Novus NVR-5720 User manual

u s e r ’s m a n u a l
NVR-5720
NVR-5736

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
2
IMPORTANT SAFEGUARDS AND WARNINGS
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of following directives and national
regulations implementing the directives:
 Electromagnetic compatibility EMC 2004/108/EC.
 Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well
as 75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European Directive on Waste Electrical and
Electronic Equipment (2002/96/EC) and further amendments. By ensuring this product is
disposed of correctly, you will help to prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this
appliance may not be treated as household waste. It shall be handed over to the applicable collection
point for the waste electrical and electronic equipment for recycling purpose. For more information
about recycling of this product, please contact your local authorities, your household waste disposal
service or the shop where you purchased the product.
RoHS Directive 2002/95/EC
Concerning for human health protection and friendly environment, we assure that our
products falling under RoHS Directive regulations, regarding the restriction of the use of
hazardous substances in electrical and electronic equipment, were designed and
manufactured in compliance with mentioned regulation. Simultaneously, we claim that our
products were tested and do not contain hazardous substances exceeding limits which could have
negative impact on human health or natural environment.
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for
self installation in households by individuals without technical knowledge.
The manufacturer is not responsible for defects and damages resulted from improper or inconsistent
with user’s manual installation of the device in the system.
ATTENTION!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT PROVISIONED FOR THE GIVEN PRODUCT IN ITS
USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR THAT ARISES FROM
THE NORMAL APPLICATION OF THE PRODUCT, ITS MANUFACTURER MUST BE CONTACTED OR THE
RESPONSIBILITY OF THE MANUFACTURER FOR THE RESULTS OF SUCH AN ACTION SHELL BE
EXCLUDED.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
3
IMPORTANT SAFEGUARDS AND WARNINGS
1. Prior to undertaking any action please consult the following manual and read all the safety and
operating instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this
manual is necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a
direct influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the
user’s manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer
is forbidden;
7. You are not allowed to use the device in high humidity environment (i.e. close to swimming pools,
bath tubs, damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers
etc.) is not recommended since it may lead to heat build-up and damaging the device itself as a
consequence;
9. Mounting the device on unstable surface or using not recommended mounts is forbidden.
Improperly mounted device may cause a fatal accident or may be seriously damaged itself. The
device must be mounted by qualified personnel with proper authorization, in accordance with this
user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with
those specified by the producer in the devices technical datasheet. Therefore, it is forbidden to
supply the devices from a power sources with unknown parameters, unstable or not meeting
producer’s requirements;
11. You cannot allow any metal objects get inside the recorder. It might cause serious damage. If a
metal object gets inside the device contact the authorised Novus service immediately.
12. The manufacturer does not bear responsibility for damage or loss of data stored on HDDs or other
media occurred during the usage of the product.
Due to the product being constantly enhanced and optimized, certain parameters and functions
described in the manual in question may change without further notice.
We strongly suggest visiting the www.novuscctv.com website in order to access the newest manual .
Technical changes reserved without prior notice and printing errors possible.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
4
TABLE OF CONTENTS
TABLE OF CONTEST.............................................................................................4
1. FOREWORD INFORMATION..........................................................................6
1.1. Network recorder’s technical data ..................................................................6
1.2. Main characteristic..........................................................................................7
1.3. Package contents.............................................................................................7
2. STARTING THE DEVICE..................................................................................8
2.1. Electrical connection and other rear panel elements. .....................................8
2.2. HDD mounting...............................................................................................9
2.3. Power connection.. .......................................................................................10
2.4. Connecting monitor......................................................................................11
2.5. Camera and Network wiring.........................................................................11
2.6. Peripheral device connection........................................................................12
3. OPERATING NVR.............................................................................................13
3.1. Front panel description.................................................................................13
3.2. Controlling via USB mouse..........................................................................13
3.3. System operation ..........................................................................................14
3.4. Startup configuration....................................................................................16
4. NVR MENU.........................................................................................................20
4.1. Live monitoring............................................................................................20
4.2. Searching and playing recorded video..........................................................22
4.3. Backup .........................................................................................................23
4.4. PTZ...............................................................................................................24
4.5. Alarm............................................................................................................24
4.6. Capture..........................................................................................................25
4.7. File manager .................................................................................................25
5. NVR CONFIGURATION ..................................................................................26
5.1. Device............................................................................................................26
5.1.1. Device info............................................................................................26
5.1.2. Device version ......................................................................................27
5.1.3. PTZ setting............................................................................................27
5.1.4. DST setting ...........................................................................................28
5.2. Channel..........................................................................................................28
5.2.1. Display setting................................................................................28
5.2.2. Video parameters............................................................................29
5.2.3. Schedule recording ........................................................................30
5.2.4. Motion ............................................................................................31
5.2.5. Video lost........................................................................................32
5.2.6. Tampering alarm ............................................................................33
5.2.7. Video mask.....................................................................................34

