Novus NVIP-ATM200 User manual

U s e r ’s m a n u a l
NVIP-ATM200

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
2
IMPORTANT SAFEGUARDS AND WARNINGS
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of the following directives and national regulations
implementing the directives:
 Electromagnetic compatibility EMC 2004/108/EC.
 Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well as
75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European 1000VAC Directive on Waste Electrical and Electronic
Equipment (2002/96/EC) and further amendments. By ensuring this product is disposed of correctly, you will
help to prevent potential negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. It shall be handed over to the applicable collection point for used up electrical and
electronic equipment for recycling purpose. For more information about recycling of this product, please contact
your local authorities, your household waste disposal service or the shop where you purchased the product.
RoHS Directive 2002/95/EC
Out of concern for human health protection and friendly environment, we assure that our products
falling under RoHS Directive regulations, regarding the restriction of the use of hazardous
substances in electrical and electronic equipment, have been designed and manufactured in
compliance with the above mentioned regulations. Simultaneously, we claim that our products have
been tested and do not contain hazardous substances whose exceeding limits could have negative
impact on human health or natural environment
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
Excluding of responsibility in case of damaging data on a disk or other devices:
The manufacturer does not bear any responsibility in case of damaging or losing data on a disk or other devices
during device operation.
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN PRODUCT IN
USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR IF IT DOES
NOT ARISE FROM THE USUAL APPLICATION OF THE PRODUCT, MANUFACTURER MUST BE
CONTACTED UNDER THE RIGOR OF EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR
THE RESULTS OF SUCH AN ACTION.

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
3
IMPORTANT SAFEGUARDS AND WARNINGS
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER
DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH
THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO
USER-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE
PERSONNEL MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
1. Prior to undertaking any action please consult the following manual and read all the safety and operating
instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual is
necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct
influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the user’s
manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer is
forbidden;
7. You are not allowed to use the camera in high humidity environment (i.e. close to swimming pools, bath tubs,
damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.) is not
recommended since it may lead to heat build-up and damaging the device itself as a consequence;
9. Mounting the camera on unstable surface or using not recommended mounts is forbidden. Improperly
mounted camera may cause a fatal accident or may be seriously damaged itself. The camera must be mounted
by qualified personnel with proper authorization, in accordance with this user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with those
specified by the producer in the camera technical datasheet. Therefore, it is forbidden to supply the camera
from a power sources with unknown parameters, unstable or not meeting producer’s requirements;

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
4
TABLE OF CONTENTS.....................................................................................................4
1. FOREWORD INFORMATION .....................................................................................6
1.1. General Characteristics........................................................................................6
1.2. NVIP-ATM200 tech specification ......................................................................7
1.3. Package contents..................................................................................................8
2. START-UP AND INITIAL IP CAMERA CONFIGURATION .................................9
2.1. Camera dimensions..............................................................................................9
2.2. Description of crucial connectors .......................................................................9
2.2. Camera installation ............................................................................................10
2.4. Starting the IP camera........................................................................................11
2.5. Initial configuration via the Web browser.........................................................13
3. NETWORK CONNECTION UTILIZING WEB BROSWER ................................14
3.1. Recommended PC specification for web browser .............................................14
3.2. Connection with IP camera via the Internet Explorer ........................................14
3.3. Connection with IP camera via the Mozilla Firefox ..........................................16
4. WWW INTERFACE - WORKING WITH IP CAMERA.........................................16
4.1. Displaying live pictures......................................................................................16
4.2. Camera configuration .........................................................................................19
4.2.1. System settings...........................................................................................20
a. System information...................................................................................20
b. User management .....................................................................................21
c. System update...........................................................................................22
4.2.2. Network......................................................................................................23
a. IP Settings.................................................................................................23
b. HTTPS......................................................................................................25
c. SNMP .......................................................................................................26
d. IP Filter.....................................................................................................27
e. QoS/DSCP ................................................................................................27
f. IEEE 802.1x ..............................................................................................28
g. DDNS .......................................................................................................29
h. Server (Mail,FTP,Samba).........................................................................30
TABLE OF CONTENTS

