Volt VUL-6703 BBZ Series User manual

VOLT®Low Voltage Landscape Lighting
VOLT®Mini Brass LED Underwater Pond Light
(Set of 3)
VUL-6703-X-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
–1–
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Mini Brass LED Underwater Pond Light
(Set of 3) VUL-6703-X-BBZ
Important: Please Read Before Installation
INSTALLATION INSTRUCTIONS
!
www.voltlighting.com
Important Safety Instructions
!
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
–2–
This xture is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes
and instructions may result in serious injury, property damage and void
the warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Use only in ponds and small decorative fountains where persons
will immerse no more than their hands and lower arms while the
product is energized.
2. DO NOT use in water intended for swimming, wading, immersion,
or bathing.
3. All installer completed cable connections must be located outside
of pond or fountain.
4. Low voltage circuit must be supplied by a power unit marked as
suitable for supplying submersible luminaires.
5. Power unit must be supplied by a circuit protected by a ground
fault circuit interrupter (GFCI).
6. “Maximum depth: 18 in (450 mm)”.

[email protected] • 813.978.3700
Package Contents
A. (1) Fixture Body
Product Dimensions
2.25” 1.75”
2.15”
1.32”
1.30”
Wire Connections
1
Place xture body on your desired location. Strip both leads from
luminaire pigtail. Using two wire connectors (sold seperately),
connect the leads from the luminaire to the main supply cable
leads. Make this connection at least 10’ outside of the water.
Pigtail
Main Supply Cable
Wire Connectors
(sold seperately)
–3–

is.VUL-6703-X-BBZ-ver6.pdf
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
www.voltlighting.com
–4–
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
