NSS Enterprises MARSHALL 14 User manual

TWO MOTOR UPRIGHT VACUUM
MARSHALL 14
MARSHALL 18
OPERATION MANUAL
PLEASE READ BEFORE OPERATING ANDKEEP
STOREDINSIDE BAGHOUSINGFORREADYREFE-
RENCE
OPERATINGINSTRUCTIONS PAGE2–8
5.959-710 A2002863 (01/02)
NSS®Enterprises, Inc.
3115 Frenchmens Road, Toledo, Ohio 43607
PHONE [phone] FAX [phone]
NSS®Enterprises,Inc.EuropeanDistributionCentre
Unit lt, Pinfold Trading Estate * 55 Nottingham Road
STAPLEFORD, NOTTINGHAM NG9 8AD ENGLAND UK.
PHONE:[phone]*FAX[phone]

Important Safety Instructions
!!
READ ALL INSTRUCTIONS BEFORE USING
THIS MACHINE.
Transport damages
If the goods have been damaged in transit,
please notify NSS®.
Warranty
If your upright vacuum has to be repaired under
terms of the conditions of warranty, please
consult your NSS®Distributor. Always return
the complete vacuum cleaner.
The conditions of warranty issued by NSS®
apply. If a malfunction is due to a defect in
materials or manufacturing, we undertake to
repair your upright vacuum at no charge in
accordance with the conditions of the NSS®
warranty.
Contents
1. Unit diagram ............................................................................................................................................................................ 4
2. Technical data ....................................................................................................................................................................... 4
3. Starting the unit and handling............................................................................................................................. 5
3.1 Connect the upper section of the vacuum cleaner to the power nozzle5
3.2 Storing and removing cable...................................................................................................................... 5
3.3 On and off positions.......................................................................................................................................... 5
3.4 Working with the suction hose.............................................................................................................. 5
3.5 Adjusting the carpet brush......................................................................................................................... 6
3.6 Electronic brush monitoring...................................................................................................................... 6
3.7 Red indicator light in handle..................................................................................................................... 6
3.8 Storage the vacuum cleaner ................................................................................................................... 6
4. Accessories............................................................................................................................................................................. 6
5. Care and maintenance................................................................................................................................................. 7
5.1 Replacing the paper filter bag ................................................................................................................ 7
5.2 Replacing the safety filter........................................................................................................................... 7
5.3 Replacing the exhaust filter...................................................................................................................... 7
5.4 Replacing the brush strip............................................................................................................................. 7
6. Troubleshooting.................................................................................................................................................................... 8

MARSHALL 14/18 OPERATION MANUAL
3
GroundingInstructions
This appliance must be grounded. If it should
malfunction or breakdown, grounding provides
a path of least resistance for electric current to
reduce the risk of electric shock. This appliance
is equipped with a cord having an equipment-
grounding conductor and grounding plug. The
plug must be plugged into an appropriate outlet
that is properly installed and grounded in accor-
dance with all local codes and ordinances.
WARNING: Improper connection of the equip-
ment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician
or service person if you are in doubt as to
whether the outlet is properly grounded. Do not
modify the plug provided with the appliance.
For a grounded, cord-connected appliance ra-
ted less than 15 amperes and intended for use
on a nominal 120-volt supply circuit, the instruc-
tions in either item 1 or 2:
1) This appliance is for use on a nominal 120-
volt circuit, and has a grounded plug that looks
like the plug illustrated in sketch A at page 2.
A temporary adaptor that looks like the adaptor
illustrated in sketches B and C may be used to
connect this plug to a 2-pole receptacle as
shown in sketch B if a properly grounded outlet
is not available. The temporary adaptor should
be used only until a properly grounded outlet
(sketch A) can be installed by a qualified elec-
trician. The green colored rigid ear, lug, or the
likeextending fromtheadaptor mustbe connec-
ted to a permanent ground such as a properly
grounded outlet box cover. Whenever the adap-
tor is used, it mus be held in place by a metal
screw.
Note:InCanada,theuse ofatemporary adaptor
isnotpermittedbytheCanadianElectricalCode.
2) This appliance is for use on a nominal 120-
volt circuit and has a grounding attachment plug
that looks like the plug illustrated in sketch A at
page 2. Make sure that the appliance is connec-
tedtoanoutlet havingthe sameconfiguration as
the plug. No adaptor should be used with this
appliance.
Safety Instructions
When using an electrical appliance, basic
precautions should always be followed,
including the following:
This machine is for commercial use.
Warning
To reduce the risk of fire, electric shock, or injury:
1. Do not operate without filters in place.
2. Use only as described in this manual. Use
only manufacturer`recommended attach-
ments.
3. Use indoors only. Do not use outdoors or on
wet surfaces.
4. Do not operate this machine near flammable
fluids, dust or vapors.
5. Do not pick up flammable or combustible
materials such as gasoline or use where
they may be present.
6. Do not vacuum anything that is burning or
smoking, such as cigarettes, matches or hot
ashes.
7. Do not handle the plug or machine with wet
hands.
8. Do not leave the machine unattended. Un-
plugmachinefromoutletwhennotinuseand
before servicing.
9. Turn off all controls, before unplugging the
machine.
10. Donotunplugmachinebypullingoncord.To
unplug, grasp the plug, not the cord.
11. Do not use with damaged cord or plug.
Connect to a properly grounded outlet (see
grounding instructions).
12. If the machine is not working properly, has
been dropped, damaged, left outdoors or
dropped into water, return it to your authori-
zed NSS® distributor.
13. Do not pull or carry by cord, use cord as a
handle, close a door on cord or pull cord
around sharp edges or corners.
14. Do not pull / run machine over cord. Keep
cord away from heated surfaces.
15. Close attention is necessary when used by or
nearchildren.Donotallowtobeusedasatoy.
16. Do not operate machine with any openings
blocked. Keep openings free of debris that
may reduce airflow.
17. Keep hair, loose clothing, fingers and all
parts of the body away from openings and
moving parts.
18. Use extra caution when cleaning on stairs.
19. Do not use machine as a step.
20. Maintenance and repairs must be done by
qualified personnel.
SAVETHESE
INSTRUCTIONS