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
5
4.2.3. A/V settings ............................................................................................... 32
a. Image setting ............................................................................................ 32
b. Video settings........................................................................................... 33
c. Audio settings .......................................................................................... 34
4.2.4. Event settings............................................................................................................. 35
a. Events....................................................................................................... 35
b. Schedule................................................................................................... 37
c. I/O Settings .............................................................................................. 38
e. Log list ..................................................................................................... 39
f. SD memory card....................................................................................... 39
5. ELECTRIC CONNECTORS AND ACCESORIES ................................................. 42
5.1. Description of camera connectors...................................................................... 42
5.2. SD card installation ........................................................................................... 43
5.3 List of supported SD cards.................................................................................. 44
6. RESTORING FACTORY DEFAULTS .................................................................... 45
6.1. Restoring software factory defaults ................................................................... 45
6.2. Restoring hardware factory defaults in IP cameras ........................................... 45
TABLE OF CONTENTS

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
6
1. FOREWORD INFORMATION
1.1. General Characteristics
 Modular, compact camera module enables the installation of the reach of conventional cameras
 Electronic day/night function
 Imager resolution: 2.0 megapixels
 Min. Illumination: 0.1 lx/F=2.0 - color mode, 0.1 lx/F=2.0 - B/W mode
 Wide Dynamic Range (WDR)
 Digital Slow Shutter (DSS)
 Digital Noise reduction (DNR)
 Privacy zones: 3
 1 alarm input and 1 output
 Other functions: mirror , 180° image rotation, antifog
 Built-in webserver: video compression and real-time network transmission
 Compression: H.264, M-JPEG
 Video processing resolution:
- 1920 x 1080 (FullHD)
- 1280 x 720 (HD720)
- 640 x 480 (VGA)
- 320 x 240 (QVGA)
- 176 x 144 (QCIF)
 3 streams: compression, resolution, speed and quality
 RTP/RTSP protocol support for video transmission
 Network connection control and IP address check function
 Pre- & post-alarm functions - video recording in AVI format
 Schedule recording function
 Motion detection
 Support for mobile devices - 3GPP stream
 Bidirectional audio transmission
 Micro SD/SDHC card support
 Diverse definition of system reactions to alarm events: e-mail with attachment, saving file on FTP
or NAS server, saving file on SD/SDHC card, alarm output activation
 Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring,
playback and remote IP devices administration
 Power supply: 12 VDC/PoE (Power over Ethernet)
FOREWORD INFORMATION

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
7
FOREWORD INFORMATION
1.2. NVIP-ATM200 specification
NVIP-ATM200
Pick-up Element 2 MPX, CMOS imager, 1/2.7”
Number of Effective Pixels 1920 (H) x 1080 (V)
Min. Illumination 0.1 lx/F=2.0 –color mode (AGC on)
0.1 lx/F=2.0 black/white mode (AGC on)
Digital Slow Shutter (DSS) x5
Digital Noise Reduction (DNR) Yes
Wide Dynamic Range 8 levels
LENS
Type Pinhole, f=4.3 mm/F=2.0
Angle of View (H) 73°
DAY/NIGHT
Type Elctronic day/night
Switch Mode Auto
NETWORK
Stream Resolution 1920 x 1080 (FullHD), 1280 x 720 (HD720), 640 x 480 (VGA),
320 x 240 (QVGA), 176 x 144 (QCIF)
Frame Rate 30 fps for each resolution
Multistreaming Mode 3 streams
Video/Audio Compression H.264, M-JPEG /G.711(32K,24K)
Number of Simultaneous Connections Max. 5
Network Protocols Support ONVIF(2.2), IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE
802.1X, RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP,
3GPP, SAMBA, Bonjour
PC Software NOVUS NMS, Internet Explorer, Google Chrome, Opera, Mozilla Firefox
OTHER FUNCTIONS
OSD IE browser, Polish, English, Russian
Privacy Zones 3
Motion Detection Yes
Prealarm/Postalarm 0 - 5 s/ 0 –10 s
System Reaction to Alarm Events E-mail with attachment, saving file on: FTP server/NAS/memory card, alarm
output activation
INTERFACES
Video Output BNC,1.0 Vp-p, 75 Ohm- maintenance only
Audio Input/Output 1/1
Alarm Input/Output 1/1
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
Memory Card Slot microSD
INSTALLATION PARAMETERS
Dimensions (mm) Camera module : 36 (W) x 36 (H) x 20 (D)
Main module : 50 (W) x 27 (H) x 97.9 (D)
Cable lenght between modules : 3000
Weight 280 g
Enclosure Black, aluminium
Power Supply PoE,12 VDC
Power Consumption 2.88 W (DC 12V) , 4,32 W (PoE)
Operating Temperature 0°C ~ 45°C

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
8
1.3. Package contents
After you open the package make sure that the following elements are inside:
 IP camera (two modules)
 Short version of user’s manual
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
FOREWORD INFORMATION