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
5
TABLE OF CONTENTS
5.3. Network......................................................................................................... 35
5.3.1. Network setting.............................................................................. 35
5.3.2. DDNS setting................................................................................. 36
5.3.3. NTP setting .................................................................................... 37
5.3.4. E-mail setting................................................................................. 38
5.3.5. Management platform.................................................................... 38
5.4. Alarm ............................................................................................................ 39
5.4.1. Alarm input.................................................................................... 39
5.4.2. Alarm output.................................................................................. 40
5.4.3. Exception ...................................................................................... 41
5.5. Account......................................................................................................... 42
5.5.1. Account setting .............................................................................. 42
5.5.2. User online..................................................................................... 44
5.6. System........................................................................................................... 45
5.6.1. Device log...................................................................................... 45
5.6.2. Stream info..................................................................................... 45
5.6.3. HDD setting ................................................................................... 46
5.6.4. Update............................................................................................ 46
5.6.5. Auto reboot .................................................................................... 47
5.6.6. Recovery configuration.................................................................. 48
5.7. Record........................................................................................................... 49
5.8. Display setting............................................................................................... 49
5.9. Image setting................................................................................................. 51
5.10. IP channel setting........................................................................................ 52
5.10.1. Manual ......................................................................................... 52
5.10.2. Synchronization time ................................................................... 55
5.10.3. Manual synchronization............................................................... 55
5.10.4. Changing channel sequence......................................................... 55
6. NETWORK OPERATIONS UTILIZING WEB BROSWER ....................... 56
6.1. Recommended PC specification for web browser connections.................... 56
6.2. Establishing a connection.............................................................................. 56
6.3. Configuration of remote access..................................................................... 58
6.4. Live monitoring interface.............................................................................. 59
6.5. Searching and playing recorded video.......................................................... 61
6.6. Backup ......................................................................................................... 62
6.7. System setup ................................................................................................ 62

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
6
FOREWORD INFORMATION
1. FOREWORD INFORMATION
1.1. Network recorder’s technical data
* Function capability depends on used communication protocol, for details please check full user manual.
** Available with using dual streaming mode
NVR-5720 NVR-5736
VIDEO I AUDIO
Network Camera up to 20 channel in resolution 1280x960 (video + audio) up to 36 channel in resolution 1280x960 (video + audio)
Camera/Protocol suport NOVUS, ONVIF, RTSP
Monitor Output Main (split screen, full screen, sequence): 1 x HDMI, 1 x VGA, 1 x BNC
Audio Output 1 x Line out
Dualstreaming support Yes*
RECORDING
Compression H.264, MJPEG
Resolution Up to 2048 x 1536 Up to 2592 x 1920
Speed
Up to 600 fps (20 x 30fps for 1280 x 960 and lower)
Up to 480 fps (16 x 30fps for 1920 x 1080)
Up to 120 fps (4 x 30fps for 2048 x 1536)
Up to 1080 fps (36 x 30fps for 1280 x 960 and lower)
Up 750 fps (25 x 30fps for 1920 x 1080)
Up to 480 fps (16 x 30fps for 2048 x 1536)
Up to 120 fps (4 x 30fps for 2592 x 1920)
Streams Size Up to 80Mb/s for the system Up to 128Mb/s for the system
Recording Mode Time-lapse, Event (Alarm, Motion detection), manual
Schedule Individual settings for: each day, each hour, each camera, possibility of combining individual recording modes
Prealarm/postalarm 0 s - 30 s/5 s - 600 s
Display
Resolution Up to 2048 x 1536 Up to 2592 x 1920
Speed Up to 600 fps (20 x 30fps)** Up to 1080 fps (36 x 30fps)**
PLAYBACK
Speed Up to 120 fps (4 x 30fps for 2048 x 1536 and lower)
Up to 240 fps (8 x 30fps for 1280 x 960 and lower)
Up to 120 fps (4 x 30fps for 1920 x 1080)
Up to 120 fps (4 x 30fps for 2048 x 1536)
Up to 120 fps (4 x 30fps for 2592 x 1920)
Recorded Data Search By date/time
BACKUP
Methods USB port (HDD or Flash memory), network
File Format AVI
STORAGE
Internal HDD Installing 9 HDD 3,5” SATA
Total Capacity 36 TB
E-SATA Yes
ALARM
Internal Input/Output 4/1 relay 16/4 relay
Camera Input/Output Support camera’s alarm input*
Motion Detection Support camera’s motion detection*
System Reaction to Alarm Events Buzzer, E-mail with attachment, output activation, screen message, recording activation, PTZ function
NETWORK
Network Interface 1 x Ethernet - RJ-45 socket, 10/100/1000 Mbit/s 2 x Ethernet - RJ-45 socket, 10/100/1000 Mbit/s
Network Protocols Support ONVIF (2.2/Profile S), RTSP, HTTP, TCP/IP, IPv4, UPNP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP
PC Software Internet Explorer
Smartphone Software MEye, MEyePro (for iPhone, Android)
Number of Connections/
Bandwidth Up to 4 connections / up to 80Mb/s for the system Up to 4 connections / up to 128Mb/s for the system
PTZ
Functions Pan, tilt, zoom, preset *
AUXILIARY INTERFACES
USB 2 x USB 2.0
OPERATING SYSTEM
Operating mode triplex
OSD Polish, English and others
Control PC mouse (in-set included), network
System Diagnostic Automatic control of HDDs, network, network cameras lost
Security Password protections, IP filtering, MAC filtering
INSTALLATION PARAMETERS
Dimensions (mm) 440 (W) x 90 (H) x 440 (L)
Weight 7 kg (without HDD)
Power Supply 200~240VAC
Power Consumption 150 W (with 9 HDDs)
Operating Temperature 0 °C ~ 50°C