OPERATION MANUAL MARSHALL 14/18
4
1. Unit diagram
1 Brush head with brush monitoring
2 Vacuumhousing
3 Recessed handle
4 Suction hose with handle
5 Red indicator light
6 ON/OFF switch with green indicator light
7 Handle with upper cable clip
8 Lower cable clip
9 Cover
10 Cover fastener
11 Latch pedal
12 Safety filter
13 Connecting hose
14 Brush adjustment knob (adjustable to
pile depth)
2. Technical data
MARSHALL 14 MARSHALL 18
Blower data:
Power P NOM 850 950 watt
Power P MAX / 8 AMPS 950 1080 watt
Low air pressure / CLOSED W.L 63" 186 180 mbar
Air quantity / CFM 91", 1-1/4" 46 46 L/sec
Brush:
Brush motor 150 200 watt
Drive toothed belt toothed belt
Sweep width / 14.3 ", 16.7 " 335 425 mm
Brush strip is exchangeable
Dimensions and weights:
Height / 48.75" 1250 1250 mm
Width / 14.5", 18.1" 360 460 mm
Weight / 17.6 LBS, 20.9 LBS 8 9.5 approx. kg
Sound pressure level 67 66 dB (A)
Subject to technical modifications

MARSHALL 14/18 OPERATION MANUAL
5
3. Starting the unit and handling
3.1 Connect the upper section of the vacuum
cleaner to the power nozzle
Unscrew both fastening screws from the upper section of the
vacuum cleaner before assembly.
Push the upper section of the vacuum cleaner upright onto the
brush head. Then insert the two support arms into the grooves
provided on the upper section of the vacuum cleaner. Fasten
with screws. Tighten screws firmly.<Figure 2>
Connect the hose to the brush head and upper section of
vacuum cleaner. Plug the connecting cable with plug at the
bottom of the power head into the female receptable at the
bottom of the vacuum housing. <Figure 3>
3.2 Storing and removing cable
The vacuum cleaner’s power cable can be wounded up around
the upper and lower cable clips. The entire cable can be easily
removed by turning the lower cable clip.
3.3 Onandoff positions
The power nozzle has a pivot latch which locks the unit in the
upright off position. To operate, tread on the latched pedal and
tip the handle backwards. <Figure 4>
Caution: do not drive the rotating brushes over the connecting
cable. Carry the unit over steps and high thresholds.
3.4 Working with the suction hose <Figure 5>
Switch the unit on via the ON/OFF switch (green light still
illuminated) .
Please note: The carpet brush switches on automatically once
the suction hose with handle is firmly located in the motor
housing. Please check.
If the suction hose with handle is pulled out of the motor housing
for vacuuming, the brush drive motor switches off automatically.
The suction hose is streched when removed and increases the
working radius for above-the-floor cleaning.
The hose handle can be separated in the middle (bayonett
connection). The crevice and upholstery nozzle can be atta-
ched to both ends.
Important: Never use the hand pipe for vacuuming without first
attaching either the crevice nozzle or the upholstery nozzle (the
cleaner will malfunction if the end of the hand pipe is worn down
– see Section 6 for Troubleshooting).
The suction handle is inserted back into the vacuum motor
housing to activate the brush motor.
Figure 2
Figure 5
Figure 3
Figure 4

