NSD VE-2CC User manual

ZEF004410502
Specifications & Instruction Manual
ABSOCODER CONVERTER FOR CC-Link Ver. 1.10
VE-2CC
VM-2CC
Applicable sensor: VRE-P028
VRE-P062
MRE-32SP062
MRE-G□SP062

6. Operation
- Do not change the controller's function switch settings during the
operation; otherwise, it will cause injury.
- Do not approach the machine after instantaneous power failure
has been recovered.
Doing so may result in injury if the machine starts abruptly, it will
cause injury.
- Be sure to check that the power supply specifications are correct;
otherwise, it may caused controller failure.
- Be sure to provide an external emergency stop circuit so that
operation can be stopped with power supply terminated immediately.
- Be sure to conduct independent trial runs for the controller before
mounting the controller to the machine;
otherwise, it may cause injury.
- When an error occur, be sure to eliminate the cause, ensure
safety, and reset the error before restarting operation;
otherwise, it may cause injury.
7. Maintenance And Inspection
- Do not disassemble, remodel, or repair the unit;
otherwise, it will cause electric shock, fire, and unit malfunction.
- The capacitor of the power line deteriorates through prolonged use.
We recommended that the capacitor be replaced every five years
to prevent secondary damage.
8. Disposal
- Be sure to handle the controller as industrial waste while
disposing of it.
1. Handling Precautions
- Do not touch components inside of the controller;
otherwise, it will cause electric shock.
- Do not damage the cable by applying excessive load, placing
heavy objects on it, or clamping;
otherwise, it will cause electric shock or fire.
DANGER
- Turn the power supply OFF before wiring, transporting, and inspecting
the controller; otherwise, it may cause electric shock.
- Provide an external safety circuit so that the entire system
functions safely even when the controller is faulty.
- Connect the grounding terminal of the controller;
otherwise, it may case electric shock or malfunction.
- Do not use the controller in the following places; water splashes,
the atmosphere of the corrosion, the atmosphere of the flammable
vapor, and the side of the combustibility.
Doing so may result in fire or the controller may become faulty.
- Be sure to use the controller and the ABSOCODER sensor in the
environment designated by the general specifications in the manual.
Failure to do so may result in electric shock, fire, malfunction or unit
failure.
- Be sure to use the specified combination of the ABSOCODER
sensor, controller and sensor cable; otherwise, it may cause fire or
controller malfunction.
CAUTION
2. Storage
CAUTION
- Do not store the controller in a place exposed to water, or toxic
gas and liquid.
- Be sure to store the controller in designed temperature and humidity
range, and do not exposed to direct sunlight.
- Be sure to consult with NSD when the controller is stored for long
periods.
- Do not hold the cable or shaft of ABSOCODER sensor during
transport; otherwise, it will cause injury or controller malfunction.
CAUTION
3. Transport
Thank you very much for purchasing our product.
Before operating this product, be sure to carefully read this manual so that
you may fully understand the product, safety instructions and precautions.
- Please submit this manual to the operators actually involved in operation.
- Please keep this manual in a handy place.
Symbol Meaning
DANGER
Incorrect handling may cause a hazardous situation that
will result in moderate injury or physical damage.
Incorrect handling may cause a hazardous situation that
will result in death or serious injury.
Instructions accompanied by a symbol may also result in serious
damage or injury. Be sure to follow the all instructions accompanied by the symbol.
Graphic Symbols
Symbol Meaning
Indicates prohibited items.
Indicates items that must be performed to.
This product is not designed to be used under any situation affecting human
life. When you are considering to use this product for special purposes such as
medical equipment, aerospace equipment, nuclear power control systems,
traffic systems, and etc., please consult with NSD.
CAUTION
CAUTION
Application Limitation
4. Installation
- Do not step on the ABSOCODER sensor or place heavy objects on
the controller; otherwise, it will cause injury.
- Do not block the exhaust port or allow any foreign matter to enter
the controller; otherwise, it will cause fire or unit failure.
- Be sure to secure the controller and ABSOCODER sensor with the
provided brackets; otherwise, it may cause malfunction, injury, or
drop.
- Be sure to secure the specified distance between the main body
and the control panel or other equipments; otherwise, it may cause
malfunction.
5. Wiring
- Be sure to secure the terminal block firmly; otherwise, it may have
risk of fire.
- Be sure to mount the terminal cover provided with the controller,
before supplying the power, starting operation after the installation,
and wiring; otherwise, it may cause electric shock.
- Be sure to keep the sensor cable, control cable, and communication
cable at least 300 mm away from the main circuit and power line;
otherwise it may cause injury or malfunction.
- Be sure to connect all cables correctly; otherwise, it may cause injury
or controller malfunction.
- Be sure to firmly connect the external I/O connectors and sensor
connectors; otherwise, it may cause incorrect inputs and outputs or
injury.
CAUTION
CAUTION
(Please read this safety guide carefully before operation)
GENERAL SAFETY RULES
DANGER
CAUTION
CAUTION
CAUTION
Signal Words
Safety precautions in this guide are classified into DANGER and CAUTION.

