift the probe from the surface and raise it in
air.
6.3.5After lifting the probe in the air the display will
indicate the last result of the thickness of the
covering, which will be changed just after the next
measurement.
6.3.6Indication of the name of the probe becomes
inverted. The following measurement will be
possible after indication of the name of the probe
takes the usual style.
Note: Zero setting is recommended for the probe
according to p.6. 5. in the case of changing

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
14
conditions of use (considerable change of the
temperature, conduction of the material) at first
activation of the probe.
6.4 Average values of measurements
The automatic averaging mode provides a default
calculation of final measurement result in the
arithmetic mean value together with the last
measurements.
6.4.1For switching on the mode of averaging press
and hold button , for more than 2 seconds.
6.4.2On display the following information will
appear:
6.4.3For resetting measurement average and
beginning new series of measurements press
button .
Counter of the
measurements
Last
measuremen
t
Measurement
average

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
15
6.4.4To return from mode with averaging press and
hold button for more than 2 seconds. The
device will return to the usual mode.
6.5 Scales of the measured value
6.5.1For choosing the scale of the measured value
(mm or µm) press .
6.5.2The chosen scale will be indicated on the
display.
6.6 Calibration
To provide an adequate measurement with the
device of the real thickness of the covering calibrate
the device. For it you need to prepare a sample of
the tested part similar or close in geometric,
electrophysical properties and in the type of
mechanical treatment of the tested product.
6.6.1 Setting zero
6.6.1.1 Install the probe perpendicularly on
prepared sample without covering normal to the
surface and press it steadily. Wait for indications
to remain constant.

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
16
6.6.1.2 Press button , after that figures:
0.000; 00.00; 000.0; or 0 will appear on the
display depending on the type of the probe and
used scale.
6.6.1.3 For checking the accuracy of the setting
zero make repeated measurements on the
prepared sample without covering. Reading
must be within the range of 0±2 µm.
Note: Zero setting is recommended for the probe
according to p.6. 5. in the case of changing
conditions of use (considerable change of the
temperature, conduction of the material) at first
activation of the probe.
6.6.2One-point correction
6.6.2.1 Switch the mode of the measurements
with averaging in accordance with p.6.4.
6.6.2.2 Prepare the sample for calibration, for it
put the sample of the reference thickness tightly
against the smooth base.
6.6.2.3 Make no less than 3 measurements.
6.6.2.4 Switch the mode of correction. For it
press twice button , after that two quick

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
17
presses , and after that again press
twice.
6.6.2.5 Indication of averaged value of the
thickness of the covering will become inverted.
Display will be as follows:
6.6.2.6 Use buttons and for
setting adequate average measurements to the
rated value of the thickness of the covering.
6.6.2.7 Press button for ending one-
point correction.
6.6.2.8 The inverted indication of the value in the
right part of the display means that the device
use settings with one-point correction.
6.6.2.9 After above procedures make several test
measurements. If inaccuracy does not exceed

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
18
value specified in p.2.4. the device is ready for
use, otherwise repeat the calibration.
Note: After changing a part for measurements for a
part with significant difference in properties, calibrate
the device for the new part again.
6.6.3Resetting one-point correction
6.6.3.1 In case of wrong calibration for resetting
the probe make measurement on a sample or a
part without covering, and after that press and
hold button for more than 5 seconds.
6.6.3.2 Indication of the scale in the right part of
the display will cease to be inverted.
6.7 Turning off the device
6.7.1For turning off the device press and hold
button .
6.7.2If measurements were not made during 1
minute, the device would switch off automatically.
7 Safety precautions
7.1 Use of the device is allowed only after reading the
operation manual.

Development and manufacturing of
non-destructive control units and
system
Coating Thickness Gauge NOVOTEST TP-1M
19
7.2 Minor malfunction the device may be fixed after
its turning off, repair is done only by NOVOTEST.
8 Transportation and storage
8.1 The device must be kept at the ambient
temperature from +5 to +40°Сand atmospheric
moisture below 80% at the temperature 25°С.
8.2 The storage place must be free off dust, acid
vapor, alkalis and aggressive gas.
8.3 Transportation of the device can be done by any
type of transport, in accordance with rules of
transportation.
8.4 During transportation, loading and keeping at the
storehouse the device must be protected against
shocks, push and moisture.
9 Device testing
9.1 The device testing must be done no less than
once a year.
9.2 The device testing can done only in Metrologic
and standards center in according with
methodological instructions applied.