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
7
FOREWORD INFORMATION
1.2. Main characteristics
 Support ONVIF and RTSP protocol
 Monitor output: HDMI, VGA, BNC
 Support 9 HDDs 3,5” inside
 Rack mount
NVR-5720
 20 video and audio channels for network cameras
 Recording speed up to 600 fps in 1280 x 960 resolution
 Supported resolution up to 2048 x 1536
NVR-5736
 36 video and audio channels for network cameras
 Recording speed up to 1080 fps in 1280 x 960 resolution
 Supported resolution up to 2592 x 1920
WARNING!
ONVIF protocol support was verified with IP cameras based on ONVIF ver. 2.2 and compatible
with the "PROFILE S".
Implementation of the ONVIF protocol by different manufacturers may vary by some functions,
which can make them work improperly or not in accordance with expectation. AAT HOLDING
Company is not responsible for incompatibility problems resulting from cameras of other brands
than NOVUS, which are using ONVIF protocol. If you are using ONVIF protocol cameras other
than NOVUS brand it is recommended to test for each time whether required functions work
correctly.
1.3. Package contents
Unpack the device carefully. After unpacking, please ensure that package contains the following items:
 Network Video Recorder: NVR-5720 / NVR-5736
 Power cord
 HDMI cable for monitor
 SATA cables for HDDs
 USB Mouse
 Accessory mounting bag
 User’s manual (short)
 CD with a full version of user’s manual and software tools and software
If any of the elements has been damaged during transport, pack all the elements back into the original
packaging and contact your supplier.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
8
STARTING THE DEVICE
2. STARTING THE DEVICE
2.1 Electrical connection and other rear panel elements.
NVR-5720 back panel
NVR-5736 back panel
1. POWER CONNECTOR: Power supply connector.
2. POWER SW: NVR power switch, plug the power cord and turn this switch on.
3. E-SATA: ESATA connector for external HDDs.
4. ALARM & RS485: Alarm input and output interface*.
5. LAN: RJ-45 connector port for connecting to the local network and internet
(for NVR-5720 also IP camera network).
6. USB: 2 x USB 2.0 ports for external Flash memory, mouse connection and
other USB compatible devices.
7. VGA: Main monitor connectors, use D-SUB VGA cable to connect monitor.
8. 1080P (HDMI): Main monitor connectors, use HDMI cable to connect monitor.
9. VOUT: Main monitor connector, BNC video output.
10. AOUT: Port for connecting local speaker with pre-amplifier.
11. AIN/SPEAK: Audio mono inputs for connecting microphones*.
12. IPC: RJ-45 connector port for connecting IP camera network
* RS485 and audio input will be available in the future.
Note: For NVR-5720 back panels bottom USB port is shared with USB port at front panel (it is the
same port), so you cannot use both ports at the same time.
2 3 6 1
12 4 7 5 9 10 8
11
5 4 7 6 9 10 8
3 11 2 1