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
9
2. START-UP AND INITIAL IP CAMERA CONFIGURATION
2.1. Camera dimensions
Dimensions in millimeters. The length of the cable connected the camera module is 3 m.
2.2. Description of crucial connectors main module
START-UP AND INITIAL CAMERA CONFIGURATION
1. Alarm input/output and audio connections
2. RJ-45 connector for connecting camera module
3. 12 VDC Power socket
4. Analog video output for connecting BNC connector (maintance only)
5. Ethernet 100 Mb/s (RJ-45 connector)
12345

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
10
START-UP AND INITIAL CAMERA CONFIGURATION
2.3. Camera installation
A) Select a location for the camera module and attach the stand to the base of the camera module with
the screw.
B) Place the camera between the forks stand and mount module with two screws.
C) Adjust the camera position and tighten the mounting screws

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
11
D) Attach the main unit and connect the camera module to the port labeled "Signal recevier”
E) (Optional) Setting the camera using the service of the analog output (BNC).
Connect the BNC connector for analog video output connector (white color video terminal,
black terminal G). Then connect the monitor to the BNC output service
12 VDC to 12 VDC power connector or cable network with PoE PoE Etherent connector.
After about 30 seconds, you should see the image from the camera. Set the camera on the selected
scene. In the upper left screen shows information on the current IP address of the camera.
2.4. Starting the IP camera
In order to start the camera, connect the Ethernet cable into the RJ45 network IP cameras, and the other
end to a network switch PoE (IEEE 802.3af).
You can also power the camera and the external stabilized power supply with parameters satisfying the
requirements of the camera.
After starting power the green LED on the Ethernet port should start blinking. The process of starting a
camera that can take about 1 minute. After this time, you can try to connect to the camera using a web
browser.
The recommended way to start configuring the IP camera is to connect to the PC or laptop in a separate
PoE switch, which is not connected to other devices. In the case of external power supply is sufficient
to use any network switch or cable connected directly to the computer. In order to obtain the
information needed to configure the network (IP address, gateway, netmask, etc.), please contact your
network administrator.
START-UP AND INITIAL CAMERA CONFIGURATION
Main unit Camera module

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
12
START-UP AND INITIAL CAMERA CONFIGURATION
 Connection utilising network switch with PoE support
 Connection utilising external power supply and network switch
 Connection utilising external power supply directly to the computer
Note : External power adapter is not included in the kit.
Computer
Main unit
Network Switch PoE
Network transmision
Power supply and
network transmission
Network transmision
Network transmision
Computer
Network Switch
12 VDC Power
Main unit
Main unit
Network transision–cross over cable
Computer
12 VDC Power

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
13
2.5. Initial configuration via the web browser
1. IP address= 192.168.1.200
2. Network mask - 255.255.255.0
3. Gateway - 192.168.1.254
4. User name - root
5. Password - pass
Knowing the camera’s IP address you need to appropriately set PC IP address, so the two devices can
operate in one network subnet ( e.g. for IP 192.168.1.1, appropriate address for the camera ranges from
192.168.1.2 to 192.168.1.254, for example 192.168.1.60). It is not allowed to set the same addresses for
camera and PC computer
You can set network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera or select
DHCP mode (DHCP server is required in this method in target network) by using web browser or by
NMS software. When you use DHCP server check IP address lease and its connection with camera
MAC address to avoid changing or losing IP address during device operation or network/DHCP server
breakdown. You have to remember to use a new camera IP address after changing network parameters.
After network setting configuration has been done, the camera can be connected to a target network.
START-UP AND INITIAL CAMERA CONFIGURATION

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
14
3. NETWORK CONNECTION UTILIZING WEB BROSWER
3.1. Recommended PC specification for web browser connections
Requirements below apply to connection with an IP camera, assuming smooth image display in
1280x800 resolution and 30 fps speed.
1. CPU Intel Dual Core 2.53 GHz or newer
2. RAM Memory min. 1024 MB
3. VGA card (any displaying Direct 3D with min. 128 MB RAM memory)
4. OS Windows 7, Windows Vista, Windows XP
5. Direct X version 9.0 or newer
6. Network card 10/100/1000 Mb/s
3.2. Connection with IP camera via the Internet Explorer
You have to enter camera IP address in the Internet Explorer address bar. If IP address is correct user
login window will be displayed:
Default user is root and default password is pass.
For safety reasons, it is recommended to change default user name and password.
NETWORK CONNECTION UTILIZING WEB BROSWER

