Nowatt Lighting CRYSTAL PLRE2 User manual

CRYSTAL
PLRE2 –PLRE4
User guide

2
Introduction…………………………………………………………………………………………………….
Overview……………………………………………………………………………………………………………….……………….
Unpacking..…………………………………………………………………………………...............………………….............
Operation.…………………………………………………………………………………….......…..………
Fixture positioning tips……………………………..………………………………………………………...………...……..
Control with the Nowatt Lighting application.…………………………………………………..………….……..
Grouping function...……………………………………………………………………………………………………………….
Installation.…………………………………….……………………………………………………....….....
Installation in concrete floor……………........……………………………………..………………………………………
Installation in coated soil………...……………………………………………………………………………………………
Installation in gravel……………..…………………………………………………………………………………………...….
Installation in a duckboard……………..…………………………………………………………………………………….
Installation in pebbles or gabions……………………………………………………………….………………….…...
Installation in flood zone…….……………………………………………………………………………………..……..…..
Maintenance and care…………….……………………………………………………………………….
Cleaning……………………..………………………………………………………………………………………….………………
Risks of material damage…………...………………………………………………………………………………………..
Waste management..…………...……………………………………………………….………………………………...……
CE declaration of conformity...……………………………………..................................................................
Warranty………………………………………………………………………………….……………………………………….…….
Sommaire
3
3
3
4
4
5
9
10
10
12
14
14
15
15
16
16
16
16
16
17

3
Overview
Usage : Solar outdoor marking stud connected with LEDs with no cabling.
The Crystal stud is standalone thanks to a solar panel and a battery.
LEDs’ colors:
-PLRE2: Amber or White 3000 K or White 4000 K.
-PLRE4: Colors RGB + White 4000 K.
Structure : Tempered glass frame thickness 15 mm on an aluminum tube.
Battery LiFePO4 (3,6 Ah).
Solar panel Sunpower Back Contact.
Operating temperatures : -10°C / + 60°C.
Class III –IP67 –IK10 –CE.
Product lifespan over 20 years.
Dimensions : 119 x 72 mm.
Weight : 1.25 kg.
Unpacking
Check all parts of the product for damage.
Do not put the product into service in case of damaged solar panel or LEDs.
The identification number of your Crystal stud is indicated on a label on the side of the product.
Tempered glass frame
LEDs
Solar panel
Aluminium tube
Introduction

4
Fixture positioning tips
Operation
Choose a suitable location where sunlight can directly reach the solar panel.
Avoid obscuration by eaves or trees.
In the northern hemisphere, favor installation to the south of obstacles, to the east or west. Do
not install due north.
In the southern hemisphere, favor installation to the north of obstacles, to the east or to the west.
Do not install due south.
Recommendations
The most critical time for solar lighting is winter.
Days are shorter than in summer, and the sun is lower in the sky. Therefore, it is advisable to
assess the correct positioning of a solar lighting device in winter, to avoid shadow areas.
It is advisable to draw up a layout plan of the site before installation. You can indicate the location
of the devices there, making sure to note their identification numbers indicated on their labels.
Example
In winter, the sun is 21°in Bordeaux, France at noon. A 2-meter-high wall then has a shadow cast
of 5 meters directed towards the North.
In summer, the sun is 68°in Bordeaux, France at noon. A 2-meter-high wall then has a shadow of
70 cm directed towards the North.
In Bordeaux in winter, the sun rises in the southeast at 7:30 a.m. and sets in the southwest at
4:30 p.m.
In Bordeaux in summer, the sun rises in the northeast at 4:30 a.m. and sets in the northwest at 8
p.m.
More information: www.sunearthtools.com/dp/tools/pos_sun.php?lang=en

5
Control with the Nowatt Lighting application
Download the Nowatt Lighting app
The Nowatt Lighting application is free to download from the Play Store and the Apple Store. You
can download it on a Smartphone or a tablet.
Activate your Bluetooth connection
Start the Nowatt Lighting application on your Smartphone
The app asks you for permission to access Bluetooth. Tap "Allow" then "OK".
Home page
Products are divided into two groups: those you have already
logged into are listed at the top in "My Modules". Others are listed
below in "New Modules".
To connect to a device, click on its identification number shown in
the menu.
Enter your password
Nowatt Lighting will communicate a password by default in the user
guide delivered with the device.
You can change the password to secure your product in the
settings.
It is important to check with the person in charge of
programming that the modified password will be recorded and
distributed to those responsible for the project.
Operation

6
Homepage information
Identification number of your product
Battery charge status
Your stud may display a 0%
state of charge on startup. Wait
a few seconds for the actual
percentage to display.
Mode : OFF / Activated / Demo
Settings
All scenarios available
in the app
Identification of the model of your
product
Operation
PLRE2 -Select a light animation
Tap "Scenario".
Select a light effect from the 4 choices available.

7
Operation
PLRE4 -Select a color
Tap "ON" then "Custom Color" at the bottom of the page to
select your color.
Use the color wheel or RGBW sliders, then press "Save" to
save your color.
To delete a color, long press on the color box and then press
"yes".
PLRE4 -Select a light animation
Tap "Scenario".
Select a light effect from the 8 choices available.

8
Confirm your product settings
The scenario you chose is written here.
Select the operating time of your device with the sliders:
-Total duration of use
-Number of hours after sunset
-Number of hours before sunrise
Check your program with demo mode by tapping “Show
Scenario". Please note that this only allows you to view the light
effect. The scenario is not saved for the following nights.
Tap "Apply Scenario" to save it. It will light up every night with this scenario.
Check your programming
If the home page indicates OFF or
Demo, your scenario is not saved, you
must repeat the previous steps.
Operation
If you selected a Monochrome scenario, confirm the color.