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
9
STARTING THE DEVICE
2.2 HDD mounting
Novus NVR supports 9 internal SATA HDD.
WARNING!
In order to find information regarding the compatible models of HDDs and their maximum
capacities, please contact Novus distributor or check the information presented at
www.novuscctv.com. AAT HOLDING Company is not responsible for any problems resulting
from using not recommended hard drives.
The list of compatible HDDs contains all the HDDs that can be used with a given DVR including
HDDs designed for office use - so called desktop disks. However, due to the fact that reliability of
the recording process and data safety are paramount factors of any CCTV system, we strongly
advise to use HDDs designed for continuous (24/7) operation.
You need to format disks to if they were used in a different device. All data saved on HDD prior
to format will be lost.
In order to mount HDD, please unscrew two screws on the NVR back side as depicted below and
remove top cover.
Inside of NVR you will see 3 brackets for 3 HDDs each. To install HDD unscrew HDD bracket from
the NVR bottom. Next put HDD in dedicated place of bracket and screw it tight.
In the same way mount HDD 2 and 3. When all HDDs are installed mount bracket to the NVRs side
and screw it tightly. Then connect the power cable and data cable to the disks.
HDD1
HDD2
HDD3
HDD4
HDD5
HDD6
HDD7
HDD8
HDD9 HDD
HDD
HDD

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
10
STARTING THE DEVICE
In the same way install HDDs in other brackets. At the end install the top cover on the NVR and screw
it back.
2.3. Connecting power adapter.
Please connect provided power cord in the rear power port of the NVR like depicted below.
To start the unit turn on the power switch on back panel. Initialization lasts for approximately 60
seconds. During this time executing any device functions and pressing any buttons is prohibited. To
shut down the device please use the menu.
CAUTION:
Make connection when the power is not applied.
Do not place the power cord under the carpet or rug. The power cord is usually earth-grounded.
However, even if it's not earth-grounded, never modify it on your own for earth-grounding.
Make sure that power adapter is placed near of NVR and secured from accidental disconnection.
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
HDD
POWER CORD
POWER SWITCH

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
11
STARTING THE DEVICE
2.4. Connecting monitor
This product supports following interfaces for main monitor: HDMI, VGA and BNC.
For HDMI and VGA outputs following resolutions are supported: 800x600, 1024x768, 1280x1024,
1366x768, 1440x900, 1920x1080.
For BNC video output it is recommended to set 800x600 resolution in NVR menu.
After changing resolution you have to confirm it by clicking YES. In case of monitor does not display
anything please wait 8 seconds, then previous resolution will be restored.
Note:
You can use the HDMI <> DVI converter to connect to the DVI monitor.
HDMI<>DVI converter it’s not included and you have to buy it separately.
2.5. Camera and Network wiring
To connect compatible IP cameras to the NVR you have to use additional network switch. By using
Ethernet cables connect the cameras and NVR to the switch, like on image below. Please notice that
the Ethernet connection is effective within 100 meter distance.
For NVR-5720 you must create local networks, for connecting cameras, client PC and internet.
Note:
To ensure recording stability from an overloaded network traffic, or unauthorised access, it is
strongly recommended to create separate network secured by router firewall from the user network.
NOVUS NVR-5720
INTERNET
PC COMPUTER
ETHERNET SWITCH
IP CAMERAS

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
12
STARTING THE DEVICE
For NVR-5736 you must create two local networks, first one NIC1 is for camera only and second one
NIC2 is for client PC and internet. NIC1 and NIC2 interfaces must have unique IP address, each
from other subnet ( the same rule like for WAN and LAN IP settings in routers).
Before adding any camera to the NVR, you have to configure its network settings like it is described
in Camera User Manual. For the next steps of camera and network configurations please check
chapter 3.4. Startup configuration.
2.6. Peripheral device connection
 Connecting audio ports
Audio output signal normally are above 200mV 1kΩ. You can connect the low impedance earphone,
or power amplifier with the external speakers.
 Connecting USB devices
NVR has 2 x USB 2.0 ports for external Flash memory, mouse connection and other USB compatible
devices. 2 USB ports (1x independent and 1x shared) are located at back panel and 1 USB port at front
panel.
Note:
For NVR-5720 back panels bottom port is shared with port at front panel (it is the same port), so you
cannot use both ports at the same time.
PC COMPUTER
LOCAL NETWORK AND
INTERNET SWITCH (NIC2)
NOVUS NVR-5720
IP CAMERAS
IP CAMERAS SWITCH (NIC1)
INTERNET