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
15
When you log on to the camera, web browser will download the applet for displaying images from the
camera. Depending on the current Internet Explorer security settings it may be necessary to accept
an ActiveX control. To do this, click the right mouse button on the message, select "Install Active X
control" and then click Install.
If the installation fails, changing security settings for the IE browser is required. In order to do that,
please choose: Tools > Internet options > Security tab > Custom level and:
 Under Download unsigned ActiveX controls - select either Enable or Prompt
 Under Initialize and script ActiveX controls not marked as safe - select Enable or Prompt
You can also add the camera’s IP address to “trusted zone” and set lowest security level for it.
In addition, when working in Windows Vista the ActiveX applet may be blocked by Windows
Defender. In such case you should allow to run this applet, or simply disable the Windows Defender.
NETWORK CONNECTION UTILIZING WEB BROSWER

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
16
In Internet Explorer 11 when problems occurs with connecting to the applet, page have to be added to
the Compatibility View settings. Select the Compatibility View Settings and then click the Add button to
add the website address of the camera. Then select the Close button.
3.3. Connection with IP camera via the Mozilla Firefox
It is also possible to connect to the camera by using Mozilla Firefox, but this browser doesn't offer full
functionality of the camera, so the recommended browser is Internet Explorer. The first run of the
IP camera in Firefox is very similar like in the IE. After you type the correct IP address you have to
write correct username and password. The default user is root and password is pass. Next, you will be
prompted to install the missing plug-in. You must be logged as administrator to install the plug-in
correctly. Then you have to follow the instruction below:
NETWORK CONNECTION UTILIZING WEB BROSWER
Click this link

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
17
A window depicting installation of particular components is then displayed. After proper installation
pictures from the camera should become visible
NETWORK CONNECTION UTILIZING WEB BROSWER
Select Run
Double clik
Choose Save file

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
18
4. WWW INTERFACE –WORKING WITH IP CAMERA
4.1. Displaying live pictures.
1. The size of the page selector
2. Stream selection (if available)
3. Outputs - activate or deactivate alarm output of camera (if available)
4. Visitors online - information about number of connected viewers
5. Activate speakers - enables sending audio from PC to camera audio output (if available)
6. Snapshot - saves current frame in JPEG format
7. Setup - camera configuration
8. Alarm - information about alarm input triggered by motion detection
WWW INTERFACE - WORKING WITH IP CAMERA
8.Alarm 9. OSD.
6.Snapshot
7.Setup
5.Speaker
2. Streaming
selection
3.Outputs 4.Online
connection
1. View Size
Selection

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
19
9. OSD - default OSD display containing time and date
Right mouse button click on the live screen view allows to use the following functions:
1. Snapshot - saves the current frame in JPEG format
2. Record start/record stop - starts or stops local disc video recording (including audio)
3. Mute - disables sound from camera (if available)
4. Full screen - switches to live view mode in full screen (Full screen mode is also enabled after
double-clicking on screen).
5. Digital zoom - Launch digital zoom function
After enabling digital zoom, window for navigating digital zoom is displayed.
Please click the Enable digital zoom first, next choose zoom factors and select desired place on the
screen to zoom in. Green rectangle indicates selected part of picture.
6. Frame Buffm Sec - Build a buffer to accumulate several video frame and play at a regular intervals.
This function can make video smooth-going when the Network speed is slow and lag. If you select
“100”, the interval between every frame is fixed to 100 mSec. The slower the Network is, the bigger
value should be selected. The default value is null.
4.2. Camera configuration
After clicking Setup button web page switches to configuration mode. On the left hand side you can see
a list of camera parameters.
System - System settings
Network - Network settings
A/V setting - Audio and video settings
Event setting - Event and action settings
To get back to live view mode you have to click Live button in bottom-right corner of screen.
WWW INTERFACE - WORKING WITH IP CAMERA

NVIP-ATM200 User’s manual ver.1.0.
All rights reserved © AAT Holding sp. z o.o.
20
WWW INTERFACE - WORKING WITH IP CAMERA
4.2.1. System settings
a. System information - Set up the camera name, select language, and set up the camera time.
 Camera model - information about camera model
 MAC Address - MAC address of a device
 Name-allows to enter server's description displayed both in the title bar and NMS software
 Language - changes OSD language
 Time stamp - enables or disables time and date on live view
 OSD position - sets the dime/date displaying position
 Text - text description on camera live view
 Date format- selects date display mode
 Time zone - selects local time zone
 NTP: Server - domain or IP address of an NTP server
 NTP: Update - sets frequency of time update
 NTP: Time shift - shifts time to local
 Synchronize with PC time - synchronizes time and date with the PC clock
 Manual - sets up a specific date and time (user-defined)
 The time and date remain the same - disables time adjustment