9
Grouping function
The grouping function allows you to create groups to send the same scenario to several devices
simultaneously (within the range of Bluetooth). However, this operation does not allow
synchronized operation of the devices. They receive the same scenario, at the same time, but they
do not communicate with each other. They remain independent.
1. Tap “Groups”.
2. Select the type of products you
want to group.
3. Enter the products you want to
include in the group. Warning: only the
products for which you have
previously entered the password
during a first connection can be
grouped.
4. Choose your scenario.
5. Apply the scenario.
Operation

10
Installation in concrete floor
This installation tutorial applies to poured concrete, paving stones and slabs, deactivated
concrete, and concrete to be poured.
1. Make a drill core hole of 130 mm in diameter for a minimum depth of 95 mm.
2. Remove the drill core, possibly with the help of a perforator.
3. Position the stud with a suction cup.
Installation

11
4. Set the stud’s height.
Pour a resting mortar (if rolling space) or fill with sand according to the following two configurations:
Flush stud:
H (mortar height) = D (coring drilling depth) -75mm
Stud protruding from the height of the collar:
H (mortar height) = D (core drilling depth) -60mm
5. Adjust flush and horizontality.
6. Fill the vertical cavity up to 2 cm before the finished floor (sand or mortar) and pack well.
7. Make finishing mortar.
8. Clean and let dry the gasket 24 hours.
Installation

12
This installation applies to coated soil, bitumen and asphalt.
1. Make a 122/130 mm diameter coring for a 90 mm depth.
2. Pour a resting mortar over 1 to 1.5 cm.
3. Apply the primer.
Installation in coated soil
4. Apply Sykaflex on the bottom of the stud (only on the metal background).
Installation

13
5. Set the stud with a suction cup.
6. Make a finishing silicone seal.
Installation

14
Use of stainless steel fixing for stud.
This device is screwed onto concrete blocks and maintained by 3 M4 screws.
Installation in gravel ground
Installation in a duckboard
Tube height for a glass protruding installation : 62 mm.
Low flange.
Tube height for a flush glass installation : 75 mm.
High flange.
Tube height for a flush glass installation : 75 mm.
High flange.
Tube height for a glass protruding installation :
62 mm.
Low flange.
Use of stainless steel fixing for stud.
This device is maintained by 3 M4 screws.
Installation

15
Installation in pebbles Installation in gabions
Installation in pebbles or gabions
1. Use 140 mm PVC tubes. Cut lenghts equal to the depth of the installation of the pebbles or
gabions.
2. Check that your stud is in OFF mode.
3. Install it at the end of the tube.
4. Fill the PVC tube with mortar or concrete.
5. Pour the polyurethane mastic of the color of your choice (white, grey or black).
Ref. : PU BOND 40 ATE VITRATEC, between the stud and the PVC tube.
6. Smooth the gasket using a plastic spatula previously moistened.
7. Let dry 20 minutes.
8. Integrate the tube and the stud in the pebbles or gabions.
9. Put the stud in ON according to the instructions.
Installation in flood zone
For installations where the studs could be covered with water for several hours a day, we
recommend to provide drainage for the cavity.
It is also recommended to use the stainless-steel fastening device (with or without a flange) and
to fill it with polyurethane.
Installation

16
Cleaning and care
The product requires no maintenance.
Regular checks for damage can increase the lifespan of the product.
Removing dirt can help increase product performance.
Risk of material damage
Unsuitable detergents may damage the luminaire.
Check surface tolerance with detergents.
If there is dirt or weather deposits on the solar panel, clean the glass frame with a soft cloth and
mild detergent.
Waste management
Please observe the legal obligations relating to waste management.
Return old devices to your dealers or directly to Nowatt Lighting.
Do not dispose of old devices with unsorted household waste.
Do not throw old devices into fire or water.
CE declaration of conformity
This product complies with the requirements of the following standards, laws and directives:
-Electromagnetic Compatibility Directive 2004/108/EC
-RoHS Directive 2001/65/EC
-Batteries and Accumulators Act (BattG)
-WEEE Electrical and Electronic Devices Directive 2012/19/EU
Maintenance and care

17
Warranty
Nowatt Lighting products are manufactured with the utmost care.
The function and safety of this product have been tested according to the currently valid
directives, with a final inspection.
Nowatt Lighting guarantees faultless condition and operation.
The warranty period is 24 months and begins on the day of sale to the customer.
It includes the elimination of defects resulting from a defect in material or construction.
The warranty will be provided at our discretion by repair or exchange of defective parts.
The warranty does not apply to wearing parts.
The warranty does not apply to damage or defects due to improper use or maintenance.
Consequential damage to other objects is excluded from the warranty.
The warranty only applies if the undisassembled device is returned accompanied by a brief
description of the defect and a receipt or invoice bearing the date of purchase and the seller's
stamp.
Please send the product properly packaged to the after-sales service.
In the event of faults not covered by the guarantee, contact your point of sale to find out if a
repair of the device is possible.
Editing date: 03/08/2022
Nowatt Lighting
1 rue Guy Moquet, 13001 Marseille, France
+ 33 4 91 02 17 06
[e-mail]
www.nowatt-lighting.com
Maintenance and care