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
13
NVR OPERATING
 Connecting alarms ports
NVR-55xx series has local alarm input and output. For connecting them please refer table below:
To activate alarm in you have to simply connect alarm input (1,2,etc) to GND cable.
Alarm output it’s a relay with 2 connectors N/O and COM
Note:
RS485 will be available in the future.
3. NVR OPERATING
3.1. Front panel description
1. ON/OFF, RESET Turn off / reset buttons.
2. LED Shows power, recording, network connection or active alarm statuses.
3. USB USB 2.0 port for external Flash memory and mouse connection.
3.2. Controlling via USB mouse
It is possible to control NVR via an USB mouse connected to the USB port. Double-clicking on any
camera in 2x2, 3x3 display mode switches the display to full-screen mode. Subsequent double-click
returns to previous display mode. Move cursor to the top or click the right key of mouse to bring up
MAIN MENU and select START icon.
Certain positions allow to select them via mouse scroll. Depending on NVR operating mode, pressing
RMB displays a corresponding function menu.
2
3
1
RS485 ALARM OUTPUT
485+ 485- NO 1 COM 1 NO 2 COM 2 NO 3 COM 3 NO 4 COM 4
1 2 3 4 5 6 7 8 GND GND
ALARM INPUT
ALARM INPUT
13 14 15 16 GND
9 10 11 12 GND

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
14
NVR OPERATING
3.3. System operations
To start NVR plug power cable and switch on power button. The power led turns on. After booting,
the video output default to multi-window output mode.
By default NVR is using English language interface.
To change language please follow the procedure like below:
 Move cursor to the top or click the right key of mouse to bring up MAIN MENU
 Select START icon and click the LOGIN icon to pop out the login menu:
 Select User “admin”, leave password blank and confirm with OK button.
Default login is “admin” / no password.
 From the MAIN MENU click DISPLAY icon , following window will be shown:
 In LANGUAGE menu select preferred language.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
15
NVR OPERATING
 Save changes by clicking OK button
 New confirmation window will appear, choose YES to confirm
Now NVR will start again with new language.
To manipulate or access menus of the NVR, you should log in again. Move cursor to the top or click
the right key of mouse to bring up MAIN MENU and select START icon
Next click the LOGIN icon to pop out the login menu:
Select User and enter the password . Use the virtual keyboard to enter the password and confirm with
OK button.
Default login is “admin” / no password. For safety reasons, it is recommended to change default
user name and password.
In order to shutdown NVR you should move cursor to the top or click the right key of mouse and
select START icon . Next click the POWER OFF icon . After that use disable button at rear
panel to turn off the power.
In order to reboot NVR you should move cursor to the top or click the right key of mouse and select
START icon . Next click the REBOOT icon . After NVR will boot again you should log in.
To prevent unauthorized access, it is recommended to log out when you leave the screen. To do that
move cursor to the top or click the right key of mouse and select START icon . Next click the
LOGOUT icon .
Note:
When user is not login or has limited rights all inactive icon and menus are greyed out.
CAUTION:
If you turn off the system in an abnormal manner such as removing the power cord while the
system is working, the disk will acquire or increase the numbers of bad sectors, causing data
loss and shortened life cycle of the disk.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
16
NVR OPERATING
3.4. Startup configuration
Prior to using NVR for the first time, initial setup is strongly advised. Before you connect the IP
cameras to the NVR, please set up network and stream parameters of IP cameras in the right way.
Note:
For suggested values for IP camera setting please refer to the “Cameras Capability Table - appendix
A" which is an integral part of this manual. If you will set wrong values some problems may appear:
the NVR cannot search the IP camera, the stream cannot be connected, the image is not fluent, the
image quality is bad and so on.
To configure NVR please follow procedure like below:
I. From the MAIN MENU click DISPLAY icon and set following parameters
 LANGUAGE - allow to select preferred language
 RESOLUTION - select the resolution most corresponding to the used monitor.
II. From the MAIN MENU click SETTING icon and go to the SYSTEM section. Select HDD
SETTING tab and check the hard drive. If it is unformatted you have to select it and press
FORMAT button.
III. From the MAIN MENU click SETTING icon and go to the DEVICE section. Select
DEVICE INFO tab and set following parameters:
 DEVICE NAME - allow to add unique name for NVR
 VIDEO FORMAT - PAL or NTSC (required for using BNC video output)
 STREAM TYPE - depending on used cameras you have to chose correct mode from the list
For eg. in mode 2x[1920*1080] + 2x[1280*720] + sub[960*576] + 1Ref + 4Play
Channel 1and 2support 1920*1080, channel 3 and 4support 1280*720, channel 1-4 sub streams
support 960*576 resolution. 4Play means that there is possible to playback for 4channels at
once. 1Ref is internal buffer capacity.
 DEVICE TIME - set up correct time and date and confirm by pressing MODIFY button
IV. From the MAIN MENU click SETTING icon and go to the NETWORK section. Select
NETWORK SETTING tab and set following parameters:
 IP (by default it is 192.168.1.188)
 SUBNET MASK (by default it is 255.255.255.0).
Note:
Be sure that IP addresses and subnet mask of the NVR and the IP cameras are in the same network
subnet (e.g. for the NVR IP address 192.168.1.188, and mask 255.255.255.0 appropriate address for
the camera ranges from 192.168.1.1 to 192.168.1.254, for example 192.168.1.201). It is not allowed to
set the same addresses for multiple devices.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
17
NVR OPERATING
Optionally if you are going to connect NVR to the Internet (for remote access, sending email, etc)
set up
 DEFAULT GATEWAY,
 FIRST and SECOND DNS.
You can alternatively check DHCP mode (DHCP server is required in this method in target
network) then all settings will be set up automatically. When you use DHCP server check IP
address lease and its linking with NVR MAC address to avoid changing or losing IP address
during device operation or network/DHCP server breakdown. This solution is not recommended
for security systems.
V. From the main window click the RMB and choose IP CHANNEL SETTING>MANUAL
Then following window appears:
To connect the IP cameras to the NVR you can find them automatically or type IP address
manually.