< VE-2CC / VM-2CC Specifications & Instruction Manual Revision History>
* The Document No. appears at the upper right of this manual's cover page.
Document No. Date Revision Description
ZEF004410500 20, Mar., 2008 1st Edition
Japanese document: ZEF004410206
ZEF004410501 3, Mar., 2014 2nd Edition
Japanese document: ZEF004410207
ZEF004410502
5, Mar., 2014
3rd Edition
Japanese document: ZEF004410208

CONTENTS
1. SUMMARY................................................................................................................................................................1
1-1. Summary............................................................................................................................................................1
1-2. Features .............................................................................................................................................................1
2. CONFIGURATION....................................................................................................................................................2
3. SPECIFICATIONS ....................................................................................................................................................3
3-1. Converter Specifications ....................................................................................................................................3
3-2. ABSOCODER and Extension Sensor Cable Specifications ..............................................................................4
4. DIMENSIONS ...........................................................................................................................................................6
4-1. Converter ...........................................................................................................................................................6
4-2. ABSOCODER Sensor........................................................................................................................................7
4-3. Extension Sensor Cable ..................................................................................................................................12
5. INSTALLATION AND PRECAUTIONS ...................................................................................................................13
5-1. Converter Installation Conditions and Precautions..........................................................................................13
5-2. ABSOCODER Sensor Installation Conditions and Precautions ......................................................................13
6. WIRING...................................................................................................................................................................14
6-1. Connection between Converter and ABSOCODER Sensor............................................................................14
6-2. Power Supply Connection................................................................................................................................14
6-3. CC-Link Connection.........................................................................................................................................15
7. NOMENCLATURE and FUNCTION .......................................................................................................................16
7-1. Part Identification and Function .......................................................................................................................16
7-2. Zero Point Setting ............................................................................................................................................17
7-3. LED Display Contents......................................................................................................................................17
8. CC-LINK COMMUNICATION .................................................................................................................................18
8-1. Readout the Position Data (Remote to Master Station)...................................................................................18
8-2. Current Position Value Setting Data (Master to Remote Station) ....................................................................19
8-3. Readout Errors.................................................................................................................................................22
9. SETTING METHODS .............................................................................................................................................23
9-1. Setting and Procedure Before the Operation...................................................................................................23
9-2. Switch Setting ..................................................................................................................................................24
10. TROUBLESHOOTING..........................................................................................................................................25
10-1. Flowchart When Having Error Signals...........................................................................................................26

1
1. SUMMARY
1-1. Summary
This manual describes the specifications and instruction procedures for the VE-2CC/VM-2CC which is able to
connect to the open-architecture network "CC-Link".
VE-2CC/VM-2CC is a converter which can detect the machine's current position value by ABSOCODER.
The ABSOCODER sensor uses a magnetic position detection format, thereby the incremental format encoder
which has been used can be replaced to VE-2CC/VM-2CC.
This converter can be used for the automatic controlling which needs position detections, such as the conveyor,
press machine, assembly machine, packing machine and etc.
The detected position data can be read by the host controller via CC-Link, so the system is able to reduce the
wiring.
1-2. Features
Features of VE-2CC/VM-2CC
(1) Absolute position detection
An absolute position detection format ensures accurate position detection even if a power interruption
condition occurs. An origin returning operation is not required.
(2) High-resolution position detection
[1] VE-2CC: 8192 divisions / turn x 1 turn
[2] VM-2CC: 4096 divisions / turn x 32 turns (In the case of using MRE-32SP062)
If ABSOCODER that "the total number of turn" is twice as much as "MRE-32SP062" is used, the
number of divisions is 1/2 per turn.
(3) Connects with CC-Link
The position data, current position value setting data, and error signal can be sent or received on CC-Link.
(4) Self-diagnosis function
The following self-diagnosis result can be checked by the remote input (RX).
- Internal CPU error (watchdog timer error)
- Memory error
- Sensor error (The sensor is disconnected or severed.)
- Low-voltage detection
(5) Current position setting function
The position data can be designated as desired value from the host controller.