OPERATION MANUAL MARSHALL 14/18
6
4. Accessories
Figure 6
3.5 Adjusting the carpet brush
Thecarpetbrushcan beadjustedtomatchtheheightof thepile.
To do this, set the vacuum cleaner to the working position
(approx. 45º) and select the required setting between 1 and 4.
<Figure 6>
Note: The brush cannot be adjusted when the cleaner is in the
upright position
Position 1: shallow pile
Position 2: deep pile
3.6 Electronicbrushmonitoring
Brush functioning is continuously controlled by electronic mo-
nitoring.
not illuminated:
brush functioning properly
orange light on:
set the pile height adjusting knob at a lower pile height
orange light on even at the lowest setting:
change brush strip.
3.7 Red indicator light
If the indicator light is on, please check the following:
a) is the filter bag full?
b) is the suction hose or connecting hose blocked?
Either exchange the filter bag or eliminate blockages.
Please note: There is no defect when the warning light comes
on while placing your hand at the suction hose inlet.
3.8 Storing the vacuum cleaner
Afterusingthevacuumcleanerstorethepowercableasdescribed
in chapter 3.2. Clean unit and store cleaner in a dry place.
Marshall 14
order no. Marshall 18 order no.
Crevice nozzle 68-9026-1 68-9026-1
Upholstery nozzle 68-9025-1 68-9025-1
Dusting brush 72-9336-1 72-9336-1
Metal extension tube 72-9335-1 72-9335-1
Brush strip, black 68-9078-1 72-9333-1
* Brush strip, red (hard) 68-9077-1 72-9334-1
** Paper filter bags (10 units) 68-9024-1 68-9024-1
Safety filter 68-9016-1 68-9016-1
* Microfilter 68-9017-1 68-9017-1
* not included in the scope of supply
** 1 unit included in the scope of supply

MARSHALL 14/18 OPERATION MANUAL
7
5. Care and maintenance
Figure 7
Figure 10
Figure 9
Figure 8
1
1
Caution: Before any maintenance work takes place, pull the
power plug out of the socket.
Check mains cable, connection cable and hoses for damage
before putting the unit into operation for the first time.
5.1 Replacing the paper filter bag <Figure 7>
• Depress the cover fastener and remove cover.
• Push the filter bag catch to the left until it is possible to pull
the filter bag off the connection piece.
Assembly:
• Insert the narrow end of the support card into the holder.
• Push the filter bag catch to the left and guide the support
card upwards over the connection piece until it slots in.
• Replace the cover.
Please note: If the cover does not close, check whether the filter
bag has been inserted properly.
5.2 Replacing the safety filter <Figure 8>
After changing the filter bag approximately 20 times, change the
safety filter.
• Press cover fastener and remove cover.
• Lift the red locking device and pull out the safety filter.
Assembly:
• Lift the red locking device and insert the new safety filter.
Please note: If the cover does not close, check whether the filter
bag has been inserted properly.
5.3 Replacing the exhaust filter <Figure 9>
After changing the filter bag approximately 20 times, change the
exhaust filter.
• Push the exhaust filter off the housing and remove.
Assembly:
• Insert the new exhaust filter.
5.4 Replacing the brush strip <Figure 10>
• Remove power cable from electrical outlet.
• Unscrew the power nozzle cover. Turn the brush so that
thebrushstripcanbepushedorpulledthroughtheopening.
Assembly:
• Insert the new brush strip and screw the cover on again.

OPERATION MANUAL MARSHALL 14/18
8
6. Troubleshooting
Figure 13
Figure 12
Figure 11
Caution: Danger from electrical current. Pull out mains power plug
before any work is carried out on electrical parts.
Have all inspections and work to be carried out on electrical parts done
by a specialist. For more extensive tasks contact customer service.
The brush and suction motor not operating, and
noted by electronic system (green indicator light still
illuminated)
Brush is blocked
- Unplug unit, check brush for any litter and, if necessary
remove the blockage. Machine is now ready to operate.
Suction motor not running / Brush motor functioning (red
indicator light goes off)
Thermal switch has disengaged motor due to overheating
- Unplug cable, replace full filter bag or remove suction hose
blockage. After approximately 20 minutes, the unit will start
up again.
Suction hose is blocked
- Switch off the unit. Remove the flexible hose from the
housing and pull it straight. Use something long to remove
the hose blockage.
- The suction hose can be disconnected from the unit by
pressing the locking lever. <Figure 11>
Connecting hose is blocked
- The connecting hose can be removed by pulling out both
ends. Remove blockage. <Figure 12>
Brushes in brush head are not rotating, suction turbine is
running
Hand pipe is not pushed into motor housing properly, or end is
worn down
- Iftheendofthepipehasbeenworndown(duetovacuuming
without first fitting the crevice or upholstery nozzle), the end
switch will not be actuated and the brushes will not rotate.
Separating the power nozzle from the upper section
of the vacuum cleaner
• Unplug the connecting cord from the vacuum motor hou-
sing. Release the plug by pressing in a pointed object (e.g.
screwdriver). <Figure 13>
• Remove the connecting hose from the brush head and the
open housing.
• Undo both screws at the side of the upper section to the
vacuum cleaner. Lift off.