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
18
NVR OPERATING
VI. Press SEARCH button to display all cameras present in network. After some time list of cameras
appears.
To add required camera to the system TICK it on the list. Selected camera will be added to first
empty channel. CHANNEL LIST is displayed at left hand side. If you press ALL button, all
available channels will be connected with camera from the list.
If you would like to remove camera added to one of the channels please select it at CHANNEL
LIST “A” and press DELETE button “B” below:
ADD ALL
BUTTON
CHANNEL
LIST SEARCH
BUTTON
SEARCH
RESULT
WINDOW
CHANNEL
SETTING
WINDOW
A
B

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
19
NVR OPERATING
VII. Next you have to fill user name and password for each camera that you add to the NVR.
Please double click at CHANNEL LIST “A” or select required channel from the CHANNEL
dropdown menu ”B”. Next check if all settings for this channel are correct, fill username and
password “C” and confirm by using SAVE button. Now you can select next channel from the
dropdown menu.
If you set up the same user name and password and other parameters for all cameras you can simply
type them and save for first channel, and then press COPY TO button, select required channels to copy
them and confirm by OK button. Note that IP address is unique and doesn’t copy.
After finishing following procedure NVR is ready to use.
Additionally you should create user accounts for each operator.
For event recording you should set up motion/alarm setting in the camera and modify SCHEDULE
RECORDING and MOTION in the NVR.
For event notification you should set up motion/alarm setting in the camera, configure NETWORK
SETTING for using Internet and EMAIL SETTING
A
B
C
A
B

NVR-5720, NVR-5736 User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
20
NVR MENU
4. NVR MENU
4.1. Live monitoring
Novus network video recorders features a multilingual OSD menu allowing for adjusting the settings of
the device. Available languages are: English, Polish, and others
As soon as the NVR completes its initialization process, it will enter the real-time monitoring image.
Displaying all cameras simultaneously is the default mode. If you move mouse to the top MENU BAR
will be shown. At the right corner of screen, shows the logged user and alarms status. In the bottom
right corner of each channel image, shows capture and recording icon, zoom mode and alarm icon.
After login in, click the right key of mouse to bring up the MAIN MENU interface. You can also move
mouse cursor to the window top display MENU BAR, which contains basic menu functions.
Click icon to pop out the menu showed below:
VIDEO WINDOW
MENU BAR MAIN MENU
